Summary of Contents for Paragon HydraFLOW
- Page 1 50 gpm max. 3000 psi max WARNING DO NOT OPERATE MACHINERY BEFORE READING MANUAL FULLY INSTALLATION, OPERATION, AND MAINTENANCE MANUAL Hydraflow - HD Operator's Manual November 04, 2019 Copyright © Paragon Tank Truck Equipment LLC...
- Page 2 Warnings NOTICE WARNING: Warning Instructions listed on this page must be reviewed by ALL operators. Safety instruction tags were attached to your unit prior to shipment. DO NOT remove, paint over or obscure in any manner. Failure to heed these warnings could result in serious bodily injury to the personnel operating and maintaining this equipment.
- Page 3 Introduction CONGRATULATIONS on your purchase of a new HydraFlow. Please examine the unit for shipping damage, and if any damage is found, report it immediately to the carrier. If unit is to be installed at a later date make sure it is stored in a clean, dry location.
-
Page 4: Safety Precautions
Safety Precautions For equipment covered specifically or indirectly in this instruction book, it is important that all personnel observe safety precautions to minimize the chances of injury. Among many considerations, the following should be particularly noted: • Rotating shafts can be dangerous. You can snag clothes, skin, hair, hands, etc. This can cause serious injury or death. •... -
Page 5: Installation
PTO, hydraulic pump, and transmission manufacturers. C. Ensure ALL safety labels are installed per manufacturer guidelines. Note: The standard filter supplied in the HydraFLOW is a 10 micron nominal. Contact Paragon Tank Truck Equipment for other filtration media options. - Page 6 Note: • Review Hose Chart (Fig. 1) to ensure the correct suction hose sizing. • For off road applications do not mount HydraFLOW directly to the frame rail. Behind the cab mount is recommended. • See system circuit drawing for complete hydraulic plumbing.
- Page 7 2. Fill the HydraFLOW 1/2 full with hydraulic lubricant. NOTE: Paragon recommends an (ISO) 32 non-foaming hydraulic oil. (Example: Mobil SHC 630 Hydraulic Oil) Use a paint filter as a strainer while filling to prevent foreign contaminants from entering the system.
-
Page 8: Overall Dimensions
Model Number Construction HD 300 T 2 X - HydraFlow HF Special Description HD Heavy Duty (50 GPM) (Leave blank if none) 001 - 16 Elbow HP, -16 Elbow LP Pressure 002 - 16 Tee HP, -16 Elbow LP 004 - 16 Elbow HP, -20 Tee LP... - Page 9 Filter Breakdown Included with Diffuser Assy Filter Lid Assy Included with Filter Assy *Spring is optional Hold Down Spring Filter Assy Diffuser Assy: 352-005 / 352-009 (lip) Filter Assy: 351-006 Filter Element Filter Assy w/ Spring: 351-003 Filter Lid: 522-001 Hold Down Spring: 580-001 Filter Element: 350-000...
- Page 10 Filter Head Options Filter Head without Lip Part # 352-005 Filter Head with Lip Part # 352-009...
-
Page 11: Parts List
Parts List... - Page 12 Parts List Item Part Number Description QTY. STD QTY. SQ. Filter Frame - bolt-in tank 500-022 500-018 Frame - weld-in tank 500-026 Tank - bolt-in 370-000 Hyd. Heat Exchanger 352-001 Filter/Diffuser - 4 bolt (Round) Filter/Diffuser - 4 bolt (Square) 352-005 -8522 Elbow 90 deg - SAE -16 x 1”...
- Page 13 Grommet, Square Filter 521-804 E Clip 1/2” 85258 Low Pressure Bypass Valve 335-001 Nut, Seal 1/2” NPT 85259 Gasket - Hydraflow Filter (Round) 526-001 Filter Cap HD Hydraflow (Round) 85250 Filter Element HD Hydraflow 350-000 Gasket HD bolt-in Tank 526-021...
- Page 14 WARRANTY – HYDRAFLOW Subject to the terms and conditions hereinafter set forth and set forth in General Terms of Sale, Paragon Tank Truck Equipment LLC (the seller) warrants products and parts of its manufacture, when shipped, will be of good quality and will be free from defects in material and workmanship.
