Checking Tcp/Ip Settings (Windows Xp) - SpeedStream 4200 User Manual

4100/4200 Router User's Guide

Checking TCP/IP Settings (Windows XP)

1. On the Windows taskbar click Start>Control Panel. This displays the
"Control Panel" window.
2. Double-click the Network Connection icon. This displays the "Network
Connections" window.
3. Right-click Local Area Connection, then click Properties. This displays
the "Local Area Connection Properties" window.
4. Select the TCP/IP protocol for your network card.
5. Click Properties. This displays the "Internet Protocol (TCP/IP)
Properties" window.
6. Ensure that Obtain an IP address automatically and Obtain DNS server address automatically
are selected.
7. Exit back to the Control Panel.
8. Restart the computer to ensure it obtains an IP address from the Router.
9. Configure internet access using the procedure described in
Operating System Configuration
Internet Access
12
Configuration.
