  • Page 1 S S S S p p p p e e e e e e e e d d d d S S S S t t t t r r r r e e e e a a a a m m m m 5800 Series 5800 Series 5800 Series...
  • Page 3  Copyright 2000, Efficient Networks, Inc. All rights reserved. Printed in the U.S.A. Product names mentioned herein may be trademarks and/or registered trade- marks of their respective companies. Efficient Networks, Inc. shall not be liable for technical or editorial errors or omissions in this document; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
  • Page 4 Software License The Software is protected by copyright laws and international copyright treaties. The Software is licensed and not sold to you. Accordingly, while you own the media (CD ROM or floppy disk) on which the Software is recorded, ENI retains ownership of the Software itself.
  • Page 5 4. Upgrades Covered. This license covers the Software originally provided to you with the Hardware, and any additional software that you may receive from ENI, whether delivered via tangible media (CD ROM or floppy disk), down loaded from ENI or delivered through customer support. Any such additional software shall be considered "Software"...
  • Page 6 Limited Warranty ENI provides the following limited warranties to the original end-user of the Hardware and Software: 1. Hardware. Efficient warrants that the Hardware will be free from defects in materials and workmanship and will perform substantially in compliance with the user documentation relating to the Hardware for a period of one year from the date the original end user received the Hardware.
  • Page 7 4. Warranty Procedures. Prior to returning a product under this warranty, the end user must first call ENI at (408) 878-6803, or send an email to ENI at support@efficient.com to obtain a return materials authorization (RMA) number. RMAs are issued between 8:00 a.m.
  • Page 8 5. Limitations. The limited warranty does not apply to any damage or failure caused by misuse, abuse, acts of nature, accidents (for example dropping or spilling fluids on the Hardware), or the like. ENI will not honor, and will consider the warranty voided, if: (1) the seal or serial number on the Product have been tampered with;...
  • Page 9 General Provisions The following general provisions apply to the foregoing Software License and Limited Warranty: 1. No Modification. No oral or written information or advice given by ENI or its dealers, distributors, employees or agents shall in any way extend, modify or add to the foregoing Software License and Limited Warranty.
  • Page 10 ACTION, WILL BE LIMITED TO, AND SHALL NOT EXCEED, THE AMOUNT PAID FOR THE HARDWARE/SOFTWARE. 3. General. This Software License and Limited Warranty will be covered by and construed in accordance with the laws of the State of Texas, and shall inure to the benefit of ENI and its successor, assignees and legal representatives.

  • Page 11: Table Of Contents

    Table of Contents Table of Contents Table of Contents Table of Contents Introduction..............10 Installation Requirements ..........11 Connecting Your Router ..........13 Configuring Your Router ..........15 Administration .............16 Web User Interface ............17 Easy Setup..............19 Access Control .............34 Feature Activation............36 Change Password ............38 Setting The Date and Time ..........40 Panel Descriptions ............42 Hardware Specifications ..........45...

  • Page 12: Introduction

    Introduction This Quick Start Guide covers basic installation and setup of the Speed- Stream 5800 Series Business Class Routers including: • 5851 Symmetric Digital Subscriber Line router (SDSL) • 5861 Asymmetric DSL / Discrete Multi Tone router (DMT) • 5865 Asymmetric DSL / DMT (international) router •...

  • Page 13: Installation Requirements

    SpeedStream 5800 Business Class Routers Installation Requirements Installation Requirements Installation Requirements Installation Requirements PC Requirements PC Requirements PC Requirements PC Requirements • CD-ROM Drive • Ethernet network interface card • TCP/IP network protocol installed • Web browser • Terminal emulation software if you want to configure your router via your computer’s serial port before placing it into service on a...
  • Page 14 Your package should contain the items listed below. If you determine anything to be damaged or missing, please contact the dealer from whom the equipment was purchased. • 1 SpeedStream 5800 Series Business Class Router • 1 Installation CD Package •...

  • Page 15: Connecting Your Router

    SpeedStream 5800 Business Class Routers Connecting Your Router Connecting Your Router Connecting Your Router Connecting Your Router Place your router in a location where it will be well ventilated. Do not stack it with other devices or place it on carpet.
  • Page 16 SpeedStream 5800 Business Class Routers The following diagram shows the router when connected: CONSOLE Connecting Your Router...

  • Page 17: Configuring Your Router

    SpeedStream 5800 Business Class Routers Configuring Your Router Configuring Your Router Configuring Your Router Configuring Your Router Your computer will be obtaining IP addresses automatically from the router. Configure the TCP/IP stack on your PC to obtain an IP address automatically.

  • Page 18: Administration

    SpeedStream 5800 Business Class Routers Administration Administration Administration Administration At the login prompt, make the following entries: User Name: login Password: admin Change Password Change Password Change Password Change Password After you have logged into your router, a dialog will appear, prompting you to change your password.

  • Page 19: Web User Interface

    Web User Interface Web User Interface Web User Interface Your SpeedStream 5800 Series Router includes a Web User Interface to provide you with easy-to-use controls and information. The Web User Interface consists of simple, linked forms that together provide clear views of your router settings and status.
  • Page 20 SpeedStream 5800 Business Class Routers Web User Interface...

  • Page 21: Easy Setup

    SpeedStream 5800 Business Class Routers Easy Setup Easy Setup Easy Setup Easy Setup Easy Setup is a set of web forms designed to provide a quick and easy setup of your router. Easy Setup is a permanent feature, accessible from any computer platform with a web browser.
  • Page 22 SpeedStream 5800 Business Class Routers Wide Area Network Interface Wide Area Network Interface Wide Area Network Interface Wide Area Network Interface The first Easy Setup screen is for entering and reviewing information about Wide Area Network (WAN) settings. Your Network Service Pro- vider can provide you with the information needed to correctly complete these WAN settings.
  • Page 23 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 24 SpeedStream 5800 Business Class Routers Point-to-Point Protocol Point-to-Point Protocol Point-to-Point Protocol Point-to-Point Protocol If you have selected PPP as your WAN protocol, you will see a screen requesting a PPP User Name and PPP Password. Enter this information in the fields provided.
  • Page 25 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 26 SpeedStream 5800 Business Class Routers RFC 1483 or 1490 Networking RFC 1483 or 1490 Networking RFC 1483 or 1490 Networking RFC 1483 or 1490 Networking If you have selected RFC 1483 (or RFC 1490 for frame relay) as your WAN protocol, you will see a screen for selecting networking options, and for setting IP routing configurations.
  • Page 27 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 28 SpeedStream 5800 Business Class Routers RFC 1483 or 1490 MER RFC 1483 or 1490 MER RFC 1483 or 1490 MER RFC 1483 or 1490 MER If you have selected RFC 1483 (or 1490 for frame relay) MER as your WAN protocol, you will see a screen for selecting networking options, and for setting IP routing configurations.
  • Page 29 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 30 SpeedStream 5800 Business Class Routers Dynamic Host Configuration Protocol Dynamic Host Configuration Protocol Dynamic Host Configuration Protocol Dynamic Host Configuration Protocol DHCP dynamically assigns IP configuration information to PCs on the LAN automatically, thus avoiding the need to set IP configuration for each PC manually.
  • Page 31 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 32 SpeedStream 5800 Business Class Routers Local Area Network Configuration Local Area Network Configuration Local Area Network Configuration Local Area Network Configuration The final screen in Easy Setup is for Local Area Network (LAN) IP con- figuration. The IP address is the network address of your router. This address must be globally unique, unless NAT has been enabled.
  • Page 33 SpeedStream 5800 Business Class Routers Easy Setup...
  • Page 34 SpeedStream 5800 Business Class Routers Click Save and Reboot to save your settings in Easy Setup. Your router will reboot with the new configuration settings. Easy Setup...
  • Page 35 SpeedStream 5800 Business Class Routers Easy Setup...

  • Page 36: Access Control

    SpeedStream 5800 Business Class Routers Access Control Access Control Access Control Access Control This feature restricts adminstrative access and control of the router to a select group of hosts. In this form, you can select which router services can be accessed from PCs. For each selected service, you can restrict the hosts that can manage the service remotely.
  • Page 37 SpeedStream 5800 Business Class Routers Access Control...

  • Page 38: Feature Activation

    SpeedStream 5800 Business Class Routers Feature Activation Feature Activation Feature Activation Feature Activation There are several optional software features available for your router, such as L2TP, IPSec, DES encryption, and 3DES encryption. These features can be purchased from the Efficient Networks web site (www.efficient.com).
  • Page 39 SpeedStream 5800 Business Class Routers Feature Activation...

  • Page 40: Change Password

    SpeedStream 5800 Business Class Routers Change Password Change Password Change Password Change Password Changing your administration password is easy. Simply type your new password into each of the fields. The new password is also required in the second field for verification.
  • Page 41 SpeedStream 5800 Business Class Routers Change Password...

  • Page 42: Setting The Date And Time

    SpeedStream 5800 Business Class Routers Setting The Date and Time Setting The Date and Time Setting The Date and Time Setting The Date and Time This feature enables you to set the date and time on your router. The current date and time from your workstation is displayed in the field labeled Current Date and Time.
  • Page 43 SpeedStream 5800 Business Class Routers Setting The Date and Time...

  • Page 44: Panel Descriptions

    SpeedStream 5800 Series Router Panel Descriptions Panel Descriptions Panel Descriptions Panel Descriptions Front Panel Front Panel Front Panel Front Panel Six lights appear on the front left panel of the router. Reading from left to right, these lights indicate the following conditions:...
  • Page 45 SpeedStream 5800 Series Router Table 1: Front Light Indications Table 1: Front Light Indications Table 1: Front Light Indications Table 1: Front Light Indications Light Indications Green:Power is on Off:Power is off TEST Amber:Running Power On Self Test Green:Router Power On Self Test successful...
  • Page 46 SpeedStream 5800 Series Router Back Panel Back Panel Back Panel Back Panel CONSOLE From left to right, back panel connections are as follows: Table 2: Back Panel Connections Table 2: Back Panel Connections Table 2: Back Panel Connections Table 2: Back Panel Connections...

  • Page 47: Hardware Specifications

    SpeedStream 5800 Business Class Routers Hardware Specifications Hardware Specifications Hardware Specifications Hardware Specifications Physical Specifications Physical Specifications Physical Specifications Physical Specifications • Dimensions: 8.4 W x 7.0 D x 1.7 H inches • 21.3 W x 17.8 D x 4.3 H cm •...
  • Page 48 SpeedStream 5800 Business Class Routers LAN Interface LAN Interface LAN Interface LAN Interface • Built-in four port Ethernet hub with four RJ-45 connectors • LAN speed up to 10 Mbps WAN Interface WAN Interface WAN Interface WAN Interface • One Digital Subscriber Line interface (RJ-14 for models 586X) RJ-...
  • Page 49 SpeedStream 5800 Business Class Routers Modem Specifications Modem Specifications Modem Specifications Modem Specifications DMT/ADSL DMT/ADSL DMT/ADSL DMT/ADSL • Up to 8 Mbps downstream • Up to 1 Mbps upstream • Supports full rate G. DMT (G.992.1), G.lite (G.992.2), G. HS (G.994.1), mgmt (G.997.1) and ANSI T1.413 Issue 2...

  • Page 50: Port Specifications

    SpeedStream 5800 Business Class Routers Port Specifications Port Specifications Port Specifications Port Specifications Table 3: Ethernet & Console Table 3: Ethernet & Console Table 3: Ethernet & Console Table 3: Ethernet & Console Ethernet Port Console Port Twisted pair transmit +...
  • Page 51 SpeedStream 5800 Business Class Routers Table 4: WAN Port - Most Models (RJ-45) Table 4: WAN Port - Most Models (RJ-45) Table 4: WAN Port - Most Models (RJ-45) Table 4: WAN Port - Most Models (RJ-45) Most Models Not connected...
  • Page 52 SpeedStream 5800 Business Class Routers Table 5: WAN Port - Models 586X DMT Routers (RJ-14) Table 5: WAN Port - Models 586X DMT Routers (RJ-14) Table 5: WAN Port - Models 586X DMT Routers (RJ-14) Table 5: WAN Port - Models 586X DMT Routers (RJ-14)

  • Page 53: Software Specifications

    SpeedStream 5800 Business Class Routers Software Specifications Software Specifications Software Specifications Software Specifications Bridging Bridging Bridging Bridging • Transparent bridging including Spanning Tree Protocol (IEEE 802- • Bridge filters Routing Routing Routing Routing • TCP/IP with RIP 1 (RFC 1058), RIP 1 compatible and RIP 2 (RFC 1389), or static routing on the LAN and/or WAN •...
  • Page 54 SpeedStream 5800 Business Class Routers • Spoofing and filtering (IP-RIP, IPX-RIP, SAP, Watchdog, serializa- tion) IP Address Translation IP Address Translation IP Address Translation IP Address Translation • Network renumbering (RFC 1631) • Network Address Translation (NAT/PAT) • LAN servers supported with NAT...
  • Page 55 SpeedStream 5800 Business Class Routers Asynchronous Transfer Mode (ATM) Asynchronous Transfer Mode (ATM) Asynchronous Transfer Mode (ATM) Asynchronous Transfer Mode (ATM) • Encapsulation (IP, bridging, and encapsulated routing) (RFC 1483) • PPP over ATM (LCC and VC multiplexing) (RFC 2364) •...
  • Page 56 SpeedStream 5800 Business Class Routers • HTTP/SNMP/Telnet/Syslog access control list • Firewall (IP filtering) • Optional VPN software (L2TP, IPSec, IKE, DES, 3DES) Software Specifications...

  • Page 57: Support

    SpeedStream 5800 Business Class Routers Support Support Support Support For specific product support, contact the organization that provided or sold the equipment to you. If you need to contact your NSP for techni- cal support, please have the following information ready: •...

  • Page 58: Compliances

    SpeedStream 5800 Business Class Routers Compliances Compliances Compliances Compliances Section 15.105(b) of the Code of Federal Regulations: Section 15.105(b) of the Code of Federal Regulations: Section 15.105(b) of the Code of Federal Regulations: Section 15.105(b) of the Code of Federal Regulations: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant of Part 15 of the FCC Rules.
  • Page 59 SpeedStream 5800 Business Class Routers Caution: Any changes or modifications not expressly approved by the party responsible for this device could void the user’s authority to operate this equipment. Canadian D.O.C. Notice Canadian D.O.C. Notice Canadian D.O.C. Notice Canadian D.O.C. Notice This product conforms to Canadian Class B emmisions regulations.
