- Page 1 User Manual of Fisheye Network Camera V8.1.2.4 Fisheye Network Camera User Manual Version：V8.1.2.4...
- Page 2 User Manual of Fisheye Network Camera V8.1.2.4 Thanks for choosing our products. If you have any questions or needs, please feel free to contact with About this manual As a general manual, it used for all of our HD Network Fisheye IP Camera. Thus, the function may differ in detail models, please make the object as the standard.
- Page 3 User Manual of Fisheye Network Camera V8.1.2.4 Warning Electrical safety regulations of the nation and the region must be strictly followed during installation or use. Please use the matched power adapter from standard company. Do not connect multiple IPCs with one single power adapter (Overload for adapter may ...
-
Page 4: Table Of Contents
User Manual of Fisheye Network Camera V8.1.2.4 CONTENT CHAPTER 1 PRODUCT INTRODUCTION......................5 1.1 PRODUCT MANUAL...........................6 1.2 PRODUCT FEATURES..........................6 CHAPTER 2 OPERATING INSTRUCTIONS......................7 2.1 NETWORK CONNECTION...........................7 ........................7 2.1.1 W IRED NETWORK CONNECTION ........................7 2.1.2 W IRELESS INTERNET ACCESS 2.2 DETECTING AND CHANGING THE IP ADDRESS.................. -
Page 5: Chapter 1 Product Introduction
User Manual of Fisheye Network Camera V8.1.2.4 7.6 EVENTS..............................44 CHAPTER 8 VR PANORAMA APP CLIENT....................52 8.1 INSTALLATION & REGISTER........................52 8.2 ADD DEVICE............................. 53 8.3 LIVE PREVIEW............................55 8.4 PLAYBACK..............................58 8.5 VR PANORAMA APP MOTION DETECTION VIDEO PLAYBACK............... 59 8.6 SETTINGS.............................. -
Page 6: Product Manual
Fisheye Network Camera support TCP / IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP and other network communication protocols; support ONVIF2.4, CGI, XM, HIKVISION, LONGSE and other Internet protocols. -
Page 7: Chapter 2 Operating Instructions
User Manual of Fisheye Network Camera V8.1.2.4 The Fisheye Network Camera supports the cloud storage function, which stores the device motion detection alarm information on the cloud server. Note Fisheye Network Camera above product features depending on the specific model, ... -
Page 8: Detecting And Changing The Ip Address
User Manual of Fisheye Network Camera V8.1.2.4 Figure 2-3 2.2 Detecting and Changing the IP Address To access the IP address of a Fisheye Network Camera, proceed as follows: Step 1: Search IPC IP address. Using the IP Search tool, you can search all the online cameras in the LAN and display ... -
Page 9: Setting The Fisheye Network Camera Over The Wan
User Manual of Fisheye Network Camera V8.1.2.4 Note: The default IP address is 192.168.1.168 and the port number is 80. The default user name is admin, and password is admin. And you are highly recommended change the initial password after your first login. For accessing the Fisheye Network Camera from different sub nets, please set the ... - Page 10 User Manual of Fisheye Network Camera V8.1.2.4 Specific steps are as follows: Step 1： Connect the Fisheye Network Camera to the router. Step 2： Assign a LAN IP address, the sub net mask and the gateway. For details, please refer to 7.3.1. Step 3：In the router, set the PPPoE user name, password and confirm the password.
-
Page 11: Chapter 3 Access To The Ipc By Client Software
User Manual of Fisheye Network Camera V8.1.2.4 Step 2: Access the Fisheye Network Camera through the LAN with a web browser or the client software. Step 3: Enable DDNS and select IP Server as the protocol type. For details, please refer to 7.3.2. -
Page 12: Chapter 4 Access To The Ipc By Web Client
User Manual of Fisheye Network Camera V8.1.2.4 Chapter 4 Access to the IPC by Web Client 4.1 Preparation before install plugin In ensuring the IPC and the current user's computer after completion of all the hardware connection and power equipment normal, open the computer, run ping the IP address of the IPC (Note: the IP address of the IPC in LAN must be unique). - Page 13 User Manual of Fisheye Network Camera V8.1.2.4 Figure 4-2 Click to download and you can choose "Run" or save directly the installation。 Click” Next” to complete the installation as shown in Figure 4-3 (1, 2, 3, 4, 5, and 6). Figure 4-3（1）...
- Page 14 User Manual of Fisheye Network Camera V8.1.2.4 Figure 4-3（3） Figure 4-3（4） Figure 4-3（5）...
-
Page 15: Interface Operations And Usage
User Manual of Fisheye Network Camera V8.1.2.4 Figure 4-3（6） Click "Finish” returning to the page. Notice If the system prompt "installation failure", please uncheck the "cancel protection mode" in the setting safety of "Internet options" and enter the "custom level" ActiveX control Settings as show in Figure 4-4, and reinstall HsWebplugin.exe after save settings. -
Page 16: Change Password
User Manual of Fisheye Network Camera V8.1.2.4 in Figure 4-5: Figure 4-5 When you log in for the first time, enter the default user name: admin, password: admin, select the system language (currently supported in Simplified Chinese, Simplified Chinese, English, Russian, Korean, Polish, French, Japanese, Spanish, Portuguese , Italian, Hebrew, Turkish, Bulgarian, Persian, German, Dutch, Czech). -
Page 17: Exit System
User Manual of Fisheye Network Camera V8.1.2.4 Figure 4-7 To change your password, follow these steps: Step 1: Enter the new password in the Password and Confirm Password fields; Step 2: Fill in the security issues as needed, this item is optional, may not fill; Step 3: Click "Save"... - Page 18 User Manual of Fisheye Network Camera V8.1.2.4 Figure 4-8 Live View: For IPC monitoring screen preview, you can switch the code stream preview, preview can also be achieved video, capture, electronic zoom and other functions. Playback：Select the time or video type to find the device TF card in the video and ...
-
Page 19: Chapter 5 Live Preview
User Manual of Fisheye Network Camera V8.1.2.4 Chapter 5 Live preview 5.1 Live preview Click " " to enter the IPC preview interface, as shown in Figure 5-1: Figure 5-1 【switching window size】In the real-time preview interface on the top left of the preview ratio option, click "4: 3", "16: 9", "X1", "full screen"... - Page 20 User Manual of Fisheye Network Camera V8.1.2.4 Turn on / off the electronic zoom function, turn on the electronic zoom function, in the preview image, hold down the left mouse button to select the electronic zoom area, the interface shows the region to enlarge the image Turn on/off Sound.
-
Page 21: Chapter 6 Playback
User Manual of Fisheye Network Camera V8.1.2.4 Chapter 6 Playback In the main interface, click “ ”into the video palyback interface. Playback interface can be stored in the camera SD card / TF card within the video file for query, playback and download operations. - Page 22 User Manual of Fisheye Network Camera V8.1.2.4 right mouse button to restore the zoom, click " " to turn off the electronic zoom. 【Capture】Video playback, click " " to capture the current playback screen image, the interface pops up the capture picture folder, which shows just captured the picture. 【...
-
Page 23: Chapter 7 Configuration
User Manual of Fisheye Network Camera V8.1.2.4 【First Page】Click to return to the first page of the video file list. 【Prev Page】Flip function, click to switch to the previous page. 【Next Page】Flip function, click to switch the next page. 【Last Page】Click to quickly jump to the last page of the video file list. 【Download】Select the file number to be downloaded in front of the "... -
Page 24: System
User Manual of Fisheye Network Camera V8.1.2.4 files you recorded with the web browser. 【Save record files to】Set the saving path for the manually recorded video files. 【 Save downloaded files to 】 Set the saving path for the downloaded video files in playback mode. - Page 25 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-2 【Device Name】The name of the current IPC. 【Firmware Version】The current version of the IPC. 【Software Version】The current HsWebplugin.exe control version of the IPC. 【WEB Version】The current page version of the IPC. 【Number of Channels】The current channels of the IPC, the default is 1.
- Page 26 User Manual of Fisheye Network Camera V8.1.2.4 【Time Zone】Displays the current device selection time zone. 【Time in Camera】Displays the current time of the device. 【NTP】The IPC time will synchronization with network, and you can change the different time zones. (This feature requires that IPC network environment can connect to the Internet.) Click on the "Save"...
-
Page 27: Scheduled Reboot
User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-5 【 Reboot System 】 The IPC will restart again automatically after clicking "Reboot System". 【 Restore Factory Settings 】 The IPC will restore to factory default parameters automatically after clicking this option.(Camera IP and other network parameters will not be restored to the factory, other settings will be restored to factory defaults.Please operate this function carefully). -
Page 28: Security
User Manual of Fisheye Network Camera V8.1.2.4 In the main interface click on the "configuration → system → log query" into the log query interface, where you can query the device login, account number, alarm and all other relevant information. As shown in Figure 7-7 below: Figure 7-7 【Search】It can find running record of IPC from the start time to end time. - Page 29 User Manual of Fisheye Network Camera V8.1.2.4 Step 1:Click "User Add" to enter the "User Edit" interface; Step 2: Input the User Name, select Level and input Password. Step 3: Click "OK" to complete the user to add.. Add User as shown in Figure 7-9: Figure 7-9 Cautions In order to improve the security of the product network, please change the...
-
Page 30: Sd Card
User Manual of Fisheye Network Camera V8.1.2.4 of passwords are risk password, do not recommend this set. To better protect your privacy and improve product safety, we recommend that you change your risk password to a high-strength password. ○ 2 Edit the User Left-click to select the user from the list and click Modify. -
Page 31: Network
User Manual of Fisheye Network Camera V8.1.2.4 ○ 2 Rec Setup In the main interface, click "Configuration → System → SDCard → Rec Setup" to enter the recording setting interface, here you can open the SD card video, set the SD card recording schedule and video mode, as shown in Figure 7-11: Figure 7-11 Note:... - Page 32 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-12 The IPC is connected to the router that have opened the DHCP function, check the DHCP option, and the IPC can be get automatically IP address、Net mask、Default Gateway and DNS。 Close DHCP, you can manually modify the IPC's IP address, subnet mask, default gateway and preferred DNS server information, manually modify the finished, click "Test"...
-
Page 33: Advance Setup
User Manual of Fisheye Network Camera V8.1.2.4 【ONVIF】When the IPC access to ONVIF agreement with the back-end equipment, the need to enable ONVIF protocol; the ONVIF protocol is enabled. 【 HIK 】 When the IPC accesses the private protocol back-end device, such as the HIK device, the HIK protocol is enabled. - Page 34 User Manual of Fisheye Network Camera V8.1.2.4 【Site Name】The input selection type corresponds to the successful domain name. 【DDNS Account】The input selection type corresponds to the registered account. 【DDNS Password】The input selection type corresponds to the registration password. 【Confirm Password】Re-enter the password, this password and DDNS password. 【Status】Shows whether the current device is set up DDNS successfully.
- Page 35 User Manual of Fisheye Network Camera V8.1.2.4 and AVI video for selection. Click on the "Save" after completing the settings. ○ 3 SMTP In the main interface, click "Configure →Network → Advanced Setup→ SMTP" to enter the mail settings interface, where you can set the SMTP server information, enter the sender mailbox, SMTP server address, port, select the upload SMTP file format, Box account and password.
- Page 36 User Manual of Fisheye Network Camera V8.1.2.4 【Email 1, 2, 3】Fill in the full address of your inbox, here up to 3 inboxes, click on the completion of the completion of the "test" to ensure that all the correctness of the input information and network connectivity of the camera.
- Page 37 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-18 【 Cloud Storage Type 】 Select the cloud storage type, Dropbox or Google in the drop-down menu. 【Web】Depending on the type of cloud storage selection play a cloud url, login web site registered account according to clew clouds.
-
Page 38: Video
User Manual of Fisheye Network Camera V8.1.2.4 the WIFI configuration interface. Here you can configure the camera to connect the WiFi to the camera, as shown in Figure 7-20 below: Figure 7-20 IPC WIFI configuration steps are as follows: Step 1: Click the "Scan" button to search for nearby WiFi hotspots; Step 2: Select to connect WiFi, enter the WiFi password;... -
Page 39: Audio
User Manual of Fisheye Network Camera V8.1.2.4 interface, where you can set the IPC device name, stream type, encoding and other video parameters, as shown in Figure 7-21: Figure 7-21 【Device Name】Setting your camera name. 【Stream Type】Here Single/Third available. 【Codec】Choose coding and resolution. 【Framerate】Set the frame rate of the current output video of the device. -
Page 40: Image
User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-22 【Open audio】Open/close device audio input. 【Audio input】Select audio input mode, according to the equipment function, a Mic input and LINE input options. 【Audio coding】Select audio encoding, G711U or G711A. 【Input the volume】Set up equipment input volume. 【Output volume】Set the device output volume. - Page 41 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-23 【 Brightness/Contrast/Saturation/Sharpness 】 You can input the value manually to set brightness, contrast, saturation, sharpness. These parameters shall be set according to the actual environment. The scope of valid values is from 0 to 255, you can drag the slider to set, and the default value is 128.
- Page 42 User Manual of Fisheye Network Camera V8.1.2.4 adjustment is activated, click [Save]. As shown in Figure 7-26: Figure 7-26 BackLight Settings efault is off, when turn on the Back Light，can setting it as 】 D 【 Min, Mid, Max. As shown below picture 7-27 ：...
-
Page 43: Osd
User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-29 Note: The actual configuration interface, please specify the specific model. 【Image Enhancement】Including flicker control, wide dynamic switch, HDR, as shown in Figure 7-30: Figure 7-30 Flicker Control ： The flash mode is selected according to the camera installation environment and the flicker standard;... -
Page 44: Events
User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-32 【Time】Turn on / off the preview interface time display. 【Text】Turn on / off the preview interface OSD text display. 【Date Format】Set the preview interface to display the date format, default day / month / year, switchable month / day / year and year / month / day options. - Page 45 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-33 【Enable】Turn on / off device motion detection alarm. Area Settings: Select the area to set the motion detection sensitivity. 【 Select All 】 Motion detection range to monitor all of the area, which Consists of 396(22*18) small squares.
- Page 46 User Manual of Fisheye Network Camera V8.1.2.4 After the day of deployment time is set, if the other time also need to set the same arming time, click the right side of the timeline " " copy button, in the "copy to" interface check the "Select All"...
- Page 47 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-35 Open the "General linkage", "upload Via SMTP", "upload Via FTP", "upload Via Cloud", ”Record Via SDcard” function, when the device motion detection alarm, the linkage corresponding way to inform the user. ○...
- Page 48 User Manual of Fisheye Network Camera V8.1.2.4 In the main interface click on the "configuration → Events → Video Tampering" to enter the video tampering settings interface. As shown in Figure 7-37: Figure 7-37 【Enable】Turn on / off device video tampering alarm. Area Settings: Select the area to set the video tampering sensitivity.
- Page 49 User Manual of Fisheye Network Camera V8.1.2.4 You can set up more than one time period for up to 8 time periods. After the day of deployment time is set, if the other time also need to set the same arming time, click the right side of the timeline "...
- Page 50 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-39 Here to open the "regular linkage", "upload FTP", "upload SMTP" function, when the device settings area is blocked and alarm, the corresponding way to inform the user. ○ 4 Alarm Input In the main interface click on the "configuration →...
- Page 51 User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-40 Linkage mode settings: Alarm linkage, including upload SMTP and FTP upload the normal linkage and IO output of the linkage alarm output, as shown in Figure 7-41: 【Regular linkage】 Including upload SMTP and upload FTP. 【...
-
Page 52: Chapter 8 Vr Panorama App Client
User Manual of Fisheye Network Camera V8.1.2.4 Figure 7-42 Set the "Cable Disconnection" and "IP Address Conflict" alarms here, and set the alarm output mode. Click on the “Save” after completing the settings. Chapter 8 VR Panorama app client 8.1 Installation & Register Fisheye cameras support the use of the VR Panorama App client and the FreeIP App client. -
Page 53: Add Device
User Manual of Fisheye Network Camera V8.1.2.4 After installation, run the "VR Panorama" phone client, select the registration interface, according to the interface prompts to register an account. FreeIP or FreeIP PRO account, you can log in without registering a new account. 8.2 Add device Step 1: Make sure that IPC is connected to the internet, P2P is on, and is online. - Page 54 User Manual of Fisheye Network Camera V8.1.2.4 Figure 8-3 Step 5 : After the mobile phone automatically recognizes the QR code, it enters the Add Device interface as shown in Figure 8-4 1 ;Enter the device name, account number, ○ password,verification code(The verification code is printed on the standard shipping label), select the device group, click "Finish", the interface prompts "Binding successful", add the device to display in the device list,as shown in Figure 8-4:...
-
Page 55: Live Preview
User Manual of Fisheye Network Camera V8.1.2.4 APP will automatically identify whether the device has a verification code, if the device has a verification code, you will be asked to enter the verification code when adding the device, otherwise there is no verification code option. 8.3 Live Preview After the device is added successfully, you can preview, record, capture and other basic operations. - Page 56 User Manual of Fisheye Network Camera V8.1.2.4 ○ ○ ○ ○ ○ ○ ○ ○ ○...
- Page 57 User Manual of Fisheye Network Camera V8.1.2.4 Figure 8-6 Toolbar for more features, as shown in Table 8-1 below: Description Android/iPhone Top view mode Top View VR Mode Fisheye mode Single-screen expansion mode Four-Split screen mode Double-screen expansion mode Cylinder mode Hanging Mode Fisheye Hanging Mode Cylinder Mode...
-
Page 58: Playback
User Manual of Fisheye Network Camera V8.1.2.4 Note: Preview fisheye device real-time video, support for automatic horizontal screen preview, and horizontal screen preview switch to support other modes, as shown in Figure 8-6 ○ 8.4 Playback VR Panorama app playback function is use to playback the IPC TF card video. Step 1 Select “Playback”... -
Page 59: Vr Panorama App Motion Detection Video Playback
User Manual of Fisheye Network Camera V8.1.2.4 ○ ○ ○ ○ ○ ○ Figure 8-7 Step 3:Video playback, click the playback interface button, switch the other date video playback, you can also drag the timeline to switch the recording of other times playing the current channel's date. 8.5 VR Panorama app motion detection video playback VR Panorama app motion detection video playback function is use to playback the... - Page 60 User Manual of Fisheye Network Camera V8.1.2.4 IPC TF card video Step1 On the device real-time preview interface, click " playback" to enter the motion detection playback interface as Figure 8-8. Step 2 More playback device’s installation reference 8.4 Video playback. Figure 8-8 Note: Motion detection alarm switch is turned on, the recording settings will automatically...
-
Page 61: Settings
User Manual of Fisheye Network Camera V8.1.2.4 Fisheye Hanging Mode Cylinder Mode Open/Close Voice Close/Open Current CH TimeLine, you could drag it left or right to switch the time of video playback. Open/Close recording Date Switch Screenshot click to Preview Table 8-2 8.6 Settings Real-time preview interface in the device ，click“... -
Page 62: Function Settings
User Manual of Fisheye Network Camera V8.1.2.4 Android/iPhone description Device name Clcik to change the name of device,click "Finish" to save Device ID Dispaly SN of device, Can not be changed Device type Dispaly device type, can not be changed click to enter "device version"... -
Page 63: Recording Settings
User Manual of Fisheye Network Camera V8.1.2.4 description Android/iPhone Motion detection alarm Open /Close device motion detection alarm, default is "close" Set alarm schedule Set equipment alarm schedule, support repeating, modifying, deleting alarm time Sensitivity Set the device's capture sensitivity, support high, medium and low sensitivity Alarm push Set motion detection alarm notification... -
Page 64: Chapter 9 Frequently Asked Questions
User Manual of Fisheye Network Camera V8.1.2.4 Android/iPhone description Display camera user name Device name Modify the camera password. After modification, click Device password "Finish" to complete the modification Table 8-7 Chapter 9 Frequently Asked Questions 1.Why can not access the camera by IE? Answer: There maybe 4 reasons, Details are as follows: a.The network unreasonable? Solution: First you can connect network by PC, check the network cable if it is good.
