PCB Piezotronics ICP 208C02 Installation And Operating Manual page 16

Model Number
208C02
Performance
Sensitivity(± 15 %)
Measurement Range(Compression)
Measurement Range(Tension)
Maximum Static Force(Compression)
Maximum Static Force(Tension)
Broadband Resolution(1 to 10,000 Hz)
Low Frequency Response(-5 %)
Upper Frequency Limit
Non-Linearity
Environmental
Temperature Range
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Output Polarity(Compression)
Physical
Stiffness
Size (Hex x Height x Sensing Surface)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting Thread
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® FORCE SENSOR
ENGLISH
50 mV/lb 11,241 mV/kN
100 lb
100 lb
600 lb
500 lb
0.001 lb-rms 0.004 N-rms
0.001 Hz
36 kHz
≤ 1 % FS
-65 to +250 °F -54 to +121 °C
≤ 0.05 %/°F
≥ 500 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA
≤ 100 Ohm
8 to 14 VDC
0.000135 lb/√Hz 0.000603 N/√Hz
0.0000276 lb/√Hz 0.000123 N√Hz
0.0000096 lb/√Hz 0.0000427 N/√Hz
0.0000021 lb/√Hz 0.0000095 N/√Hz
Positive
6 lb/µin
0.625 in x 0.625 in x 0.500 in 15.88 mm x 15.88 mm x 12.7 mm
0.80 oz
Stainless Steel Stainless Steel
Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
Side
10-32 Female 10-32 Female
SI
Optional versions have identical specifications and accessories as listed for the standard model
0.4448 kN
0.4448 kN
- Negative Output Polarity
2.669 kN N
2.224 kN Output Polarity(Compression)
[1]
[2]
0.001 Hz - TEDS Capable of Digital Memory and Communication Compliant with IEEE 1451.4
TLD
[3]
36 kHz
Output Bias Voltage
[4]
≤ 1 % FS
W - Water Resistant Cable
≤ 0.09 %/°C
≥ 500 sec
NOTES:
2 to 20 mA
[1] Typical.
≤ 100 Ohm
[2] Calculated from discharge time constant.
8 to 14 VDC
[3] Estimated using rigid body dynamics calculations.
[1]
[4] Zero-based, least-squares, straight line method.
[5] See PCB Declaration of Conformance PS023 for details.
[1]
[1]
[1]
Positive
[1]
1.05 kN/µm
SUPPLIED ACCESSORIES:
22.7 gm
Model 080A81 Thread Locker (1)
Model 081B05 Mounting Stud (10-32 to 10-32) (2)
Hermetic
Model 084A03 Impact Cap (1)
Model M081A62 Mounting stud, 10-32 to M6 x 1, BeCu with shoulder (2)
Side
Entered: LK
Date: 5/11/2017
3425 Walden Avenue, Depew, NY 14043
OPTIONAL VERSIONS
except where noted below. More than one option may be used.
Negative
8 to 15 VDC
Engineer: DK Sales: RM Approved: BAM
Date: 5/11/2017 Date: 5/11/2017 Date: 5/11/2017
Revision: K
ECN #: 46791
Negative
8 to 15 VDC
Spec Number:
8467
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
