Specification - Sealey SSCL.1 Manual

Keep the trap door blocked open.
Mobile access and working towers designed in accordance with EN 1004-1 are not anchor points for fall arrest systems.
9
Working on a platform is only allowed if there is a complete guard rail consisting of handrails, intermediate rails and toeboards.
9
After assembly or modification, the following basic information should be displayed on the mobile access and working tower, and it
9
should be clearly visible from the ground (on a label, for example):
The name and contact details of the person in charge;
Whether the mobile access and working tower is ready for use or not;
The load category and the uniformly distributed load value for the mobile access and working tower;
Whether the mobile access and working tower is solely intended for interior use only;
The assembly date.
1.1. LOAD STRUCTURE:
Mobile access and working tower category III EN 1004-1
9
Point load: 150 Kg on a single loaded platform
9
Maximum allowable load on a single level: 2000 N/ m² (≈ 169 Kg) uniformly distributed on the platform
9
1 person per platform (see platform details above)
9
Only the last platform should have a person on it, provided the load limits detailed above are respected!
9
The use of stabilizers is compulsory for all mobile tower heights.
9
2. INTRODUCTION
SSCL.1: EN 131 Approved high quality scaffold platform system for the professional tradesman. Robust aluminium frame unit with anodized
finish for durable corrosion resistance. Heavy-duty platform with trap door for safe access to platform. Can be used as a 3mtr or 4mtr working
height platform by fitting extension kit supplied with the unit. Unique design enables the unit to be quickly and easily folded down without tools
for transportation or storage. 780mm Width means unit will pass through most doorways even when fully erected. High hand rail for comfort and
safety. Four large Ø125mm castors for easy mobility.
SSCL.2: Extension kit for Model No. SSCL.1, increases platform height to 1.6m and working height to 3.6m. Supplied with 2 x 1m ladder
extensions and 1 x safety rail. Manufactured from robust aluminium with anodized finish for durable corrosion resistance.
SSCL3: Extension kit for Model No. SSCL.1, increases platform height to 3.35m and working height to 5.35m. Supplied with 2 x 2m ladders, 4
x safety rails, 2 x Ø35 Diagonal supports and 1 x Additional Platform with trapdoor. Manufactured from robust aluminium with anodized finish for
durable corrosion resistance.
SSCL4: Extension kit for Model No. SSCL.1, SSCL.2 and SSCL3, increases platform height to 5.1m and working height to 7.1m. Supplied with 2
x 2m ladders, 4 x Ø35 diagonal supports. Manufactured from robust aluminium with anodized finish for durable corrosion resistance.

3. SPECIFICATION

Model No: ..................................................................SSCL.1
Depth: ........................................................................ 890mm
Description: ........................................................... Base Pack
Capacity: ................................................................. 200kg/m
Max. Platform Height: .................................................... 0.6m
Max. Working Height: ..................................................... 1.6m
Width: ....................................................................... 1770mm
Width with legs: ........................................................ 3084mm
Model No: ..................................................................SSCL.2
Depth: ........................................................................ 890mm
Description: .................................................Extension Pack 2
Capacity: ................................................................. 200kg/m
Max. Platform Height: .................................................... 1.6m
Max. Working Height: ..................................................... 3.6m
Width: ....................................................................... 1770mm
Width with legs: ........................................................ 3084mm
Note: ........................................ Only when used with SSCL.1
© Jack Sealey Limited
Model No: ...................................................................SSCL3
Depth: ........................................................................ 830mm
Description: .................................................Extension Pack 3
Capacity: ................................................................. 200kg/m
2
Max. Platform Height: .................................................3.35m*
Max. Working Height: ..................................................5.35m*
Width with legs: ........................................................ 3084mm
Note: ....................... *only when used with SSCL.1 & SSCL.2
Model No: ...................................................................SSCL4
Depth: ........................................................................ 830mm
Description: .................................................Extension Pack 4
Capacity: ................................................................. 200kg/m
2
Max. Platform Height: ................................................. 5.1m**
Max. Working Height: .................................................. 7.1m**
Width: ....................................................................... 1770mm
Width with legs: ........................................................ 3084mm
Note: .........** only when used with SSCL.1, SSCL.2, SSCL.4
Original Language Version SSCL.1, SSCL.2, SSCL3, SSCL4 Issue:1 (1) 24/04/23
