WisyCom BFLT1 Quick Start Manual

Filter Version
(filter type indicated on serial number sticker)
F1:
Europe, UK and USA version
Tunable: 470-758 MHz (40 MHz band)
Bandpass (MHz):
170-608 170-698 170-1160 170-1260
470-608 470-698 470-1160 470-1260
518-608 518-698 518-1160 518-1260
566-698 566-1160 566-1260 960-1160
960-1260 820-832 733-758 940-960
Main Accessories
(for an updated and full list, visit wisycom.com)
PSP15V1A2:
Hirose 4 pin connector (15VDC 1.2mA)
Supplied with EU/UK/USA/AU plugs
ABTS: Bluetooth antenna
ADFC: FC/APC adapter (to upgrade BFL optical
connector from SC/APC to FC/APC)
ADST:
ST/APC adapter (to upgrade BFL optical
connector from SC/APC to ST/APC)
CNGA26:
tor from BNC to N)
Conformity
Safety EN62368-1:2014; EMC: ETSI EN 300 386 V1.6.1
(2012-04) and FCC CFR-47 part 15 Sub part B
BFLT1
QUICK USER GUIDE
F2:
Japan and Korea version
Tunable: 470-758 MHz (40 MHz band)
Bandpass (MHz):
170-608 170-698 170-714
470-608 470-698 470-714
518-608 518-698 518-714
566-698 566-714 566-1260 614-698
614-714 614-1260 806-810
1240-260
90-264 Vac power supply with
N connector (to upgrade RF connec-
IC
Serial Number:
170-1260
This guide is intended to assist you with initial quick setup and
470-1260
operation for your Wisycom product.
518-1260
927-935
You can refer to Wisycom Authorized Distributors for technical
support and information about service and repairs available in your
region or contact us directly by email.
WISYCOM S.r.l.
Via Tiepolo 7/E
35019 Tombolo (PD) - ITALY
+39 0424 382605
support@wisycom.com
sales@wisycom.com
Download Documentation and Firmware
Get declaration, user manual, tips, software,
specifications, on the download page:
wisycom.com/products/d/bflt1-bflr1/
Product Registration and Warranty
Register your product to extend your warranty
and receive updates on latest firmware:
wisycom.com/products/my-account
Keep up with Wisycom online
Follow us on Facebook and Instagram. You
can also subscribe on Youtube for more.
wisycom.com/social
BFLT1
QUICK USER GUIDE
Purchase Date:
WISYCOM INC.
14301 Sullyfield Circle, Suite C
Chantilly, VA 20151- USA
+1 703-574-7505
support.us@wisycom.com
sales.us@wisycom.com
