Summary of Contents for HOLDEN MY17 BL Astra

  • Page 1 MY17 BL Astra Owner’s Manual...
  • Page 2 It also helps us let you know if there is an existing safety recall or rework on your vehicle. To update your details, please take a few minutes to fill in and mail the form at the back of the Service & Warranty Booklet or visit Holden’s website at: www.holden.com.au/forms/change-of-owner-details...

  • Page 3: Table Of Contents

    Contents Introduction ........2 In brief ..........4 Keys, doors and windows .... 17 Seats, restraints ......39 Storage ........53 Instruments and controls ..... 58 Lighting ........85 Climate control ......92 Driving and operating ....101 Vehicle care ....... 142 Service and maintenance ..

  • Page 4: Introduction

    Introduction Introduction...
  • Page 5 Introduction Introduction ● The table of contents at the 9 Warning beginning of this manual and Your vehicle is a designed within each section shows where combination of advanced technology, Text marked 9 Warning provides the information is located. safety, environmental friendliness information on risk of accident or ●...

  • Page 6: In Brief

    In brief In brief Vehicle unlocking Initial drive information To open the boot lid after unlocking, push the touchpad switch below the Press button c to unlock the doors boot lid moulding. and load compartment. Open the Radio remote control 3 20, doors by pulling the handles.
  • Page 7 In brief Remote engine start Cancelling a remote start With this feature the engine can be To cancel a remote start, do any of the started from outside the vehicle. following: ● Press and hold O until the side Starting the Vehicle lights turn off.
  • Page 8 In brief Seat adjustment Backrest inclination Seat height Longitudinal adjustment Pull lever, adjust inclination and Lever pumping motion release lever. Allow the backrest to : seat higher Pull handle, slide seat, release engage audibly. down : seat lower handle. Try to move the seat back and Seat position 3 40.
  • Page 9 In brief Head restraint adjustment Seat belt Mirror adjustment Interior mirror Pull the head restraint upwards or Pull out the seat belt and engage in press the catch to release and push belt buckle. The seat belt must not be To adjust the mirror, move the mirror the head restraint downwards.
  • Page 10 In brief Steering wheel adjustment Exterior mirrors Select the relevant exterior mirror and Unlock the lever, adjust the steering adjust it. wheel, then engage the lever and ensure it is fully locked. Convex exterior mirrors 3 33, Electric adjustment 3 33, Folding Do not adjust the steering wheel exterior mirrors 3 34.
  • Page 11 In brief Instrument panel overview...
  • Page 12 In brief Power windows ..... 35 16 Climate control system ..92 29 Light switch ......85 Central locking system ..23 17 Fuse box ......160 Rear fog lights ...... 88 Exterior mirrors ..... 33 18 USB input, AUX input ....9 Instrument illumination ..
  • Page 13 In brief Exterior lighting Headlight flash, high beam and Turn and lane-change signals low beam Automatic light control lever up : left turn signal lever down : right turn signal headlight flash : pull lever AUTO : automatic light control: high beam : push lever exterior lighting is switched...
  • Page 14 In brief Horn Washer and wiper systems Hazard warning flashers Windscreen wiper Operated with the ¨ button. Press j. Hazard warning flashers 3 87. : fast : slow INT : interval wiping or automatic wiping with rain sensor OFF : off For single wipe when the wiper is off, press lever down to position 1x.
  • Page 15 In brief Climate control Windscreen washer Demisting and defrosting the windows, air conditioning system Heated rear window, heated exterior mirrors Pull lever. Press button V. Windscreen washer system 3 60, Washer fluid 3 149. Press button A/C to switch on The heating is operated by pressing dehumidification (drying) of the air.
  • Page 16 In brief Transmission Demisting and defrosting the Automatic transmission windows, electronic climate Manual transmission control system P : park R : reverse Reverse: with the vehicle stationary, N : neutral Press button V. D : drive depress clutch pedal and then press Press button A/C to switch on the release button on the selector dehumidification (drying) of the air.
  • Page 17 In brief Starting off Starting the engine ● Do not operate accelerator pedal. ● Ignition switch: turn key to Check before starting off position 3 and release ● Tyre pressure and condition 3 162, 3 187. ● Engine oil level and fluid levels 3 147.
  • Page 18 In brief Parking If the vehicle is on a downhill Caution slope, set the selector lever to 9 Warning position P before removing the After running at high engine ignition key or switching off speeds or with high engine loads, ●...

  • Page 19: Keys, Doors And Windows

    Keys, doors and windows Keys, doors and Keys, locks Power windows ......35 Heated rear window ....37 windows Sun visors ........37 Keys Roof ..........37 Sunroof ........37 Caution Keys, locks ........17 Do not attach heavy or bulky items Keys ..........

  • Page 20: Remote Engine Start

    Keys, doors and windows Included mechanical key element must be used for manual operation if central locking system fails, 3 23. Press button at the side of the housing and remove key from the unit. The cap above the lock cylinder in the driver's door must be removed from the driver's door handle.
  • Page 21 Keys, doors and windows Starting the engine using remote The engine will shut off after 15 minutes unless a time extension is start done or the ignition is turned on. To start the engine using the If the vehicle is low on fuel, do not use electronic key: the remote start feature.

  • Page 22: Radio Remote Control

    Keys, doors and windows The vehicle's ignition must be turned ● The oil pressure is low. The remote control has an on and then back off before the approximate range of up to ● Two remote vehicle starts, or a remote start procedure can be used 50 metres.
  • Page 23 Keys, doors and windows To replace: 2. Remove battery with a very small Fault screw driver at the mark, see If the central locking system cannot illustration. be operated with the radio remote 3. Replace battery. Use CR 2032 or control, the cause may be one of the equivalent battery.

  • Page 24: Electronic Key System

    Keys, doors and windows Electronic key system This feature can be identified by a To replace: button on the outside door handles. Additionally the electronic key includes the functionality of the radio remote control 3 20. Handle with care, protect from moisture and high temperatures and avoid unnecessary operation.

  • Page 25: Memorised Settings

    Keys, doors and windows 2. Insert flat screw driver in the Fault ● automatic climate control center of the recess and separate ● lighting If the central locking cannot be the back cover of the electronic ● Infotainment system operated or the engine cannot be unit by turning the screw driver a started, the cause may be one of the ●...
  • Page 26 Keys, doors and windows Note Unlocking mode can be set in the In the event of an accident in which vehicle personalisation menu in the airbags or belt pretensioners are Colour-Info-Display. It can be deployed, the vehicle is configured as follows: automatically unlocked.
  • Page 27 Keys, doors and windows Unlocking and opening the boot lid Electronic key system operation Unlocking Press button X twice when the With locked doors and the electronic The electronic key must be outside key in range to the door handle, press ignition is off to open boot lid only.
  • Page 28 Keys, doors and windows All doors, load compartment and fuel The boot lid and the doors can be filler flap are locked. unlocked by pressing the button ● only the driver's door, load under the boot lid moulding when compartment and fuel filler flap If the driver's door is not closed electronic key is in range.
  • Page 29 Keys, doors and windows Remote control: to remove the cap, Electronic key: to remove the cap, Press the e button to lock. fold out mechanical key by pressing press button at the side and extract Press the c button to unlock. the knob on the remote control.

  • Page 30: Automatic Locking

    Keys, doors and windows Manual unlocking Manual locking After locking install the cap above the lock cylinder: insert the cap with the Manually unlock the driver's door by Push inside locking knob of all doors lower side in the recesses and swivel inserting and turning the key in the except driver's door or press and push the cap until it engages at...

  • Page 31: Child Locks

    Keys, doors and windows To unlock the doors: Settings can be changed in the menu Settings can be changed in the menu Settings, I Vehicle in the Settings, I Vehicle in the ● Press c. Info-Display. Vehicle personalisation Info-Display. Vehicle personalisation ●...

  • Page 32: Doors

    Keys, doors and windows Doors To deactivate, move the button to rear position. Load compartment Boot lid Opening Press the touchpad switch below the boot lid moulding to open when the vehicle is unlocked. Closing Boot lid is unlocked together with the doors by pressing c on remote control.

  • Page 33: Vehicle Security

    Keys, doors and windows Vehicle security Use interior handle. the boot lid. Always check the Do not push the touchpad switch moving area above and behind the Anti-theft alarm system whilst closing as this will unlock the boot lid. boot lid again. The anti-theft alarm system monitors: Note Lock the vehicle by pressing e on the...
  • Page 34 Keys, doors and windows Status LED Deactivation ● Radio remote control or electronic key: directly by Status LED is integrated in the sensor Radio remote control: Unlocking the pressing e twice within on top of the instrument panel. vehicle by pressing button c 5 seconds.

  • Page 35: Immobiliser

    Keys, doors and windows Exterior mirrors Electronic key system: Unlocking the Vehicle messages 3 81. vehicle by pressing the button and pulling the handle on any exterior Immobiliser Convex shape door deactivates anti-theft alarm The convex exterior mirror contains The system is part of the ignition system.

  • Page 36: Folding Mirrors

    Keys, doors and windows Interior mirrors In position 0 no mirror is selected. objects and other vehicles around you. Do not drive while either Folding mirrors Manual anti-dazzle outside rearview mirror is folded back. Heated mirrors For pedestrian safety, the exterior To reduce dazzle, adjust the lever on mirrors will swing out of their normal the underside of the mirror housing.

  • Page 37: Windows

    Keys, doors and windows Windows Windscreen stickers Do not attach stickers such as toll Windscreen road stickers or similar on the windscreen in the area of the interior Heat-reflecting windscreen mirror. Otherwise the detection zone of the sensor and the view area of the The heat-reflecting windscreen has a camera in the mirror housing could be coating which reflects solar radiation.
  • Page 38 Keys, doors and windows All doors (except driver's door LTZ Operation standby Overload model): Power windows can be operated for If the windows are repeatedly Pushing gently to the first detent or approx. 10 minutes after the ignition operated within short intervals, the pulling: window moves up or down as is switched off or until the driver's door window operation is disabled for...

  • Page 39: Heated Rear Window

    Keys, doors and windows Roof Heated rear window Sunroof 9 Warning Take care when operating the sun roof. Risk of injury, particularly to children. Keep a close watch on the movable parts when operating them. Ensure that nothing Open or close becomes trapped in them as they move.
  • Page 40 Keys, doors and windows If the sunroof is raised, it can be opened in one step by pressing p. Sunblind The sunblind is manually operated. Close or open the sunblind by sliding. When the sunroof is open, the sunblind is always open. General hints Safety function If the sunroof encounters resistance...

  • Page 41: Seats, Restraints

    Seats, restraints Seats, restraints Head restraints The upper edge of the head restraint should be at upper head level. If this is not possible for extremely tall Position people, set to highest position, and set to lowest position for small people. Head restraints ......

  • Page 42: Front Seats

    Seats, restraints Front seats Head restraints on rear seats Seat position 9 Warning Only drive with the seat correctly adjusted. 9 Danger Do not sit nearer than 25 cm from ● Sit with buttocks as far back the steering wheel, to permit safe against the backrest as possible.

  • Page 43: Manual Seat Adjustment

    Seats, restraints ● Sit with shoulders as far back Longitudinal adjustment Backrest inclination against the backrest as possible. Set the backrest rake so that it is possible to easily reach the steering wheel with arms slightly bent. Maintain contact between shoulders and the backrest when turning the steering wheel.

  • Page 44: Armrest

    Seats, restraints Armrest Heating Seat height Lever pumping motion The armrest can be slid forwards by Adjust heating to the desired setting 10 cm. Under the armrest there is a by pressing the ß button for the : seat higher storage compartment.

  • Page 45: Rear Seats

    Seats, restraints Rear seats Seat belts temperature outside is below approximately 10°C. They are cancelled when the ignition is turned Armrest Press the button to use the heated seats after the vehicle is started. The heated seat indicator lights do not turn on during a remote start.

  • Page 46: Three-Point Seat Belt

    Seats, restraints Seat belts are designed to be used by Belt force limiters pretensioners. Do not make any only one person at a time. Child modifications to belt pretensioner On the front seats, stress on the body restraint system 3 48. components as this will invalidate is reduced by the gradual release of the vehicle type approval.
  • Page 47 Seats, restraints Unfasten Using the seat belt while pregnant Loose or bulky clothing prevents the belt from fitting snugly. Do not place To release belt, press red button on objects such as handbags or mobile 9 Warning belt buckle. phones between the belt and your body.

  • Page 48: Airbag System

    Seats, restraints Airbag system necessary to have the steering wheel, the instrument panel, parts of the panelling, the door seals, The airbag system consists of a handles and the seats replaced. number of individual systems Do not make any modifications to depending on the scope of the airbag system as this will equipment.

  • Page 49: Side Airbag System

    Seats, restraints Side airbag system The forward movement of the front seat occupants is retarded, thereby considerably reducing the risk of injury to the upper body and head. 9 Warning Optimum protection is only provided when the seat is in the proper position 3 40.

  • Page 50: Curtain Airbag System

    Seats, restraints Child restraints 9 Warning Child restraint systems Children who are seated in close proximity to a side airbag may be When a child restraint system is being at risk of serious or fatal injury if the used, pay attention to the following airbag deploys, especially if the usage and installation instructions child’s head, neck, or chest is...
  • Page 51 Check your approved child restraints and/or local road safety regulations certain locations within the before seating a child in the front vehicle. Holden strongly seat. Where legally allowable, you recommends that you refer to your may install a forward-facing child...
  • Page 52 Seats, restraints Isofix child restraint systems Top-tether child restraint systems restraint in the front seat, but always move the passenger seat Top-tether fastening eyes are marked as far back as it will go. with the symbol : on the load Child restraint anchorages are compartment cover.
  • Page 53 Seats, restraints Selecting the right system Only allow children to enter and exit the vehicle at the side facing away The rear seats are the safest location from the traffic. to fasten a child restraint system. When the child restraint system is not Your child should travel facing in use, secure the seat with a seat belt backwards in the vehicle, until as old...

  • Page 54: Child Restraint Installation Locations

    Seats, restraints Child restraint installation locations Permissible options for fastening a child restraint system with a three-point seat belt Weight class On front passenger seat On rear outboard seats On rear centre seat Group 0: up to 10 kg Group 0+: up to 13 kg Group I: 9 to 18 kg Group II: 15 to 25 kg Group III: 22 to 36 kg...

  • Page 55: Storage

    Storage Storage Storage compartments The glovebox should be closed whilst driving. Cupholders 9 Warning Storage compartments ....53 Glovebox ........53 Do not not store heavy or sharp Cupholders ........ 53 objects in the storage Front storage ......54 compartments. Otherwise, the Armrest storage ......

  • Page 56: Front Storage

    Storage Front storage Armrest storage Storage under the front armrest Additional cupholders are located in the rear armrest. Fold down the A storage compartment is located armrest. next to the steering wheel. Press button to fold up the armrest. The armrest must be in rearmost position.

  • Page 57: Centre Console Storage

    Storage Load compartment Centre console storage The rear seat backrest may be undivided or split into two parts. The backrest can be folded down. Load compartment extension ● Press and hold the catch to push the head restraints down 3 39. ●...

  • Page 58: Rear Floor Storage Cover

    Storage Rear floor storage cover Rear floor cover The backrests are properly engaged The seat belt of the centre seat could when the red mark near the release be locked when the backrest is folded lever is no longer visible. up too quickly.

  • Page 59: Loading Information

    Storage Loading information ● When transporting objects in the ● Optional equipment and load compartment, the backrests accessories increase the kerb of the rear seats must not be weight. angled forward. ● Driving with a roof load increases ● Do not allow the load to protrude the sensitivity of the vehicle to above the upper edge of the cross-winds and has a...

  • Page 60: Instruments And Controls

    Instruments and controls Instruments and Controls Malfunction indicator light ..71 Brake system ......71 controls Antilock brake system (ABS) ..71 Steering wheel adjustment Gear shifting ......71 Lane keep assist ....... 71 Electronic Stability Control off . . . 72 Controls ........

  • Page 61: Steering Wheel Controls

    Instruments and controls Steering wheel controls Horn On the backside of the steering wheel there are buttons for volume and Driver Information Centre, some Press j. various functions of the Infotainment driver assistance systems, system. Infotainment system and a connected Infotainment information is available mobile phone can be operated via the in the Infotainment system manual.

  • Page 62: Windscreen Wiper/Washer

    Instruments and controls Windscreen wiper/washer Adjustable wiper interval Windscreen wiper with rain sensor Windscreen wiper with adjustable wiper interval Wiper lever in position INT. : fast Turn the adjuster wheel to adjust the : slow desired wipe interval: : fast AUTO : automatic wiping with rain short interval : turn adjuster...

  • Page 63: Outside Temperature

    Instruments and controls Do not use if the windscreen is frozen. Pull lever. Washer fluid is sprayed onto the windscreen and the wiper Switch off in car washes. wipes a few times. Adjustable sensitivity of the rain Washer fluid 3 149. sensor Outside temperature A drop in temperature is indicated...

  • Page 64: Clock

    Instruments and controls 7'' Colour-Info-Display Auto Set To choose whether time and date are Press ; and then select Settings. to be set automatically or manually, Select Time and Date to display the select Auto Set. respective submenu. For time and date to be set automatically, select On - RDS.

  • Page 65: Power Outlets

    Instruments and controls Clock display Select Clock Display to enter the respective submenu. To turn off the digital clock display in the menus, select Off. Power outlets Adjust hours and minutes by touching A further 12 Volt power outlet is n or o.

  • Page 66: Warning Lights, Gauges And Indi- Cators

    Instruments and controls Warning lights, gauges Odometer USB charging port and indicators Instrument cluster In some versions, the needles of the instruments briefly rotate to the end position when the ignition is switched Speedometer A USB port for charging devices is The total recorded distance is located in the centre console.

  • Page 67: Tachometer

    Instruments and controls Tachometer Midlevel instrument cluster Uplevel instrument cluster Select Trip/fuel information ; menu Select Info page Q on main menu. Displays the engine speed. Choose page Trip A or Trip B by by pressing m or n on the right Drive in a low engine speed range for pressing c on the steering wheel.

  • Page 68: Fuel Gauge

    Instruments and controls Fuel gauge Engine coolant temperature Caution gauge If engine coolant temperature is too high, stop vehicle, switch off engine. Danger to engine. Check coolant level. Service display The engine oil life system lets you know when to change the engine oil and filter.

  • Page 69: Control Indicators

    Instruments and controls Control indicators The remaining oil life duration menu Remaining oil life duration is indicated is displayed in the Driver Information in %. The control indicators described are Centre 3 74. not present in all vehicles. The Reset description applies to all instrument For Midlevel display, press 9 on the versions.
  • Page 70 Instruments and controls...

  • Page 71: Turn Signal

    Instruments and controls Control indicator in the roof u Antilock brake system (ABS) A Vehicle detected ahead 3 73 console 3 71 Door open 3 73 R Gear shifting 3 71 Turn signal E Following distance 3 119 O flashes green. a Lane keep assist 3 71 A turn signal or the hazard warning Electronic Stability Control off...

  • Page 72: Airbag And Belt Tensioners

    Instruments and controls Illuminates Seat belt status on rear seats workshop. The airbags and belt pretensioners may fail to trigger in the After the ignition has been switched (vehicles with Uplevel display) event of an accident. on until the seat belt has been X illuminates green or grey or flashes fastened.

  • Page 73: Malfunction Indicator Light

    Instruments and controls Antilock brake system Illuminates when the engine is Flashes when the engine is running running (ABS) Stop, switch off engine. Vehicle Fault that could lead to catalytic u illuminates yellow. battery is not charging. Engine converter damage. Ease up on the Illuminates for a few seconds after the cooling may be interrupted.

  • Page 74: Electronic Stability Control Off

    Instruments and controls Illuminates green Illuminates Illuminates when the engine is running The system is switched on and ready A fault in the system is present. to operate. Continued driving is possible. Driving Caution stability, however, may deteriorate Illuminates yellow depending on road surface Engine lubrication may be conditions.

  • Page 75: Low Fuel

    Instruments and controls Low fuel High beam assist Illuminates yellow Y illuminates or flashes yellow. f illuminates green. The distance to a preceding moving vehicle gets too small or when The high beam assist is activated Illuminates approaching another vehicle too 3 86.

  • Page 76: Information Displays

    Instruments and controls Information displays Midlevel display Some of the displayed functions differ when the vehicle is being driven or at a standstill and some functions are Driver Information Centre only active when the vehicle is being The Driver Information Centre is driven.
  • Page 77 Instruments and controls Vehicle and service messages are ● Phone information, displayed by Press m to open main menu page. popped up in the Driver Information Phone, see description below. Select a main menu page via d or c. Centre if required. Confirm messages ●...
  • Page 78 Instruments and controls Trip/fuel information menu, ; ● Economy trend To reset on Midlevel display, press 9 for a few seconds, on Uplevel or Info ● Eco index display, press n and confirm with On Midlevel display the pages The following list contains all possible Remaining Oil Life, Battery voltage Info Menu pages.
  • Page 79 Instruments and controls When the fuel tank has to be refuelled Eco information menu, @ Economy Trend immediately, a warning message Turn the adjuster wheel to select a appears and remains on the display. page and follow the instructions given Additionally, the control indicator Y in in the submenus: the fuel gauge flashes 3 73.
  • Page 80 Instruments and controls Simultaneously the average Vehicle information menu, ? or Speed warning consumption value is indicated. Options Audio Menu The following list contains all possible Options Menu pages. Some may not Audio menu enables browsing for be available for your particular music, selecting from favourites or vehicle.

  • Page 81: Info Display

    Instruments and controls Valet mode ● date 3 62 ● Infotainment system, see Some functions of the Driver Infotainment manual. Information Centre and the Info- Display can be limited for some ● indication of rear view camera 3 129 drivers. ●...
  • Page 82 Instruments and controls 8'' Colour-Info-Display Press MENU to confirm a selection. Valet mode Press BACK to exit a menu without Some functions of the Driver Selecting menus and settings changing a setting. Information Centre and the Info- There are three options to operate the Press ;...

  • Page 83: Vehicle Messages

    Instruments and controls Vehicle messages Messages in the Info-Display ● If a warning message appears in the Driver Information Centre. Some important messages may ● If the electronic key is not in the Messages are indicated in the Driver appear additionally in the Info- passenger compartment.

  • Page 84: Vehicle Personalisation

    Instruments and controls Vehicle personalisation The warning message will disappear after the engine has been started twice without a voltage drop. The vehicle's behaviour can be If the vehicle battery cannot be personalised by changing the settings recharged, have the cause of the fault in the Info-Display.
  • Page 85 Instruments and controls ● Lighting Relock Remotely Unlocked Vehicle Doors: Activates or deactivates ● Climate and Air Quality Vehicle Locator Lights: Activates the automatic relock function or deactivates the entry lighting. Auto Fan Speed: Modifies the after unlocking without opening level of the cabin airflow of the Exit Lighting: Activates or the vehicle.
  • Page 86 Instruments and controls Exit Lighting: Activates or unlocking without opening the deactivates and changes the vehicle. duration of exit lighting. Passive Door Unlock: Changes ● Power Door Locks the configuration to unlock only the driver's door or the whole Unlocked Door Anti-Lockout: vehicle whilst unlocking.

  • Page 87: Lighting

    Lighting Lighting Exterior lighting When headlights are on, 8 illuminates. Control indicator 8 3 73. Light switch Tail lights Exterior lighting ......85 Light switch ........ 85 Tail lights are illuminated together Automatic light control ....85 with headlights and sidelights. High beam .........

  • Page 88: High Beam

    Lighting Automatic headlight activation The camera in the windscreen 50 km/h. High beam is switched off at detects the lights of oncoming or a speed below 35 km/h, but high During poor lighting conditions the preceding vehicles. Once activated, beam assist remains active. headlights are switched on.

  • Page 89: Headlight Flash

    Lighting Daytime running lights Deactivation In the event of an accident with airbag deployment the hazard warning Daytime running lights increase If high beam assist is active and high flashers are activated automatically. visibility of the vehicle during daylight. beam is on, push f once or pull indicator lever once to deactivate high They are switched on automatically Turn and lane-change...

  • Page 90: Rear Fog Light

    Lighting Interior lighting For three flashes, e.g. when changing The vehicle rear fog light may be lanes, press the lever until resistance deactivated when towing a trailer or a is felt and then release. plug is connected with the socket, e.g. Instrument panel when a bicycle carrier is used.

  • Page 91: Interior Lights

    Lighting Sunvisor lights On vehicles with light sensor, the Operate rocker switch: brightness can only be adjusted when : automatic switching on Illuminates when the cover is opened. the exterior lights are on and the light and off. sensor detects night conditions. press u : on.

  • Page 92: Lighting Features

    Lighting Lighting features Exit lighting Settings menu (Exit Lighting) in Settings, I Vehicle in the Info-Display. The following lights will switch on if Info-Display 3 79. Centre console lighting the ignition is switched off: Vehicle personalisation 3 82. Spotlight incorporated in the interior ●...
  • Page 93 Lighting In the second stage a message which confirms the activation of the vehicle battery discharge protection will be displayed in the Driver Information Centre. Switching off electric lights To prevent discharge of the vehicle battery when the ignition is switched off, some interior lights are switched off automatically after some time.

  • Page 94: Climate Control

    Climate control Climate control Climate control systems ● Fan speed Z ● Cooling A/C Air conditioning system ● Air recirculation 4 ● Demisting and defrosting V Climate control systems ....92 9 Danger Heated rear window Ü 3 37, Air conditioning system ..... 92 Electronic climate control Do not sleep in a vehicle with the Temperature TEMP...
  • Page 95 Climate control Demisting and defrosting the ● Set temperature control to Press button A/C to switch on cooling. warmest level. Activation is indicated by the LED in windows V the button. Cooling is only functional ● Switch on heated rear window Ü. Air is directed to the windscreen and when the engine is running and ●...

  • Page 96: Electronic Climate Control System

    Climate control Air recirculation mode 4 Briefly open the windows to allow hot The exchange of fresh air is air to disperse quickly. reduced in air recirculation mode. ● Press button A/C to switch on In operation without cooling the air cooling.
  • Page 97 Climate control Indication Automatic mode AUTO Controller and buttons for the following functions: The preselected temperature is Basic setting for maximum comfort: ● Automatic mode AUTO indicated in the right rotary knob. ● Press button AUTO, the air ● Temperature Each change of settings is shown in distribution and fan speed are ●...

  • Page 98: Air Distribution Modes M, K, L, J

    Climate control ● Set temperature by turning the If the minimum temperature Lo is set, Set the desired fan speed using the right rotary knob. Suggested the climate control system runs at left rotary knob. The fan speed is comfort setting is 22 °C. maximum cooling, if cooling A/C is indicated by the number of switched on.

  • Page 99: J : To Windscreen, Front Door

    Climate control J : to windscreen, front door ● Press button V. Activation is Cooling A/C windows and foot well indicated by the LED in the M : to head area via adjustable air button. vents ● Press A/C to switch on K : to foot well dehumidification (drying) of the L : to foot well and head area...
  • Page 100 Climate control The Info-Display will indicate A/C Press button 4 to activate the air Remote start climate control ON when cooling is activated or A/C recirculation mode. Activation is operation OFF when the cooling is deactivated. indicated by the LED in the button. The climate control system may run Press button 4 again to deactivate System ON/OFF X...

  • Page 101: Air Vents

    Climate control Air vents To close the centre air vents, turn the adjuster wheel to the left. To close the side air vents, turn the adjuster wheel Adjustable air vents downwards. At least one air vent must be open while the cooling is on. 9 Warning Do not attach any objects to the slats of the air vents.

  • Page 102: Maintenance

    Climate control Maintenance Air conditioning regular operation Air intake In order to ensure continuously efficient performance, cooling must be operated for a few minutes once a month, irrespective of the weather and time of year. Operation with cooling is not possible when the outside temperature is too low.

  • Page 103: Driving And Operating

    Driving and operating Driving and Driving hints Parking brake ......112 Brake assist ......113 operating Hill start assist ......113 Control of the vehicle Ride control systems ....113 Never coast with engine not Traction Control system ..113 Electronic Stability Control ..

  • Page 104: Steering

    Driving and operating Starting and operating Steering 0 : ignition off: Some functions remain active until key is If power steering assist is lost removed or driver's door is New vehicle running-in because the engine stops or due to a opened, provided the ignition was system malfunction, the vehicle can Do not brake unnecessarily hard for...

  • Page 105: Power Button

    Driving and operating Power button button illuminates. Control indicators Steering wheel lock illuminate and most electrical The steering wheel lock activates functions are operable. automatically when: Engine start ● The vehicle is stationary. Operate clutch pedal (manual ● The ignition has been switched transmission) or brake pedal off.

  • Page 106: Retained Power Off

    Driving and operating Starting the engine display No Remote Detected or To switch off the engine, press Replace Battery in Remote Key when Engine Start/Stop again. Remove the you try to start the vehicle. electronic key from the centre Vehicles with ignition switch console.
  • Page 107 Driving and operating Vehicles with power button Emergency shut off during driving Starting the vehicle at low temperatures If the engine needs to be switched off during driving in case of emergency, Starting the engine without additional press Engine Start/Stop for longer heaters is possible down to -30 °C.

  • Page 108: Overrun Cut-Off

    Driving and operating Parking Possible reasons for a non-starting If the vehicle is on a downhill engine: slope, set the selector lever to ● Clutch pedal not operated 9 Warning position P before removing the (manual transmission) ignition key or switching off ●...

  • Page 109: Engine Exhaust

    Driving and operating Engine exhaust Caution Caution After running at high engine Fuel grades other than those listed 9 Danger speeds or with high engine loads, on pages 3 133, 3 183 could operate the engine briefly at a low damage the catalytic converter or Engine exhaust gases contain load or run in neutral for...

  • Page 110: Automatic Transmission

    Driving and operating Automatic transmission Selector lever The selector lever is locked in P and can only be moved when the ignition is on and the brake pedal is applied. The automatic transmission permits automatic gearshifting (automatic mode) or manual gearshifting (manual mode).

  • Page 111: Manual Mode

    Driving and operating Manual mode Do not accelerate while engaging a the shift is not executed. This can gear. Never depress the accelerator cause a message in the Driver pedal and brake pedal at the same Information Centre. time. In manual mode no automatic shifting When a gear is engaged, the vehicle to a higher gear takes place at high slowly begins to creep when the...

  • Page 112: Fault

    Driving and operating Fault ● Special programmes automatically adapt the shifting In the event of a fault a vehicle points when driving up inclines or message is displayed in the Driver down hills. Information Centre. Vehicle ● When starting off in snowy or icy messages 3 81.

  • Page 113: Manual Transmission

    Driving and operating Manual transmission 3. Insert a screwdriver into the Caution opening as far as it will go and move the selector lever out of P or It is not advisable to drive with the N. If P or N is engaged again, the hand resting on the selector lever.

  • Page 114: Brakes

    Driving and operating Brakes ABS starts to regulate brake pressure Fault as soon as a wheel shows a tendency to lock. The vehicle remains 9 Warning The brake system comprises two steerable, even during hard braking. independent brake circuits. ABS control is made apparent If there is a fault in the ABS, the If a brake circuit fails, the vehicle can through a pulse in the brake pedal...

  • Page 115: Brake Assist

    Driving and operating Ride control systems Brake assist If brake pedal is depressed quickly Traction Control system and forcefully, maximum brake force is automatically applied. The Traction Control system (TC) is a component of the Electronic Stability Operation of brake assist might Control 3 114.

  • Page 116: Electronic Stability Control

    Driving and operating press t briefly to deactivate TC, k considerably improves the driving 9 Warning stability of the vehicle on slippery road illuminates. Deactivation is displayed surfaces. as status message in the Driver Do not let this special safety Information Centre.

  • Page 117: Driver Assistance Systems

    Driving and operating Driver assistance Deactivation Additionally the selected mode is displayed as status message in the systems Driver Information Centre. If the vehicle comes into threshold with deactivated ESC, the system will 9 Warning reactivate ESC for the time duration of the threshold, when the brake Driver assistance systems are pedal is depressed once.
  • Page 118 Driving and operating It is the responsibility of the driver to Switching on Vehicle speed can be increased by comply with local posted speed limits. depressing the accelerator pedal. For safety reasons, the cruise control When the accelerator pedal is cannot be activated until the foot released, the previously stored speed brake has been operated once.

  • Page 119: Forward Collision Alert

    Driving and operating Deactivation Switching off the ignition also Additionally the driver gets notified by switches off cruise control and a flashing red LED stripe which is Press button y, control indicator m in deletes the stored speed. projected on the windscreen in the instrument cluster illuminates white.
  • Page 120 Driving and operating Caution The colour lighting of this control indicator does not correspond to local traffic laws on following distance. The driver bears full responsibility for maintaining safe following distance according to applicable traffic rules, weather and road conditions etc. at all times.

  • Page 121: Following Distance Indication

    Driving and operating General information In the following cases, forward collision alert may not detect a vehicle ahead or sensor performance is 9 Warning limited: Forward collision alert is just a ● on winding roads warning system and does not ●...

  • Page 122: Parking Assist

    Driving and operating Parking assist Rear parking assist 9 Warning The driver bears full responsibility for the parking manoeuvre. Rear parking assist is designed to support a driver in parking and not replace the driver’s attention. The driver must always check the Select Info menu via steering wheel surrounding area when driving The system has four ultrasonic...
  • Page 123 Driving and operating engaged, respectively up to The distance indication can be three seconds and then extinguishes. 1.5 metres while reverse gear is inhibited by vehicle messages with a A message is indicated in the Driver engaged. higher priority. After dismissing the Information Centre.
  • Page 124 Driving and operating Indication The system warns the driver with acoustic signals against potentially hazardous obstacles in front of the vehicle in a distance range up to 80 cm and against potentially hazardous obstacles behind the vehicle in a distance range up to 50 cm while a forward gear is engaged, respectively up to 1.5 m while reverse gear is engaged.
  • Page 125 Driving and operating When the system is deactivated Vehicle messages 3 81. manually, the LED in the button Advanced parking assist extinguishes and Park Assist Off pops-up in the Driver Information 9 Warning Centre. After a manual deactivation, the front- It is the driver who bears full rear parking assist is activated again responsibility for accepting the...
  • Page 126 Driving and operating Functionality Parking slot searching mode, indication in the Driver Information Centre The system has six ultrasonic parking When searching for a parking slot, the sensors each in both the rear and system is ready to operate after front bumper.
  • Page 127 Driving and operating Indication in the Info-Display When a slot is detected, a visual When a slot is detected, a visual feedback in the Driver Information feedback on the Info-Display and an The indication may be shown on the acoustic signal is given. Centre and an acoustic signal is colour-info display.
  • Page 128 Driving and operating A brief vibration in the steering wheel ● The direction of driving during the Deactivation after engaging reverse gear indicates parking manoeuvre. The system is deactivated by: that the steering is controlled by the ● The demand to shift into reverse ●...
  • Page 129 Driving and operating Fault external noise sources may cause Parking assist systems do not A message appears when: the system to fail to detect detect objects outside the ● There is a fault in the system. obstacles. detection range. ● The driver did not successfully Special attention must be paid to complete the parking low obstacles which can damage...

  • Page 130: Side Blind Spot Alert

    Driving and operating manoeuvre. Take care of the 9 Warning availability of the suggested parking slot. Side blind spot alert does not replace driver attention. The Surface irregularities, e.g. on driver's complete attention is construction zones, are not required when driving. detected by the system.

  • Page 131: Rear View Camera

    Driving and operating The system can be activated or dirt, snow, ice, slush, or in heavy Do not reverse or park the vehicle deactivated in the menu Settings in rainstorms. Cleaning instructions using only the rear view camera. the Info-Display, vehicle 3 174.
  • Page 132 Driving and operating Display settings Brightness and contrast can be set by tapping the touch screen display when rear view camera is active. Deactivation The camera is switched off when a certain forward speed is exceeded or if reverse gear is not engaged for approx.

  • Page 133: Lane Keep Assist

    Driving and operating 7'' Colour-Info-Display: Activation or ● The vehicle had a rear end Unintended lane departure is deactivation of the visual guiding lines accident. assumed and the warning symbols can be ● There are extreme temperature ● without using turn signal changed by touch buttons in the lower changes.
  • Page 134 Driving and operating Activation The system is operable at vehicle Deactivation speeds above 60 km/h and if lane The system is deactivated by markings are available. pressing a, the LED in the button The system gently turns the steering extinguishes. wheel and the control indicator a changes to yellow, if the vehicle Fault...

  • Page 135: Fuel

    Driving and operating Fuel 9 Danger 9 Warning Fuel for petrol engines Always keep your attention on the Under no circumstances should road and maintain proper vehicle you use fuel containing more than Use of clean, unleaded petrol of position within the lane, otherwise 10% ethanol.
  • Page 136 Driving and operating To open, turn the cap slowly 9 Danger anticlockwise. Fuel is flammable and explosive. No smoking, no naked flames or sparks around fuel. If you can smell fuel in your vehicle, have the cause of this remedied immediately by a workshop.

  • Page 137: Trailer Hitch

    The vehicle is designed primarily as a passenger vehicle, so handling, durability and economy may be affected by towing a trailer. Your Holden Dealer will help supply and install towing equipment to suit your requirements. Trailer towing 3 136.

  • Page 138: Trailer Towing

    Holden towing equipment is recommended where it is available. Where it is not available, no recommendation is made as to the make of equipment to be used. Holden will not accept liability for defects occurring in inappropriate towing equipment or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment.
  • Page 139 Driving and operating Towing with Electronic Stability Control (ESC) You may hear noise from the ESC modulator when it is working. The ESC is reacting to the vehicle movement caused by the trailer, which mainly occurs during cornering. This is considered normal when towing heavier trailers. Recommended procedure for attaching a trailer When a trailer is hitched to the vehicle, it places a weight on the tow bar.
  • Page 140 Driving and operating If the attitude of the vehicle is compromised, adjust the vehicle and trailer load within the specifications to improve the attitude. If the vehicle attitude cannot be corrected, use a load distribution hitch. Note At no time may the maximum towing capacity exceed the maximum specified. Refer to Maximum towing capacity previously in this chapter.
  • Page 141 Remember that bull bars may affect airbag operation. Running in before towing Holden recommends that you drive your new vehicle for at least 1,500 km before towing. If you must tow in the first 1,500 km of the vehicle's life, do not exceed 80 km/h.
  • Page 142 Driving and operating Vehicle maintenance More frequent vehicle maintenance is required when using the vehicle for towing. Refer to the Service & Warranty Booklet in the vehicle's glovebox.

  • Page 143: Trailer Stability Assist

    Driving and operating Trailer stability assist If the system detects snaking movements, engine power is reduced and the vehicle/trailer combination is selectively braked until the snaking ceases. While system is working keep steering wheel as still as possible. Trailer stability assist (TSA) is a function of the Electronic Stability Control 3 114.

  • Page 144: Vehicle Care

    Vehicle care Vehicle care General Information Electrical system ......157 Fuses ........157 Accessories and vehicle Engine compartment fuse box . 158 Instrument panel fuse box ..160 modifications General Information ....142 Load compartment fuse box ..161 We recommend the use of genuine Accessories and vehicle Vehicle tools ......

  • Page 145: Vehicle Storage

    Vehicle care Vehicle storage End-of-life vehicle recovery ● Open the bonnet, close all doors and lock the vehicle. Information on end-of-life vehicle Storage for a long period of time ● Disconnect the clamp from the recovery centres and the recycling of negative terminal of the vehicle end-of-life vehicles is available on our If the vehicle is to be stored for several...

  • Page 146: Vehicle Checks

    Vehicle care Vehicle checks 9 Danger Performing work The ignition system uses extremely high voltage. Do not touch. Bonnet Opening Open the bonnet. 9 Warning Only perform engine compartment checks when the ignition is off. The cooling fan may start operating even if the ignition is off.
  • Page 147 Vehicle care Closing Before closing the bonnet, press the support into the holder. Lower the bonnet and let it fall into the latch from a low height (20-25 cm). Check that the bonnet is engaged. Caution Do not press the bonnet into the latch to avoid dents.

  • Page 148: Engine Compartment Overview

    Vehicle care Engine compartment overview...

  • Page 149: Engine Oil

    Vehicle care 1. Engine air filter We recommend the use of the same grade of engine oil that was used at 2. Brake fluid container 3 149 last change. 3. Engine oil cap 3 147 The engine oil level must not exceed 4.

  • Page 150: Engine Air Filter

    Vehicle care Engine air filter Coolant level Caution Too low a coolant level can cause engine damage. 3. Unscrew the 4 screws and remove the air filter housing. 1. Unclip and remove the air intake duct (1). Engine coolant 2. Loosen the hose clamp and The coolant provides freeze disconnect the air outlet hose (2).

  • Page 151: Washer Fluid

    Vehicle care Washer fluid Once new brake linings are installed, 9 Warning do not brake unnecessarily hard for the first few journeys. Allow the engine to cool before opening the cap. Carefully open Brake fluid the cap, relieving the pressure slowly.

  • Page 152: Vehicle Battery

    Vehicle care Brake fluid 3 177. When the vehicle battery is being replaced, please ensure that there are no open ventilation holes in the Vehicle battery vicinity of the positive terminal. If a ventilation hole is open in this area, it must be closed off with a dummy cap, and the ventilation in the vicinity of the Batteries do not belong in household...

  • Page 153: Wiper Blade Replacement

    Vehicle care Bulb replacement Wiper blade replacement Meaning of symbols: ● No sparks, naked flames or smoking. Switch off the ignition and switch off the relevant switch or close the doors. ● Always shield eyes. Explosive gases can cause blindness or Only hold a new bulb at the base.

  • Page 154: Halogen Headlights

    Vehicle care Halogen headlights Front turn signal light (1) 2. Remove the bulb by pulling out straight from the socket and Halogen headlights without LED replace the bulb. Daytime running lights 3. Insert the bulb holder into the reflector and rotate clockwise. High beam (2) 1.
  • Page 155 Vehicle care 4. Detach the bulb from the bulb holder and replace the bulb. 5. Insert the bulb holder and install spring clip. 6. Fit the cap and rotate clockwise. Low beam and Daytime running light 2. Disengage spring clip from 2.
  • Page 156 Vehicle care 3. Disengage the bulb socket from Front turn signal light (1) 2. Remove the bulb by pulling out the plug connector by pressing straight from the socket and the retaining lug. replace the bulb. 4. Remove and replace the bulb 3.

  • Page 157: Tail Lights

    Vehicle care 3. Disengage the bulb socket from the plug connector by lifting the retaining lug. 4. Remove and replace the bulb socket with bulb and attach the plug connector. 5. Insert the bulb holder, engaging the two lugs into the reflector and rotate clockwise to secure.

  • Page 158: Side Turn Signal Lights

    Vehicle care 5. Remove the bulb socket from the 2. Remove and retain the pushpins 6. Install the bulb socket by turning taillamp assembly by turning it securing the flocking. Pull back clockwise. anticlockwise. the flocking to expose bulb 7. Push the flocking back into place sockets.

  • Page 159: Instrument Panel Illumination

    Vehicle care Electrical system Load compartment light Have bulbs replaced by a workshop. Fuses Instrument panel Data on the replacement fuse must match the data on the defective fuse. illumination There are two fuse boxes in the Have bulbs replaced by a workshop. vehicle: ●...

  • Page 160: Engine Compartment Fuse Box

    Vehicle care Engine compartment fuse The fuse box is in the front left of the engine compartment. Disengage the cover and remove it. Note Not all fuses may be fitted. Place the fuse extractor on the various types of fuse from the top or side, and withdraw fuse.
  • Page 161 Vehicle care No. Circuit No. Circuit No. Circuit Washer front / washer rear Front wiper 34 Flex fuel sensor Air conditioning clutch 19 – 35 – Starter 20 Engine control module 36 VAR_FUNC – 21 Starter 37 Headlight leveling device High beam LH 22 –...

  • Page 162: Instrument Panel Fuse Box

    Vehicle care Instrument panel fuse box No. Circuit The fuse box is located behind a 49 ESCL (Electrical steering cover. column lock) 50 – 51 Central gateway 52 Mirror defog1 53 Rear window defog 54 – 55 Mirror defog2 56 – 57 ABS pump Pull the cover and remove.

  • Page 163: Load Compartment Fuse Box

    Vehicle care No. Circuit No. Circuit No. Circuit 17 Body control module 32 Body control module Cigarette lighter 18 Data link connector 33 – Power outlet front 19 – 34 Shifter / PRNDL Climate control system, fan 20 Diagnostic module 35 –...

  • Page 164: Vehicle Tools

    Vehicle care Vehicle tools Wheels and tyres Tools Tyre condition, wheel condition Drive over edges slowly and at right angles if possible. Driving over sharp edges can cause tyre and wheel damage. Do not trap tyres on the kerb when parking. Regularly check the wheels for damage.

  • Page 165: Tread Depth

    Vehicle care The driver is responsible for correct information label and tyre pressure adjustment of tyre pressure. chart are valid for cold tyres, which means at 20 °C. 9 Warning The pressure increases by nearly 10 kPa for a 10 °C temperature If the pressure is too low, this can increase.

  • Page 166: Tyre Rotation

    Vehicle care about the extent of the damage to Tyres age, even if they are not used. Front and rear tyres can wear the tyre, have it removed from the We recommend tyre replacement differently depending on: wheel and examined by a tyre every six years.

  • Page 167: Tyre Chains

    9 Warning 9 Warning Use of unsuitable tyres or wheels may lead to accidents and will Holden only recommends use of All passengers must be out of the invalidate the vehicle type tyre chains on 16” wheels. vehicle when it is being jacked.
  • Page 168 Vehicle care Make the following preparations and ● Never crawl under a jacked-up Do not get under a vehicle that is observe the following information: vehicle. supported by a jack. No person ● Park the vehicle on a level, firm ●...
  • Page 169 Vehicle care 3. Ensure the jack is correctly positioned under the relevant vehicle jacking point. Ensure that the edge of the body 2. Fold out the wheel wrench and fits into the notch of the jack. install ensuring that it locates securely and loosen each wheel nut by half a turn.

  • Page 170: Spare Wheel

    Vehicle care ground. Do not raise the jack any Jacking position for lifting platform Front arm position of the lifting further. platform at the underbody. 5. Unscrew the wheel nuts. Spare wheel 6. Change the wheel. Spare wheel 3 168. This vehicle is equipped with a temporary spare tyre, which has 7.
  • Page 171 Vehicle care The temporary spare tyre has always 2. The spare wheel is secured with a The floor cover can be placed on the a steel wheel. wing nut. Untwist nut to take out projecting wheel. the spare wheel. Caution 9 Warning Under the spare wheel there is the box with vehicle tools.

  • Page 172: Jump Starting

    Vehicle care Jump starting Spare wheel with directional tyre 9 Warning If possible, fit directional tyres such The vehicle battery is located in the Avoid contact with eyes, skin, that they roll in the direction of travel. load compartment under a cover in The rolling direction is indicated by a fabrics and painted surfaces.
  • Page 173 Vehicle care ● Do not disconnect the discharged Route the leads so that they cannot vehicle battery from the vehicle. catch on rotating parts in the engine compartment. ● Switch off all unnecessary electrical consumers. To start the engine: ● Do not lean over the vehicle 1.

  • Page 174: Towing

    Vehicle care Towing Please observe the following Insert a screwdriver in the slot at the procedures when towing a vehicle: outside of the cap. Release the cap by carefully moving the screwdriver Towing the vehicle ● No passenger should remain in sideways.

  • Page 175: Towing Another Vehicle

    Vehicle care Switch on ignition to release steering Insert cap and engage. wheel lock and to permit operation of brake lights, horn and windscreen Towing another vehicle wiper. Transmission in neutral. Caution Drive slowly. Do not drive jerkily. Excessive tractive force can damage the vehicle.

  • Page 176: Appearance Care

    Vehicle care Appearance care If using a vehicle wash, comply with Caution the vehicle wash manufacturer's instructions. The windscreen wiper Exterior care Drive slowly. Do not drive jerkily. must be switched off. Remove Excessive tractive force can antenna and external accessories Locks damage the vehicle.
  • Page 177 Vehicle care Thoroughly rinse and chamois-off the Windows and windscreen wiper Clean rims with a pH-neutral wheel vehicle. Rinse chamois frequently. cleaner. blades Use separate chamois for painted Rims are painted and can be treated Use a soft lint-free cloth or chamois and glass surfaces: remnants of wax with the same agents as the body.

  • Page 178: Interior Care

    Vehicle care Interior care Caution Interior and upholstery Close Velcro fasteners as open Velcro fasteners on clothing could Only clean the vehicle interior, damage seat upholstery. including the instrument panel fascia and panelling, with a dry cloth or The same applies to clothing with interior cleaner.

  • Page 179: Service And Maintenance

    The detailed, up-to-date service Recommended fluids and schedule for your vehicle is available lubricants ........ 177 Operating materials are at your Holden dealer. hazardous and could be See your service booklet for the poisonous. Handle with care. Pay service schedules and for more attention to information given on information.
  • Page 180 (LLC) antifreeze approved for Topping up engine oil Use and ask for engine oils with the the vehicle. Consult a Holden dealer. dexos certification mark. Oils meeting Engine oils of different manufacturers The system is factory filled with...
  • Page 181 Service and maintenance Brake and clutch fluid Over time, brake fluid absorbs moisture which will reduce braking effectiveness. The brake fluid should therefore be replaced at the specified interval. 9 Warning Using brake fluid other than GM recommended brake fluid may cause corrosion to components of the braking system and reduced braking performance.

  • Page 182: Technical Data

    Technical data Technical data Vehicle identification Identification plate Vehicle Identification Number Vehicle identification ....180 Vehicle Identification Number .. 180 Identification plate ....180 Vehicle data ....... 182 Recommended fluids and lubricants ........ 182 Engine data ......183 Vehicle weight ......184 Vehicle dimensions ....
  • Page 183 Technical data Information on identification label: Engine serial number 1 : Approval number 1.4L Petrol engine 2 : Manufacturer 3 : Category 4 : Number of seats 5 : Vehicle identification number 6 : Compliance date The combined total of front and rear axle loads must not exceed the permissible gross vehicle weight.

  • Page 184: Vehicle Data

    Technical data Vehicle data Recommended fluids and lubricants International service schedule Required engine oil quality Engine Oil quality Oil grade 1.4L Petrol dexos1 ® Gen2 SAE 5W-30...

  • Page 185: Engine Data

    Technical data Engine data Engine 1.4L Piston displacement [cm 1399 Engine power [kW] Refer to www.holden.com.au Torque [Nm] Refer to www.holden.com.au Fuel type Petrol Octane rating RON recommended possible possible...

  • Page 186: Vehicle Weight

    Technical data Vehicle weight Maximum vehicle payloads Engine Occupants (average 68 kg each) Luggage (kg) Total load (kg) 1.4L Maximum front and rear axle loads Engine Front axle loads (kg) Rear axle loads (kg) 1.4L MT 1.4L AT Loading information 3 57.

  • Page 187: Vehicle Dimensions

    Technical data Vehicle dimensions Length [mm] 4665 Width without exterior mirrors [mm] 1807 Width with two exterior mirrors [mm] 2046 Height [mm] 1464 Length of load compartment floor [mm] 1043 Length of load compartment with folded rear seats [mm] 1799 Load compartment width [mm] Load compartment height [mm] Wheelbase [mm]...

  • Page 188: Capacities

    Technical data Capacities Engine oil Engine 1.4L including Filter [l] between MIN and MAX [l] Fuel tank Petrol, refilling quantity [l]...

  • Page 189: Tyre Pressures

    Technical data Tyre pressures Engine Tyres Comfort with up to 3 people ECO with up to 3 people With full load front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) [kPa/bar] ([psi]) [kPa/bar] ([psi]) [kPa/bar] ([psi]) ([psi]) ([psi]) 1.4L 205/55 R16 220/2.2 (32) 220/2.2 (32)

  • Page 190: Customer Information

    Customer information Customer Customer information Holden Customer Care Office information Should you wish to speak to a Holden Owner assistance representative, you are welcome to contact the Holden Customer Care Holden Customer Care team. Refer below for operating hours and various methods of Customer information ....

  • Page 191: Collision Damage Repair

    , iPod , iPod touch , iPod ® ® ® Booklet in your vehicle’s glove box. You can also write to Holden at the nano , iPad and Siri are registered ® ® ® address below: trademarks of Apple Inc.

  • Page 192: Vehicle Data Recording And Privacy

    / devices. If required, you will receive rotational speed, deceleration, further information at these Holden lateral acceleration) dealers. After an error has been corrected, the data are deleted from ● Malfunctions and defects in...

  • Page 193: Radio Frequency Identification (Rfid)

    RFID technology in Holden vehicles does not use or record personal information or link with any other Holden system containing...

  • Page 194: Index

    Index Brakes ....... 112, 149 Brake system ....... 71 Accessories and vehicle Breakdown........172 modifications ......142 Bulb replacement ....... 151 Adjustable air vents ..... 99 Airbag and belt tensioners ... 70 Airbag label........46 Capacities ........186 Airbag system ......46 Catalytic converter .....
  • Page 195 Engine oil pressure ...... 72 Entry lighting ........ 90 Danger, Warnings and Cautions . . . 3 Halogen headlights ....152 Event data recorders....190 Daytime running lights ....87 Hand brake......... 112 Exit lighting ........90 Dimensions......... 185 Hazard warning flashers ....87 Exterior care ......
  • Page 196 Interior care ....... 176 Midlevel display......74 Reading lights ......89 Interior lighting......88 Mirror adjustment ......7 Rear floor storage cover ....56 Interior lights ......89, 156 Misted light covers ....... 88 Rear fog light ......73, 88 Interior mirrors......
  • Page 197 Side turn signal lights ....156 Tread depth ....... 163 Spare wheel ....... 168 Trip odometer ......64 Warning chimes ......81 Speedometer ....... 64 Turn and lane-change signals ..87 Warning lights....... 64 Starting and operating....102 Turn signal ........69 Washer and wiper systems ..

Table of Contents

Save PDF
