Preface
Thank you for purchasing this camera. This camera will help you to fulfill all
your digital picture processing needs.
The camera is equipped with five modes (Capture Mode, Playback
Mode, DSC Setup Mode, Video Mode, and Macro Mode) for your explo-
ration.
This light and handy digital camera offers 4.23 mega pixels high-quality
image along with precise 12 x zoom (3 x optical plus 4 x digital) The built-
in 16MB memory can store your images. The stylish metallic case is
crafted from aluminum alloy, making this camera light and portable.
Through a USB cable connection, pictures can be easily transmitted from
the camera to the PC. Nine recorded images can be displayed on the
high resoultion LCD. Continuous shooting function is also available for
users to take multiple frames of scenes in quick succession.
Note:
i
1.
The company keeps the right to change the con-
tents of this document, spec of this camera in the
future, without prior notice.
Advertisement
Table of Contents
Related Manuals for Rollei dt4200
Summary of Contents for Rollei dt4200
- Page 1 Mode, DSC Setup Mode, Video Mode, and Macro Mode) for your explo- ration. This light and handy digital camera offers 4.23 mega pixels high-quality image along with precise 12 x zoom (3 x optical plus 4 x digital) The built- in 16MB memory can store your images.
-
Page 2: Table Of Contents
Table of Contents Preface...i Prior to Operating the Camera...1 Unpacking the camera...1 Identifying components...2 Loading the battery and SD Card...3 Basic Settings...4 Formatting the Internal Memory and the SD Card...4 Basic Operating Procedure...5 Turning the Camera ON/OFF...5 Basic Shooting...5 Auto-Focus Function...6 Zooming In/Out...6 Flash Setting...6 Playback...6... -
Page 3: Prior To Operating The Camera
Prior to Operating the Camera Set this digital camera by following these quick and simple instructions. Unpacking the camera Clear all items from the box. (It is highly recommended that the box and wrap- pings are kept for future usage) -
Page 4: Identifying Components
Identifying components Flash Viewfinder Handstrap Hook Microphone DC-in & USB Connector Power Button Speaker Battery & SD Card Compartment Battery Charging Status LED Red (Charging), Green (Done) AC Adapter LED CAUTION! Auto-Focus LED Self timer LED Zoom Lens Display Button Power/Flash LED Viewfinder TFT LCD... -
Page 5: Loading The Battery And Sd Card
Loading the battery and SD Card This camera uses a Li-ion battery. The battery and SD card share the same compart- ment and door Full Middle Empty CAUTION! 1.Slide the battery/SD Card cover in the direc- tion of the arrow, then lift to open. 2.Load the included battery in the compartment. -
Page 6: Basic Settings
NOTE: Upon loading new battery, users will need to reset their Basic Settings Do not open the battery/SD card cover or remove the battery when the camera is in its ON status. Only remove the battery and SD card when the camera is not in use, or in its OFF status. -
Page 7: Basic Operating Procedure
Basic Operating Procedure This section provides simple and basic directions to get you started with your camera. From this section, you will learn how to turn the camera on and off, shoot pictures, zoom In and Out, set your flash, and playback your pictures. -
Page 8: Auto-Focus Function
Auto-Focus Function Under Auto-Focus, the camera lens focuses automatically when the shut- ter release is pressed halfway. To activate Auto-Focus, please follow these steps: Zooming In/Out This camera has 3 x optical zoom and 4 x digital zoom. The zoom bar located on the left side of the LCD display, informs users of the zoom sta- tus while the zoom in or out button is pressed. -
Page 9: Five Main Camera Modes And Instructions
Five Main Camera Modes and Instructions This section describes the five modes included in this camera. An in- depth coverage of these modes will be further described. Here are the five main functions of this camera: Camera Mode Video Mode Capture Mode Playback Mode Function Setting... - Page 10 Macro Mode DSC Setup Mode NOTE: Press the display button once to delete the icons from the LCD display. To turn the LCD display sim- ply press the display button a second time. To save your battery power, it is best to not leave your dis- play ON for a long period of time.
-
Page 11: Video Mode
Video Mode Video Mode allows you to use the camera as a movie recorder, and set the self-timer for recording purpose. The length is based on the capacity of your SD card and internal memory. Users can still achieve optical zoom function before actual recording is being made. -
Page 12: Capture Mode
Capture Mode Capture mode will allow you to shoot single, continuous images, set your flash and self-timer. Depending on the environment and setting, the cam- era’s settings will work accordingly. To exit the setting menu, simply press the menu button. White Balance ISO (100/200) Flash... -
Page 13: Self Timer
• FLASH Setting 1.To set the Flash, press the Five-Way Switch to the Left to select the desired Flash setting. You will have the four types of Flash settings: Flash Off, Auto Red-eye reduction, Flash Force On, and Night. Once you’ve set your Flash setting, proceed with your picture taking. -
Page 14: Capture Mode Setup
Capture Mode Setup To enter/exit Capture Mode Setup, press the menu button. Once you are in the Capture Mode Setup, you will be able to adjust the follow- ing settings. To select each individual function settings, press the UP or DOWN arrow. Function Resolution Image Quality... - Page 15 White Balance Sharpness EV Adjust Scene Users can select the fol- lowing white balance: Auto (Default) Shade Tungsten Fluorescent Users can select the fol- lowing sharpness: Normal (Default) High Users can select the fol- lowing EV adjust: from EV+2.0~ toEV -2.0, in EV 0.5 step increase Users can select the fol- lowing scene:...
-
Page 16: Playback Mode
Resolution (with 16 MB SD Card) 2720 x 2040 (5.5M) 2304 x 1728 (4.0M) 1600 x 1200 (2.0M) 1280 x 960 (1.3M) 640 x 480 (VGA) Playback Mode This mode will allow you to replay/view your images or video. It can also protect your desired images, set DPOF, slide show and voice memo. -
Page 17: Displaying Thumbnails
• Displaying Thumbnails Turn the Mode Dial to Playback Mode. Press the display button twice to activate thumbnails in sets of nine. Use the Five-Way Switch to change the image selection. Press OK button to magnify images to standard size. Press the left or right button to view other images. -
Page 18: Macro Mode
Digital Print Order Users can select from: Format or DPOF Frame Set Reset all Voice Memo You are allowed 20 sec- onds to record voice memo. Users can select from: Record Erase Play Macro Mode Macro mode is best used for taking close-up images with franges from 15-50 cm. -
Page 19: Dsc Setup Mode
DSC SETUP MODE Under this mode, you will be able to set your desired settings. There are a total of eight different settings. Languages Auto Power Off Date and Time Slide Show Order Turn the mode dial to enter the DSC Setup Mode. Select the type of setup you want to perform by pushing the left or right button. - Page 20 Slide Show Users can select the: Interval Repeat Direction Sound Effect Users can select either on or off Languages Users can select from the following languages: Deutsch English French Italian Japanese Korean Spanish Simplified Chinese Traditional Chinese TV-Out Users can select from: NTSC Five Main Camera Modes and Instructions Under this setting, users...
- Page 21 Restoring Reset back to default. To revert the setting back to the default setting. Press the OK if you want to, if not, press the “right” or “left” button to con- tinue next setting. When restoring is completed, "done" will appear on the LCD.
-
Page 22: Making Connections
Installing software Insert the CD-ROM into your CD-ROM drive. Click “Digital Camera Driver” and Install if your operating system is Windows 98. Users can pick 4 selections and press Install (it can all be done at the same time). Driver is for uploading pictures to you computer, if the operation system is Win 98 The installation wizard will guide you through the installation. - Page 23 A. Editing with ArcSoft Turn the computer ON. Connect the camera and the computer with the USB port cable. Turn the camera ON. Launch Photo Impression (the inclusive software which you have downloaded from the CD-ROM.) Select "from folder", you can find your camera as a new disk to upload your images to edit.
-
Page 24: Connecting Through Tv-Out Via Docking Station (Optional)
Connecting through TV-out via docking station (optional) Before you proceed, please determine your corresponding TV-Out mode. This camera will allow you to achieve full camera functions by TV-out connec- tion. The user can operate each function through the TV monitor instead of the LCD display. -
Page 25: Appendix
APPENDIX Specifications Features Effective pixels Removable storage card Internal memory Estimated number of storable pictures Video mode display Lens Focus/ Shooting dis- tance Digital zoom View finder Flash mode Content 4.23M sensor, scale up to 5.5M SD/MMC 16MB NAND Flash Memory Compression ratio@ 1 : 8, 16MB SD card 5.5M: 8 pictures... - Page 26 LCD monitor Camera Interface Multiple language UI Compatible Battery Battery Level AC Adapter (optional) Docking interface (Optional) Dimension (WxHxD) Weight System requirements Windows Macintosh 1.6" TFT LCD, 80,000 pixel and above Mini USB/DC-in English/French/German/Italian/Spanish/ Japanese/Traditional and Simplified Chi- nese/ Korean Li-ion battery High/ Middle/ Low/ Empty 5 V 2A...
- Page 27 Rollei and the logo are registered trademarks or tradem arks of Rollei Fototechnic GmbH in the Unit ed States and/or other countries. Microsoft and W indows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
