  • Page 1 3.3 MegaPixels DSC User Manual - English...

  • Page 2: Table Of Contents

    Safety Precautions Specifications Name of Parts Before Using the Camera 1. Preparation ○ Powering the Camera Storage Media ○ 2. Recording ○ Basic Recording Other Advanced Menu Functions 3. Playback / Delete Basic Playback ○ Various Playback Functions Deleting Files ○...

  • Page 3: Safety Precautions

    Safety Precautions Danger Do not attempt to disassemble, repair or alter the equipment yourself. The high-voltage circuitry in the equipment poses significant electrical hazard. Do not attempt to disassemble, alter or directly solder the battery. Do not put the battery in a fire, attempt to heat it, uses it in high temperature environment such as next to a fire or inside a car.

  • Page 4: Specifications

    General Video Signal Protocol Power Source Dimensions (WxHxD) Weight Operating Conditions Storage Temperature Memory Media Internal Memory Memory Card Specification NTSC / PAL Rechargeable Lithium-Ion Battery 3.7V / AC Adapter 5V 116.7 x 53.8 x 29.5 mm (4.5” x 2.1” x 11.6) Approx.
  • Page 5 Camera 1/2.7 inch 3.34 mega pixels Lens Zoom Lens F2.8 ~ 3.8 Focal Length f = 5.9 ~ 11.8 mm (equivalent to 38 ~ 76 mm in 35 mm format ) Shooting Range General: Approx. 14 cm (5.5”) (at Wide) Approx.

  • Page 6: Name Of Parts

    Camera a. Front b. Back Card Cover Card Cover Switch Names of Parts Shutter Release Flash Power Sensor Switch Battery Recharging and Self-Timer LED Flash Lens Wrist Strap Eyelet Power Supply USB Terminal Terminal DC Input Battery Cover...

  • Page 7: Main Switch

    Operating Parts PIC Button Vedio Out LCD Monitor Main Switch The camera offers a number of modes for recording and playback. The mode dial is used to select the desired mode. Mode Dial Mode Name Set up mode SET UP Playback mode Still Picture mode Button...

  • Page 8: Icon Display

    Continuous Shooting mode Motion Picture 4-way Button For Up / Down / Left / Right and Zoom Function. Left MENU / ENTER Button Display Menu and various modes. Button Icon Display Icon Display Blinking Picture are recorded continuously while the shutter release button is pressed.

  • Page 9: Display Button

    PIC Button The camera offers six image quality modes: 2848 x 2136N, 2048 x 1536NC, 2048 x 1536F, 2048 x 1536N, 1600 x 1200N, and 1280 x 960. The default is 2048 x 1536N. 2848 x 2136N used for taking pictures with higher image quality.

  • Page 10: Before Using The Camera

    Before using the camera Attaching the Wrist Strap Attach the wrist strap to the camera. Pass the end of the strap through the wrist strap eyelet on the camera. Setting the Date and Time 1. Set the mode dial to [ SET UP ]. 2.

  • Page 11: Preparation

    1. Preparation Powering the Camera Loading the Battery 1. Check that the camera is turned off and slide the battery cover open. 2. Load the battery and close the battery cover. Charging the battery 1. Turn off the camera power. 2.

  • Page 12: Storage Media

    Storage Media This camera uses Internal Memory and Secure Digital (SD) Card as storage media to record data. Internal Memory The size of the Internal Memory is 16 MB. Secure Digital Memory Card Insert the SD Memory Card 1. Check that the camera is turned off. 2.

  • Page 13: Sd Memory Card

    Formatting the Internal Memory and SD Memory Card 1. Set the mode dial to [ SET UP ]. 2. Press the button to select [ FORMAT ] and press the RIGHT button. 3. Press the button to select [ CARD ] or [ Internal ] and press the [ ENTER ] button.

  • Page 14: Recording

    2. Recording Basic Recording 1. Turn on the camera. Slide the power switch to turn on the camera. 2. Set the mode dial to [ 3. Select the PIC (image quality) mode. Press the PIC button to select the image quality mode. In Continuous Mode, Image Enlargement Mode and Non-com pressed Mode can not be PIC button does not work to Motion Picture Mode.

  • Page 15: Exposure Compensation

    Recording Capacities Mode / PIC Mode 2848 x 2048 x 1536 Still (No. of Images) 1600 x 1200 1280 x 960 Motion Picture (min:sec) Using the Flash 1. Set the mode dial to [ 2. Press the button to select a flash mode. You can choose from four flash mode: Flash Off, Auto, Forced Flash, and Slow Synchro.

  • Page 16: White Balance

    2. Check that has been selected and press ENTER button. 3. Press button to select the compensation level and press ENTER button. 4. Press shutter release button. White Balance : The white balance can be adjusted so that images can be recorded in natural colors no matter what light source the subject is exposed.

  • Page 17: Other Advanced Menu Functions

    Other Advance Menu Functions In MENU, user can set the following functions: Focus: can be set in Still, Continuous, and Motion Picture Mode Date Imprint: can be set in Still and Continuous Mode ISO: can be set in Still and Continuous Mode Red-eye Reduction: can be only set in Still Mode Time Exposure: can be only set in Still Mode Methods to set...

  • Page 18: Playback / Delete

    3. Playback / Delete Basic Playback Playing Still Picture / Continuous Files 1. Set the mode dial to [ 2. Press button to select the file to be played back. Press button to display the previous file and file. If keep the button pressed, the file will advance continuously. Playing a Motion Picture File 1.
  • Page 19 Playing File on a TV Connecting 1. Make sure the camera is turned off. 2. Open the Video Out Terminal cover and connect the Video Out Cable to the terminal. 3. Connect the other end of the Video Out Cable to the Video-In Terminal of the TV.

  • Page 20: Various Playback Functions

    Various Playback Functions Thumbnail Playback This function enables user to play 9-file at once for quick searching. 1. Set the mode dial to [ 2. Press button to select The screen will change to the thumbnail display. 100-0005 2002/07/15 11:25 3.

  • Page 21: Protecting A File

    To move the display position Press DISPLAY button, than use position displayed. Press DISPLAY button again to return to the zoom playback screen. 4. Press CANCEL button. The screen will return to the normal playback screen. Protecting a File This function enables the user to protect important files. Protecting / Unprotecting a Single File or All Files 1.

  • Page 22: Playback Mode

    Other Advance Functions under [ MENU ] in Playback Mode Auto Playback This function allows user to select playback time (1 SEC. 3 SEC. 5 SEC. 10 SEC. or 30 SEC.) to play all files automatically. 1. Set the mode dial to [ the MENU button.
  • Page 23 Specifying the Number of Prints 1. Press button to select [ ALL ] or [ ONE FILE ] and press ENTER button. Specify the number of prints. In case of [ ALL ], press to specify the number of prints and press ENTER button.
  • Page 24 2. Press ENTER button to complete the setting. Press CANCEL button to exit the operation. Canceling the DPOF Setting 1. Select [ STND ] or [ INDEX ] and press ENTER button. DPOF STND PRINTS INDEX PRINTS CANCEL DPOF CONFIRM SELECT: BACK:CANCEL 2.

  • Page 25: Deleting Files

    Deleting Files This section explains how to delete recorded files. Deleting a Single File 1. Set the mode dial to [ 2. Press button to select the file you want to delete and press MENU button. 3. Check that [ ] has been selected and press ENTER button.

  • Page 26: Changing The Camera Settings

    Changing the Camera Settings This section explains how to change the camera settings: 1.Turn the mode dial to [ SET UP ]. The set up menu displays. 2.Press change the setting. 3.Press button to enter the camera setting and make decision. 4.Press ENTER to complete the setting.

  • Page 27: Digital Zoom

    Focus ISO Setting DIGITAL ZOOM Set it to ON to enable the digital zoom function. Note If Digital Zoom function does not be actived, the Tele and Wide button only for Optical Zoom control. After you active the Digital Zoom function, when you set to the end of Tele of the Optical Zoom, the Digital Zoom bar will appear in 2 seconds if keep pressing the Tele key.

  • Page 28: Date Setting

    This function enables you to set whether sequential numbers are automatically assigned to files. Set to ON: The camera remembers the last file name assigned and even when a new memory card is inserted, numbers are assigned in sequence to subsequent files. Set to OFF: When a new memory card is inserted, files name are assigned in sequence from 0001.

  • Page 29: Transferring Your Image To The Computer

    file size is bigger than the memory space of the Memory Card and no copy action will be taken. Please make sure there is sufficient memory in card to copy all files. STORAGE (Selecting a Recording Destination) This function allows you to select whether to record shot files in Internal Memory or on the Secure Digital Memory Card.

  • Page 30: Video Capture

    Note If use the Mass Storage Function, the mode dial must turn to “ PLAY “. Attention If you disconnect the cable before close the Mass Storage, the Storage Destination (the hard disk) will be damaged. Video Capture Driver Installation The steps are as below: 1.

  • Page 31: Warning Message

    Warning Message If the warning message is displayed on the LCD monitor, follow the procedures below. Message NO CARD FORMAT CARD CARD ERROR CARD PROTECTED INSUFFICIENT MEMORY CANNOT RECORD MOVIE FILE PROTECTED UNMATCHED FILE FILE NUMBER OVER NO FILE Important : 1.
