Summary of Contents for Keychron K11 Pro

  • Page 1 K11 Pro Bluetooth Mechanical Keyboard...
  • Page 2 IN THE BOX: Keychron K11 Pro Bluetooth Mechanical Keyboard x 1 Type-C Cable x 1 Manual x 1 Quick Start Guide x 1 Extra Keycaps Set x 1...
  • Page 3 QUICK START GUIDE If you are a Windows user, please find the appropriate keycaps in the box, then follow the instructions below to find and replace the following keycaps. Mac / Windows...
  • Page 4 Connect Bluetooth Press fn1 + Q (for 4 seconds) and pair with device named Keychron K11 Pro. Bluetooth fn1 + Q Connect Cable Bluetooth...
  • Page 5 The VIA Key Remapping Software Please visit caniusevia.com to download the latest VIA software to remap the keys. If the VIA software cannot recognize your keyboard, please reach out to our support to get the instruction. (VIA only works when Your keyboard’s best friend the keyboard is connected by wire to the computer.) The Layers...
  • Page 6 Multimedia Key and Function Key Multimedia keys Function keys In order to get Multimedia Key, you need to press fn1 and Key. In order to get Function Key, you need to press fn2 and Key. The Backlight Press fn1 + A to change the lighting effect Press fn1 + caps lock to turn the backlight on/off fn1 + A fn1 + caps lock...
  • Page 7 Adjust The Backlight Brightness Press fn1 + S to increase the backlight brightness Press fn1 + X to decrease the backlight brightness fn1 + S fn1 + X Warranty The keyboard is highly customizable and easy to be rebuilt. If anything goes wrong with any of the keyboard components of keyboard during the warranty period, we will only replace the defective parts of the keyboard, not the whole keyboard.
  • Page 8 Watch The Building Tutorial On Our Website If you are building the keyboard for the first time, we highly recommend you watch the building tutorial video on our website first, then start building the keyboard yourself. Factory Reset Troubleshooting? Don’t know what’s going on with the keyboard? ①...
  • Page 9 Charging port: USB Type-C Mode: Bluetooth / Wired Bluetooth operating distance: Within 10 meters (open space) Name of Bluetooth device: Keychron K11 Pro Operating environment: -10 to 50°C Technical specifications can be subjected to change without notice, we apologize for any...
  • Page 10 K11 PRO BLUETOOTH MECHANICAL KEYBOARD OVERVIEW ① ② ③ ④ Windows ① Bluetooth Indicator ② Win/Android Mac/iOS (OS Toggle Switch) ③ BT OFF Cable (Mode Toggle Switch) ④ Charging Port...
  • Page 11 DEFAULT KEY LAYOUT: LAYER 0: This layer will be activated when your keyboard’s system toggle is switched to Mac. Left Option...
  • Page 12 LAYER 1: This layer will be activated when your keyboard’s system toggle is switched to Windows. LWin LWin = Left Windows LAlt = Left Alt RAlt = Right Alt...
  • Page 13 LAYER 2: This layer will be activated when your keyboard’s system toggle is switched to Mac and press the fn1/MO(2) key. Scr+ Vol- Scr- Vol+ BTH1 PgUp Home PgDn Toggle...
  • Page 14 LAYER 3: This layer will be activated when your keyboard’s system toggle is switched to Windows and press the fn1/MO(3) key. Scr+ Vol- Scr- Vol+ BTH1 PgUp Home PgDn Toggle...
  • Page 15 LAYER 4: This layer will be activated when you press the fn2/MO(4) key.
  • Page 16: Key Description

    KEY DESCRIPTION Key Description Key Description Scr- Screen Brightness Decrease RGBMd- RGB Mode Previous Scr+ Screen Brightness Increase Hue+ Hue Increase Bright- Backlight Decrease Hue- Hue Decrease Bright+ Backlight Increase RGB SPI RGB Speed Increase Prvs Previous RGB SPD RGB Speed Decrease Layer 1 will be activated Play Play/Pause...
  • Page 17: Led Status Overview

    Fully charged in around 3 hours, a green battery indicator will appear. *The Keychron keyboard is compatible with all USB ports. Please use a 5V 1A adapter or USB 3.0 for the best performance. The Keychron K11 Pro can be charged in Bluetooth/on/off mode.
  • Page 18: Wired Mode

    3. Hold “fn1+Q” key for 4 seconds to activate Bluetooth pairing (the Bluetooth indicator fast flashes for 3 minutes to detect pairing). 4. Search for the Bluetooth device “Keychron K11 Pro” on your device and connect it (the Bluetooth indicator goes off after successful pairing).
  • Page 19: Backlight Setting

    RECONNECT: 1. Switch the keyboard to the Bluetooth option to activate the keyboard. 2. The Bluetooth indicator flashes for 4 seconds and automatically pairs with the last paired device. 3. If the Bluetooth indicator is off, press any button to enter the connection again. * The keyboard must have been paired with the device to perform this function.
  • Page 20 3 — INPUT METHOD SWITCH...
  • Page 21 My keyboard isn’t working. For the computer/smartphone: Go to your device Bluetooth settings>Select the keyboard and remove/delete/unpair it. Then restart your device. For the keyboard: Turn the keyboard off and back on. Then reconnect it to your device. Bluetooth connection is interrupted even within 10 meters. Check if the keyboard is resting on a metal surface that can interfere with the Bluetooth signal.
  • Page 22 Safety Precaution: Keep the product, accessories and packaging parts out of the reach of children to prevent any accidents and choking hazards. Always keep the product dry to avoid corrosion. Do not expose the product to extreme temperatures below -10°C(5°F) or above 50°C(131°F) to preserve the lifespan of the keyboard.
  • Page 23 K11 Pro 蓝牙机械键盘...
  • Page 24 内容清单 Keychron K11 Pro 蓝牙机械键盘 x 1 USB线 x 1 拔键器 x 1 赠送键帽套装 x 1 说明书 x 1 快速上手指南 x 1...
  • Page 25 快速上手指南 如果你是Windows用户, 请在包装盒里找到如下的键帽, 用拔键器拔下键盘上的对应键帽并且更换。 Mac / Windows...
  • Page 26 连接蓝牙 长按fn1+Q四秒使键盘进入配对模式, 键盘的配对名为: Keychron K11 Pro。 把开关拨到蓝牙模式 Bluetooth fn1 + Q 连接有线 把开关拨到有线模式 Bluetooth...
  • Page 27 关于VIA映射软件 可以访问caniusevia.com 下载最新的VIA软件, VIA是可以映射按键的软件。 如果VIA软件不能识别你的键盘, 请联系我们以获得技术支持。 (VIA 仅在键盘通过线连接到计算机时有效。 ) 关于键盘键层说明 键盘有五层按键设置。 层0是用于Mac系统, 如果您的系统拨片切换到Mac档位, 如果您的系统拨片切换到Win档位, 层1是用于Windows系统, 层0将被激活。 层1将被激活。 层2是用于Mac系统多媒体, 层3是用于Windows系统多媒体, 层4是用于功能键。...
  • Page 28 多媒体键和功能键 多媒体键 功能键 按击 fn1 和 就能得到多媒体键。 按击 fn2 和 就能得到功能键。 更改键盘背光模式以及快速关闭/开启键盘背光 组合fn1+A键, 更改键盘背光模式。 组合fn1+caps lock键, 可快速关闭/开启键盘背光。 fn1 + A fn1 + caps lock...
  • Page 29 调整键盘背光亮度 组合fn1+S键, 提高键盘背光亮度。 组合fn1+X键, 减少键盘背光亮度。 fn1 + S fn1 + X 保修 由于K11 Pro客制化键盘是可高度定制且易于组装的, 所以键盘的任何一个部件出了问题, 我们只会更换键盘有问题的部件而不是整个键盘。...
  • Page 30 键盘组装教程 如果您没有安装过类似产品的经验, 我们建议您观看我们网站上的键盘组装教程视频, 然后再开始进行键盘组装。 恢复出厂模式 如果键盘出现了故障, 不知道怎么办? 1. 将数据线插入键盘, 并将键盘拨动到Cable模式。 2. 依照顺序长按fn2+J+Z (等待四秒) ; 3. 从我们的网站为您的键盘下载正确的固件和QMK工具箱; 4. 将键盘拨动到OFF模式, 拔掉空格键键帽, 然后找到位于PCB上面的 复位按钮; 5. 首先长按住复位键, 然后将键盘拨动到Cable模式。 放开这个复位键, 此时键盘会进入DFU模式; 6. 然后您可以使用QMK工具箱进行刷新固件的操作; 7. 再次将键盘恢复出厂设置长按fn2+J+Z (等待四秒) 。 * 步骤指南可以在我们的网站上找到。...
  • Page 31 K11 PRO 键盘概述 ① ② ③ ④ Windows ① 蓝牙指示灯 ② Win/Android Mac/iOS (OS切换开关) ③ BT OFF Cable (连接模式切换开关) ④ 充电口...
  • Page 32 K11 PRO 键盘规格 按键: 68键 轴: 机械轴 电池: 2000mAh 充电时间: 3小时 充电端口: USB Type-C 模式: 蓝牙 / 有线 蓝牙工作距离: 最长10米 (开放空间) 蓝牙设备名称: Keychron K11 Pro 功能说明 LED状态显示如下: 功能 LED位置 状态 低电量—红灯闪烁 充电—红灯长亮 充电 电源指示灯 满电—绿灯 快闪—切换 蓝牙 蓝牙指示灯 熄灭—连接成功 慢闪—配对...
  • Page 33 按键布局 层0: 当您的系统拨片切换到Mac档位的时候, 层0将被激活使用。 Left Option...
  • Page 34 层1: 当您的系统拨片切换到Windows档位的时候, 层1将被激活使用。 LWin LWin = Left Windows LAlt = Left Alt RAlt = Right Alt 层2: 当您的系统拨片切换到Mac档位并组合fn1/MO(2)键的时候, 层2将被激活使用。 Scr+ Vol- Scr- Vol+ BTH1 PgUp Home PgDn Toggle...
  • Page 35 层3: 当您的系统拨片切换到Windows档位并组合fn1/MO(3)键的时候, 层3将被激活使用。 Scr+ Vol- Scr- Vol+ BTH1 PgUp Home PgDn Toggle 层4: 当您长按fn2/MO(4)键的时候, 层4将被激活使用。...
  • Page 36 K11 PRO 客制化键盘多媒体按键说明 BTH1 蓝牙连接设备 1 BTH2 蓝牙连接设备 2 蓝牙连接设备 3 BTH3...
  • Page 37 3. 键盘背光灯将打开。 * 在有线模式下, 键盘不会自动进入省电模式。 蓝牙模式 1. 将键盘 “模式切换” 拨动到 BT 位置。 2. 键盘背光灯将打开。 3. 长按 “fn1+Q” 键4秒激活蓝牙配对 (蓝牙指示灯闪烁3分钟) 。 4. 在你的装置上搜索蓝牙装置 “Keychron K11 Pro” 并连接它 (配对成功后蓝牙指示灯熄灭) 。 注意: 此键盘支持通过组合键 “fn1+Q” / “fn1+W” / “fn1+E” 依次配对最多3台设备。 * 因蓝牙版本较多等原因, 初次连接可能出现连接缓慢或连接失败等问题, 请耐心检查设备设置是否正确。...
  • Page 38 切换至蓝牙装置 短按组合键 “fn1+Q” / “fn1+W” / “fn1+E” 切换到其他装置。 *切换过程可能会因切换频繁或切换速度过快, 导致延迟, 此时请耐心等待或重新切换。 回连 1. 将键盘切换到Bluetooth位置启动键盘。 2. 蓝牙指示灯快闪4秒, 自动配对上一次配对的设备。 3. 如蓝牙指示灯熄灭, 可按任何按键再次进入回连状态。 * 键盘必须曾经配对该装置才能实现此功能。 关闭键盘 将 “模式切换” 拨至OFF, 此时本产品关闭所有模式, 但可以进行正常充电。 系统切换 1 — MacOS / iOS 连接到Mac或iOS操作系统时, 请将键盘上方系统开关拨至Mac/iOS。 2 — WINDOWS / 安卓 当键盘连接到...
  • Page 39 疑难排解 我无法将键盘与我的装置配对。 答: 确认您要配对的装置可使用蓝牙。 重新启动装置并尝试再次与键盘配对。 注意: 在Windows计算机上, 新的蓝牙连接有时需要额外的软件更新 - 在出现表示成功完成的消息后, 该过程可能仍在进行中。 配对 后至少等待20分钟, 以确保在重新启动计算机之前完成所有更新。 确认装置配置可接受蓝牙连接 (Windows) 并支持外部键盘 (HID配置文件) 。 转到蓝牙装置>打开设置, 然后选择以下复选框: 允许蓝牙装置找到这台电脑 允许蓝牙装置连接到这台电脑 当蓝牙装置想要连接时提醒我 我的键盘无法使用。 答: 请打开您的电脑/智能手机上的蓝牙设置>选择键盘并删除此设备/取消配对, 然后重启您的设备; 关闭并重新打开键盘, 然后重新连接到您的装置。 蓝牙连接或在10米内受干扰。 答: 检查键盘是否放在可能干扰蓝牙信号的金属表面上。 第三方输入工具与键盘不兼容 答: 由于Windows / Android 系统的兼容性、 版本、 品牌和驱动程序, 第三方输入工具在使用键盘时或被影响。 请确保你的作业系统 和驱动程序为最新版本。...
  • Page 40 注意事项: 请勿将本产品, 其配件和包装部件放在儿童接触到的地方, 以防发生意外引致窒息。 请保持产品干燥, 以免腐蚀。 请勿将产品暴露在低于-10°C (5°F) 或高于50°C (131°F) 的极端温度下, 以维持键盘或电池的使用寿命。...
