80 V CORDLESS SNOW SHOVEL
Purchase Date
1
ITEM
#0533632
MODEL #KSS 1280B-06
Español p. 19
Advertisement
Table of Contents
Related Manuals for Kobalt KSS 1280B-06
Summary of Contents for Kobalt KSS 1280B-06
- Page 1 ITEM #0533632 80 V CORDLESS SNOW SHOVEL MODEL #KSS 1280B-06 Español p. 19 ATTACH YOUR RECEIPT HERE Purchase Date Serial Number Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications......................2 Package Contents........................3 Symbols..........................5 Safety Information ......................6 Preparation ........................... 9 Assembly Instructions ......................9 Operating Instructions ....................... 11 Care and Maintenance......................13 Troubleshooting........................16 Warranty ..........................17 Replacement Parts List...................... 18 PRODUCT SPECIFICATIONS SPECIFICATIONS Type Cordless, battery-operated Motor 80 V brushless motor... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Upper Handle Assembly Lower Handle Assembly... - Page 4 HARDWARE CONTENTS (not shown actual size) Fastening Knob Screws Bolt (preassembled) Qty. 1 Qty. 1 Qty. 4...
-
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their mean- ing. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz... -
Page 6: Safety Information
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not DANGER avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which, if not WARNING avoided, could result in death or serious injury. - Page 7 • Thoroughly inspect the area where the equipment is to be used and remove all stones, sticks, wires, bones, and other foreign objects. • Stop the blade(s) when crossing gravel drives, walks, or roads. • Use only 80-volt Kobalt batteries.
- Page 8 SAFETY INFORMATION GENERAL SAFETY RULES • Verify that the power tool is secure while transporting. • Store the power tool in a dry area that will prevent unauthorized use or damage. Keep out of the reach of children. • Keep handles dry, clean, and free of debris. Clean the power tool after each use. Refer to the Maintenance Section in this manual for more information.
-
Page 9: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 5 minutes ASSEMBLY INSTRUCTIONS WARNING To prevent accidental starting that could cause serious personal injury, always remove the battery... - Page 10 ASSEMBLY INSTRUCTIONS WARNING Follow these instructions in order to avoid injury and to reduce the risk of electric shock or fire: • Replace the battery pack or the charger immediately if the battery case or charger cord is damaged. • Verify that the switch is in the OFF position before inserting or removing the battery pack. •...
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS 1. ADJUSTING THE AUXILIARY HANDLE POSITION • Position the front/auxiliary handle (G) onto the upper portion of the shovel section by sliding over the rubber sleeve (H). • Once the front handle is in the desired position, slide the bolt (CC) through the underside of the handle and secure with the fastening knob (AA). - Page 12 OPERATING INSTRUCTIONS 3. STOPPING THE SNOW SHOVEL • Release the trigger switch. • The lock-out button will pop out and the snow shovel will stop. 4. USING THE SNOW SHOVEL • Start the snow shovel by following the starting instructions. The depth and weight of the snow will determine the forward speed.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE 1. TRANSPORTING THE SNOW SHOVEL • Allow the motor to cool down before transporting. • Secure the snow shovel while transporting. • When moving the snow shovel, grasp it by the top handle and auxiliary handle. 2. SCRAPER REPLACEMENT IMPORTANT: Always remove the battery from the tool before performing any maintenance on it. - Page 14 CARE AND MAINTENANCE 3. IMPELLOR REPLACEMENT • Remove the right side • Remove the belt. • Pull the belt tensioner cover by removing 6 (idler arm) away from screws. the drive pulley. Be sure not to lose the washer and screw left. •...
- Page 15 CARE AND MAINTENANCE • Replace and tighten • Replace and tighten the • Replace and tighten the the remaining nut to remaining screws to remaining screws to secure the left side plate secure the left side cover. secure the pulley assembly.
-
Page 16: Troubleshooting
CARE AND MAINTENANCE WARNING In order to avoid personal injury and the risk of fire and electric shock, remove the battery pack before adjusting, inspecting, or cleaning the snow shovel. STORAGE • Allow the motor to cool down before storing. •... -
Page 17: Warranty
WARRANTY 5-YEAR LIMITED WARRANTY This 80 V Lithiuim-Ion snow shovel is warranted to the original purchaser from the original purchase date for five (5) years subject to the warranty coverage described herein. This 80 V Lithiuim-Ion snow shovel is warranted for the original user to be free from defects in material and workmanship.
