EEI – 3333 / 3334

STEP 3:

Insert Stretcher (4) into the upper hole on the bottom of Front Leg (3) and Seat Frame (2) as shown.
Insert 1 piece of Front Leg (3) into the upper hole on the bottom of Seat Frame (2) as shown.
Attach by 2 pieces of Bolt (B), 2 pieces of Spring Washer (D) and 2 piece of Flat Washer (E) as shown.
Repeat the same steps for Front Leg (3).
Do not fully tighten Bolts (B) for either leg.
Left (L)
B x 4 D x 4

STEP 4:

Attach 1 piece of CSK M4 (G) to the Stretcher (4) to Chair Back (1) and Front Leg (3).
Repeat steps to the other side of the Stretcher.
G x 4
Customer Service 908-368-1025︱www.modwayfurniture.com
DINING CHAIR
3
4
3
Right (R)
B
E
D
E x 4
3
4
G
2
1
1
Hardware & Tool required
Hardware & Tool required
