THANK YOU
Thank you purchasing a Vada Flow Boss Wall Mount Accessory Kit!
Follow the steps opposite to set it up quick smart.
SPECIFICATIONS
COMPATIBLE VADA PRODUCTS:
…
Vada Flow Boss
Digital Water
Switching Unit
VFB-DSU
ADDITIONAL PRODUCTS REQUIRED FOR INSTALLATION:
Screwdriver
Wire cutters
…
…
2
VADA FLOW BOSS
WALL MOUNT ACCESSORY KIT VFB-DSU-WM
Wire stripper
…
QUICK START GUIDE
INSTALLATION
Let's get started!
1. Remove all items from packaging.
2. Open the three poli splicing mechanism by
turning the ends clockwise as illustrated.
3. Feed the cable through the open
mechanism.
4. Connect the wiring as indicated below.
L
L
N
N
L=30mm
L=30mm
L=8mm
L=8mm
5. Lock the mechanism by tightening the
screws clockwise.
6. Slide the mechanism up.
1
2
3
