Vision D
W480 VISION D
User's Manual
Rev. 1001
12ME-W48VSD-1001R
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product are
recyclable and reusable. GIGABYTE works with you to protect the environment.
o cerca il tuo prodotto tra le
migliori offerte di Schede Madri
Gigabyte W480

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte W480 VISION D

Summary of Contents for Gigabyte W480 VISION D

  • Page 1 W480 VISION D User's Manual Rev. 1001 12ME-W48VSD-1001R For more product details, please visit GIGABYTE's website. To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
  • Page 2 GIGABYTE's prior written permission. Documentation Classifications In order to assist in the use of this product, GIGABYTE provides the following types of docu- mentations: „ For quick set-up of the product, read the Quick Installation Guide included with the product.

  • Page 3: Table Of Contents

    Table of Contents Box Contents ........................5 Optional Items .........................5 W480 VISION D Motherboard Layout ................6 W480 VISION D Motherboard Block Diagram ..............7 Chapter 1 Hardware Installation ..................9 Installation Precautions ................... 9 1-2 Product Specifications ................... 10 Installing the CPU and CPU Cooler............... 14 1-3-1 Installing the CPU ....................14...
  • Page 4 Chapter 4 Drivers Installation ..................81 Drivers & Software ..................81 Application Software ..................82 Information ..................... 82 Chapter 5 Unique Features...................83 BIOS Update Utilities ..................83 5-1-1 Updating the BIOS with the Q-Flash Utility ............83 5-1-2 Updating the BIOS with the @BIOS Utility ............86 5-1-3 Using Q-Flash Plus ....................87 APP Center ....................

  • Page 5: Box Contents

    Box Contents 5 W480 VISION D motherboard 5 Motherboard driver disc 5 User's Manual 5 Quick Installation Guide 5 Four SATA cables 5 One antenna 5 One G Connector 5 Two thermistor cables 5 One RGB LED strip extension cable The box contents above are for reference only and the actual items shall depend on the product package you obtain.

  • Page 6: W480 Vision D Motherboard Layout

    W480 VISION D Motherboard Layout D_LED2 CPU_FAN USB20 LED_C2 ATX_12V_2X2 ATX_12V_2X4 CPU_OPT DP_HDMI LGA1200 TYPEC_1 U32G2_2 Intel ® Thunderbolt ™ TYPEC_2 Controller U32G2_1 U32_LAN2 USB 3.2 Gen 1 Hub U32_LAN1 SYS_FAN1 AUDIO PCIEX16 Intel 2.5GbE LAN ® Intel GbE LAN ®...

  • Page 7: W480 Vision D Motherboard Block Diagram

    W480 VISION D Motherboard Block Diagram PCI Express 3.0 Bus CPU CLK+/- (100~500 MHz) Switch DDR4 2933/2666/2400/2133 MHz LGA1200 CPU 1 DisplayPort IN HDMI 1.4 BIOS 1 M.2 Socket 3 (M2A_CPU) Switch 1 PCI Express 2 PCI Express 2 SATA 6Gb/s (SATA3 0, 1) PCI Express 3.0 Bus 1 M.2 Socket 3 (M2M_SB)
  • Page 8 - 8 -...

  • Page 9: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: • Prior to installation, make sure the chassis is suitable for the motherboard. •...

  • Page 10: Product Specifications

    Xeon processor. ® Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Š Support for Extreme Memory Profile (XMP) memory modules Š (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) Onboard Integrated Graphics Processor+Intel Thunderbolt 3 Controller: ®...
  • Page 11 Expansion Slots Š 1 x PCI Express x16 slot, running at x16 (PCIEX16) * F or optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot, running at x8 (PCIEX8) Š * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
  • Page 12 Internal 2 x RGB LED strip headers Š Connectors 3 x M.2 Socket 3 connectors Š 6 x SATA 6Gb/s connectors Š 1 x front panel header Š 1 x front panel audio header Š 1 x USB Type-C header, with USB 3.2 Gen 2 support ™...
  • Page 13 System ATX Form Factor; 30.5cm x 24.4cm Form Factor Š * GIGABYTE reserves the right to make any changes to the product specifications and product-related information without prior notice. Please visit GIGABYTE's website Please visit the Support\Utility List for support lists of CPU, memory page on GIGABYTE's website to modules, SSDs, and M.2 devices.

  • Page 14: Installing The Cpu And Cpu Cooler

    Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. (Go to GIGABYTE's website for the latest CPU support list.) • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.
  • Page 15 B. Follow the steps below to correctly install the CPU into the motherboard CPU socket. • Before installing the CPU, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the CPU. •...

  • Page 16: Installing The Cpu Cooler

    1-3-2 Installing the CPU Cooler Refer to the steps below to correctly install the CPU cooler on the motherboard. (Actual installation process may differ depending the CPU cooler to be used. Refer to the user's manual for your CPU cooler.) Male Push Pin Direction of the Arrow Sign on the Male Push Pin The Top of Female Push Pin Female Push Pin Step 1: Step 2: Apply an even and thin layer of thermal grease on Before installing the cooler, note the direction of the the surface of the installed CPU.

  • Page 17: Installing The Memory

    • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) • Always turn off the computer and unplug the power cord from the power outlet before installing the memory to prevent hardware damage.

  • Page 18: Installing A Memory

    1-4-2 Installing a Memory Before installing a memory module, make sure to turn off the computer and unplug the power cord from the power outlet to prevent damage to the memory module. DDR4 and DDR3 DIMMs are not compatible to each other or DDR2 DIMMs. Be sure to install DDR4 DIMMs on this motherboard. Notch DDR4 DIMM A DDR4 memory module has a notch, so it can only fit in one direction. Follow the steps below to correctly install...

  • Page 19: Installing An Expansion Card

    Installing an Expansion Card Read the following guidelines before you begin to install an expansion card: • Make sure the motherboard supports the expansion card. Carefully read the manual that came with your expansion card. • Always turn off the computer and unplug the power cord from the power outlet before installing an expansion card to prevent hardware damage.

  • Page 20: Setting Up Amd Crossfire ™ Configuration

    Setting up AMD CrossFire Configuration ™ A. System Requirements - Windows 10 64-bit operating system - A CrossFire-supported motherboard with two PCI Express x16 slots and correct driver - CrossFire-ready graphics cards of identical brand and chip and correct driver - CrossFire bridge connector(s) (Note)

  • Page 21: Back Panel Connectors

    Back Panel Connectors USB 2.0/1.1 Port The USB port supports the USB 2.0/1.1 specification. Use this port for USB devices. USB 2.0/1.1 Port (Q-Flash Plus Port) The USB port supports the USB 2.0/1.1 specification. Use this port for USB devices. Before using Q-Flash Plus , make sure to insert the USB flash drive into this port first.
  • Page 22 Follow the steps below to install the DisplayPort or Thunderbolt devices: ™ Step 2: Step 1: Connect your DisplayPort cable or Mini-DisplayPort Then connect the DisplayPort or Thunderbolt ™ cable (purchased separately) from the graphics devices to Thunderbolt 3 connector to complete. ™...
  • Page 23 Line Out/Front Speaker Out The line out jack. This jack supports audio amplifying function. For better sound quality, it is recommended that you connect your headphone/speaker to this jack (actual effects may vary by the device being used). Mic In/Side Speaker Out The Mic in jack. Audio Jack Configurations: Headphone/ Jack 4-channel 5.1-channel 7.1-channel 2-channel Center/Subwoofer Speaker Out Rear Speaker Out Line In/Side Speaker Out Line Out/Front Speaker Out Mic In/Side Speaker Out •...

  • Page 24: Internal Connectors

    Internal Connectors ATX_12V_2X2/ATX_12V_2X4 F_PANEL F_AUDIO CPU_FAN F_U32C SYS_FAN1/2/3/4 F_U32 SYS_FAN5_PUMP/SYS_FAN6_PUMP F_USB1/F_USB2 CPU_OPT SPI_TPM EC_TEMP1/EC_TEMP2 QFLASH_PLUS D_LED1/D_LED2 CLR_CMOS LED_C1/LED_C2 SATA3 0/1/2/3/4/5 CPU/DRAM/VGA/BOOT M2A_CPU/M2M_SB/M2P_SB Read the following guidelines before connecting external devices: • First make sure your devices are compliant with the connectors you wish to connect. • Before installing the devices, be sure to turn off the devices and your computer. Unplug the power cord from the power outlet to prevent damage to the devices.
  • Page 25 1/2) ATX_12V_2X2/ATX_12V_2X4/ATX (2x2, 2x4, 12V Power Connectors and 2x12 Main Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, first make sure the power supply is turned off and all devices are properly installed.
  • Page 26 3/4) CPU_FAN/SYS_FAN1/2/3/4 (Fan Headers) All fan headers on this motherboard are 4-pin. Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire). The speed control function requires the use of a fan with fan speed control design. For optimum heat dissipation, it is recommended that a system fan be installed inside the chassis.
  • Page 27 6) CPU_OPT (Water Cooling CPU Fan Header) The fan header is 4-pin and possesses a foolproof insertion design. Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation (the black connector wire is the ground wire).
  • Page 28 8) D_LED1/D_LED2 (Addressable LED Strip Headers) The headers can be used to connect a standard 5050 addressable LED strip, with maximum power rating of 5A (5V) and maximum number of 1000 LEDs. Pin No. Definition V (5V) D_LED1 Data No Pin D_LED2 Connect your addressable LED strip to the header.
  • Page 29 S B_ 10) SATA3 0/1/2/3/4/5 (SATA 6Gb/s Connectors) The SATA connectors conform to SATA 6Gb/s standard and are compatible with SATA 3Gb/s and SATA 1.5Gb/s standard. Each SATA connector supports a single SATA device. The Intel Chipset supports RAID 0, RAID 1, ® RAID 5, and RAID 10. Refer to Chapter 3, "Configuring a RAID Set," for instructions on configuring a RAID array. F_USB3 F Pin No. Definition F_USB3 F SATA3 3 5 1 2 4 0 F_USB3 F To enable hot-plugging for the SATA ports, refer to Chapter 2, "BIOS Setup," "Settings\IO Ports\ SATA And RST Configuration," for more information.
  • Page 30 Installation Notices for the PCIEX4, M.2 and SATA Connectors: The availability of the SATA connectors may be affected by the type of device installed in the M.2 sockets. The M2A_CPU connector shares bandwidth with the SATA3 0, 1 connectors. The M2M_SB connector shares bandwidth with the SATA3 4, 5; the M2P_SB connector shares bandwidth with the PCIEX4 connector. Refer to the following tables for details.
  • Page 31 12) F_PANEL (Front Panel Header) Connect the power switch, reset switch, speaker, chassis intrusion switch/sensor and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. Power Switch Speaker Power LED Hard Drive Reset Power LED Activity LED Switch Chassis Intrusion Header...
  • Page 32 13) F_AUDIO (Front Panel Audio Header) The front panel audio header supports High Definition audio (HD). You may connect your chassis front panel audio module to this header. Make sure the wire assignments of the module connector match the pin assignments of the motherboard header. Incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it. Pin No.
  • Page 33 F_USB30 F_ U 15) F_U32 (USB 3.2 Gen 1 Header) The header conforms to USB 3.2 Gen 1 and USB 2.0 specification and can provide two USB ports. For purchasing the optional 3.5" front panel that provides two USB 3.2 Gen 1 ports, please contact the local dealer. Pin No. Definition Pin No. Definition VBUS SSRX1- SSRX1+ B S S SSTX2+ SSTX1- SSTX2-...
  • Page 34 F_USB3 F 17) SPI_TPM (Trusted Platform Module Header) You may connect an SPI TPM (Trusted Platform Module) to this header. Pin No. Definition Data Output Power (3.3V) No Pin Data Input Chip Select S F_ 18) QFLASH_PLUS (Q-Flash Plus Button) Q-Flash Plus allows you to update the BIOS when your system is off (S5 shutdown state).
  • Page 35 19) CLR_CMOS (Clear CMOS Jumper) Use this jumper to clear the BIOS configuration and reset the CMOS values to factory defaults. To clear the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds. Open: Normal Short: Clear CMOS Values • Always turn off your computer and unplug the power cord from the power outlet before clearing the CMOS values.
  • Page 36 21) CPU/DRAM/VGA/BOOT (Status LEDs) The status LEDs show whether the CPU, memory, graphics card, and operating system are working properly after system power-on. If the CPU/DRAM/VGA LED is on, that means the corresponding device F_USB3 F_USB30 3 is not working normally; if the BOOT LED is on, that means you haven't entered the operating system yet. USB 0_ B CPU: CPU status LED DRAM: Memory status LED...

  • Page 37: Chapter 2 Bios Setup

    To access the BIOS Setup program, press the <Delete> key during the POST when the power is turned on. To upgrade the BIOS, use either the GIGABYTE Q-Flash or @BIOS utility. Q-Flash allows the user to quickly and easily upgrade or back up BIOS without entering the operating system.

  • Page 38: Startup Screen

    Startup Screen The following startup Logo screen will appear when the computer boots. Function Keys Function Keys: <DEL>: BIOS SETUP\Q-FLASH Press the <Delete> key to enter BIOS Setup or to access the Q-Flash utility in BIOS Setup. <F12>: BOOT MENU Boot Menu allows you to set the first boot device without entering BIOS Setup. In Boot Menu, use the up arrow key <h>...

  • Page 39: The Main Menu

    The Main Menu Advanced Mode The Advanced Mode provides detailed BIOS settings. You can press the arrow keys on your keyboard to move among the items and press <Enter> to accept or enter a sub-menu. Or you can use your mouse to select the item you want.
  • Page 40 B. Easy Mode Easy Mode allows users to quickly view their current system information or to make adjustments for optimum performance. In Easy Mode, you can use your mouse to move through configuration items or press <F2> to switch to the Advanced Mode screen. BIOS Setup - 40 -...

  • Page 41: Favorites (F11)

    Favorites (F11) Set your frequently used options as your favorites and use the <F11> key to quickly switch to the page where all of your favorite options are located. To add or remove a favorite option, go to its original page and press <Insert>...

  • Page 42: Tweaker

    Tweaker Whether the system will work stably with the overclock/overvoltage settings you made is dependent on your overall system configurations. Incorrectly doing overclock/overvoltage may result in damage to CPU, chipset, or memory and reduce the useful life of these components. This page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results. (Inadequately altering the settings may result in system's failure to boot. If this occurs, clear the CMOS values and reset the board to default values.) &...
  • Page 43 ƒ Advanced CPU Settings & CPU Over Temperature Protection (Note) Allows you to fine-tune the TJ Max offset value. (Default: Auto) & FCLK Frequency for Early Power On Allows you to set the FCLK frequency. Options are: Normal(800Mhz), 1GHz, 400MHz. (Default: 1GHz) & Hyper-Threading Technology Allows you to determine whether to enable multi-threading technology when using an Intel CPU that ® supports this function. This feature only works for operating systems that support multi-processor mode. Auto lets the BIOS automatically configure this setting. (Default: Auto) &...
  • Page 44 & Race To Halt (RTH) /Energy Efficient Turbo (Note) (Note) Enables or disables the CPU power saving related settings. (Default: Auto) & Voltage Optimization Allows you to determine whether to enable voltage optimization to reduce power consumption. (Default: Auto) & Intel(R) Turbo Boost Technology (Note) CPU Turbo Boost technology. Auto lets the BIOS Allows you to determine whether to enable the Intel ®...
  • Page 45 & C6/C7 State Support Allows you to determine whether to let the CPU enter C6/C7 mode in system halt state. When enabled, the CPU core frequency and voltage will be reduced during system halt state to decrease power consumption. The C6/C7 state is a more enhanced power-saving state than C3. Auto lets the BIOS automatically configure this setting. This item is configurable only when C-States Control is set to Enabled. (Default: Auto) & C8 State Support (Note) Allows you to determine whether to let the CPU enter C8 mode in system halt state. When enabled, the CPU core frequency and voltage will be reduced during system halt state to decrease power consumption.
  • Page 46 & Extreme Memory Profile (X.M.P.) (Note) Allows the BIOS to read the SPD data on XMP memory module(s) to enhance memory performance when enabled. Disables this function. (Default) Disabled Uses Profile 1 settings. Profile1 Uses Profile 2 settings. (Note) Profile2 & System Memory Multiplier Allows you to set the system memory multiplier. Auto sets memory multiplier according to memory SPD data.
  • Page 47 S kip memory detection and training in some specific criteria for faster memory Enable Fast Boot boot. Disable Fast Boot Detect and train memory at every single boot. & Realtime Memory Timing Allows you to fine-tune memory timings after the BIOS stage. (Default: Auto) & Memory Enhancement Settings Provides several memory performance enhancement settings: Auto, Relax OC, Enhanced Stability, Normal (basic performance), Enhanced Performance, High Frequency, High Density, and DDR-4500+. (Default: Auto) & Memory Channel Detection Message Allows you to determine whether to show an alert message when the memory is not installed in the optimal memory channel.

  • Page 48: Settings

    Settings ƒ Platform Power & Platform Power Management Enables or disables the Active State Power Management function (ASPM). (Default: Disabled) & PEG ASPM Allows you to configure the ASPM mode for the device connected to the CPU PEG bus. This item is configurable only when Platform Power Management is set to Enabled.
  • Page 49 & Soft-Off by PWR-BTTN Configures the way to turn off the computer in MS-DOS mode using the power button. Press the power button and then the system will be turned off instantly. (Default) Instant-Off Delay 4 Sec. Press and hold the power button for 4 seconds to turn off the system. If the power button is pressed for less than 4 seconds, the system will enter suspend mode.
  • Page 50 ƒ IO Ports & Initial Display Output Specifies the first initiation of the monitor display from the installed PCI Express graphics card or the onboard graphics. Sets the onboard graphics as the first display. (Note) IGFX Sets the graphics card on the PCIEX16 slot as the first display. (Default) PCIe 1 Slot Sets the graphics card on the PCIEX8 slot as the first display. PCIe 2 Slot Sets the graphics card on the PCIEX4 slot as the first display. PCIe 3 Slot & Internal Graphics Enables or disables the onboard graphics function. (Default: Auto) & DVMT Pre-Allocated Allows you to set the onboard graphics memory size. Options are: 32M~512M. (Default: 64M) & DVMT Total Gfx Mem Allows you to allocate the DVMT memory size of the onboard graphics. Options are: 128M, 256M, MAX. (Default: 256M) &...
  • Page 51 & OnBoard LAN Controller (Intel 2.5GbE LAN Chip, LAN2) ® Enables or disables the Intel 2.5GbE LAN function. (Default: Enabled) ® If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to Disabled.
  • Page 52 & IPv4 HTTP Support Enables or disables HTTP boot support for IPv4. This item is configurable only when Network Stack is enabled. (Default: Disabled) & IPv6 PXE Support Enables or disables IPv6 PXE Support. This item is configurable only when Network Stack is enabled. (Default: Disabled) & IPv6 HTTP Support Enables or disables HTTP boot support for IPv6. This item is configurable only when Network Stack is enabled. (Default: Disabled) & PXE boot wait time Allows you to configure how long to wait before you can press <Esc> to abort the PXE boot. & Media detect count Allows you to set the number of times to check the presence of media.
  • Page 53 ƒ Miscellaneous & LEDs in System Power On State Allows you to enable or disable motherboard LED lighting when the system is on. Disables the selected lighting mode when the system is on. Off Enables the selected lighting mode when the system is on. (Default) &...
  • Page 54 ƒ PC Health Status & Reset Case Open Status Keeps or clears the record of previous chassis intrusion status. (Default) Disabled Clears the record of previous chassis intrusion status and the Case Open field will Enabled show "No" at next boot. & Case Open Displays the detection status of the chassis intrusion detection device attached to the motherboard CI header. If the system chassis cover is removed, this field will show "Yes", otherwise it will show "No". To clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings to...
  • Page 55 ƒ Smart Fan 5 & Monitor Allows you to select a target to monitor and to make further adjustment. (Default: CPU FAN) & Fan Speed Control Allows you to determine whether to enable the fan speed control function and adjust the fan speed. Allows the fan to run at different speeds according to the temperature.

  • Page 56: System Info

    System Info. This section provides information on your motherboard model and BIOS version. You can also select the default language used by the BIOS and manually set the system time. & Access Level Displays the current access level depending on the type of password protection used. (If no password is set, the default will display as Administrator.) The Administrator level allows you to make changes to all BIOS settings;...

  • Page 57: Boot

    A password is required for booting the system and for entering the BIOS Setup System program. (Default) & Full Screen LOGO Show Allows you to determine whether to display the GIGABYTE Logo at system startup. Disabled skips the GIGABYTE Logo when the system starts up. (Default: Enabled) & Boot Option Priorities Specifies the overall boot order from the available devices. Removable storage devices that support GPT format will be prefixed with "UEFI:" string on the boot device list. To boot from an operating system that...
  • Page 58 & VGA Support Allows you to select which type of operating system to boot. Auto Enables legacy option ROM only. EFI Driver Enables EFI option ROM. (Default) This item is configurable only when Fast Boot is set to Enabled or Ultra Fast. & USB Support Disable Link All USB devices are disabled before the OS boot process completes. Full Initial All USB devices are functional in the operating system and during the POST.
  • Page 59 & Other PCI devices Allows you to select whether to enable the UEFI or Legacy option ROM for the PCI device controller other than the LAN, storage device, and graphics controllers. Do not launch Disables option ROM. UEFI Enables UEFI option ROM only. (Default) Enables legacy option ROM only. Legacy This item is configurable only when CSM Support is set to Enabled. & Administrator Password Allows you to configure an administrator password. Press <Enter> on this item, type the password, and then press <Enter>. You will be requested to confirm the password. Type the password again and press <Enter>. You must enter the administrator password (or user password) at system startup and when entering BIOS Setup.

  • Page 60: Save & Exit

    Save & Exit & Save & Exit Setup Press <Enter> on this item and select Yes. This saves the changes to the CMOS and exits the BIOS Setup program. Select No or press <Esc> to return to the BIOS Setup Main Menu. &...

  • Page 61: Chapter 3 Configuring A Raid Set

    Chapter 3 Configuring a RAID Set RAID Levels RAID 0 RAID 1 RAID 5 RAID 10 Minimum Number of Hard ≥2 ≥3 Drives Array Capacity Number of hard Size of the smallest (Number of hard (Number of hard drives * Size of the drive drives -1) * Size of drives/2) * Size of the smallest drive the smallest drive smallest drive Fault Tolerance To create a RAID set, follow the steps below:...
  • Page 62 B. Configuring SATA controller mode in BIOS Setup Make sure to configure the SATA controller mode correctly in system BIOS Setup. Step 1: Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test). Go to Settings\IO Ports\SATA And RST Configuration, make sure SATA Controller(s) is enabled. To create RAID, set SATA Mode Selection to Intel RST Premium With Intel Optane System Acceleration. Then save the settings and restart your computer.
  • Page 63 C-1. Using EZ RAID GIGABYTE motherboards provide you with the EZ RAID feature, allowing you to quickly configure a RAID array with simplified steps. Step 1: After restarting the computer, enter the BIOS Setup and go to Settings. Press <Enter> on the EZ RAID item. Select the type of hard drives you use for RAID in the Type tab and then press <Enter>. (Figure 2) Figure 2 Step 2: Go to the Mode tab to select a RAID level. RAID levels supported include RAID 0, RAID 1, RAID 10, and RAID 5 (the selections available depend on the number of the hard drives being installed).
  • Page 64 After completing, you'll be brought back to the Intel(R) Rapid Storage Technology screen. Under RAID Volumes you can see the new RAID volume. To see more detailed information, press <Enter> on the volume to check for information on RAID level, stripe block size, array name, and array capacity, etc. (Figure 4). Figure 4 Delete RAID Volume To delete a RAID array, press <Enter> on the volume to be deleted on the Intel(R) Rapid Storage Technology screen. After entering the RAID VOLUME INFO screen, press <Enter> on Delete to enter the Delete screen. Press <Enter>...
  • Page 65 C-2. UEFI RAID Configuration Step 1: In BIOS Setup, go to Boot and set CSM Support to Disabled (Figure 6). Save the changes and exit BIOS Setup. Figure 6 Step 2: After the system reboot, enter BIOS Setup again. Then enter the Settings\IO Ports\Intel(R) Rapid Storage Technology sub-menu (Figure 7).
  • Page 66 Step 3: On the Intel(R) Rapid Storage Technology menu, press <Enter> on Create RAID Volume to enter the Create RAID Volume screen. Enter a volume name with 1~16 letters (letters cannot be special characters) under the Name item and press <Enter>. Then, select a RAID level (Figure 8). RAID levels supported include RAID 0, RAID 1, RAID 10, and RAID 5 (the selections available depend on the number of the hard drives being installed). Next, use the down arrow key to move to Select Disks. Figure 8 Step 4: Under Select Disks item, select the hard drives to be included in the RAID array. Press the <Space> key on the hard drives to be selected (selected hard drives are marked with "X"). Then set the stripe block size (Figure 9). The stripe block size can be set from 4 KB to 128 KB. Once you have selected the stripe block size, set the volume capacity.
  • Page 67 Step 5: After setting the capacity, move to Create Volume and press <Enter> to begin. (Figure 10) Figure 10 After completing, you'll be brought back to the Intel(R) Rapid Storage Technology screen. Under RAID Volumes you can see the new RAID volume. To see more detailed information, press <Enter> on the volume to check for information on RAID level, stripe block size, array name, and array capacity, etc. (Figure 11) Figure 11 - 67 - Configuring a RAID Set...
  • Page 68 Delete RAID Volume To delete a RAID array, press <Enter> on the volume to be deleted on the Intel(R) Rapid Storage Technology screen. After entering the RAID VOLUME INFO screen, press <Enter> on Delete to enter the Delete screen. Press <Enter> on Yes (Figure 12). Figure 12 Configuring a RAID Set - 68 -...
  • Page 69 C-3. Configuring Legacy RAID ROM You’ll need a discrete graphics card to enter the legacy RAID ROM utility. Enter the Intel legacy RAID BIOS ® setup utility to configure a RAID array. Skip this step and proceed with the installation of Windows operating system for a non-RAID configuration. Step 1: In BIOS Setup, go to Boot and set CSM Support to Enabled and Storage Boot Option Control to Legacy. Next, go to Settings\IO Parts\SATA And RST Configuration and make sure USE RST Legacy OROM is set to Enabled.
  • Page 70 Step 3: After entering the CREATE VOLUME MENU screen, enter a volume name with 1~16 letters (letters cannot be special characters) under the Name item and press <Enter>. Then, select a RAID level (Figure 15). RAID levels supported include RAID 0, RAID 1, RAID 10, and RAID 5 (the selections available depend on the number of the hard drives being installed). Press <Enter> to proceed. Intel(R) Rapid Storage Technology - Option ROM - 17.8.0.4507 Copyright (C) Intel Corporation. All Rights Reserved. [ CREATE VOLUME MENU ] Name : Volume0 RAID Level : RAID0(Stripe)
  • Page 71 Step 5: Enter the array capacity and press <Enter>. Finally press <Enter> on the Create Volume item to begin creating the RAID array. When prompted to confirm whether to create this volume, press <Y> to confirm or <N> to cancel (Figure 17). Intel(R) Rapid Storage Technology - Option ROM - 17.8.0.4507 Copyright(C) Intel Corporation. All Rights Reserved. [ CREATE VOLUME MENU ] Name : Volume0 RAID Level : RAID0(Stripe) Disks :...
  • Page 72 Recovery Volume Options Intel Rapid Recover Technology provides data protection by allowing users to easily restore data and system ® operation using a designated recovery drive. With the Rapid Recovery Technology, which employs RAID 1 functionality, users can copy the data from the master drive to the recovery drive; if needed, the data on the recovery drive can be restored back to the master drive. Before you begin: •...
  • Page 73 Step 3: Press <Enter> under the Select Disks item. In the SELECT DISKS box, press <Tab> on the hard drive you want to use for the master drive and press <Space> on the hard drive you want to use for the recovery drive. (Make sure the recovery drive has equal or larger capacity than the master drive.) Then press <Enter> to confirm (Figure 21).
  • Page 74 Delete RAID Volume To delete a RAID array, select Delete RAID Volume in MAIN MENU and press <Enter>. In the DELETE VOLUME MENU section, use the up or down arrow key to select the array to be deleted and press <Delete>. When prompted to confirm your selection (Figure 23), press <Y> to confirm or <N> to abort.

  • Page 75: Installing The Raid Driver And Operating System

    Installing the RAID Driver and Operating System With the correct BIOS settings, you are ready to install the operating system. A. Installing Windows As some operating systems already include Intel RAID driver, you do not need to install separate RAID driver ® during the Windows installation process. After the operating system is installed, we recommend that you install all required drivers from the motherboard driver disk using "Xpress Install"...
  • Page 76 B. Rebuilding an Array Rebuilding is the process of restoring data to a hard drive from other drives in the array. Rebuilding applies only to fault-tolerant arrays such as RAID 1, RAID 5 or RAID 10 arrays. The procedures below assume a new drive is added to replace a failed drive to rebuild a RAID 1 array. (Note: The new drive must have equal or greater capacity than the old one.) Turn off your computer and replace the failed hard drive with a new one. Restart your computer. • Performing the Rebuild in the Operating System While in the operating system, make sure the chipset driver has been installed from the motherboard driver disk. Then launch the Intel Rapid Storage Technology utility from the Start menu.
  • Page 77 • Restoring the Master Drive to a Previous State (for Recovery Volume only) When two hard drives are set to Recovery Volume in Update on Request mode, you can restore the master drive data to the last backup state when needed. For example, in case the master drive detects a virus, you can restore the recovery drive data to the master drive. Step 1: Select 4.

  • Page 78: Installing An Intel ® Optane ™ Memory

    Installing an Intel Optane Memory ® ™ A. System Requirements 1. Intel Optane memory ® ™ 2. The Optane memory must have at least 16 GB capacity, and it must have equal or smaller capacity than ™ the hard drive/SSD to be accelerated. 3. The Optane memory cannot be used to accelerate an existing RAID array; the accelerated hard drive/SSD ™...
  • Page 79 B-2: Installation in Intel RST Premium With Intel Optane System Acceleration mode If the SATA controller has been configured in Intel RST Premium With Intel Optane System Acceleration mode, please follow the steps below: Step 1: Step 2: Go to Settings\IO Ports\SATA And RST Configuration After system restarts, go to the BIOS Setup, make sure CSM and make sure USE RST Legacy OROM is disabled and Support under the Boot menu is disabled.
  • Page 80 Configuring a RAID Set - 80 -...

  • Page 81: Chapter 4 Drivers Installation

    Chapter 4 Drivers Installation • Before installing the drivers, first install the operating system. • After installing the operating system, insert the motherboard driver disk into your optical drive. Click on the message "Tap to choose what happens with this disc" on the top-right corner of the screen and select "Run Run.exe." (Or go to My Computer, double-click the optical drive and execute the Run.exe program.) Drivers &...

  • Page 82: Application Software

    Application Software This page displays the apps that GIGABYTE develops and some free software. You can select the apps you want and click the Install icon to begin the installation. Information This page provides detailed information on the drivers on the driver disk. The Contact page provides contact information of the GIGABYTE Taiwan headquarter. You can click the URL on this page to link to the...

  • Page 83: Chapter 5 Unique Features

    Chapter 5 Unique Features BIOS Update Utilities GIGABYTE motherboards provide two unique BIOS update tools, Q-Flash and @BIOS . GIGABYTE Q-Flash ™ ™ and @BIOS are easy-to-use and allow you to update the BIOS without the need to enter MS-DOS mode.
  • Page 84 Click Q-Flash (F8) or select the Q-Flash item on the System Info menu to access Q-Flash. B. Updating the BIOS In the main menu of Q-Flash, use the keyboard or mouse to select an item to execute. When updating the BIOS, choose the location where the BIOS file is saved. The following procedure assumes that you have saved the BIOS file to a USB flash drive.
  • Page 85 Step 2: The screen will show that the BIOS file is being read from your USB flash drive. Please select Fast or Intact to begin the BIOS update. The screen will then display the update process. • Do not turn off or restart the system when the system is reading/updating the BIOS. • Do not remove the USB flash drive or hard drive when the system is updating the BIOS. Step 3: The system will restart after the update process is complete. Step 4: During the POST, press <Delete>...

  • Page 86: Updating The Bios With The @Bios Utility

    Internet). Failure to do so may result in a corrupted BIOS or a system that is unable to start. 3. GIGABYTE product warranty does not cover any BIOS damage or system failure resulting from an inadequate BIOS flashing.

  • Page 87: Using Q-Flash Plus

    5-1-3 Using Q-Flash Plus A. Before You Begin 1. From GIGABYTE's website, download the latest compressed BIOS update file that matches your motherboard model. 2. Uncompress the downloaded BIOS file, save it to your USB flash drive, and rename it to GIGABYTE.bin. Note: The USB flash drive must use the FAT32/16 file system and it must be a USB 2.0 flash drive. 3. Connect the power cables to the 12V power connector (connect either one if there are two) and main power connector. 4. Please turn on the power supply before connecting the USB flash drive to the Q-Flash Plus port on the back panel. B. Using Q-Flash Plus Press the Q-Flash Plus button and the system will automatically search and match the BIOS file in the USB flash drive on the Q-Flash Plus port. The QFLED and the Q-Flash Plus button on the rear panel will flash during...

  • Page 88: App Center

    APP Center GIGABYTE App Center gives you easy access to a wealth of GIGABYTE apps that help you get the most from your GIGABYTE motherboard . Using a simple, unified user interface, GIGABYTE App Center allows you (Note) to easily launch all GIGABYTE apps installed on your system, check related updates online, and download the apps, drivers, and BIOS.

  • Page 89: Easytune

    5-2-1 EasyTune GIGABYTE's EasyTune is a simple and easy-to-use interface that allows users to fine-tune their system settings or do overclock/overvoltage in Windows environment. The EasyTune Interface Tabs Information Description The Smart Boost tab provides you with different levels of CPU frequency to choose to achieve desired system performance. After making changes, be sure to restart your system for these changes to take effect.

  • Page 90: Fast Boot

    5-2-2 Fast Boot Through the simple GIGABYTE Fast Boot interface, you can enable or change the Fast Boot or Next Boot After AC Power Loss setting right in the operating system. The Fast Boot Interface Using Fast Boot • BIOS Fast Boot: This option is the same as the Fast Boot option in BIOS Setup.

  • Page 91: Game Boost

    5-2-3 Game Boost This app allows you to flexibly manage your applications to optimize your gaming performance by freeing up system resources and memory usage. The Game Boost Interface Using Game Boost Select the application you want to suspend and then click Go to optimize your system for gaming. To revert the computer back to the state it was before, click Revert. In addition, two hotkeys are provided as follows: •...

  • Page 92: Rgb Fusion

    Windows environment. The RGB Fusion Interface Using RGB Fusion • The icon on the top right corner: Allows you to return to the main menu. icon on the top right corner: Allows your computer to connect to the GIGABYTE RGB Fusion app installed on your handheld devices. (Note 2) • Click the icon of the desired device and select the LED color/ lighting behaviour on the right section of the screen. Static All LEDs emit a single color.
  • Page 93 • Options for controlling the LEDs on the motherboard and digital LED strip. Click the motherboard icon for further settings. (Note) Select your desired area and select the LED color/ lighting behaviour on the right section of the screen. Static The selected region LEDs emit a single color. Pulse The selected region LEDs simultaneously fade in and fade out. Flash The selected region LEDs simultaneously flash on and off.

  • Page 94: Smart Backup

    5-2-5 Smart Backup Smart Backup allows you to back up a partition as an image file every hour. You can use these images to restore your system or files when needed. The Smart Backup main menu: Button Description Allows you to select the source and destination Settings partition Start Allows you to create a rescue drive Backup Now Allows you to perform the backup immediately File Allows you to recover your files from the backup Recovery...
  • Page 95 Recovering your system with Smart Backup: Steps: 1. Click the System Recovery button on the main menu. 2. Select the location where your backup is saved. 3. Use the time slider to select a time point. 4. Select a partition backup created on the selected time point and click Restore.

  • Page 96: System Information Viewer

    5-2-6 System Information Viewer GIGABYTE System Information Viewer allows you to monitor and adjust the fan speed in the operating system. You can also display the hardware monitor information on the desktop to view the system status at any time.

  • Page 97: Usb Dac-Up 2

    5-2-7 USB DAC-UP 2 GIGABYTE USB DAC-UP 2 allows you to increase the output voltage of the USB 3.2 Gen 1 ports on the front or back panel to strengthen the stability of your USB device(s). The USB DAC-UP 2 Interface Using USB DAC-UP 2 Click the drop down list on the right of the USB 3.2 Gen 1 connector you want to adjust the voltage and choose...
  • Page 98 Unique Features - 98 -...

  • Page 99: Chapter 6 Appendix

    Chapter 6 Appendix 6-1 Configuring Audio Input and Output After you install the included motherboard drivers, make sure your Internet connection works properly. The system will automatically install the audio driver from Microsoft Store. Restart the system after the audio driver is installed. 6-1-1 Configuring 2/4/5.1/7.1-Channel Audio The motherboard provides five audio jacks on the back panel which support 2/4/5.1/7.1-channel audio. (Note) Center/Subwoofer Line In Speaker Out The picture to the right shows the default audio jack...
  • Page 100 Step 3: On the Speakers screen, click the Speaker Configuration tab. In the Speaker Configuration list, select Stereo, Quadraphonic, 5.1 Speaker, or 7.1 Speaker according to the type of speaker configuration you wish to set up. Then the speaker setup is completed. B.
  • Page 101 D. Configuring the Headphone When you connect your headphone to the Line out jack on the back panel or front panel, make sure the default playback device is configured correctly. Step 1: Locate the icon in the notification area and right-click on the icon.

  • Page 102: Configuring S/Pdif Out

    6-1-2 Configuring S/PDIF Out The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio quality. 1. Connecting a S/PDIF Out Cable: Connect a S/PDIF optical cable to an external decoder for transmitting the S/PDIF digital audio signals. Connects to a S/PDIF optical cable 2. Configuring S/PDIF Out: On the Realtek Digital Output screen, Select the sample rate and bit depth in the Default Format section. Appendix - 102 -...

  • Page 103: Stereo Mix

    6-1-3 Stereo Mix The following steps explain how to enable Stereo Mix (which may be needed when you want to record sound from your computer). Step 1: Locate the icon in the notification area and right-click on the icon. Select Open Sound settings. Step 2: Select Sound Control Panel.

  • Page 104: Using The Voice Recorder

    Step 4: Now you can access the HD Audio Manager to configure Stereo Mix and use Voice Recorder to record the sound. 6-1-4 Using the Voice Recorder After setting up the audio input device, to open the Voice Recorder, go to the Start menu and search for Voice Recorder.

  • Page 105: Dts:x ® Ultra

    6-1-5 DTS:X Ultra ® Hear what you have been missing! DTS:X Ultra technology is designed to enhance your gaming, movies, AR, ® and VR experiences on headphones and speakers. It delivers an advanced audio solution that renders sounds above, around, and close to you, stepping up your game play to new levels. Now with support for Microsoft Spatial sound. Key features include: Believable 3D audio •...
  • Page 106 B. Using DTS Sound Unbound Installing DTS Sound Unbound Step 1: Connect your headphones to the front panel line out jack and make sure your Internet connection works properly, Locate the icon in the notification area and right-click on the icon. Click on Spatial Sound and then select DTS Sound Unbound.

  • Page 107: Troubleshooting

    Troubleshooting 6-2-1 Frequently Asked Questions To read more FAQs for your motherboard, please go to the Support\FAQ page on GIGABYTE's website. Q: Why is the light of my keyboard/optical mouse still on after the computer shuts down? A: Some motherboards provide a small amount of standby power after the computer shuts down and that's why the light is still...

  • Page 108: Troubleshooting Procedure

    6-2-2 Troubleshooting Procedure If you encounter any troubles during system startup, follow the troubleshooting procedure below to solve the problem. START Turn off the power. Remove all peripherals, connecting cables, and power cord etc. Make sure the motherboard does not short-circuit with the chassis or Isolate the short circuit. other metal objects.
  • Page 109 The power supply, CPU or When the computer is turned on, is the CPU cooler running? CPU socket might fail. The problem is verified and solved. The graphics card, expansion slot, or monitor Check if there is display on your monitor. might fail. The problem is verified and solved. Turn off the computer. Plug in the keyboard and mouse and restart the computer.

  • Page 110: Debug Led Codes

    Debug LED Codes Regular Boot Code Description PEI Core is started. Pre-memory CPU initialization is started. 12~14 Reserved. Pre-memory North-Bridge initialization is started. 16~18 Reserved. Pre-memory South-Bridge initialization is started. 1A~2A Reserved. 2B~2F Memory initialization. Memory installed. 32~36 CPU PEI initialization. 37~3A IOH PEI initialization. 3B~3E PCH PEI initialization. 3F~4F Reserved. DXE Core is started. NVRAM initialization. Installation of the PCH runtime services. 63~67 CPU DXE initialization is started.
  • Page 111 Code Description PCI Bus initialization is started. PCI Bus hot plug initialization. PCI Bus enumeration for detecting how many resources are requested. Check PCI device requested resources. Assign PCI device resources. Console Output devices connect (ex. Monitor is lighted). Console input devices connect (ex. PS2/USB keyboard/mouse are activated). Super IO initialization. USB initialization is started. Issue reset during USB initialization process. Detect and install all currently connected USB devices. Activated all currently connected USB devices.
  • Page 112 Code Description USB device hot plug-in. PCI device hot plug. Clean-up of NVRAM. Reconfigure NVRAM settings. B8~BF Reserved. C0~CF Reserved. S3 Resume Code Description S3 Resume is started (called from DXE IPL). Fill boot script data for S3 resume. Initializes VGA for S3 resume. OS S3 wake vector call. Recovery Code Description Recovery mode will be triggered due to invalid firmware volume detection. Recovery mode will be triggered by user decision. Recovery is started. Recovery firmware image is found.
  • Page 113 Code Description PCH initialization error. Some of the Architectural Protocols are not available. PCI resource allocation error. Out of Resources. No Space for Legacy Option ROM initialization. No Console Output Devices are found. No Console Input Devices are found. It is an invalid password. D9~DA Can't load Boot Option. Flash update is failed. Reset protocol is failed. DE~DF Reserved.

  • Page 114: Regulatory Notices

    Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Product Name: Motherboard Trade Name: GIGABYTE Model Number: W480 VISION D Responsible Party – U.S. Contact Information: G.B.T. Inc. Address: 17358 Railroad street, City Of Industry, CA91748 Tel.: 1-626-854-9338 Internet contact information: https://www.gigabyte.com FCC Compliance Statement: This device complies with Part 15 of the FCC Rules, Subpart B, Unintentional Radiators.
  • Page 115 (Cd, Pb, Hg, Cr+6, PBDE, PBB, DEHP, BBP, DBP and DIBP). de equipos radioeléctricos 2014/53/EU, Directiva de bajo voltaje The parts and components have been carefully selected to meet RoHS 2014/35/EU, Directiva RoHS (recast) 2011/65/EU. El cumplimiento de requirement. Moreover, we at GIGABYTE are continuing our efforts to estas directivas se evalúa mediante las normas europeas armonizadas. develop products that do not use internationally banned toxic chemicals. Dichiarazione di conformità CE European Union (EU) Community Waste Electrical &...
  • Page 116 European Community Directive RED Directive Compliance Statement: This equipment is suitable for home and office use in all the European Community Member States and EFTA Member States. The low band 5.15 -5.35 GHz is for indoor use only for the countries listed in the table below: Wireless module country approvals: Wireless module model name: AX201NGW Wireless module manufacturer: Intel ® Corporation Korea Wireless Statement: 5.15 — 5.35 GHz 대역에서의 작동은 실내로。 Japan Wireless Statement: 5.15 GHz帯 ~ 5.35 GHz帯: 屋内のみの使用。 Taiwan NCC Wireless Statements / 無線設備警告聲明： 低功率電波輻射性電機管理辦法...
  • Page 117 - 117 - Appendix...
  • Page 118 Appendix - 118 -...

  • Page 119: Contact Us

    FAX: +86-29-85510930 Shenyang Web address: https://www.gigabyte.com/latam • Giga-Byte SINGAPORE PTE. LTD. - Singapore TEL: +86-24-83992342 WEB address: https://www.gigabyte.com/sg FAX: +86-24-83992102 • Thailand • GIGABYTE TECHNOLOGY (INDIA) LIMITED - India WEB address: https://www.gigabyte.com/th WEB address: https://www.gigabyte.com/in • Vietnam • Saudi Arabia WEB address: https://www.gigabyte.com/vn WEB address: https://www.gigabyte.com/sa • Gigabyte Technology Pty. Ltd. - Australia WEB address: https://www.gigabyte.com/au...
  • Page 120 • G.B.T. TECH. CO., LTD. - U.K. • Turkey WEB address: https://www.gigabyte.com/uk WEB address: http://www.gigabyte.com.tr/ • Giga-Byte Technology B.V. - The Netherlands • Russia WEB address: https://www.gigabyte.com/nl WEB address: http://www.gigabyte.ru/ • GIGABYTE TECHNOLOGY FRANCE - France • Poland WEB address: https://www.gigabyte.com/fr WEB address: http://www.gigabyte.pl/ • Sweden • Ukraine WEB address: https://www.gigabyte.com/se WEB address: http://www.gigabyte.ua/ • Italy •...
