Inspiron 13
7000 Series
Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. Dell
and the Dell logo are trademarks of Dell Inc. in the United States and/or other
™
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies
2014 ‑ 11
Rev. A00
Regulatory model: P57G | Type: P57G001
Computer model: Inspiron 13‑7348
Views
Modes
Specifications
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
Advertisement
Table of Contents
Related Manuals for Dell P57G
Summary of Contents for Dell P57G
- Page 1 Views Modes Specifications Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other ™...
- Page 2 Views Specifications Front Front Left Right Power/Battery status light Base Indicates the power state and battery state of the computer. Solid white light — Power adapter is connected to the computer and the battery is being charged. Solid yellow light — Battery charge is low or critical. Display Off—...
- Page 3 Views Specifications Left Front Left Right Security-cable slot USB 3.0 port Connect a security cable to prevent unauthorized Connect peripherals such as storage devices, printers, Base movement of your computer. and so on. Provides data transfer speeds up to 5 Gbps. Power-adapter port Headset port Connect a power adapter to provide power to your...
- Page 4 NOTE: You can customize the power‑button Passive stylus behavior in Power Options. For more information, see Display Me and My Dell at dell.com/support. Allows you to draw shapes, select items, and perform touch gestures on the screen. Volume-control buttons (2) Press to increase or decrease the volume.
- Page 5 Views Specifications Base Front Left Right Left-click area Right-click area Base Press to left click. Press to right click. Touchpad Move your finger on the touchpad to move the mouse pointer. Tap to left click and two finger tap to right click. Display...
- Page 6 Views Specifications Display 3 4 5 Front Left Right Left microphone Camera-status light Base Provides high‑quality digital sound input for audio Turns on when the camera is in use. recording, voice calls, and so on. Right microphone Ambient-light sensor Provides high‑quality digital sound input for audio Detects the ambient light and automatically adjusts the recording, voice calls, and so on.
- Page 7 Modes Tablet Notebook Tablet Stand Tent...
-
Page 8: Dimensions And Weight
Specifications Views Dimensions and Weight Height 19 mm (0.75 in) Width 330 mm (13 in) Depth 222 mm (8.74 in) Weight (maximum) 1.67 kg (3.70 lb) NOTE: The weight of your computer varies depending on the configuration ordered and the manufacturing variability. Dimensions and System Ports and... -
Page 9: System Information
Specifications Views System Information Computer model Inspiron 13‑7348 Processor • 5 generation Intel Core i3 • 5 generation Intel Core i5 • 5 generation Intel Core i7 Chipset Integrated in the processor Dimensions and System Ports and Memory Communications Video Audio Storage Weight... - Page 10 Specifications Views Memory Slot One SODIMM slot Type DDR3L Speed 1600 MHz Configurations supported 4 GB and 8 GB Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
-
Page 11: Ports And Connectors
Specifications Views Ports and Connectors External: • One USB 3.0 port • One USB 2.0 port • One USB 3.0 port with PowerShare Audio/Video • One HDMI port • One headset port Internal: M.2 card One M.2 card slot for Wi‑Fi and Bluetooth combo card Dimensions and System Ports and... - Page 12 Specifications Views Communications Wireless • Wi‑Fi 802.11 b/g/n • Wi‑Fi 802.11 ac • Bluetooth 4.0 • WiDi Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
- Page 13 Specifications Views Video Controller Intel HD Graphics Memory Shared system memory Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
- Page 14 Specifications Views Audio Controller Realtek ALC3234 with Waves MaxxAudio Speakers Speaker output: Average 2 watt Peak 2.5 watt Microphone Digital‑array microphones in camera assembly Volume controls Media‑control shortcut keys and volume‑control buttons. Dimensions and System Ports and Memory Communications Video Audio Storage Weight...
- Page 15 Specifications Views Storage Interface SATA 3 Gbps Hard drive One 2.5‑inch drive Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment...
-
Page 16: Media-Card Reader
Specifications Views Media-Card Reader Type One 2‑in‑1 slot Cards supported • SD Card • MultiMedia Card (MMC) Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader Environment... - Page 17 Specifications Views Display Type • 13.3‑inch HD WLED touch • 13.3‑inch Full HD WLED touch Full HD Resolution (maximum) 1366 x 768 1920 x 1080 Dimensions: Height 164.97 mm (6.49 in) 165.10 mm (6.50 in) Width 293.42 mm (11.55 in) 293.60 mm (11.55 in) Diagonal 337.82 mm (13.30 in)
- Page 18 Specifications Views Keyboard Type Backlit keyboard Shortcut keys Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key.
-
Page 19: Shortcut Keys
Keyboard Shortcut Keys Turn off/on wireless Mute audio Pause/Break Decrease volume Sleep Increase volume Scroll lock Play previous track/chapter Toggle Fn‑key lock Play/Pause Play next track/chapter Switch to external display Open Search charm Toggle keyboard backlight Decrease brightness Increase brightness... - Page 20 Specifications Views Camera Resolution: Still image 0.92 megapixel Video 1280 x 720 (HD) at 30 fps (maximum) Diagonal viewing angle 74 degrees Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter...
- Page 21 Specifications Views Touchpad Resolution: Horizontal 304.8 dpi Vertical 304.8 dpi Dimensions: Width 102 mm (4.01 in) Height 62 mm (2.44 in) Dimensions and System Ports and Memory Communications Video Audio Storage Weight Information Connectors Media‑Card Computer Display Keyboard Camera Touchpad Battery Power Adapter Reader...
- Page 22 Specifications Views Battery Type 3 cell Dimensions: Width 77.20 mm (3.04 in) Depth 254 mm (10 in) Height 6.80 mm (0.27 in) Weight (maximum) 0.25 kg (0.55 lb) Voltage 11.4 VDC Charging time when the computer is off Within 4 hours (approximate) Operating time Varies depending on operating conditions and can significantly reduce under...
-
Page 23: Power Adapter
Specifications Views Power Adapter Type 65 W Input voltage 100 VAC–240 VAC Input frequency 50 Hz–60 Hz Input current (maximum) 1.70 A Output current (maximum) 3.34 A Rated output voltage 19.50 VDC Temperature range: Operating 0°C to 40°C (32°F to 104°F) Storage –40°C to 70°C (–40°F to 158°F) Dimensions and... -
Page 24: Computer Environment
Specifications Views Computer Environment Airborne contaminant level G1 as defined by ISA‑S71.04‑1985 Operating Storage Temperature range 0°C to 35°C (32°F to 95°F) –40°C to 65°C (–40°F to 149°F) Relative humidity (maximum) 10% to 90% (non‑condensing) 0% to 95% (non‑condensing) Vibration (maximum) 0.66 GRMS 1.30 GRMS Shock (maximum)
