Table of Contents
Advertisement
Quick Links
This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
!
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Adults and especially children should be alerted to the hazards of high surface temperatures.
Young children should be supervised near the gas grill.
Notice to Installer: Leave these instructions with the grill owner for future reference.
DO NOT REMOVE
N415-0705-AU Sep 10.21
!
Do not try to light this appliance without
reading the "lighting" instructions section of
this manual.
Do not use or store gasoline or other
flammable liquids or vapors near this
appliance.
A ULPG cylinder not connected for use must
not be stored near this or any other appliance.
If the information in these instructions is
not followed exactly, a fire or explosion may
result, causing property damage, personal
injury or death.
Wolf Steel Ltd.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
grills@napoleon.com
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
ROGUE-1
RXT425SB/SIB
RXT525SB/SIB
RXT625SB/SIB
WARNING
IApMO GMK10539
AS/NZS 5263.1.7
www.napoleon.com
EN
PG.20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Napoleon ROGUE-1 RXT425SB/SIB
Summary of Contents for Napoleon ROGUE-1 RXT425SB/SIB
- Page 1 Young children should be supervised near the gas grill. Notice to Installer: Leave these instructions with the grill owner for future reference. DO NOT REMOVE Wolf Steel Ltd. 214 Bayview Drive, Barrie, Ontario, CANADA L4N 4Y8 IApMO GMK10539 grills@napoleon.com AS/NZS 5263.1.7 N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 2 NAPOLEON. NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and workmanship from the date of purchase, for the following period: Aluminum castings / stainless steel base ...........
-
Page 3: Safe Operating Practices
• Never use lighter fluid in a gas grill. • Use charcoal briquettes only with a Napoleon charcoal tray designed for this unit. • Burner controls must be off when turning supply cylinder or natural gas supply valve on. •... - Page 4 25% of least 25% of total wall area total wall area In the case of balconies, at least 20% of the total of the side, back and front wall areas shall be and remain open and unrestricted. www.napoleon.com N415-0705-AU Sep 10.21...
- Page 5 DIMENSIONS ORIFICE SIZES ULPG MAIN BURNER 1.79 mm SIDE BURNER (INFRARED) 1.07 mm REAR BURNER 1.15 mm 1.15 mm 1.85 mm SIDE BURNER (FLAME) 1.45 mm N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 6 DIMENSIONS ORIFICE SIZES ULPG MAIN BURNER 1.65 mm SIDE BURNER (INFRARED) 1.07 mm REAR BURNER 1.15 mm 1.15 mm 1.85 mm SIDE BURNER (FLAME) 1.45 mm www.napoleon.com N415-0705-AU Sep 10.21...
- Page 7 DIMENSIONS ORIFICE SIZES ULPG MAIN BURNER 1.65 mm SIDE BURNER (INFRARED) 1.07 mm REAR BURNER 1.15 mm 1.15 mm 1.85 mm SIDE BURNER (FLAME) 1.45 mm N415-0705-AU Sep 10.21 www.napoleon.com...
-
Page 8: General Information
It can be used by a qualified service person when servicing the grill to determine if the regulator is functioning properly. The screw within the pressure tap must always be kept tight, except when performing a pressure test on the regulator (qualified service personnel only). www.napoleon.com N415-0705-AU Sep 10.21... -
Page 9: Gas Hook-Up Instructions
Hand tighten counter clockwise. Do not use tools. Leak test all joints prior to using the grill. A leak test must be performed annually and each time a cylinder is hooked up or if a part of the gas system is replaced. N415-0705-AU Sep 10.21 www.napoleon.com... -
Page 10: Leak Testing Instructions
Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Solutions department and have the grill inspected by a certified gas installer. STOP If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer. -
Page 11: Lighting Instructions
5. When no longer in use, ensure side burner pilot through the grill and sear plate while turning the flame has extinguished before closing side burner lid corresponding burner valve to high. NOTE! Do not use rear burner while operating main burner. N415-0705-AU Sep 10.21 www.napoleon.com... -
Page 12: Cooking Instructions
Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Direct Cooking: Place food to be cooked on the grill directly over the heat. This method is generally used for searing or for foods that do not require prolonged cooking times such as hamburgers, steaks, chicken pieces, or vegetables. - Page 13 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red.
- Page 14 To add an 6 min. – Well done exotic taste to your meat, High setting 3 min. each side. try adding hickory-flavored woodchips to Napoleon’s woodchip smoker. Chicken pieces High setting 2 min. each side. 20-25 min. The joint connecting the...
-
Page 15: Cleaning Instructions
Scrape the sear plates with a putty knife or scraper, and use a wire brush to remove the ash. Remove the sear plates and brush debris from the burners with the brass wire brush. Sweep all debris from inside the gas grill into the drip pan. N415-0705-AU Sep 10.21 www.napoleon.com... -
Page 16: Maintenance Instructions
Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner. - Page 17 CAUTION! Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.
-
Page 18: Troubleshooting
Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding the Contact your authorized Napoleon dealer for... -
Page 19: Ordering Replacement Parts
3. A concise description of the problem (‘broken’ is not sufficient). 4. Proof of purchase (photocopy of the invoice). In some cases, Napoleon could request to have the parts returned to the factory for inspection before providing replacement parts. Before contacting Napoleon dealer, please note that the following items are not covered by the warranty: •... - Page 20 Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. WARNING! Clip hose to cart heat shield using bushing supplied. Failure to follow these instructions could result in property damage, personal injury or death. www.napoleon.com N415-0705-AU Sep 10.21...
- Page 21 WARNING – FIRE HAZARD WARNING! Do not route hose underneath drip pan. WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 22 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Solutions department and have the grill inspected by a certified gas installer. STOP...
- Page 23 N010-1041-SeR base assembly N010-0999-SeR base assembly N010-1280-SeR base assembly N305-0096 stainless steel main cooking grid N305-0113 stainless steel 525 center cooking grid N200-0118-GY1SG base back cover N200-0127-GY1SG base back cover N200-0135-GY1SG base back cover N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 24 N010-0869-BK-SeR black door assembly N010-0984-BK-SeR black door assembly N010-1221-BK-SeR black door assembly N105-0011 door bushing N325-0094-SeR door handle N080-0380-GY1SG door magnet bracket N080-0254G tank inhibitor bracket N590-0327-GY1SG tank inhibitor shelf N080-0378-GY1SG door pivot bracket www.napoleon.com N415-0705-AU Sep 10.21...
- Page 25 N345-0018 natural gas hose N530-0003 QCC1 regulator N710-0094 drip pan N710-0108 drip pan N710-0120 drip pan 56425 cast iron griddle N010-1592-SeR side shelf assembly N240-0045 electrode N720-0073 pilot tube N455-0079 pilot orifice N565-0014 infrared burner screen N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 26 S83024 cast iron cooking grids S83022 stainless steel cooking grids S83021 cast iron cooking grids x - standard p - propane units only n- natural gas units only ac - accessory sp -special edition www.napoleon.com N415-0705-AU Sep 10.21...
- Page 27 N415-0705-AU Sep 10.21 www.napoleon.com...
- Page 28 Napoleon products are protected by one or more U.S. and Canadian N415-0705-AU and/or foreign patents or patents pending. www.napoleon.com...
