MIDI Implementation

1. Receive Data
■Channel Voice Messages
* Not received in Multitimbre mode or Performance mode when the Receive Switch
parameter (MULTITIMBRE/MIDI or PERFORM/MIDI) is OFF.
●Note Off
Status
2nd byte
8nH
kkH
9nH
kkH
n = MIDI channel number:
0H - FH (ch.1 - 16)
kk = note number:
00H - 7FH (0 - 127)
vv = note off velocity:
00H - 7FH (0 - 127)
●Note On
Status
2nd byte
9nH
kkH
n = MIDI channel number:
0H - FH (ch.1 - 16)
kk = note number:
00H - 7FH (0 - 127)
vv = note on velocity:
01H - 7FH (1 - 127)
●Polyphonic Key Pressure
Status
2nd byte
AnH
kkH
n = MIDI channel number:
0H - FH (ch.1 - 16)
kk = note number:
00H - 7FH (0 - 127)
vv = Polyphonic Key Pressure:
00H - 7FH (0 - 127)
●Control Change
* If the corresponding Controller number is selected for the Patch Control Source 1, 2, 3, 4,
5, 6, 7 or 8 parameter (PATCH Edit Com Matrix Ctrl), the corresponding effect will
occur.
❍Bank Select (Controller number 0, 32)
Status
2nd byte
BnH
00H
BnH
20H
n = MIDI channel number:
0H - FH (ch.1 - 16)
mm, ll = Bank number:
00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received when the Receive Bank Select (SYSTEM Com MIDI/USB) is OFF.
* The Patches corresponding to each Bank Select are as follows.
BANK SELECT
| PROGRAM
| PATCH
MSB | LSB
| NUMBER
| NUMBER
-----+-----------+-----------+-----------
087 | 000
| 001 - 128 | 001 - 128
| 001
| 001 - 128 | 129 - 256
| 002
| 001 - 128 | 257 - 384
| 003
| 001 - 128 | 385 - 512
❍Portamento Time (Controller number 5)
Status
2nd byte
BnH
05H
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Portamento Time:
00H - 7FH (0 - 127)
❍Data Entry (Controller number 6, 38)
Status
2nd byte
BnH
06H
BnH
26H
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
❍Volume (Controller number 7)
Status
2nd byte
BnH
07H
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Volume:
00H - 7FH (0 - 127)
3rd byte
vvH
00H
3rd byte
vvH
3rd byte
vvH
3rd byte
mmH
llH
3rd byte
vvH
3rd byte
mmH
llH
3rd byte
vvH
Model: V-Synth XT
Date: Mar. 24, 2005
Version: 1.00
❍Panpot (Controller number 10)
Status
2nd byte
BnH
0AH
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Panpot:
00H - 40H - 7FH (Left - Center - Right),
❍Expression (Controller number 11)
Status
2nd byte
BnH
0BH
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Expression:
00H - 7FH (0 - 127)
❍Hold 1 (Controller number 64)
Status
2nd byte
BnH
40H
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Control value:
00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
❍Portamento (Controller number 65)
Status
2nd byte
BnH
41H
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Control value:
00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍Sostenuto (Controller number 66)
Status
2nd byte
BnH
42H
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Control value:
00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍Effect 1 (Reverb Send Level) (Controller number 91)
Status
2nd byte
BnH
5BH
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Reverb Send Level:
00H - 7FH (0 - 127)
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status
2nd byte
BnH
5DH
n = MIDI channel number:
0H - FH (ch.1 - 16)
vv = Chorus Send Level:
00H - 7FH (0 - 127)
❍RPN MSB/LSB (Controller number 100, 101)
Status
2nd byte
BnH
65H
BnH
64H
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then
Data Entry (Controller numbers 6 and 38) should be sent to set the value. Once RPN
messages are received, Data Entry messages that is received at the same MIDI channel after
that are recognized as changing toward the value of the RPN messages. In order not to
make any mistakes, transmitting RPN Null is recommended after setting parameters you
need.
3rd byte
vvH
3rd byte
vvH
3rd byte
vvH
3rd byte
vvH
3rd byte
vvH
3rd byte
vvH
3rd byte
vvH
3rd byte
mmH
llH
1
