GRACE FULL
OWNER'S MANUAL
VENDOR ITEM NO. :
PNRAL4BH / PNRAL4FS / PNRAL4RL - SNOWFALL
PNRBL4BH / PNRBL4FS / PNRBL4RL - RAVEN
PNRCL4BH / PNRCL4FS / PNRCL4RL - DARK MOCHA
PNKXL4BH / PNKXL4FS / PNKXL4RL - BLUEBERRY
PNKGL4BH / PNKGL4FS / PNKGL4RL - ELEPHANT GREY
ASSEMBLY PARTS LIST
BOX 1 - HEADBOARD
(SKU PNRAL4BH/PNRBL4BH/PNRCL4BH
PART NO. IMAGE
A HEADBOARD PANEL
B
LEFT HEADBOARD LEG
C RIGHT HEADBOARD LEG
HEADBOARD HARDWARE KIT PACKED IN BOX 1
1 ALLEN BOLT (6X35mm)
2 SPRING WASHER (M6)
3 FLAT WASHER (M6)
4 ALLEN KEY
GRACE LOW PROFILE BED FULLY ASSEMBLED
ASSEMBLY INSTRUCTIONS
STEP 1 :
USE HEADBOARD HARDWARE PACKED IN BOX 1
FOR STEP 1.
UPDATED : MAY 3RD, 2023
LOW PROFILE BED
/PNKXL4BH/PNKGL4BH
QUANTITY
DESCRIPTION
X8
BOX 2 - FOOTBOARD-SLATS
) (SKU PNRAL4FS/PNRBL4FS/PNRCL4FS/PNKXL4FS/PNKGL4FS)
PART NO. IMAGE
D
1
E
1
F
1
BED HARDWARE KIT PACKED IN BOX 2
5
8
6
8
7
8
8
1
BOX 3 - SIDE RAILS
(SKU PNRAL4RL/PNRBL4RL/PNRCL4RL
G
ASSEMBLE ON A SOFT SURFACE
STEP 2 :
USE HARDWARE PACKED IN BOX 2 FOR STEP 2
AND ALL REMAINING STEPS .
DESCRIPTION
FOOTBOARD
BED SLAT
SUPPORT LEG
PAN HEAD SCREW (6X15mm)
WOOD SCREW (8x30mm)
ALLEN KEY
ALLEN BOLT (6X40mm)
/PNKXL4RL/PNKGL4RL
SIDE RAIL
0:30
NOT PROVIDED
QUANTITY
1
5
5
13
11
1
6
)
2
1
