HEARST FULL/QUEEN BED
ASSEMBLY INSTRUCTIONS
BOX #1
BOX #1
A. HEADBOARD 1PC
B. RIGHT LEG
1PC
C. LEFT LEG
1PC
D. STRETCHER
1PC
C
BOX #2
E. SIDE RAIL
1 SET
ASSEMBLY COMPLETE
TOOL REQUIRED PHILLIPS HEAD SCREW DRIVER
A
B
E
00 : 30
(NOT PROVIDED)
BOX #3
F. FOOTBOARD
G. SLAT ROLL
H. SLAT SUPPORT
D
H
HARDWARE PACKED IN BOX #2
1
ALLEN BOLT (M8X60)
2
ALLEN BOLT (M6X40)
3
ALLEN BOLT (M8X30)
4
ALLEN BOLT (M6X35)
5
SPRING WASHER (M8)
6
FLAT WASHER (M8)
7
SPRING WASHER (M6)
8
FLAT WASHER (M6)
9
WOOD SCREW (M4X30)
10
ALLEN KEY
MODUS
F U R N I T U R E
1 PC
1 SET
5 PCS
F
G
8 PCS
2 PCS
16 PCS
5 PCS
24 PCS
24 PCS
2 PCS
2 PCS
10 PCS
1 PC
