Congratulations on your choice of the Roland Digital Piano HPi-5.
201a
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" and "IMPORTANT NOTES" (p.
2; p. 4). These sections provide important information concerning the proper operation of the unit. Additionally, in order
to feel assured that you have gained a good grasp of every feature provided by your new unit, Owner's manual should be
read in its entirety. The manual should be saved and kept on hand as a convenient reference.
Musical Score Shown In
A Large LCD Screen
The musical score can be displayed not only for
the internal songs, but also for commercially
available song files.
Lyrics and fingering numbers can also be displayed.
* The fingering numbers are displayed only for some of the internal
songs.
A "Wonderland" Sure To Please
Children
"Wonderland" is a world of sound which children
can enjoy, with a "DRUM," a "SFX" of sounds, and
more. A note-guessing game is also included.
All rights reserved. No part of this publication may be reproduced in any form
Owner's Manual
Authentic Piano Performance
High-quality concert grand piano tones,
along with the Progressive Hammer
Action Keyboard, which gives more
realistic piano touch let you enjoy truly
authentic piano performances.
A Wealth Of Onboard Songs
The instrument comes with 168 piano
songs, all carefully selected so almost
every genre is represented—whether it
be piano etudes, or popular tunes.
Of course, all internal songs can be
viewed in the score screen.
Copyright © 2001 ROLAND CORPORATION
without the written permission of ROLAND CORPORATION.
Easy Game-like Operation
After pressing the button for the desired
function, operation consists basically of
pressing the cursor buttons and [ ] [ ]
buttons located in the center of the panel.
You can enjoy versatile performance
with easy operation.
Convenient Functions
For Practicing
Song data can be played back one
hand (part) at a time, and you can
use the internal metronome and
other convenient functions for
practicing.
