Roland KC-150 Specifications

Specifications
C - 550 C - 350
Rated Power Output 180 W 120 W
Nominal Input Level CH 1 (MIC/LINE) -50 to -20 dBu -50 to -20 dBu
(1 kHz)
CH 2-4 (LINE) -20 dBu -20 dBu
STEREO LINK 0 dBu 0 dBu
AUX -10 dBu -10 dBu
Nominal Output Level LINE OUT +4 dBu +4 dBu
(1 kHz)
STEREO LINK 0 dBu 0 dBu
SUB WOOFER +4 dBu +4 dBu
Speakers 38 cm (15 inches) x 1, 30 cm (12 inches) x 1,
Tweeter x 1 Tweeter x 1
CH1 INPUT Jack CH1 INPUT Jack
Connectors
(XLR type) (XLR type)
CH1-4 INPUT L (MONO) Jacks CH1-4 INPUT L (MONO) Jacks
(1/4" phone type) (1/4" phone type)
CH1-4 INPUT R Jacks CH1-4 INPUT R Jacks
(1/4" phone type) (1/4" phone type)
LINE OUT L (MONO) Jacks LINE OUT L (MONO) Jack
(XLR type, 1/4" phone type) (1/4" phone type)
LINE OUT R Jacks LINE OUT R Jack
(XLR type, 1/4" phone type) (1/4" phone type)
AUX IN Jacks AUX IN Jacks
(RCA phono type) (RCA phono type)
SUBWOOFER OUT Jack SUBWOOFER OUT Jack
(1/4" phone type) (1/4" phone type)
STEREO LINK OUT Jack STEREO LINK OUT Jack
(1/4" phone type) (1/4" phone type)
STEREO LINK IN Jack STEREO LINK IN Jack
(1/4" phone type) (1/4" phone type)
PHONES Jack PHONES Jack
(Stereo 1/4" phone type) (Stereo 1/4" phone type)
Power Supply AC 117 V, AC 230 V, AC 240 V AC 117 V, AC 230 V, AC 240 V
Power Consumption 135 W 100 W
Dimensions 590 (W) x 445 (D) x 536 490 (W) x 385 (D) x 470
(H) mm, 23-1/4 (W) x 17- (H) mm, 19-5/16 (W) x 15-
9/16 (D) x 21-1/8 (H) 3/16 (D) x 18-9/16 (H)
inches (excluding casters) inches
29.0 kg, 63 lbs 15 oz 22.0 kg, 48 lbs 9 oz
Weight
Owner's Manual,
Accessories
Owner's Manual
Casters (x4)
The Ultimate Amplifier for Keyboards and Organ.
The KC-1000 is our most powerful keyboard amp ever. This 5-channel tower uses DSP technology and a 310-
watt/7-speaker system to accurately reproduce the full frequency range of organs, synthesizers and other
® ®
electronic musical instruments. Onboard RSS and COSM effects create realistic tone cabinet reverberation
when used with VK-Series organs, while unique ambient effects, split-
frequency compression and 3-band EQ make the KC-1000 perfect
for performance.
Specifications
Rated Power Output 310W Speakers 15" (38 cm) x 1, 6.3" (16 cm) x 4,
1" (2.5 cm) x 2 Controls Channel Organ Volume, Cabinet Modeling Sound
Type, Orchestral Volume, Synth/AUX Volume, Mic Volume, Ambience Volume,
Tone Control Low, Tone Control Middle, Tone Control High, Master Volume, Line
Out Volume, Phones Volume Connectors ORGAN Input (L/Mono, R),
ORCHESTRAL Input (L/Mono, R), SYNTH/AUX Input (L/Mono, R), MIC Input
(Mono), STEREO LINK OUT, STEREO LINK IN, LINE OUT (XLR type
balanced L, R, 1/4" phone type unbalanced L/Mono, R), HEADPHONES
Power Consumption 225W (AC 117/230/240 V) Dimensions (incl. the
casters) 595 (W) x 535 (D) x 970 (H) mm (23-7/16" x 21-1/16" x 38-3/16")
Weight 64 kg (141 lbs. 2 oz.)
Options
DR-20 RH-50 DP-2 FS-5U
Dynamic micophone Headphones Pedal Switch Footswitch
Visit us online at www.roland.co.jp
C - 150 C - 60 CW - 1
65 W 40 W 200W
-50 to -20 dBu -50 to -20 dBu
-20 dBu -20 dBu
+4 dBu
-10 dBu -10 dBu
+4 dBu +4 dBu
+4 dBu
+4 dBu +4 dBu
30 cm (12 inches) x 1, 25 cm (10 inches) x 1,
25 cm (10 inches) x 1
Tweeter x 1 Tweeter x 1
Channel 1 Input Jacks Channel 1 Input Jacks INPUT Connectors L, R
(XLR type, 1/4" phone type) (XLR type, 1/4" phone type) (XLR type)
Channel 2 Input Jack Channel 2 Input Jack INPUT Jacks L (MONO), R
(1/4" phone type) (1/4" phone type) (1/4" phone type)
Channel 3 Input Jack Channel 3 Input Jack THRU OUT Connectors L, R
(1/4" phone type) (1/4" phone type) (XLR type)
Channel 4 Input Jack AUX IN Jacks THRU OUT Jacks L, R
(1/4" phone type) (RCA phono type) (1/4" phone type)
AUX IN Jacks LINE OUT Jack FOOT SW Jack
(RCA phono type) (1/4" phone type) (SUBWOOFER ON/OFF)
LINE OUT Jack SUB WOOFER OUT Jack
(1/4" phone type) (1/4" phone type)
SUB WOOFER OUT Jack PHONES Jack
(1/4" phone type) (1/4" TRS phone type,
mono signal output)
PHONES Jack
(1/4" TRS phone type,
mono signal output)
AC 117 V, AC 230 V, AC 240 V AC 117 V, AC 230 V, AC 240 V AC 117 V, AC 230 V, AC 240 V
55 W 45 W 135 W
480 (W) x 295 (D) x 435 420 (W) x 300 (D) x 410 438 (W) x 440 (D) x 460
(H) mm, 18-15/16 (W) x (H) mm, 16-9/16 (W) x (H) mm, 17-1/4 (W) x 17-
11-5/8 (D) x 17-1/8 (H) 11-13/16 (D) x 16-3/16 (H) 3/8 (D) x 18-1/8 (H)
inches inches inches
14.0 kg, 30 lbs 14 oz 12.5 kg, 27 lbs 9 oz 23.0 kg, 50 lbs 12 oz
Owner's Manual,
Owner's Manual
Owner's Manual
Power Cord
* 0 dBu = 0.775 Vrms
C - 1000
Stereo Mixing Keyboard Amplifier
All specifications and appearances are subject to change.
All trademarks are the property of their respective companies.
Printed in Japan September 2002 RAM-3612 ERK-NK ADE-2
Simp ly th e Bes t
