Pakole ZENIT 80+ User Manual

Propane or natural gas-fired zenit-type tube radiant heater
Hide thumbs Also See for ZENIT 80+:
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
PROPANE OR NATURAL GAS-FIRED
ZENIT-TYPE TUBE RADIANT HEATER
Appliance types:
ZENIT 80
12...42
+
Linear - and "U"- form types.
EN
www.pakole.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZENIT 80+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pakole ZENIT 80+

Summary of Contents for Pakole ZENIT 80+

  • Page 1 User’s Manual PROPANE OR NATURAL GAS-FIRED ZENIT-TYPE TUBE RADIANT HEATER Appliance types: ZENIT 80 12...42 Linear - and “U”- form types. www.pakole.com...

  • Page 2: Table Of Contents

    ZENIT Contents TYPE TUBE RADIANT HEATER Contents 1. Safety information ........................3 2. General Instruction .........................4 Installer’s responsibilities ......................4 Data board ..........................4 Corrosive materials ........................5 Standards and laws ........................5 Safety signs ..........................5 Safe usage ..........................5 3. Transportation, unpacking, handling ...................6 4. Operation principle ........................6 5.

  • Page 3: Safety Information

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Safety information Read and understand this manual thoroughly before installing starting or servicing this equipment. The improper installation or using can cause serious damages! Keep this manual in a safe place in order to obtain information in case of incidental problems! GENERAL SAFETY NOTICES Disregard of instructions and notices of this Manual can cause serious bodily injuries or damages...

  • Page 4: General Instruction

    The appliance is equipped with data board, which is placed on outside of device’s door. On this data board there are information con- cerning the type of device, gas type, electrical connection and flue types. Manufacturer Type PAKOLE Trade Kft. ZENIT-32/L/80+ 8000 Székesfehérvár, Nominal input: 32 kW Börgöndi út 8-10.

  • Page 5: Corrosive Materials

    Qualified service engineers are those having specific technical experience and/or valid license in the field of heating and cooling in- stallation for home and industry. In any case, call the Manufacturer office or the closest dealer (www.pakole.com) and ask for further informations.

  • Page 6: Transportation, Unpacking, Handling

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER ATTENTION • Never use the unit to support other equipment. • Never leave tools, spare parts, etc. inside the unit. • Make sure that all inspection panels are closed properly. • Do no expose the unit to inflammable gases. FORBIDDEN! ATTENTION •...

  • Page 7: Installation

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Installation Components of „I” -form tube radiant heater, assembly distances Reflector Burner Electrical connection 2. picture: “I”-form appliance Components of „U”-form tube radiant heater, assembly distances U-element Combi hanger 3. picture: “U”- form appliance...

  • Page 8: Appliance Installation

    The appliance has to be placed in that way that its every part be accessible. WARNING! Only a qualified person can install the appliances who participated in training which was organised by Pakole Trade Kft in every year. It is forbidden to install the device as an user. 1 2 1 1 1 0 Attachment of flexible gas pipe has to be directly to the outside threaded gas connection of appliance located on the back side of it.

  • Page 9: Regulatory Options

    After these the thermostat sut off the appliance. Type of thermostat can be: only use capable type of control which can handle the modulation control.(e.g.: FP-MOD type by Pakole Trade Kft.)

  • Page 10: Electrical Connection

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Electrical connection ATTENTION! Both the fan and the ignition control needs 230V/50Hz mains voltage. Before connecting the appliance to the gas pipe line, please disconnect it from the power line and close the gas valve front of the burner. The appliance must be connected to a grounded power supply system! If the above instructions are not followed that can lead to death, heavy injuries or property demages! VIGYÁZAT...
  • Page 11 ZENIT User’s Manual TYPE TUBE RADIANT HEATER The minimal mounting height Input (kW) mounting height (m) Bevitt teljesítmény (kW), beépítési magasság (m) Type Execution Location Típus Kivitel Szerelés Vízszintes horizontal „U” „U” alakú FORM ZENIT Egyenes horizontal Vízszintes „I” FORM „E”...

  • Page 12: Combustion-Air Supply

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Combustion-air supply Combustion air may be drawn in from more spaces. a) from inside (heated) space b) from outside, in case outside combustion-air system is connected to the fan. The combustion air must not drawn in from internal space in the following cases: •...
  • Page 13 ZENIT User’s Manual TYPE TUBE RADIANT HEATER In case of using more 90° elbows the following correction has to be considered: Correction 1 pc 90° elbow = 1 m exhaust tube (combustion products leading tube) Namelly using more than one 90° elbow the lenght of exhaust system has to be proportionally reduced with the corrective value. The exit module of exhaust system must be at least higher than 1 m from openings(sucking hole of vent etc.) of force-assisted ventilation systems.

  • Page 14: Exhoust Out Taking +Combustion Air Intaking

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER c) Slanting roof exit flue (B23) 14.picture: Flue leading across slanting roof d) Appliances with common exit flue (B33) Zenit Tube Radiant Heaters Zenit Tube Radiant Heaters 15.picture: Common flue vent set Exhoust out taking +combustion air intaking A) Coaxial side wall flue vent set (C13) Ø...
  • Page 15 ZENIT User’s Manual TYPE TUBE RADIANT HEATER b) Coaxial roof vent set (C33) Roof flue vent and combustion air intake element Ø 100mm INOX fule element Ø 100mm INOX combustion Air tube 17.picture: Coaxial roof vent set c) Linear type tube heater with closed burning flue vent system (C53) Vertical flue vent element Ø...

  • Page 16: Appliance Operation

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Appliance operation ATTENTION! The installation of appliance must be only executed by qualified service or specialist authorized by retailer. The 2 years guarantee of appliance can be ensured only in this case. Before putting operation of appliance the leak-proof/pressure test of gas supply system must be fulfilled. •...

  • Page 17: Maintance

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER In case during 5 seconds sparking (ignition) the continuous flame shape is stabilized, - and stable electrical signal is come back from the electrode – the appliance operates and the green control lamp is lighting. During operation of appliance its automatic burner control con- trols the condition of differential pressure switch and signals coming from the flame control continuously, and if the position of differential pressure switch is changed –...

  • Page 18: Maintenance Supervisions By A Qualified Service Department

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER ATTENTION! Before any maintenance operation tha appliance must be disconnected from the power supply by turn off the electrical main switch and pull out the electrical plug on the back of the appliance. ATTENTION! In case operational circumstances of appliance (atmosphere is contaminated with corrosive substances, dirt etc.) need it, then supervision and cleaning may have done more often! The main reason of this that the settled dirt on the radiant tubes can damage...

  • Page 19: Enclosure

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Enclosure Enclosure 1.: Variety-list of ZENIT 80+ -type tube radiant heaters (Minimum and maximum pipe lengths allowed for full lengths) ZENIT selection list of tube radiants Full lenght (m ) Input Type Power (kW) ZENIT -12/8 12,8/7,9...

  • Page 20: Enclosure 2.: Heating And Consumption Values Of Zenit 80+ -Type Tube Radiant Heaters

    ZENIT User’s Manual TYPE TUBE RADIANT HEATER Enclosure 2.: Heating and consumption values of ZENIT 80 -type tube radiant heaters Gas consumption Input power Type kg/h (kW) Natural gas Propan ZENIT -12/8 12,8/7,9 1,34/0,83 1,07/0,66 1,03/0,64 ZENIT -14/9,3 14,1/8,9 1,48/0,93 1,18/0,74 1,14/0,72 ZENIT...

  • Page 21: Eco-Design Declaration Of Conformity

    - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 22 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 23 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 24 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 25 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 26 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 27 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 28 - Singl stage (ON-OFF) output At minimum heat 0,06 - Two stage (100%-60%-OFF) output In standby - Modulated mode Permanent pilot flame power requirement Pilot flame pow- er requirement pilot (if applicable) Contact PAKOLE Trade Kft. H-8000, Székesfehérvár, Börgöndi út, 8-10 details...
  • Page 29 If you would like to contact us the type and serial number of device always be at hand. In case of other needed information write to the following address: PAKOLE TRADE Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. Tel.: +36 22 316 484...
  • Page 30 PAKOLE TRADE Ipari és Kereskedelmi Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. http://www.pakole.com E-mail: mail@pakole.hu Tel.: +36 22 316 484 Fax: +36 22 316 074...
