Page 1 TS8300 series Online Manual English...
Page 2: Table Of Contents
Canon IJ Network Device Setup Utility Screen........
Page 3 Handling Paper, Originals, Ink Tanks, Multi-purpose Tray, Memory Card, etc.. Loading Paper............Paper Sources.
Page 4 Deep Print Head Cleaning............159 Aligning the Print Head.
Page 5 Setting the Ink to be Used............223 Managing the Printer Power.
Page 6 Canon IJ Status Monitor Description........
Page 7 Scanning............370 Scanning from Computer (Windows).
Page 8 Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Wireless Router Settings........... . 425 Cannot Proceed beyond Printer Connection Screen.
Page 9 Failed to MP Drivers Installation (Windows)..........484 Updating MP Drivers in Network Environment (Windows).
Page 10 6000..............533 C000.
Page 11: Using Online Manual
Using Online Manual Operating Environment Symbols Used in This Document Touch-enabled Device Users (Windows) Printing Online Manual Trademarks and Licenses Screenshots in This Manual...
Page 12: Symbols Used In This Document
Symbols Used in This Document Warning Instructions that, if ignored, could result in death, serious personal injury, or property damage caused by incorrect operation of the equipment. These must be observed for safe operation. Caution Instructions that, if ignored, could result in personal injury or property damage caused by incorrect operation of the equipment.
Page 13: Touch-Enabled Device Users (Windows)
Touch-enabled Device Users (Windows) For touch actions, you need to replace "right-click" in this document with the action set on the operating system. For example, if the action is set to "press and hold" on your operating system, replace "right-click" with "press and hold."...
Page 14: Trademarks And Licenses
(1998) are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. and licensed to Canon Inc. • Autodesk and AutoCAD are registered trademarks or trademarks of Autodesk, Inc., and/or its subsidiaries and/or affiliates in the USA and/or other countries.
Page 15 Apache License Version 2.0, January 2004 http://www.apache.org/licenses/ TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION 1. Definitions. "License" shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9 of this document. "Licensor" shall mean the copyright owner or entity authorized by the copyright owner that is granting the License.
Page 16 2. Grant of Copyright License. Subject to the terms and conditions of this License, each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable copyright license to reproduce, prepare Derivative Works of, publicly display, publicly perform, sublicense, and distribute the Work and such Derivative Works in Source or Object form. 3.
Page 17 7. Disclaimer of Warranty. Unless required by applicable law or agreed to in writing, Licensor provides the Work (and each Contributor provides its Contributions) on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied, including, without limitation, any warranties or conditions of TITLE, NON-INFRINGEMENT, MERCHANTABILITY, or FITNESS FOR A PARTICULAR PURPOSE.
Page 18 Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
Page 19 Use is subject to license terms below. This distribution may include materials developed by third parties. Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 20 TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. ---- Part 6: Cisco/BUPTNIC copyright notice (BSD) ----- Copyright (c) 2004, Cisco, Inc and Information Network Center of Beijing University of Posts and Telecommunications.
Page 21 SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 22 FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 23 MIT License Copyright (c) 1998, 1999, 2000 Thai Open Source Software Center Ltd Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:...
Page 24 CONCERNING THE MERCHANTABILITY OF THIS SOFTWARE OR ITS FITNESS FOR ANY PARTICULAR PURPOSE. (1) Red Hat Incorporated Copyright (c) 1994-2009 Red Hat, Inc. All rights reserved. This copyrighted material is made available to anyone wishing to use, modify, copy, or redistribute it subject to the terms and conditions of the BSD License.
Page 25 The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project. This license applies to all files found in such packages, and which do not fall under their own explicit license.
Page 26 The FreeType Project is copyright (C) 1996-2000 by David Turner, Robert Wilhelm, and Werner Lemberg. All rights reserved except as specified below. 1. No Warranty -------------- THE FREETYPE PROJECT IS PROVIDED `AS IS' WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Page 27 Discusses general use and applications of FreeType, as well as future and wanted additions to the library and distribution. If you are looking for support, start in this list if you haven't found anything to help you in the documentation. o freetype-devel@nongnu.org Discusses bugs, as well as engine internals, design issues, specific licenses, porting, etc.
Page 28 THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL COPYRIGHT HOLDERS AND CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
Page 29: Basic Operation
Basic Operation Printing Photos from a Computer Printing Photos from a Smartphone/Tablet Copying Printing Photos from Memory Card Printing a Disc Label from a Computer Copying a Disc Label...
Page 30: Printing Photos From A Computer
Printing Photos from a Computer This section describes how to print photos with Easy-PhotoPrint Editor. 1. Open rear tray cover (A). Pull straight up and fold back paper support (B). 2. Open the feed slot cover (C). 3. Slide right paper guide (D) to open both paper guides. 4.
Page 31 5. Slide right paper guide (D) to align with both sides of paper stack. 6. Close feed slot cover (C) gently. After closing the feed slot cover, the paper setting confirmation screen for the rear tray appears on the touch screen.
Page 32 From the Start menu, select (All apps >) Canon Utilities > Easy-PhotoPrint Editor. For macOS: From the Go menu in Finder, select Application and double-click the Canon Utilities folder, the Easy- PhotoPrint Editor folder, and then the Easy-PhotoPrint Editor icon.
Page 33 11. Click photos (G) you want to print and select Open (H). For Windows: To select two or more photos at a time, click photos while pressing the Ctrl key. For macOS: To select two or more photos at a time, click photos while pressing the command key. 12.
Page 34 For Windows: Click Print (J). For macOS: Click Next. When the Print dialog appears, specify your model name, paper, and other options, and then click Print. The operation panel is opened and the paper output tray is pulled out automatically, then printing will start.
Page 35: Printing Photos From A Smartphone/Tablet
Printing Photos from a Smartphone/Tablet This section describes how to print photos with Canon PRINT Inkjet/SELPHY. For details on how to download Canon PRINT Inkjet/SELPHY, see below. Print Photos from Your Smartphone 1. Open rear tray cover (A). Pull straight up and fold back paper support (B).
Page 36 5. Slide right paper guide (D) to align with both sides of paper stack. 6. Close feed slot cover (C) gently. After closing the feed slot cover, the paper setting confirmation screen for the rear tray appears on the touch screen.
Page 37 If not, select Change to change the settings in accordance with the size and type of the loaded paper. 8. Start (Canon PRINT Inkjet/SELPHY) from your smartphone/tablet. 9. Select Photo Print on Canon PRINT Inkjet/SELPHY. The list of photos saved on your smartphone/tablet is displayed. 10. Select a photo.
Page 38: Copying
Copying This section describes how to load originals and copy them to plain paper loaded in the cassette. 1. Pull out the cassette (A) from the printer. 2. Remove the cassette cover (B). 3. Slide paper guides (C) in front and (D) on right to open guides. 4.
Page 39 5. Align paper guides (C) in front and (D) on right with paper length and width. 6. Mount cassette cover (B) and insert cassette into printer.
Page 40 7. Select Copy (E) on HOME screen. 8. Select Standard copy. 9. Open document cover (F). 10. Load original WITH SIDE TO COPY FACING DOWN and align it with alignment mark (G). 11. Close the document cover. 12. Check paper settings and tap Black (H) or Color (I). The operation panel is opened and the paper output tray is pulled out automatically, then copying will start.
Page 41 Important • Do not open the document cover until copying is complete. Note • Your printer is equipped with many other convenient copy features. Copying...
Page 42: Printing Photos From Memory Card
Printing Photos from Memory Card This section describes how to print photos on a memory card. 1. Open rear tray cover (A). Pull straight up and fold back paper support (B). 2. Open the feed slot cover (C). 3. Slide right paper guide (D) to open both paper guides. 4.
Page 43 5. Slide right paper guide (D) to align with both sides of paper stack. 6. Close feed slot cover (C) gently. After closing the feed slot cover, the paper setting confirmation screen for the rear tray appears on the touch screen.
Page 44 7. If page size and media type on touch screen match size and type of paper loaded in rear tray, select Yes. If not, select Change to change the settings in accordance with the size and type of the loaded paper. 8.
Page 45 The operation panel is opened and the paper output tray is pulled out automatically, then printing will start. Important • Do not remove the memory card during printing. Data on the memory card may be damaged. Note • Your printer is equipped with many other convenient photo print features. Printing Photo Data...
Page 46: Printing A Disc Label From A Computer
From the Start menu, select (All apps >) Canon Utilities > Easy-PhotoPrint Editor. For macOS: From the Go menu in Finder, select Application and double-click the Canon Utilities folder, the Easy- PhotoPrint Editor folder, and then the Easy-PhotoPrint Editor icon.
Page 47 4. Select type of printable disc (C) and select Next (D). 5. Click Browse (E) in Computer: and select folder with photos you want to print. 6. Click photos (F) you want to print and select Open (G). 7. Edit disc label and select Next (H). You can change the background or add texts.
Page 48 8. Open operation panel (I) until horizontal. 9. Specify number of copies and other options under Print Settings (J). For Windows: Specify the number of copies, your printer name, and other options. For macOS: Specify the number of copies and other options. 10.
Page 49 11. When message prompting you to load printable disc appears on printer's touch screen, take out multi-purpose tray from multi-purpose tray storage compartment (L). 12. Place printable disc on multi-purpose tray. 1. WITH PRINT SIDE FACING UP, place printable disc, and press it against lock (M) at bottom. 2.
Page 50 13. Place multi-purpose tray on multi-purpose tray guide. 14. Insert multi-purpose tray straight in in horizontal direction until arrow ( ) on multi-purpose tray guide is approximately aligned with arrow ( ) on multi-purpose tray. 15. Select OK on printer's touch screen. The multi-purpose tray is drawn into the printer and printing will start.
Page 51 17. While pressing down lock (M), take out printable disc from slits (N) on multi-purpose tray, and remove it. Note • Easy-PhotoPrint Editor enables you to print photos onto the disc label with various layouts. Easy-PhotoPrint Editor Guide...
Page 52: Copying A Disc Label
Copying a Disc Label This section describes how to copy the label of an existing disc (BD/DVD/CD, etc.) and print it onto a printable disc. 1. Select Copy (A) on the HOME screen. 2. Select Disc label copy (B). 3. Check message and select OK. 4.
Page 53 5. Specify the amount of ink (E). If the print result is blurry, select Bleed-proof. Blurring may be reduced by printing with less ink. 6. Open the document cover (F). 7. Load copy source (BD/DVD/CD, etc.) WITH ITS LABEL SIDE DOWN on platen. 8.
Page 54 11. Tap Black (H) or Color (I). A message prompting you to load the printable disc is displayed. 12. Take out multi-purpose tray from multi-purpose tray storage compartment (J). 13. Place printable disc on multi-purpose tray. 1. WITH PRINT SIDE FACING UP, place printable disc, and press it against lock (K) at bottom.
Page 55 2. While pressing down lock with printable disc, insert top of printable disc into slits (L). 14. Place multi-purpose tray on multi-purpose tray guide. 15. Insert multi-purpose tray straight in in horizontal direction until arrow ( ) on multi-purpose tray guide is approximately aligned with arrow ( ) on multi-purpose tray.
Page 56 18. While pressing down lock (K), take out printable disc from slits (L) on multi-purpose tray, and remove it. Note • Your printer is equipped with many other disc label print features. Disc Label Printing...
Page 57: Network
Network Available Connection Methods The following connection methods are available on the printer. • Wireless Connection Connect the printer and devices (e.g. computer/smartphone/tablet) using a wireless router. If you have a wireless router, we recommend you use one for wireless connection. ◦...
Page 58 Changing Network Settings See below for changing connection settings for the printer and computer/smartphone/tablet. • To change network connection method: Reconfiguration Method of Wi-Fi Connection Changing the Connection Mode • To add computer/smartphone/tablet to the printer: Connects to Another Computer via LAN/Changes from USB to LAN Connection •...
Page 59: Restrictions
Restrictions When connecting another device while a device (such as a computer) is already connected to the printer, connect it using the same connection method as the connected device. If you connect using a different connection method, the connection to the device in use will be disabled. Connect via wireless router •...
Page 60 • In Wireless Direct mode, you can connect up to five devices at the same time. If you try to connect a sixth device while five devices are already connected, an error will appear. If an error appears, disconnect a device that does not use the printer, then configure settings again. •...
Page 61: Network Connection Tips
Network Connection Tips Default Network Settings Detect Same Printer Name Connects to Another Computer via LAN/Changes from USB to LAN Connection Printing Network Settings Reconfiguration Method of Wi-Fi Connection...
Page 62: Default Network Settings
Enable/disable IPv6 Enable Enable/disable WSD Enable Timeout setting 15 minutes Enable/disable Bonjour Enable Service name Canon TS8300 series LPR protocol setting Enable RAW protocol Enable LLMNR Enable PictBridge communication Enable ("XX" represents alphanumeric characters.) * Default value depends on printer. To check value, use operation panel.
Page 63 *1 "ab" is specified at random and "XX" represents last two digits of printer's MAC address. (The value is specified when the printer is turned on for the first time.) *2 The password is specified automatically when the printer is turned on for the first time.
Page 64: Detect Same Printer Name
Detect Same Printer Name When the printer is detected during setup, plural printers with the same name may appear on the results screen. Select a printer with checking the printer settings against those on detection result screen. • For Windows: Check the printer's MAC address or serial to select the correct printer from the results.
Page 65: Connects To Another Computer Via Lan/Changes From Usb To Lan Connection
Connects to Another Computer via LAN/Changes from USB to LAN Connection To connect an additional computer to the printer via LAN, or to change from USB to LAN connection, click here and perform setup.
Page 66: Printing Network Settings
Product information – Product Name Product name XXXXXXXX ROM Version ROM version XXXXXXXX Serial Number Serial number XXXXXXXX Network Diagnostics Network diagnostics – Diagnostic Result Diagnostic result XXXXXXXX Result Codes Result codes XXXXXXXX Result Code Details Result code details http://canon.com/ijnwt...
Page 67 Wireless LAN Wireless LAN Enable/Disable Infrastructure Infrastructure Enable/Disable 3-2-1 Signal Strength Signal strength 0 to 100 [%] 3-2-2 Link Quality Link quality 0 to 100 [%] 3-2-3 Frequency Frequency XX (GHz) 3-2-4 MAC Address MAC address XX:XX:XX:XX:XX:XX 3-2-5 Connection Connection status Active/Inactive 3-2-6 SSID...
Page 68 XXXX:XXXX:XXXX:XXXX 3-2-23 Stateless Prefix Stateless prefix length Length3 3-2-24 Stateless Address4 Stateless address 4 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-25 Stateless Prefix Stateless prefix length Length4 3-2-26 Default Gateway1 Default gateway 1 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-27 Default Gateway2 Default gateway 2 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-28 Default Gateway3 Default gateway 3 XXXX:XXXX:XXXX:XXXX...
Page 69 3-3-12 TCP/IPv6 TCP/IPv6 Enable/Disable 3-3-13 Link Local Address Link local address XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-3-14 Link Local Prefix Link local prefix length Length 3-3-15 IPsec IPsec setting Active 3-3-16 Security Protocol Security method – 3-3-17 Wireless LAN DRX Discontinuous recep- Enable/Disable tion (wireless direct) Other Settings Other settings...
Page 70 5-20 Cert. Fingerprt(SHA-1) Certificate finger- xxxxxxxx xxxxxxxx xxxxxxxx print(SHA-1) xxxxxxxx xxxxxxxx 5-21 Cert. Fin- Certificate finger- xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx gerprt(SHA-256) print(SHA-256) xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx Bluetooth Bluetooth settings – Bluetooth Setting Bluetooth Enable/Disable Bluetooth Device Ad- Bluetooth device ad- XXXXXXXX dress dress of the printer...
Page 71: Reconfiguration Method Of Wi-Fi Connection
Reconfiguration Method of Wi-Fi Connection Follow either procedure below to change Wi-Fi connection method (infrastructure or Wireless Direct). • For Windows: ◦ Click here and redo setup. ◦ Perform settings on the Network Settings screen on IJ Network Device Setup Utility. Important •...
Page 72: Ij Network Device Setup Utility (Windows)
IJ Network Device Setup Utility (Windows) IJ Network Device Setup Utility Starting Up IJ Network Device Setup Utility Diagnosing and Repairing Network Settings Performing/Changing Network Settings List of Models Which Does Not Support Diagnosis and Repair Function List of Models Which Does Not Support IPv6 Configuration via USB Connection...
Page 73: Ij Network Device Setup Utility
IJ Network Device Setup Utility IJ Network Device Setup Utility allows you to diagnose or repair the network status, and to perform printer settings on network. Use IJ Network Device Setup Utility for: • Searching printers on network and performing initial network setup for detected printers •...
Page 74: Starting Up Ij Network Device Setup Utility
Start up IJ Network Device Setup Utility as shown below. • In Windows 10, select Start > (All apps > ) > Canon Utilities > IJ Network Device Setup Utility. • In Windows 8.1 or Windows 8, select IJ Network Device Setup Utility on the Start screen to start IJ Network Device Setup Utility.
Page 75: Diagnosing And Repairing Network Settings
Diagnosing and Repairing Network Settings IJ Network Device Setup Utility diagnoses and repairs computer settings or connection between the computer and printer when a problem (e.g. cannot print from a printer on the network) occurs. Important • Some models do not support diagnosis and repair function. For details: List of Models Which Does Not Support Diagnosis and Repair Function Follow the procedure below.
Page 76: Performing/Changing Network Settings
Performing/Changing Network Settings Canon IJ Network Device Setup Utility Screen Performing Network Settings...
Page 77: Canon Ij Network Device Setup Utility Screen
Items on Canon IJ Network Device Setup Utility Screen Menus on Canon IJ Network Device Setup Utility Screen Items on Canon IJ Network Device Setup Utility Screen Toolbar Items on Canon IJ Network Device Setup Utility Screen The screen below appears when you start up IJ Network Device Setup Utility and select Printer Network Setup.
Page 78 Appears after performing network setup and clicking Set to close the window. • Requires Setup Indicates the printer is required to perform Wi-Fi setup. Performing/Changing Wi-Fi Settings • Not Set Indicates the printer cannot be used on network, or IPv6 is disabled. Specify an IP address or enable IPv6 on Network Settings..
Page 79 Selecting a printer from the printer list displays its current status and what to do next. Menus on Canon IJ Network Device Setup Utility Screen This section describes menus on Canon IJ Network Device Setup Utility screen. A: Printer Settings menu...
Page 80 D: Help menu Help Menu Items on Canon IJ Network Device Setup Utility Screen Toolbar This section describes items on Canon IJ Network Device Setup Utility Screen toolbar. A: Perform wired or Wi-Fi setup. Note • This item has the same function as Network Settings... in the Printer Settings menu.
Page 81: Performing Network Settings
Performing Network Settings Performing/Changing Wired LAN Connection (Ethernet Cable) Settings Performing/Changing Wi-Fi Settings Assigning Printer Information...
Page 82: Performing/Changing Wired Lan Connection (Ethernet Cable) Settings
Performing/Changing Wired LAN Connection (Ethernet Cable) Settings Follow the procedure below to perform/change wired LAN settings. Note • For some models, you can perform network setup for a USB connected printer using IJ Network Device Setup Utility. Select USB on Switch View under the View menu to display printers for which you can perform setup.
Page 83 7. Perform/change settings. You can switch the screen between IPv4 and IPv6. Click the tab to switch the protocol. • IPv4 settings A: Use IPv4 address Always selected. (displayed in a gray out state) B: Get IP address automatically Select this option to use an IP address automatically assigned by a DHCP server. DHCP server functionality must be enabled on your router.
Page 84 A: Use IPv6 address Select when you use the printer with IPv6 environment. B: Use Stateless Address: Select when you use an IP address assigned automatically. Use a router compatible with IPv6. Note • This setting item is not available depending on the printer you are using. C: Use Manual Address: Select this option if no DHCP server functionality is available in your setup where you use the printer, or you want to use a fixed IP address.
Page 85: Performing/Changing Wi-Fi Settings
Performing/Changing Wi-Fi Settings Follow the procedure below to perform/change Wi-Fi settings. Important • Enable Easy wireless connect (Cableless setup) before performing printer setup. (Not required if you change the IP address.) For details, search for "NR049" on your printer's online manual and see the page shown.
Page 86 Select Wi-Fi and click OK. 6. Enter password and click OK. The Network Settings screen appears. 7. Perform/change settings. You can switch the screen between IPv4 and IPv6. Click the tab to switch the protocol. • IPv4/IPv6 settings A: Network Type: Select the Wi-Fi mode.
Page 87 The network name (SSID) for Wireless Direct appears while in Wireless Direct. C: Search... The Detected Wireless Routers screen is displayed to select a wireless router to connect to. For a wireless router already connected to the computer, Available is displayed on Communication Status.
Page 88 Enter the IP address, subnet mask, and default gateway. • IPv6 settings Note • If you select a USB connected printer on step 4, you cannot perform IPv6 settings depending on the printer you are using. For details, see List of Models Which Does Not Support IPv6 Configuration via USB Connection.
Page 89 D: Use DHCPv6: Select when you obtain an IP address using DHCPv6. Note • This setting item is not available depending on the printer you are using. 8. Click Set.
Page 90: Assigning Printer Information
Assigning Printer Information Follow the procedure below to assign/change printer location name or device name. The names appear on Device Name: and Location: on the Canon IJ Network Device Setup Utility screen. Note • If USB is selected from the pulldown menu on the toolbar, this setting item is not available.
Page 91: List Of Models Which Does Not Support Diagnosis And Repair Function
List of Models Which Does Not Support Diagnosis and Repair Function The following models does not support "Diagnose and Repair" function of IJ Network Device Setup Utility. • G4000 series • PRO-500 series • PRO-1000 series • MB2100 series • MB2700 series •...
Page 92: List Of Models Which Does Not Support Ipv6 Configuration Via Usb Connection
List of Models Which Does Not Support IPv6 Configuration via USB Connection For the following models, you can perform settings only for IPv4 using IJ Network Device Setup Utility. (You cannot perform settings for IPv6.) • iB4100 series • MG3000 series •...
Page 93 • TR9530 series • TS3300 series • E3300 series...
Page 94: Handling Paper, Originals, Ink Tanks, Multi-Purpose Tray, Memory Card, Etc
Handling Paper, Originals, Ink Tanks, Multi-purpose Tray, Memory Card, etc. Loading Paper Placing Multi-purpose Tray Loading Originals Inserting the Memory Card Replacing Ink Tanks...
Page 95: Loading Paper
Loading Paper Paper Sources Loading Paper in the Rear Tray Loading Paper in the Cassette Loading Envelopes in Rear Tray...
Page 96: Paper Sources
Paper Sources The printer has two paper sources for feeding paper, the rear tray (A) and cassette (B). You can load all supported paper on the rear tray. Supported Media Types You can load A4, B5, A5, or Letter-sized plain paper in the cassette. Note •...
Page 97: Loading Paper In The Rear Tray
For details on the Canon genuine paper, see Supported Media Types. • You can use general copy paper or Canon Red Label Superior WOP111/Canon Océ Office Colour Paper SAT213. For the page size and paper weight you can use for this printer, see Supported Media Types.
Page 98 3. Open the feed slot cover (C). 4. Slide right paper guide (D) to open both paper guides. 5. Load paper stack in portrait orientation WITH PRINT SIDE FACING UP.
Page 99 6. Slide right paper guide (D) to align with both sides of paper stack. Do not slide the paper guides too hard against the paper. The paper may not be fed properly. Important • Always load paper in portrait orientation (E). Loading paper in landscape orientation (F) can cause paper jams.
Page 100 7. Close feed slot cover (C) gently. After closing the feed slot cover, the paper setting confirmation screen for the rear tray appears on the touch screen. 8. If page size and media type on touch screen match size and type of paper loaded in rear tray, select Yes.
Page 101 Note • When printing starts, the operation panel is opened and the paper output tray is pulled out automatically. • There are various types of paper, such as paper with a special surface coating for printing photos at optimal quality and paper suitable for documents. Each media type has specific preset settings (how ink is used and sprayed, distance from nozzles, etc.), that allow you to print to that type with optimal image quality.
Page 102: Loading Paper In The Cassette
Note • In the cassette, be sure to load only plain paper. • You can use general copy paper or Canon Red Label Superior WOP111/Canon Océ Office Colour Paper SAT213. For the page size and paper weight you can use for this printer, see Supported Media Types.
Page 103 4. Slide paper guides (C) in front and (D) on right to open guides. 5. Load paper stack in portrait orientation WITH PRINT SIDE FACING DOWN, and place it in center of cassette. Important • Always load paper in portrait orientation (E). Loading paper in landscape orientation (F) can cause paper jams.
Page 104 6. Slide front paper guide (C) to align it with paper stack. Align paper guide with where it clicks into place. 7. Slide right paper guide (D) to align it with paper stack. Do not slide the paper guide too hard against the paper. The paper may not be fed properly. Note •...
Page 105 8. Mount cassette cover (B) and insert cassette into printer. Push the cassette into the printer until it stops. Note • When printing starts, the operation panel is opened and the paper output tray is pulled out automatically. • To prevent incorrect printing, this printer has a function that detects whether the settings for the paper loaded in the cassette matches the paper settings.
Page 107: Loading Envelopes In Rear Tray
Loading Envelopes in Rear Tray You can load Envelope DL and Envelope Com 10 on the rear tray. The address is automatically rotated and printed according to the envelope's direction by specifying with the printer driver properly. Important • Printing of envelopes from the operation panel or from a PictBridge (Wi-Fi) compliant device is not supported.
Page 108 3. Open the feed slot cover (C). 4. Slide right paper guide (D) to open both paper guides. 5. Load envelopes in portrait orientation WITH PRINT SIDE FACING UP. Up to 10 envelopes can be loaded at once. Fold flap of the envelope and load the envelope in portrait orientation with the address side facing up. 6.
Page 109 Do not slide the paper guides too hard against the envelopes. The envelopes may not be fed properly. Note • Do not load envelopes higher than the load limit mark (E). 7. Close feed slot cover (C) gently.
Page 110 After closing the feed slot cover, the paper setting confirmation screen for the rear tray appears on the touch screen. 8. If page size and media type shown on touch screen match size and type of envelopes loaded in rear tray, select Yes. If not, select Change to change the settings in accordance with the size and type of the loaded envelopes.
Page 111: Placing Multi-Purpose Tray
Placing Multi-purpose Tray Cautions When Printing with Multi-purpose Tray Placing a Printable Disc Placing Printable Nail Stickers...
Page 112: Cautions When Printing With Multi-Purpose Tray
Cautions When Printing with Multi-purpose Tray Cautions Common to using Multi-purpose Tray • Be sure to use the multi-purpose tray supplied with this printer. • Do not mount the multi-purpose tray while the printer is in operation. • Do not remove the multi-purpose tray while the printer is in operation. Doing so may damage the printer, the multi-purpose tray, or the media.
Page 113: Placing A Printable Disc
Placing a Printable Disc Before Placing a Printable Disc Placing a Printable Disc Removing a Printable Disc...
Page 114: Before Placing A Printable Disc
Before Placing a Printable Disc A printable disc differs from regular disc (BD/DVD/CD, etc.) in that its label surface has been specially processed or printing by an inkjet printer. The following items are needed to print onto the printable disc. •...
Page 115: Placing A Printable Disc
Placing a Printable Disc To print onto a printable disc, place it on the supplied multi-purpose tray, and then insert it into the printer. This procedure also applies to printing from a computer. Important • Do not mount the multi-purpose tray until the message prompting you to load the printable disc appears.
Page 116 1. WITH PRINT SIDE FACING UP, place printable disc, and press it against lock (C) at bottom. 2. While pressing down lock with printable disc, insert top of printable disc into slits (D). 3. Place multi-purpose tray on multi-purpose tray guide.
Page 117 4. Insert multi-purpose tray straight in in horizontal direction until arrow ( ) on multi-purpose tray guide is approximately aligned with arrow ( ) on multi-purpose tray. Important • Do not insert the multi-purpose tray beyond the arrow ( ) on the multi-purpose tray guide. Note •...
Page 118: Removing A Printable Disc
Removing a Printable Disc 1. Pull out multi-purpose tray. 2. While pressing down lock (A), take out printable disc from slits (B) on multi-purpose tray, and remove it. Important • Do not touch the printing surface when removing the disc from the multi-purpose tray. Note •...
Page 119: Placing Printable Nail Stickers
Placing Printable Nail Stickers Before Placing Printable Nail Stickers Placing Printable Nail Stickers Removing Printable Nail Stickers...
Page 120: Before Placing Printable Nail Stickers
Before Placing Printable Nail Stickers The following items are needed to print onto Printable Nail Stickers. • Multi-purpose tray (supplied with the printer) The multi-purpose tray is stored in the multi-purpose tray storage compartment of the paper output tray. • Printable Nail Stickers (NL-101) Note •...
Page 121: Placing Printable Nail Stickers
Placing Printable Nail Stickers To print onto Printable Nail Stickers, place them on the multi-purpose tray supplied with the printer, and then insert them into the printer. Important • Do not mount the multi-purpose tray until the message prompting you to load Printable Nail Stickers appears.
Page 122 1. WITH PRINT SIDE FACING UP, place Printable Nail Stickers and press it against lock (C) at bottom. 2. While pressing down lock with Printable Nail Stickers, insert two tabs (D) on top into slits (E) on multi-purpose tray. 3. Place multi-purpose tray on multi-purpose tray guide.
Page 123 4. Insert multi-purpose tray straight in in horizontal direction until arrow ( ) on multi-purpose tray guide is approximately aligned with arrow ( ) on multi-purpose tray. Important • Do not insert the multi-purpose tray beyond the arrow ( ) on the multi-purpose tray guide. Note •...
Page 124: Removing Printable Nail Stickers
Removing Printable Nail Stickers 1. Pull out multi-purpose tray. 2. Remove Printable Nail Stickers. While pressing down lock (A), remove two tabs (B) on the top out of slits (C). Important • Do not touch the printing surface when removing Printable Nail Stickers. Note •...
Page 125 4. Insert multi-purpose tray straight into multi-purpose tray storage compartment. When not using the multi-purpose tray, insert it in the multi-purpose tray storage compartment.
Page 126: Loading Originals
Loading Originals Loading Originals on Platen Loading Based on Use Supported Originals How to Detach / Attach the Document Cover...
Page 127: Loading Originals On Platen
Loading Originals on Platen 1. Open the document cover. 2. Load original WITH SIDE TO SCAN FACING DOWN on platen. Loading Based on Use Supported Originals Important • Be sure to observe the following when loading the original on the platen. Failure to observe the following may cause the scanner to malfunction or the platen glass to break.
Page 128 Important • After loading the original on the platen, be sure to close the document cover before starting to copy or scan.
Page 129: Loading Based On Use
Loading Based on Use Load the original in the correct position according to the function to use. If you do not load the original correctly, it may not be scanned properly. Originals Function How to Load Magazines, Newspapers, and Copying Loading the Original to Be Documents Aligned with the alignment mark...
Page 130 Loading the Original to Be Aligned with the alignment mark Place the original WITH THE SIDE TO SCAN FACING DOWN on the platen and align it with the alignment mark . Portions placed on the diagonally striped area cannot be scanned. Important •...
Page 131 Loading Two or More Originals on Platen Place the originals WITH THE SIDE TO SCAN FACING DOWN. Allow 0.40 in. (1 cm) or more space between the edges (diagonally striped area) of the platen and the originals, and between the originals. Portions placed on the diagonally striped area cannot be scanned.
Page 132: Supported Originals
Supported Originals Item Details Types of originals • Text document, magazine, or newspaper • Printed photo, postcard, business card, or disc (BD/DVD/CD, etc.) Size (width x height) Max. 8.5 x 11.7 in. (216 x 297 mm) Note • When loading a thick original such as a book on the platen, you can load it by removing the document cover from the printer.
Page 133: How To Detach / Attach The Document Cover
How to Detach / Attach the Document Cover Detaching the document cover: Hold up the document cover in portrait orientation and then tip it back. Attaching the document cover: Fit both hinges (A) of the document cover into the holder (B) and insert both hinges of the document cover vertically as illustrated below.
Page 135: Inserting The Memory Card
Inserting the Memory Card Before Inserting the Memory Card Inserting the Memory Card Removing the Memory Card...
Page 136: Before Inserting The Memory Card
Before Inserting the Memory Card The following types of memory cards and image data are compatible with the printer. Important • If you took and saved photos on a type of memory card that does not guarantee the operation on your PictBridge (Wi-Fi) compliant device, the image data may be unreadable on the printer or damaged.
Page 137 Printable Image Data • This printer accepts images taken with a camera compliant with the Design rule for Camera File system (Exif 2.2/2.21/2.3 compliant), TIFF (Exif 2.2/2.21/2.3 compliant). Other image or movie types such as RAW images cannot be printed. •...
Page 138: Inserting The Memory Card
Inserting the Memory Card Important • When a memory card is inserted into the card slot, the Access lamp is lit. When the Access lamp is flashing, the printer is accessing the memory card. In this case, do not touch the area around the card slot.
Page 139 Important • Part of the memory card will protrude from the card slot, but do not force it into the slot any further. This can damage the printer or the memory card. • Make sure that the memory card is correctly oriented before inserting it into the card slot. If you force the memory card into the card slot in the wrong orientation, the memory card or the printer can be damaged.
Page 140: Removing The Memory Card
Removing the Memory Card Important • If you used the card slot as the memory card drive of a computer, you must perform the "safe removal" operation on your computer before physically removing the memory card from the printer. Setting Up Card Slot as Memory Card Drive of Computer 1.
Page 141: Replacing Ink Tanks
Replacing Ink Tanks Replacing Ink Tanks Checking Ink Status on the Touch Screen Ink Tips...
Page 142: Replacing Ink Tanks
Replacing Ink Tanks When remaining ink cautions or errors occur, the message will appear on the touch screen to inform you of the error. In this state, the printer cannot print or scan. Take appropriate action according to the message. When Error Occurred Note •...
Page 143 Important • Do not touch other parts besides the ink tanks. • Handle the ink tank carefully to avoid staining of clothing or the surrounding area. • Discard the empty ink tank according to the local laws and regulations regarding disposal of consumables.
Page 144 5. Hold the ink tank with the orange protective cap (E) pointing up while being careful not to block the Y-shape air hole (D). 6. Lift up the tab on the orange protective cap (E) to remove it off GENTLY. Important •...
Page 145 8. Press on the top of the ink tank until the ink tank snaps firmly into place. Important • You cannot print if the ink tank is installed in the wrong position. Be sure to install the ink tank in the correct position according to the label on the print head holder.
Page 146 Caution • When closing the scanning unit / cover, be careful not to get your fingers caught. Note • If the error message appears after the scanning unit / cover is closed, take appropriate action. When Error Occurred • When you start printing after replacing the ink tank, the printer starts cleaning the print head automatically.
Page 147: Checking Ink Status On The Touch Screen
Checking Ink Status on the Touch Screen 1. Make sure that the power is turned on, and display the HOME screen. If the HOME screen is not displayed, tap (HOME) to display it. 2. Select (Hint) on HOME screen. Using the Operation Panel The hint menu screen will appear.
Page 148: Ink Tips
Ink may be used for purposes other than printing. When you use the Canon printer for the first time after you install the bundled ink tanks, the printer consumes a small amount of ink in the amount to enable printing by filling the nozzles of the Print Head with ink.
Page 149: If Printing Is Faint Or Uneven
If Printing Is Faint or Uneven Maintenance Procedure Printing the Nozzle Check Pattern Examining the Nozzle Check Pattern Cleaning the Print Head Deep Print Head Cleaning Aligning the Print Head Aligning the Print Head Manually...
Page 150: Maintenance Procedure
Maintenance Procedure If print results are blurred, colors are not printed correctly, or print results are unsatisfactory (e.g. misaligned printed ruled lines), perform the maintenance procedure below. Important • Do not rinse or wipe the print head and ink tank. This can cause trouble with the print head and ink tank.
Page 151 • When you have performed the procedure until step 4 and the problem has not been resolved, turn off the power and clean the print head deeply again after 24 hours. If the problem is still not resolved, the print head may be damaged. Contact your nearest Canon service center to request a repair.
Page 152 Adjusting Print Head Position...
Page 153: Printing The Nozzle Check Pattern
Printing the Nozzle Check Pattern Print the nozzle check pattern to determine whether the ink ejects properly from the print head nozzle. Note • If the remaining ink level is low, the nozzle check pattern will not be printed correctly. Replace the ink tank whose ink is low.
Page 154 Examine the nozzle check pattern.
Page 155: Examining The Nozzle Check Pattern
Examining the Nozzle Check Pattern Examine the nozzle check pattern, and clean the print head if necessary. 1. Check if there are missing lines in the pattern C or horizontal white streaks in the pattern D. A: No missing lines/No horizontal white streaks B: Lines are missing/Horizontal white streaks are present 2.
Page 156 For A (no missing lines or no horizontal white streaks) in both the pattern C and pattern D: The cleaning is not required. Select All A, confirm the message, then select OK. The screen will return to the Maintenance screen. For B (lines are missing or horizontal white streaks are present) in the pattern C or pattern D, or in both patterns: The cleaning is required.
Page 157: Cleaning The Print Head
Cleaning the Print Head Clean the print head if lines are missing or if horizontal white streaks are present in the printed nozzle check pattern. Cleaning unclogs the nozzles and restores the print head condition. Cleaning the print head consumes ink, so clean the print head only when necessary. You need to prepare: a sheet of A4 or Letter-sized plain paper Check that printer is turned on.
Page 158 The operation panel is opened and the paper output tray is pulled out automatically. The nozzle check pattern will be printed. Examine the nozzle check pattern. Note • If the problem is not resolved after cleaning the print head twice, clean the print head deeply.
Page 159: Deep Print Head Cleaning
Deep Print Head Cleaning If print quality does not improve by the standard cleaning of the print head, clean the print head deeply. Cleaning the print head deeply consumes more ink than the standard cleaning of the print head, so clean the print head deeply only when necessary.
Page 160 If the problem is not resolved, turn off the power and clean the print head deeply again after 24 hours. If the problem is still not resolved, the print head may be damaged. Contact your nearest Canon service center to request a repair.
Page 161: Aligning The Print Head
Aligning the Print Head If printed ruled lines are misaligned or print results are otherwise unsatisfactory, adjust the print head position. Note • If the remaining ink level is low, the print head alignment sheet will not be printed correctly. Replace the ink tank whose ink is low.
Page 162 The operation panel is opened and the paper output tray is pulled out automatically. The print head alignment sheet is printed, and the print head is aligned automatically. This takes about 4 minutes. Note • If automatic print head alignment fails, an error message appears on the touch screen. When Error Occurred 7.
Page 163: Aligning The Print Head Manually
Aligning the Print Head Manually Try aligning the print head manually after automatic print head alignment if printing results are not as expected, as when printed ruled lines are misaligned. Note • For details on automatic print head alignment, see Aligning the Print Head.
Page 164 The operation panel is opened and the paper output tray is pulled out automatically. The print head alignment pattern will be printed. 7. When Did the patterns print correctly? appears, make sure pattern was printed correctly, and if so, select Yes. 8.
Page 165 • If all patterns look different, choose the pattern in which horizontal streaks are least noticeable. Subtle horizontal streaks Noticeable horizontal streaks 10. Repeat these steps until you have finished entering pattern numbers for columns B to H, and then select OK. 11.
Page 166 13. Repeat these steps until you have finished entering pattern numbers for columns J to P, and then select OK. 14. Check message and select OK. The third set of patterns is printed. 15. Examine third patterns and tap a. In column a, find pattern in which stripes are least noticeable, and then select the number of that pattern.
Page 167: Cleaning
Cleaning Cleaning Exterior Surfaces Cleaning Platen and Document Cover Cleaning Paper Feed Rollers Cleaning Inside the Printer (Bottom Plate Cleaning) Cleaning Cassette Pads...
Page 168: Cleaning Paper Feed Rollers
Cleaning Paper Feed Rollers If the paper feed roller is dirty or paper powder is attached to it, paper may not be fed properly. In this case, clean the paper feed roller. Cleaning will wear out the paper feed roller, so perform this only when necessary.
Page 169 The printer starts cleaning. The cleaning will be complete when the paper is ejected. 11. When the completion message appears, select OK. If the problem is not resolved after cleaning the paper feed roller, contact your nearest Canon service center to request a repair.
Page 170: Cleaning Inside The Printer (Bottom Plate Cleaning)
Cleaning Inside the Printer (Bottom Plate Cleaning) Remove stains from the inside of the printer. If the inside of the printer becomes dirty, printed paper may get dirty, so we recommend performing cleaning regularly. You need to prepare: a sheet of A4 or Letter-sized plain paper* * Be sure to use a new piece of paper.
Page 171 9. Load only this sheet of paper in the cassette with the ridges of the creases facing up and the edge of the half with no crease facing to the far side. 10. Mount cassette cover (A) and insert cassette into printer. 11.
Page 172 Important • Be sure to turn off the power and unplug the power cord before cleaning the printer.
Page 173: Overview
Overview Safety Safety Precautions Regulatory Information WEEE (EU & EEA) Handling Precautions Canceling Print Jobs Legal Restrictions on Scanning/Copying Printer Handling Precautions Transporting Your Printer When Repairing, Lending, or Disposing of the Printer Keeping Print Quality High Main Components and Their Use Main Components Power Supply Using the Operation Panel...
Page 174: Safety
Safety Safety Precautions Regulatory Information WEEE (EU&EEA)
Page 175: Safety Precautions
Safety Precautions Safety Precautions • This manual contains important notices and safety precautions about your printer. Do not use the printer in ways other than described in the accompanying manuals, as this may result in fire, electric shock or other unexpected accidents. Safety standard marks and declarations are only valid for the supported voltages and frequencies in the applicable countries or regions.
Page 176 In case ink gets in contact with eyes, rinse with water immediately. In case ink gets in contact with skin, wash with soap and water immediately. If irritation to eyes or skin persists, obtain medical advice immediately. • Moving the printer Do not hold the printer by the cassette.
Page 177 General Notices • Do not tilt the printer, stand it on end, or turn it upside down. This may cause ink to leak. • Do not place anything on top of the printer. Be especially careful to avoid metal objects such as paper clips and staples, and containers holding flammable liquids such as alcohol or thinner.
Page 178: Regulatory Information
20cm between the radiator and persons body (excluding extremities: hands, wrists, feet and ankles) and must not be colocated or operated with any other antenna or transmitter. Canon U.S.A., Inc. One Canon Park Melville, New York 11747...
Page 179 Interference Do not use the printer around medical equipment or other electronic devices. Signals from the printer may interfere with the correct operation of these devices.
Page 180: Weee (Eu&Eea)
For more information about where you can drop off your waste equipment for recycling, please contact your local city office, waste authority, approved WEEE scheme or your household waste disposal service. For more information regarding return and recycling of WEEE products, please visit www.canon- europe.com/weee.
Page 181 U kunt ook het schema voor de afvoer van afgedankte elektrische en elektronische apparatuur (AEEA) raadplegen. Ga voor meer informatie over het inzamelen en recyclen van afgedankte elektrische en elektronische apparatuur naar www.canon- europe.com/weee.
Page 182 RAEE autorizado o con el servicio de recogida de basuras doméstico. Si desea más información acerca de la devolución y reciclado de RAEE, visite la web www.canon-europe.com/weee. Només per a la Unió Europea i a l’Espai Econòmic Europeu (Noruega, Islàndia i Liechtenstein)
Page 183 Yderligere oplysninger om, hvor du kan bortskaffe dit elektronikaffald med henblik på genanvendelse, får du hos de kommunale renovationsmyndigheder. Yderligere oplysninger om returnering og genanvendelse af affald af elektrisk og elektronisk udstyr får du ved at besøge www.canon- europe.com/weee.
Page 184 Du kan få mer informasjon om hvor du kan avhende utrangert utstyr til resirkulering ved å kontakte lokale myndigheter, et godkjent WEEE-program eller husholdningens renovasjonsselskap. Du finner mer informasjon om retur og resirkulering av WEEE-produkter på www.canon-europe.com/weee. Vain Euroopan unionin sekä ETA:n (Norja, Islanti ja Liechtenstein) alueelle.
Page 185 Lisätietoja sähkö- ja elektroniikkalaiteromun keräyksestä ja kierrätyksestä on osoitteessa www.canon-europe.com/weee. Endast för Europeiska unionen och EES (Norge, Island och Liechtenstein) Den här symbolen visar att produkten enligt WEEE-direktivet (2012/19/EU) och nationell lagstiftning inte får sorteras och slängas som hushållsavfall. Den här produkten ska lämnas in på en därför avsedd insamlingsplats, t.ex.
Page 186 WEEE lub skontaktować się z przedsiębiorstwem zajmującym się wywozem odpadów domowych. Więcej informacji o zwracaniu i recyklingu zużytego sprzętu elektrycznego i elektronicznego znajduje się w witrynie www.canon-europe.com/weee. Platí len pre štáty Európskej únie a EHP (Nórsko, Island a Lichtenštajnsko)
Page 187 EEIA struktūru vai sadzīves atkritumu apsaimniekošanas iestādi. Lai saņemtu plašāku informāciju par elektrisko un elektronisko iekārtu nodošanu pārstrādei, apmeklējiet tīmekļa vietni www.canon-europe.com/weee. Tik Europos Sąjungai ir EEE (Norvegijai, Islandijai ir Lichtenšteinui) Šis ženklas reiškia, kad gaminio negalima išmesti su buitinėmis atliekomis, kaip yra nustatyta Direktyvoje...
Page 188 į savo miesto valdžios institucijas, atliekų tvarkymo organizacijas, patvirtintų EEĮ atliekų sistemų arba jūsų buitinių atliekų tvarkymo įstaigų atstovus. Išsamesnės informacijos apie EEĮ atliekų grąžinimo ir perdirbimo tvarką galite rasti apsilankę tinklalapyje www.canon- europe.com/weee. Samo za Evropsko unijo in EGP (Norveška, Islandija in Lihtenštajn) Ta simbol pomeni, da tega izdelka v skladu z direktivo OEEO (2012/19/EU) in državno zakonodajo ne...
Page 189 DEEE aprobată sau serviciul de colectare a deşeurilor menajere. Pentru mai multe informaţii privind returnarea şi reciclarea produselor DEEE, vizitaţi www.canon-europe.com/ weee. Samo za Europsku uniju i EEZ (Norveška, Island i Lihtenštajn) Ovaj simbol pokazuje da se ovaj proizvod ne smije odlagati s kućnim otpadom sukladno WEEE Direktivi...
Page 190 će doprineti efikasnom korišćenju prirodnih resursa. Za više informacija o tome gde možete da predate vašu staru opremu radi recikliranje, vas molimo, da kontaktirate lokalne gradske vlasti, komunalne službe, odobreni plan reciklaže ili Gradsku čistoću. Za više informacija o vraćanju i recikliranju WEEE proizvoda, posetite stranicu www.canon-europe.com/weee.
Page 191: Handling Precautions
Handling Precautions Canceling Print Jobs Legal Restrictions on Scanning/Copying Printer Handling Precautions Transporting Your Printer When Repairing, Lending, or Disposing of the Printer Keeping Print Quality High...
Page 192: Legal Restrictions On Scanning/Copying
Legal Restrictions on Scanning/Copying Scanning, printing, copying, or modifying copies of the following may be punishable under law. This list is non-exhaustive. When in doubt, check with a local legal representative. • Paper money • Money orders • Certificates of deposit •...
Page 193: Printer Handling Precautions
Printer Handling Precautions Do not place any object on the document cover! Do not place any object on the document cover. It will fall into the rear tray when the document cover is opened and cause the printer to malfunction. Also, place the printer where objects will not fall on it.
Page 194: Transporting Your Printer
Transporting Your Printer When relocating the printer for changing your living place or repairing it, make sure of the following. Important • Pack the printer in a sturdy box so that it is placed with its bottom facing down, using sufficient protective material to ensure safe transport.
Page 195 7. Use adhesive tape to secure all the covers on the printer to keep them from opening during transportation. Then pack the printer in the plastic bag. 8. Attach the protective material to the printer when packing the printer in the box.
Page 196: When Repairing, Lending, Or Disposing Of The Printer
When Repairing, Lending, or Disposing of the Printer If you have entered personal data, passwords and/or other security settings on the printer, such information may be stored in the printer. When sending the printer for repair, lending or transferring the printer to another person, or disposing of the printer, please be sure to follow the steps below in order to delete such information and prevent third parties from accessing it.
Page 197: Keeping Print Quality High
Keeping Print Quality High The key to printing with the optimal printing quality is to prevent the print head from drying or clogging. Always observe the following rules for optimal printing quality. Note • Depending on the type of paper, ink may blur if you trace the printed area with a highlight pen or paint- stick, or bleed if water or sweat comes in contact with the printed area.
Page 198: Main Components And Their Use
Main Components and Their Use Main Components Power Supply Using the Operation Panel...
Page 199: Main Components
Main Components Front View Rear View Inside View Operation Panel...
Page 200: Front View
Front View A: Operation Panel Use to change the settings of the printer or to operate it. Before printing starts, this automatically opens. Operation Panel B: Platen Load an original here. C: Document Cover Open to load an original on the platen. D: Cassette Load A4, B5, A5, or Letter-sized plain paper into the cassette, and insert it into the printer.
Page 201 I: Card Slot Insert a memory card. Before Inserting the Memory Card J: Access lamp Lights or flashes to indicate the memory card status. Inserting the Memory Card K: Multi-purpose Tray Guide Place the multi-purpose tray here. L: Multi-purpose Tray Storage Compartment The multi-purpose tray supplied with the printer can be stored here.
Page 202 M: Rear Tray Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same time, and fed automatically one sheet at a time. Loading Paper in the Rear Tray Loading Envelopes in Rear Tray N: Paper Support Extend to load paper in the rear tray.
Page 203: Rear View
Rear View A: USB Port Plug in the USB cable to connect the printer with a computer. B: Power Cord Connector Plug in the supplied power cord. C: Transport Unit Cover Open when removing jammed paper. D: Rear Cover Detach when removing jammed paper. Important •...
Page 204: Inside View
Inside View A: Scanning Unit / Cover Scans originals. Also, lift and open it to replace an ink tank or to remove jammed paper inside the printer. B: Print Head Holder The print head is pre-installed. Note • For details on replacing an ink tank, see Replacing Ink Tanks.
Page 205: Operation Panel
Operation Panel A: ON button/ON lamp Turns the power on or off. Lights after flashing when the power is turned on. Before turning on the power, make sure that the document cover is closed. B: Touch Screen Displays messages, menu items, and the operational status. Directly touch the screen lightly with your finger tip to select a menu item or displayed button.
Page 206: Power Supply
Power Supply Checking that Power Is On Turning the Printer On and Off Checking the Power Plug/Power Cord Unplugging the Printer...
Page 207: Checking That Power Is On
Checking that Power Is On The ON lamp is lit when the printer is turned on. Even if the touch screen is off, if the ON lamp is lit, the printer is on. Note • It may take a while for the printer to start printing immediately after you turn on the printer. •...
Page 208: Turning The Printer On And Off
Turning the Printer On and Off Turning on the printer 1. Press the ON button to turn on the printer. The ON lamp flashes and then remains lit. Checking that Power Is On Note • It may take a while for the printer to start printing immediately after you turn on the printer. •...
Page 209 Important • When you unplug the power cord after turning off the printer, be sure to confirm that the ON lamp is off. Note • When pressing the ON button, a confirmation screen to retract the paper output tray on the touch screen.
Page 210: Checking The Power Plug/Power Cord
Checking the Power Plug/Power Cord Unplug the power cord once a month to confirm that the power plug/power cord does not have anything unusual described below. • The power plug/power cord is hot. • The power plug/power cord is rusty. •...
Page 211: Unplugging The Printer
Unplugging the Printer To unplug the power cord, follow the procedure below. Important • When you unplug the power cord, press the ON button, then confirm that the ON lamp is off. Unplugging the power cord while the ON lamp is lit or flashing may cause drying or clogging of the print head and print quality may be reduced.
Page 212 The specification of the power cord differs depending on the country or region of use.
Page 213: Using The Operation Panel
Using the Operation Panel The operation panel consists of the ON button (A) and touch screen (B). Touch the HOME screen on the touch screen with your finger tip to select menus for copying, scanning, and other functions. Operations on the HOME Screen A: ON button B: Touch Screen Basic Operation of the touch screen...
Page 214 Touch Touch lightly with your finger tip. To move forward (or go back) menus or photos continuously, keep touching the forward (or back) mark. Flick Flick your finger on the screen up, down, left, or right. Use to switch menus or move forward or backward through photos. Drag While lightly touching the screen, move your finger up, down, left, or right.
Page 215 Operations on the HOME Screen Display the menu screen or the settings screen from the HOME screen. C: Basic menu Select to copy or scan using the operation panel. After selecting a basic menu, the particular menus are displayed. D: Network Displays the current network status.
Page 216 (Signal strength: 50 % or less): The problem such as the printer cannot print may occur. Place the printer near the wireless router. Wi-Fi is enabled but the printer is not connected to the wireless router. Wireless Direct is enabled. Wi-Fi and Wireless Direct are disabled.
Page 217 (HOME) Displays the HOME screen. (Back) Returns the touch screen to the previous screen. Black Starts black & white copying, scanning, etc. Color Starts color copying, scanning, etc. Stop Cancels operation when print, copy, or scan job is in progress.
Page 218: Changing Settings
Changing Settings Changing Printer Settings from Your Computer (Windows) Changing Printer Settings from Your Computer (macOS) Changing Settings from Operation Panel...
Page 219: Changing Printer Settings From Your Computer (Windows)
Changing Printer Settings from Your Computer (Windows) Changing the Print Options Registering a Frequently Used Printing Profile Setting the Ink to be Used Managing the Printer Power Changing the Printer Operation Mode...
Page 220: Changing The Print Options
Changing the Print Options You can change the detailed printer driver settings for print data that is sent from an application software. Check this check box if part of the image data is cut off, the paper source during printing differs from the driver settings, or printing fails.
Page 221: Registering A Frequently Used Printing Profile
Registering a Frequently Used Printing Profile You can register the frequently used printing profile to Commonly Used Settings on the Quick Setup tab. Unnecessary printing profiles can be deleted at any time. Registering a Printing Profile 1. Open the printer driver setup window 2.
Page 222 Quick Setup tab. The name and icon are displayed in Commonly Used Settings. Important • To save the page size, orientation, and number of copies that was set in each sheet, click Options..., and check each item. Note • When you re-install the printer driver or upgrade the printer driver version, the print settings that are already registered will be deleted from Commonly Used Settings.
Page 223: Setting The Ink To Be Used
Setting the Ink to be Used This feature enables you to specify the most appropriate ink tank among installed ink tanks according to an intended use. 1. Open the printer driver setup window 2. Click Print Options... on the Page Setup tab The Print Options dialog box appears.
Page 224: Managing The Printer Power
Managing the Printer Power This function allows you to manage the printer power from the Canon IJ Printer Assistant Tool. Power Off The Power Off function turns off the printer. When you use this function, you will not be able to turn the printer on from the Canon IJ Printer Assistant Tool.
Page 225 Note • When the printer is turned off, the Canon IJ Status Monitor message varies depending on the Auto Power On setting. When the setting is Enable, "Printer is standing by" is displayed. When the setting is Disable,...
Page 226: Changing The Printer Operation Mode
Check this check box to prevent paper abrasion. Align heads manually Usually, the Print Head Alignment function in the Canon IJ Printer Assistant Tool is set to automatic head alignment, but you can change it to manual head alignment. If the printing results of automatic Print Head Alignment are not satisfactory, perform manual head alignment.
Page 227 Rotate 90 degrees left when orientation is [Landscape] On the Page Setup tab, you can change the rotation direction of the Landscape in the Orientation. To rotate the print data 90 degrees to the left during printing, select this item. To rotate the print data 90 degrees to the right during printing, clear this item.
Page 228: Changing Settings From Operation Panel
Changing Settings from Operation Panel Changing Settings from Operation Panel Setting Items on Operation Panel Print settings LAN settings Bluetooth settings PictBridge settings Smartphone photo print settings Other device settings Language selection Firmware update Reset setting Feed settings Web service setup ECO settings Quiet setting System information...
Page 229: Changing Settings From Operation Panel
Changing Settings from Operation Panel This section describes the procedure to change the settings in the Device settings screen, taking the steps to specify Amount of extension as an example. Check that printer is turned on. 2. Select (Setup) on the HOME screen. Using the Operation Panel 3.
Page 230 For more on setting items on the operation panel: Setting Items on Operation Panel...
Page 231: Setting Items On Operation Panel
Setting Items on Operation Panel Items for Printer Other device settings Language selection Web service setup ECO settings Quiet setting Items for Paper/Printing Print settings Bluetooth settings PictBridge settings Smartphone photo print settings Feed settings Items for Maintenance/Management LAN settings Firmware update Reset setting System information...
Page 232: Print Settings
Print settings • Prevent paper abrasion Use this setting only if the print surface becomes smudged. Important • Be sure to set this back to OFF after printing since it may result in lower printing speed or lower print quality. •...
Page 233 Important • For Letter-sized or Legal-sized paper, you can adjust the left/right margins between -0.06 in. (-1.5 mm) and +0.06 in. (+1.5 mm) even if you specify the value over 0.06 in. (1.5 mm).
Page 234: Lan Settings
LAN settings Wi-Fi Wireless Direct Wi-Fi When Wi-Fi is selected in the LAN settings screen, the network settings information of the printer when it is connected by Wi-Fi appears in the Wi-Fi setting list screen. To print the network settings, select Print details in the LAN settings screen and select Yes. Printing Network Settings Important •...
Page 235 • Wi-Fi setup Selects the setup method for Wi-Fi connection. ◦ Easy wireless connect Select if you specify the settings of the access point information to the printer directly from a device (e.g. smartphone, or tablet) without operating the wireless router. Follow the on-screen instructions of the connecting device for the setup procedure.
Page 236 Network (SSID)/device name DIRECT-XXXX-TS8300series Password XXXXXXXXXX (10 characters) Wi-Fi security WPA2-PSK(AES) No. of devices connected now XX/XX IPv4 address XXX. XXX. XXX. XXX (12 characters) IPv4 subnet mask XXX. XXX. XXX. XXX (12 characters) IPv4 default gateway XXX. XXX. XXX. XXX (12 characters) IPv6 link-local address XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX (32 characters)
Page 237 • You cannot use a hyphen for the initial or last character of the printer name. • TCP/IP settings Performs IPv4 or IPv6 setting. • WSD setting Setting items when you use WSD (one of the network protocols supported in Windows). ◦...
Page 238 Enables/disables LLMNR (Link-Local Multicast Name Resolution). Selecting Enable allows the printer to detect printer's IP address from the printer name without a DNS server. • IPP settings Selecting Enable allows you to print via the network with the IPP protocol. •...
Page 239: Other Device Settings
Other device settings • Date display format Changes the display format of dates when printed. Note • When ON is selected for Print date on the print settings screen in printing from a memory card, the date is printed in the date display format you selected. Setting Items for Photo Printing Using Operation Panel •...
Page 240 ON button to turn off the printer. • Wi-Fi pairing settings In order to connect Canon PRINT Inkjet/SELPHY, multiple configurations will be performed. ◦ Enable/disable pairing Set the printer's Wi-Fi pairing function to enable or disable.
Page 241: Language Selection
Language selection Changes the language for the messages and menus on the touch screen. Japanese / English / German / French / Italian / Spanish / Portuguese / Dutch / Danish / Norwegian / Swedish / Finnish / Russian / Ukrainian / Polish / Czech / Slovene / Hungarian / Slovak / Croatian / Romanian / Bulgarian / Turkish / Greek / Estonian / Latvian / Lithuanian / Simplified Chinese / Korean / Traditional Chinese / Thai / Indonesian / Vietnamese...
Page 242: Firmware Update
Firmware update You can update the firmware of the printer, check the firmware version, or perform settings of a notification screen, a DNS server and a proxy server. Important • When you use this function, make sure the printer is connected to the Internet. Note •...
Page 243: Reset Setting
Reset setting You can set the settings back to the default. • Web service setup only Sets the Web service settings back to the default. • LAN settings only Sets the LAN settings back to the default. • Settings only Sets the settings such as the paper size or media type back to the default.
Page 244: Feed Settings
Feed settings By registering the paper size and the media type loaded on the rear tray or in the cassette, you can prevent the printer from misprinting by displaying the message before printing starts when the paper size or the media type of the loaded paper differs from the print settings.
Page 245: Web Service Setup
◦ IJ Cloud Printing Center setup Registers/Deletes the printer to/from Canon Inkjet Cloud Printing Center. ◦ Check Web service setup Make sure whether the printer is registered to Google Cloud Print or Canon Inkjet Cloud Printing Center. • Issue registration code In order to link the web service and printer, obtain the registration code from the service origin.
Page 246: Eco Settings
ECO settings This setting allows you to use automatic duplex printing as a default to save paper and to turn on/off the printer automatically to save electricity. Using Power Saving Function Using Duplex Printing Using Power Saving Function Follow the procedure below to use power saving function. Check that printer is turned on.
Page 247 Check that printer is turned on. 2. Select (Setup) on the HOME screen. Using the Operation Panel 3. Select ECO. 4. Select Two-sided print settings. 5. Specify settings as necessary. A: Select two-sided copying as a default. B: Select two-sided printing of template forms on the printer as a default. Note •...
Page 248: Quiet Setting
Quiet setting Enables this function on the printer if you want to reduce the operating noise, such as when printing at night. Follow the procedure below to perform setting. Check that printer is turned on. 2. Select (Setup) on the HOME screen. Using the Operation Panel 3.
Page 249: System Information
System information To display this menu, select System information in (Hint). • Current version Displays the current firmware version. • Printer name Displays the printer name currently specified. • Serial number Displays the printer serial number. • MAC address (Wi-Fi) Displays the MAC address for Wi-Fi.
Page 250: Specifications
Specifications General Specifications Interface USB Port: Hi-Speed USB * Network Port: Wi-Fi: IEEE802.11n / IEEE802.11g / IEEE802.11b / IEEE802.11a Card Slot: * A computer that complies with Hi-Speed USB standard is required. Since the Hi-Speed USB interface is fully upwardly compatible with USB 1.1, it can be used at USB 1.1.
Page 251 Scan Specifications Scanner driver Windows: TWAIN 1.9 Specification, WIA Maximum scanning size A4/Letter, 8.5 x 11.7 in. (216 x 297 mm) Optical resolution (horizontal x 2400 x 4800 dpi * vertical) * Optical Resolution represents the maximum sampling rate based on ISO 14473.
Page 252 The necessary amount of hard disk space may be changed without notice. Other Supported OS iOS, Android, Windows 10 Mobile Some functions may not be available with the supported OS. Refer to the Canon web site for details. Mobile Printing Capability Apple AirPrint Google Cloud Print...
Page 253: Information About Paper
Information about Paper Supported Media Types Paper Load Limit Unsupported Media Types Handling Paper Before Printing on Art Paper Print Area...
Page 254: Supported Media Types
Canon website. • Genuine Canon paper is not available in some countries or regions. Note that in the United States, Canon paper is not sold by model number. Instead, purchase paper by name.
Page 255 Printing from Digital Camera • You can use non-Canon genuine art paper. For details, access our website. You cannot print in the top and bottom 1.38 in. (35 mm) margins of the paper (in the printing direction).
Page 256 • KG/4"x6"(10x15) • 5"x7"(13x18cm) • 7"x10"(18x25cm) • 8"x10"(20x25cm) • L(89x127mm) • 2L(127x178mm) • Square 3.5" • Square 5" • Hagaki • Hagaki 2 • Envelope Com 10 • Envelope DL • Nagagata 3 • Nagagata 4 • Yougata 4 • Yougata 6 •...
Page 257: Paper Load Limit
Note • Page sizes and media types differ depending on the country or region where the paper is sold. For details on page sizes and media types, access the Canon website. Paper Load Limits of Rear Tray and Cassette Genuine Canon Paper Paper for printing documents: Media Name <Model No.>...
Page 258 Light Fabric Iron-on Transfers <LF-101> Dark Fabric Iron-on Transfers <DF-101> Double sided Matte Paper <MP-101D> Paper other than Genuine Canon Paper Common Name Rear Tray Cassette Plain Paper (including recycled paper)*1 Approx. 100 sheets (Legal: Approx. 100 sheets 10 sheets)
Page 259: Unsupported Media Types
• Paper that is too thin (weighing less than 17 lb (64 g /m • Paper that is too thick (plain paper weighing more than 28 lb (105 g /m ), except for Canon genuine paper) • Paper thinner than a postcard, including plain paper or notepad paper cut to a small size (when printing on paper smaller than A5) •...
Page 260: Handling Paper
Handling Paper • Be careful not to rub or scratch the surfaces of any types of paper when handling. • Hold the paper as closely as possible to its edges and try not to touch the printing surface. The print quality may be degraded if the printing surface is smudged with sweat or oil that comes from your hands.
Page 261: Before Printing On Art Paper
Before Printing on Art Paper When using art paper, dust is liable to be generated. It is therefore recommended that paper dust be removed on art paper just before printing. You will need a soft hair brush (or similar brush used to clean office automation equipment).
Page 262 3. To complete the removal of paper dust, brush the paper in the other direction from top to bottom.
Page 263: Printing
Printing Printing from Computer Printing from Smartphone/Tablet Printing Using Operation Panel Printing from Digital Camera Paper Settings...
Page 264: Printing From Computer
Printing from Computer Printing from Application Software (Windows Printer Driver) Printing from Application Software (macOS AirPrint) Printing Using Canon Application Software Printing Using a Web Service...
Page 265: Printing From Application Software (Windows Printer Driver)
Printing from Application Software (Windows Printer Driver) Basic Printing Setup Basic Various Printing Methods Changing the Print Quality and Correcting Image Data Overview of the Printer Driver Printer Driver Description Updating the MP Drivers...
Page 266: Basic Printing Setup
Basic Printing Setup This section describes settings on the Quick Setup tab used for basic printing. Basic Printing Setup Check that printer is turned on Load paper in printer 3. Open printer driver's setup screen 4. Select frequently used settings On the Quick Setup tab, use Commonly Used Settings to select from predefined print settings.
Page 267 Important • The print quality selections will differ depending on which print setting you select. 6. Select paper source For Paper Source, select Automatically Select, Rear Tray, or Cassette, whichever matches your purpose. Important • The paper source settings that can be selected may differ depending on the paper type and size.
Page 268 7. Click OK The printer will now print using these settings. Important • When you select Always Print with Current Settings, the settings on the Quick Setup, Main, and Page Setup tabs are saved, and those settings are used in subsequent printings. •...
Page 269 From Paper Source, check the setting or select a new paper source. The current printer settings appear in Media Type and Page Size. 4. Apply settings To apply the printer settings to the printer driver, click Set. Note • If the Type on the printer is set to Ink Jet Hagaki, Hagaki K, or Hagaki, or if the Page size on the printer is set to 2L/5"x7"(13x18), click Set to display the dialog box.
Page 270: Paper Settings On The Printer Driver And The Printer (Media Type)
Media Type in the printer driver the printer Canon Red Label Superior <WOP111> Plain Paper Plain paper Canon Océ Office Colour Paper <SAT213> Plain Paper Plain paper High Resolution Paper <HR-101N> High Resolution Paper High-Res Paper Canon genuine papers (Photo Printing) Paper information reg- Media name <Model No.>...
Page 271 Light Fabric Iron-on Transfers <LF-101> Light Fabric Iron-on Transfers Others Double sided Matte Paper <MP-101D> Matte Photo Paper Matte Commercially available papers Paper information registered on the Media name Media Type in the printer driver printer Plain Paper (including recycled paper) Plain Paper Plain paper Envelopes Envelope...
Page 272: Paper Settings On The Printer Driver And The Printer (Paper Size)
Paper Settings on the Printer Driver and the Printer (Paper Size) When you use this printer, selecting a paper size that matches the print purpose will help you achieve the best print results. You can use the following paper sizes on this printer. Printer Paper Size in the printer driver Cassette paper information registered on the printer Letter 8.5"x11"...
Page 273 Card 2.17"x3.58" 55x91mm Card 2.17"x3.58" Custom Size Others...
Page 274: Various Printing Methods
Various Printing Methods Setting a Page Size and Orientation Setting the Number of Copies and Printing Order Perform Borderless Printing Scaled Printing Page Layout Printing Tiling/Poster Printing Duplex Printing Setting Up Envelope Printing Printing on Postcards...
Page 275: Setting A Page Size And Orientation
Setting a Page Size and Orientation The paper size and orientation are essentially determined by the application software. When the page size and orientation set for Page Size and Orientation on the Page Setup tab are same as those set with the application software, you do not need to select them on the Page Setup tab.
Page 276: Setting The Number Of Copies And Printing Order
Setting the Number of Copies and Printing Order You can also set the number of copies on the Quick Setup tab. 1. Open the printer driver setup window 2. Specify the number of copies to be printed For Copies on the Page Setup tab, specify the number of copies to be printed. 3.
Page 277 • Print from Last Page: /Collate: • Print from Last Page: /Collate: 4. Click OK When you perform print, the specified number of copies will be printed with the specified printing order. Important • When the application software that you used to create the document has the same function, specify the settings on the printer driver.
Page 278: Perform Borderless Printing
Perform Borderless Printing The borderless printing function allows you to print data without any margin by enlarging the data so that it extends slightly off the paper. In standard printing, margins are created around the document area. However, in borderless printing function, these margins are not created. When you want to print data such as a photo without providing any margin around it, set borderless printing.
Page 279 Click OK when the confirmation message appears. When a message prompting you to change the media type appears, select a media type from the list and click OK. 3. Check the paper size Check the Page Size list. When you want to change it, select another page size from the list. The list displays only sizes that can be used for borderless printing.
Page 280 Expanding the Range of the Document to Print Setting a large amount of extension allows you to perform borderless printing with no problems. However, the portion of the document extending off the paper range will not be printed and for this reason, the subjects around the perimeter of a photo may not be printed.
Page 281: Scaled Printing
Scaled Printing 1. Open the printer driver setup window 2. Set scaled printing Select Scaled from the Page Layout list on the Page Setup tab. 3. Select the paper size of the document Using Page Size, select the page size that is set with your application software. 4.
Page 282 • Specify a scaling factor Directly type in a value into the Scaling box. The current settings are displayed in the settings preview on the left side of the printer driver. 5. Click OK When you perform print, the document will be printed with the specified scale. Important •...
Page 283 Note • Selecting Scaled changes the printable area of the document.
Page 284: Page Layout Printing
Page Layout Printing The page layout printing function allows you to print more than one page image on a single sheet of paper. 1. Open the printer driver setup window 2. Set page layout printing Select Page Layout from the Page Layout list on the Page Setup tab. The current settings are displayed in the settings preview on the left side of the printer driver.
Page 285 Page Layout To change the number of pages to be printed on a single sheet of paper, select the number of pages from the list. Page Order To change the page arrangement order, select a placement method from the list. Page Border To print a page border around each document page, check this check box.
Page 286: Tiling/Poster Printing
Tiling/Poster Printing The tiling/poster printing function allows you to enlarge image data, divide it into several pages, and print these pages on separate sheets of paper. You can also paste the pages together to create a large print like a poster. Setting Tiling/Poster Printing 1.
Page 287 4. Set the number of image divisions and the pages to be printed If necessary, click Specify..., specify the following settings in the Tiling/Poster Printing dialog box, and then click OK. Image Divisions Select the number of divisions (vertical x horizontal). As the number of divisions increases, the number of sheets used for printing increases.
Page 288 In the settings preview on the left of the Page Setup tab, click the pages that do not need to be printed. The pages that were clicked are deleted, and only the pages to be printed are displayed. Note • Click the deleted pages to display them again. •...
Page 289: Duplex Printing
Duplex Printing You can also set duplex printing in Additional Features on the Quick Setup tab. Performing Automatic Duplex Printing You can perform the duplex printing without having to turn over the paper. 1. Open the printer driver setup window 2.
Page 290 Use normal-size printing Print without reducing the page. Use reduced printing Reduce the page slightly during printing. 5. Specify the side to be stapled The best Stapling Side is selected automatically from the Orientation and Page Layout settings. To change the setting, select another stapling side from the list. 6.
Page 291 3. Select the layout Select Normal-size, Fit-to-Page, Scaled, or Page Layout from the Page Layout list. 4. Specify the side to be stapled The best Stapling Side is selected automatically from the Orientation and Page Layout settings. To change the setting, select another stapling side from the list. 5.
Page 292 (Operation stops temporarily). Do not touch the paper during this time. You can change the ink drying wait time at Custom Settings in the Canon IJ Printer Assistant Tool. • When you use the automatic duplex printing function to print a postcard, print the address side first and then print the message side.
Page 293: Setting Up Envelope Printing
• If Envelope Com 10, Envelope DL, Yougata 4 4.13"x9.25", or Yougata 6 3.86"x7.48" is selected for Printer Paper Size, the printer rotates the paper 90 degrees to the left to print, regardless of the Rotate 90 degrees left when orientation is [Landscape] setting for Custom Settings in the Canon IJ Printer Assistant Tool.
Page 294 To hide the guide messages, check the Do not show this message again check box. To show the guide again, click the View Printer Status button on the Maintenance tab, and start the Canon IJ Status Monitor. Then click Envelope Printing from Display Guide Message of the Option menu to enable the setting.
Page 295: Printing On Postcards
Printing on Postcards Load postcard on the printer 2. Open the printer driver setup window 3. Select commonly used settings Display the Quick Setup tab, and for Commonly Used Settings, select Standard. 4. Select the media type For Media Type, select Ink Jet Hagaki (A), Ink Jet Hagaki, Hagaki K (A), Hagaki K, Hagaki (A), or Hagaki.
Page 296 • If you want to display a guide message when performing postcard printing, open the Maintenance tab and click View Printer Status to start the Canon IJ Status Monitor. On the Option menu, choose Display Guide Message and click Hagaki Printing to enable the setting.
Page 297: Overview Of The Printer Driver
Overview of the Printer Driver Canon IJ Printer Driver Opening Printer Driver's Setup Screen Canon IJ Status Monitor Checking Ink Status from Your Computer Instructions for Use (Printer Driver)
Page 298: Canon Ij Printer Driver
Canon IJ Printer Driver The Canon IJ printer driver (simply called printer driver below) is software that you install onto your computer so that it can communicate with the printer. The printer driver converts the print data created by your application software into data that your printer can understand, and sends the converted data to the printer.
Page 299: Opening Printer Driver's Setup Screen
Opening Printer Driver's Setup Screen You can display the printer driver's setup screen from your application software or by clicking the printer icon. Displaying the Printer Driver's Setup Screen from Your Application Software Perform this procedure to set up the print settings during printing. 1.
Page 300: Canon Ij Status Monitor
• The information displayed on the Canon IJ Status Monitor may differ depending on the country or region where you are using your printer. When Errors Occur The Canon IJ Status Monitor is automatically displayed if an error occurs (e.g., if the printer runs out of paper or if the ink is low).
Page 301 In such cases, take the appropriate action as described.
Page 302: Checking Ink Status From Your Computer
You can check the remaining ink level and the ink tank types for your model. 1. Open the printer driver setup window 2. Launching the Canon IJ Status Monitor On the Maintenance tab, click View Printer Status. 3. Display Estimated ink levels...
Page 303: Instructions For Use (Printer Driver)
Instructions for Use (Printer Driver) This printer driver is subject to the following restrictions. Keep the following points in mind when using the printer driver. Restrictions on the Printer Driver • Depending on the document type to be printed, the paper feed method specified in the printer driver may not operate correctly.
Page 304 2. Open the printer driver setup window, and on the Page Setup tab, set Page Size to the same paper size that you specified in Word. 3. Set the Page Layout that you want, and then click OK to close the window. 4.
Page 305: Printer Driver Description
Printer Driver Description Quick Setup Tab Description Main Tab Description Page Setup Tab Description Maintenance Tab Description Canon IJ Status Monitor Description...
Page 306: Quick Setup Tab Description
Quick Setup Tab Description The Quick Setup tab is for registering commonly used print settings. When you select a registered setting, the printer automatically switches to the preset items. Commonly Used Settings The names and icons of frequently used printing profiles are registered. When you select a printing profile according to the purpose of the document, settings that match the purpose are applied.
Page 307 If Page Size, Orientation, and Copies were set from the application software, those settings have priority. Envelope If you select this setting for printing an envelope, Media Type is set automatically to Envelope. In the Envelope Size Setting dialog box, select the size of the envelope to be used. Greeting Card When selected for printing a greeting card, the Media Type is automatically set to Inkjet Greeting Card.
Page 308 and click Specify..Then in the Page Layout Printing dialog box that appears, specify the Page Order. 4-on-1 Printing Prints four pages of the document, side by side, on one sheet of paper. To change the page sequence, click the Page Setup tab, select Page Layout for Page Layout, and click Specify..
Page 309 Prints the document by rotating it 90 degrees relative to the paper feed direction. You can change the rotation direction by going to the Canon IJ Printer Assistant Tool, opening the Custom Settings dialog box, and then using Rotate 90 degrees left when orientation is [Landscape] check box.
Page 310 Always Print with Current Settings Prints documents with the current settings starting from the next print execution. When you select this function and then close the printer driver setup window, the information that you set on the Quick Setup, Main, and Page Setup tabs are saved and printing with the same settings is possible starting from the next print execution.
Page 311 Save the orientation setting Saves the Orientation to the printing profile in Commonly Used Settings. To apply the saved print orientation when the printing profile is selected, check this check box. If this check box is unchecked, the print orientation is not saved, and consequently the Orientation setting is not applied when the printing profile is selected.
Page 312 Switching the Paper Source to Match the Purpose Displaying the Print Results Before Printing Setting Paper Dimensions (Custom Size) Printing a Color Document in Monochrome Specifying Color Correction Adjusting Color Balance Adjusting Brightness Adjusting Contrast Registering a Frequently Used Printing Profile...
Page 313: Main Tab Description
Main Tab Description The Main tab allows you to create a basic print setup in accordance with the media type. Unless special printing is required, normal printing can be performed just by setting the items on this tab. Settings Preview The paper illustration shows how the original will be laid out on a sheet of paper.
Page 314 Print Quality Selects your desired printing quality. Select one of the following to set the print quality level that is appropriate for the purpose. Important • Depending on the Media Type settings, the same print results may be produced even if the Print Quality is changed.
Page 315 Custom dialog box Set the quality level, and select the desired print quality. Quality You can use the slider bar to adjust the print quality level. Important • Certain print quality levels cannot be selected depending on the settings of Media Type. Note •...
Page 316 • When Grayscale Printing is checked on the Main tab, Color Correction appears grayed out and is unavailable. Driver Matching With Canon Digital Photo Color, you can print sRGB data with color tints that most people prefer. Adjusts the colors by using an ICC profile when printing. Important •...
Page 317 Displaying the Print Results Before Printing...
Page 318: Page Setup Tab Description
Prints the document by rotating it 90 degrees relative to the paper feed direction. You can change the rotation direction by going to the Canon IJ Printer Assistant Tool, opening the Custom Settings dialog box, and then using Rotate 90 degrees left when orientation is...
Page 319 To rotate the document 90 degrees to the left when printing, select the Rotate 90 degrees left when orientation is [Landscape] check box. Rotate 180 degrees Prints the document by rotating it 180 degrees against the paper feed direction. The width of print area and the amount of extension that are configured in other application software will be reversed vertically and horizontally.
Page 320 Page Layout Multiple pages of document can be printed on one sheet of paper. Specify... Opens the Page Layout Printing dialog box. Click this button to set details on page layout printing. Tiling/Poster This function enables you to enlarge the image data and divide the enlarged data into several pages to be printed.
Page 321 Important • If the application used to create your document has a similar function, specify the number of copies with the application without specifying it here. Print from Last Page Check this check box when you want to print from the last page in order. If you do this, you do not need to sort the pages into their correct order after printing.
Page 322 Preview Icon Shows the settings made on the Page Layout Printing dialog box. You can check what the print result will look like before you actually print the data. Page Layout Specifies the number of document pages to fit on one sheet. Page Order Specifies the document orientation to be printed on a sheet of paper.
Page 323 Booklet Printing dialog box This dialog box allows you to set how to bind the document as a booklet. Printing only on one side and printing a page border, can also be set in this dialog box. The settings specified in this dialog box can be confirmed in the settings preview on the printer driver. Preview Icon Shows the settings made on the Booklet Printing dialog box.
Page 324 In this case, check this function. Important • When this function is enabled, normally the paper feeding method cannot be changed from the Canon IJ Preview. Ungroup Papers Sets the display method of Media Type, Page Size, and Printer Paper Size.
Page 325 Print after creating print data by page The print data is created in page units, and printing starts after the processing of one page of print data is complete. If a printed document contains unintended results such as streaks, selecting this check box may improve the results.
Page 326 Define Stamp... Opens the Stamp Settings dialog box. You can check the details of a selected stamp or save a new stamp. Place stamp over text Sets how the stamp is to be printed over the document. Check the Stamp check box to enable this. Check this check box to print a stamp over the printed document page.
Page 327 For Date/Time/User Name, the creation date/time and user name of the printed object are displayed in Stamp Text. Important • Stamp Text appears grayed out and is unavailable if Date/Time/User Name is selected. TrueType Font Selects the font for the stamp text string. Style Selects the font style for the stamp text string.
Page 328 Position Specifies the stamp position on the page. Selecting Custom from the list allows you to enter values for the X-Position and Y-Position coordinates directly. Rotation Specifies the angle of rotation for the stamp. The angle can be set by entering the number of degrees.
Page 329 Select File... Opens the dialog box to open a file. Click this button to select a bitmap file (.bmp) to be used as the background. Layout Method Specifies how the background image is to be placed on the paper. When Custom is selected, you can set coordinates for X-Position and Y-Position. Intensity Adjusts the intensity of the bitmap to be used as a background.
Page 330: Maintenance Tab Description
Maintenance Tab Description The Maintenance tab allows you to start the Canon IJ Printer Assistant Tool or check the status of the printer. Maintenance and Preferences Canon IJ Printer Assistant Tool is started. You can perform printer maintenance or change the settings of the printer.
Page 331 Important • If the font for displaying the language of your choice is not installed in your system, the characters will be garbled.
Page 332: Canon Ij Status Monitor Description
Overview of the Canon IJ Status Monitor The Canon IJ Status Monitor uses images and messages to display the printer status and the ink status. During printing, you can check information about the document being printed and the print progress.
Page 333 Ink Model Number You can look up the correct ink tank for your printer. Option Menu If a printer message appears, select Enable Status Monitor to start the Canon IJ Status Monitor. Select Enable Status Monitor to use the following commands: Always Display Current Job Displays the Canon IJ Status Monitor whenever a document is being printed.
Page 334 Displays the For secure communication window. This window allows you to download the route certificate, register it to the browser, and disable warning displays. Help Menu Select this menu to display Help information for the Canon IJ Status Monitor including version and copyright information.
Page 335: Installing The Mp Drivers
Installing the MP Drivers You can access our web site through the Internet and download the latest MP Drivers for your model. 1. Turn off the printer 2. Start the installer Double-click the icon of the downloaded file. The installation program starts. Important •...
Page 336: Printing Using Canon Application Software
Printing Using Canon Application Software Easy-PhotoPrint Editor Guide...
Page 337: Printing From Smartphone/Tablet
Printing from Smartphone/Tablet Printing from iPhone/iPad/iPod touch (iOS) Printing from Smartphone/Tablet (Android) Printing from Windows 10 Mobile Device Printing/Scanning with Wireless Direct...
Page 338: Printing/Scanning With Wireless Direct
Printing/Scanning with Wireless Direct You can connect devices (e.g. computer, smartphone, or tablet) to the printer by two methods below. • Wireless connection (connecting devices via a wireless router) • Direct wireless connection (connecting devices using Wireless Direct) This section describes Wireless Direct, which allows you to print or scan by connecting the devices to the printer directly.
Page 339 8. Select ON. The Wireless Direct is enabled and a device can be connected to the printer wirelessly. Note • To show the password, select Show password. To hide the password, select Hide password. • The Wireless Direct setting list screen shows settings for when using the printer with Wireless Direct.
Page 340 • For more on printing or scanning from a device via Wi-Fi, refer to the device's or application's instruction manual. • You can print/scan from your smartphone or tablet by installing Canon PRINT Inkjet/SELPHY. Download it from App Store and Google Play.
Page 341 6. Select Settings. 7. Select a setting item. • Change SSID/device name Change the identifier (SSID) for Wireless Direct. The identifier (SSID) is the printer's name (device name) displayed on a Wi-Fi Direct compatible device. Follow the procedure below to change the identifier (SSID). 1.
Page 342 If you want the printer to display the screen to inform you a Wi-Fi Direct compatible device is connecting to the printer, select Yes. Important • To prevent an unauthorized access, we recommend you should select the setting to display the confirmation screen.
Page 343: Printing Photo Data
Printing Photo Data Printing Photographs Saved on Memory Card Basic Setting Items for Photo Printing Using Operation Panel...
Page 344: Printing Photographs Saved On Memory Card
Printing Photographs Saved on Memory Card You can print the photograph saved on the memory card easily. This section describes the procedure to print the photograph in Select photo print. Check that printer is turned on. Load photo paper. 3. Select Print on the HOME screen.
Page 345 You can print a copy of the displayed photo by tapping Color. • To change the display method, the number of copies, or the print settings: near the bottom of the displayed photo to display menus. A: Total number of copies is displayed When tapping, the Check total no.
Page 346 Note • You can specify the number of copies for each photo. Display the photo you want to print and specify the number of copies when the desired photo is displayed. C: Select to switch the photo group. For details: Using Useful Display Functions D: Select to display the Settings screen.
Page 347 F: Select to zoom in on the photo. For details: Using Useful Display Functions G: Select display photo with specifying the date (last modified date of data). For details: Using Useful Display Functions H: Select to display the multiple photos at once. For more on the display method: Using Useful Display Functions 8.
Page 348 • While processing the print job, you can add the print job (Reserve photo print). Adding Print Job Adding Print Job You can add the print job (Reserve photo print) while printing photos. Follow the procedure below to add the print job. 1.
Page 349: Setting Items For Photo Printing Using Operation Panel
Setting Items for Photo Printing Using Operation Panel You can specify the setting of page size, media type, photo fix and so on to print the photos saved on the memory card. Print Settings Screen How to display the print settings screen varies with the print menu. •...
Page 350 on the touch screen. In this case, select on the upper left on the touch screen to check the message and change the setting. • The settings of the page size, media type, etc. are retained even if another print menu is selected or the printer is turned off.
Page 351 Other device settings...
Page 352: Disc Label Printing
Disc Label Printing Copying Label Side of Disc Basic Printing Photo from Memory Card onto Disc Label...
Page 353: Copying Label Side Of Disc
Copying Label Side of Disc You can copy the label of an existing BD/DVD/CD and print it on a printable disc. Important • You cannot print on 3.15 in. (8 cm) printable discs. • Do not mount the multi-purpose tray until the message prompting you to load the printable disc appears.
Page 354 If the print result is blurry, select Bleed-proof. Blurring may be reduced by printing with less ink. 7. Follow on-screen instructions to load copy source BD/DVD/CD on platen and select OK. The print setting confirmation screen is displayed. Important • Be sure to load the copy source BD/DVD/CD with its label side down on the center of the platen. If you load it near the edge of the platen, part of the image may be cut off.
Page 355 Note • You can see the procedure to set the printable disc by selecting How to set. • For more on setting the printable disc: Placing a Printable Disc 11. Select OK. The printer starts copying. Note • Tap Stop to cancel copying. •...
Page 356: Printing Photo From Memory Card Onto Disc Label
Printing Photo from Memory Card onto Disc Label You can print a photograph saved on a memory card onto the disc label of the printable disc. Important • You cannot print on 3.15 in. (8 cm) printable discs. • Do not mount the multi-purpose tray until the message prompting you to load the printable disc appears.
Page 357 A: Specify the outer circle. B: Specify the inner circle. Note • Measure the outer and inner diameters of the printing surface of the printable disc and make sure you set a value smaller than the measured value for the outer diameter, and a value larger than the measured value for the inner diameter.
Page 358 12. Check message and tap Color. 13. Follow on-screen instructions to set printable disc. Note • You can see the procedure to set the printable disc by selecting How to set. • For more on setting the printable disc: Placing a Printable Disc 14.
Page 359: Paper Settings
Paper Settings By registering the paper size and the media type loaded on the rear tray or in the cassette, you can prevent the printer from misprinting by displaying the message before printing starts when the paper size or the media type of the loaded paper differs from the print settings.
Page 360 • When you insert the cassette: Paper size is detected and set automatically in the printer. * You can load only plain paper in the cassette. Important • For more on the proper combination of paper settings you can specify by the printer driver (Windows) or on the touch screen: Paper Settings on the Printer Driver and the Printer (Media Type) Paper Settings on the Printer Driver and the Printer (Paper Size)
Page 361 Check the message and select Next. When the screen to select the operation is displayed, select one of the operations below. Note • Depending on the setting, the choices below may not be displayed. Print with the loaded paper. Select if you want to print/copy on the paper loaded without changing the paper settings. For example, when the paper setting for printing/copying is A5 and the paper information registered to the printer is A4, the printer starts printing/copying on the paper loaded in the rear tray or in the cassette without changing the paper size setting for printing/copying.
Page 362 Default Setting for Displaying the Message which Prevents Misprinting • When you print/copy using the operation panel of the printer or when you print from smartphone/tablet: The message which prevents misprinting is enabled by default. To change the setting: Feed settings •...
Page 363: Copying
Copying Reducing/Enlarging Copies Making Copies Basics Two-Sided Copying Special Copy Menu Copying Using Smartphone or Tablet...
Page 364: Making Copies
Making Copies This section describes the procedure to copy with Standard copy. Check that printer is turned on. Load paper. 3. Select Copy on the HOME screen. Using the Operation Panel 4. Select Standard copy. The Copy standby screen is displayed. Load original on platen.
Page 365 to specify the number of copies. If you keep touching here, the number scrolls by 10. You can also flick the number to specify. C: Display the print setting items. For more on the setting items: Setting Items for Copying D: Specify the page size and the media type.
Page 366 The screen below is displayed when you can add the copying job. Load the original on the platen and tap the same button (Color or Black) as the one which you previously tapped. Important • When you load the original on the platen, move the document cover gently. Note •...
Page 367: Setting Items For Copying
Setting Items for Copying You can change the copy settings such as magnification and intensity. Print Settings Screen Note • For more on the print settings screen or the setting item for Photo copy, see Copying Photos. The following screen is displayed by selecting Settings in the Copy standby screen. Example in Standard copy: Preview When Preview is displayed on the print settings screen, selecting Preview allows you to preview an...
Page 368 Note • Depending on the copy menu, some setting items cannot be selected. This section describes the setting items in Standard copy. The setting item which cannot be selected is displayed grayed out. For more on the setting items for Photo copy, see Copying Photos. •...
Page 369 • Page size Select the page size of the loaded paper. • Type (Media type) Select the media type of the loaded paper. • Print qlty (Print quality) Adjust print quality according to the original. Important • If you use Draft with Type set to Plain paper and the quality is not as good as expected, select Standard or High for Print qlty and try copying again.
Page 370: Scanning
Scanning Scanning from Computer (macOS) Scanning from Computer (Windows) Scanning from Operation Panel Scanning Using Smartphone/Tablet...
Page 371: Scanning From Computer (Windows)
Scanning from Computer (Windows) Scanning According to Item Type or Purpose (IJ Scan Utility) IJ Scan Utility Features Scanning Easily (Auto Scan) Basics Scanning Documents and Photos Creating/Editing PDF Files Setting Passwords for PDF Files Editing Password-Protected PDF Files Scanning Using Application Software (ScanGear) Scanning Tips Positioning Originals (Scanning from Computer) Network Scan Settings...
Page 372: Scanning According To Item Type Or Purpose (Ij Scan Utility)
Scanning According to Item Type or Purpose (IJ Scan Utility) IJ Scan Utility Features Scanning Easily (Auto Scan) Basics Scanning Documents and Photos Creating/Editing PDF Files Setting Passwords for PDF Files Editing Password-Protected PDF Files...
Page 373: Ij Scan Utility Features
IJ Scan Utility Features Use IJ Scan Utility to scan and save documents, photos, or other items at one time by simply clicking the corresponding icon. Multiple Scanning Modes Auto allows for one click scanning with default settings for various items. Document will sharpen text in a document or magazine for better readability, and Photo is best suited for scanning photos.
Page 374 Note • To set the applications to integrate with, see Settings Dialog Box.
Page 375: Scanning Easily (Auto Scan)
Scanning Easily (Auto Scan) Auto Scan allows for automatic detection of the type of the item placed on the platen. Important • The following types of items may not be scanned correctly. In that case, adjust the cropping frames (scan areas) in whole image view of ScanGear (scanner driver), and then scan again. Photos with a whitish background Items printed on white paper, hand-written text, business cards, and other unclear items Thin items...
Page 376: Scanning Documents And Photos
Scanning Documents and Photos Scan items placed on the platen with settings suitable for documents or photos. Save documents in formats such as PDF and JPEG, and photos in formats such as JPEG and TIFF. 1. Place the item on the platen. Positioning Originals (Scanning from Computer) 2.
Page 377: Creating/Editing Pdf Files
Creating/Editing PDF Files You can create PDF files by scanning items placed on the platen. Add, delete, rearrange pages or make other edits in the created PDF files. Important • You can create or edit up to 100 pages of a PDF file at one time. •...
Page 378 5. Click (Scan) on Toolbar. Scanning starts. Note • To open a file saved on the computer, click Open... from the File menu, and then select the file you want to edit. • You can switch the view with the Toolbar buttons. For details, see PDF Edit Screen. 6.
Page 379 When deleting pages: Click the page you want to delete, and then click (Delete Page) on the Toolbar. Note • These buttons appear when two or more pages have been created. 8. Select Save As... in File menu. The Save dialog box appears. 9.
Page 380: Scanning Using Application Software (Scangear)
Scanning Using Application Software (ScanGear) What Is ScanGear (Scanner Driver)? Starting ScanGear (Scanner Driver) Scanning in Basic Mode ScanGear (Scanner Driver) Screens General Notes (Scanner Driver) Important • Available functions and settings vary depending on your scanner or printer.
Page 381: What Is Scangear (Scanner Driver)
What Is ScanGear (Scanner Driver)? ScanGear (scanner driver) is software required for scanning documents. Use the software to specify the output size, image corrections, and other settings. ScanGear can be started from IJ Scan Utility or applications that are compatible with the standard TWAIN interface.
Page 382 Advanced Mode Use the Advanced Mode tab to scan by specifying the color mode, output resolution, image brightness, color tone, and other settings.
Page 383: Starting Scangear (Scanner Driver)
Starting ScanGear (Scanner Driver) Use ScanGear (scanner driver) to make image corrections and color adjustments when scanning. Start ScanGear from IJ Scan Utility or other applications. Note • If you have more than one scanner or have a network compatible model and changed the connection from USB connection to network connection, set up the network environment.
Page 384: Scanning In Basic Mode
Scanning in Basic Mode Use the Basic Mode tab to scan easily by following these simple on-screen steps. To scan multiple documents at one time from the Platen, see Scanning Multiple Documents at One Time with ScanGear (Scanner Driver). When scanning from the ADF (Auto Document Feeder), preview is not available. Important •...
Page 385 Important • Some applications do not support continuous scanning from the ADF. For details, see the application's manual. Note • To scan magazines containing many color photos, select Magazine (Color). 3. Click Preview. Preview image appears in the Preview area. Important •...
Page 386 Note • Colors are adjusted based on the document type selected in Select Source. 4. Set Destination. Note • Skip ahead to Step 7 if an ADF option is selected in Select Source. 5. Set Output Size. Output size options vary with the selected Destination. 6.
Page 387: Scangear (Scanner Driver) Screens
ScanGear (Scanner Driver) Screens Basic Mode Tab Advanced Mode Tab...
Page 388: Basic Mode Tab
Basic Mode Tab Use the Basic Mode tab to scan easily by following these simple on-screen steps. This section describes the settings and functions available on the Basic Mode tab. (1) Settings and Operation Buttons (2) Toolbar (3) Preview Area Note •...
Page 389 Document (Color) ADF Duplex (only for models supporting ADF duplex scanning) Scan both sides of documents from the ADF in color. Document (Grayscale) ADF Duplex (only for models supporting ADF duplex scanning) Scan both sides of documents from the ADF in black and white. Important •...
Page 390 "OCR software" is software that converts text scanned as an image into text data that can be edited in word processors and other programs. Output Size Select an output size. Output size options vary by the item selected in Destination. Flexible Adjust the cropping frames (scan areas) freely.
Page 391 Deleting: Select the output size you want to delete in Output Size List, and then click Delete. Click Save to save the items listed in Output Size List. Important • Predefined output sizes such as A4 and 1024 x 768 pixels cannot be deleted. Note •...
Page 392 Correct gutter shadow Corrects shadows that appear between pages when scanning open booklets. Important • Be sure to see Gutter Shadow Correction for precautions and other information on using this function. Color Pattern... Adjust the image's overall color. Correct colors that have faded due to colorcast or other reasons and reproduce natural colors while previewing color changes.
Page 393 • The image returns to its original state when you preview again. (Rotate Right) Rotates the preview image 90 degrees clockwise. • The result will be reflected in the scanned image. • The image returns to its original state when you preview again. (Auto Crop) Displays and adjusts the cropping frame automatically to the size of the document displayed in the Preview area.
Page 394 When (Thumbnail) is displayed on Toolbar: Cropping frames are specified according to the document size, and thumbnails of scanned images appear. Only the images with the checkbox selected will be scanned. Note • When multiple images are previewed, different outlines indicate different selection status. Focus Frame (thick blue outline): The displayed settings will be applied.
Page 395 Note • Create cropping frame(s) on the displayed image. In thumbnail view, one cropping frame can be created per image. In whole image view, multiple cropping frames can be created. Adjusting Cropping Frames (ScanGear) Related Topic Scanning in Basic Mode...
Page 396: Advanced Mode Tab
Advanced Mode Tab This mode allows you to make advanced scan settings such as the color mode, output resolution, image brightness, and color tone. This section describes the settings and functions available on the Advanced Mode tab. (1) Settings and Operation Buttons (2) Toolbar (3) Preview Area Important...
Page 397 Enter Setting Name and click Add; the name appears in Favorite Settings List. When you click Save, the item appears in the Favorite Settings list and can be selected, along with the predefined items. To delete an item, select it in Favorite Settings List and click Delete. Click Save to save the settings displayed in Favorite Settings List.
Page 398 Note • Zoom rescans the document and displays high-resolution image in Preview. • (Enlarge/Reduce) on the Toolbar zooms in on the preview image quickly. However, the resolution of the displayed image will be low. Preview Performs a trial scan. Scan Starts scanning.
Page 399 In thumbnail view: In whole image view: (Thumbnail) / (Whole Image) Switches the view in the Preview area. (3) Preview Area (Clear) Deletes the preview image from the Preview area. It also resets the Toolbar and color adjustment settings. (Crop) Allows you to specify the scan area by dragging the mouse.
Page 400 (Uncheck All Frames) Available when two or more frames are displayed. Deselects the checkboxes of the images in thumbnail view. (Select All Frames) Available when two or more frames are displayed. Selects the images in thumbnail view and outlines them in blue. (Select All Cropping Frames) Available when two or more cropping frames are specified.
Page 401 Note • When multiple images are previewed, different outlines indicate different selection status. Focus Frame (thick blue outline): The displayed settings will be applied. Selected Frame (thin blue outline): The settings will be applied to the Focus Frame and Selected Frames simultaneously. To select multiple images, click them while pressing the Ctrl key.
Page 402: General Notes (Scanner Driver)
General Notes (Scanner Driver) ScanGear (scanner driver) is subject to the following restrictions. Keep these points in mind when using it. Scanner Driver Restrictions • When using the NTFS file system, the TWAIN data source may not be invoked. This is because the TWAIN module cannot be written to the winnt folder for security reasons.
Page 403 • When scanning Platen size images into Microsoft Office 2003 (Word, Excel, PowerPoint, etc.), click Custom Insert in the Insert Picture from Scanner or Camera screen. Otherwise, images may not be scanned correctly. • When scanning images into Microsoft Office 2007/Microsoft Office 2010 (Word, Excel, PowerPoint, etc.), use Microsoft Clip Organizer.
Page 404: Scanning Tips
Scanning Tips Positioning Originals (Scanning from Computer) Network Scan Settings IJ Network Scanner Selector EX2 Menu and Setting Screen...
Page 405: Positioning Originals (Scanning From Computer)
Positioning Originals (Scanning from Computer) This section describes how to load originals on the platen for scanning. If items are not placed correctly they may not be scanned correctly. Important • Be sure to observe the following when loading the original on the platen. Failure to observe the following may cause the scanner to malfunction or the platen glass to break.
Page 406 Important Important • Large items (such as A4 size photos) that cannot be • For the portions in which items cannot be scan- placed away from the edges/arrow (alignment mark) of ned, see Loading Originals. the platen may be saved as PDF files. To save in a for- mat other than PDF, scan by specifying the data format.
Page 407: Network Scan Settings
• If the icon is not displayed in the notification area on the desktop, follow the procedure below to start. Windows 10: From the Start menu, click (All apps >) Canon Utilities > IJ Network Scanner Selector EX2. Windows 8.1:...
Page 408 Search charm, then search for "IJ Network Scanner Selector EX2". Windows 7: From the Start menu, click All Programs > Canon Utilities > IJ Network Scanner Selector EX2 > IJ Network Scanner Selector EX2. The icon appears in the notification area on the desktop, and the Scan-from-PC Settings screen appears.
Page 409 • If the icon is not displayed in the notification area on the desktop, follow the procedure below to start. Windows 10: From the Start menu, click (All apps >) Canon Utilities > IJ Network Scanner Selector EX2. Windows 8.1: Click IJ Network Scanner Selector EX2 on the Start screen.
Page 410 4. Select your scanner or printer from Scanners and click OK. Select the MAC address of your scanner or printer. Note • When multiple scanners are connected via a network, you can select up to three scanners. 5. In the Scan-from-PC Settings screen, click OK. Note •...
Page 411: Frequently Asked Questions
Frequently Asked Questions Cannot Find Printer on Network Cannot Find Printer while Using Wi-Fi Network Key (Password) Unknown Network Cannot Print or Connect For other questions about network, click here. Printer Does Not Print Printouts Are Blank/Blurry or Fuzzy/Inaccurate or Bleeding Colors/Streaks or Lines Printout Results Are Unsatisfactory Print List of Support Code for Error (Paper Jams)
Page 412 Printout Results Are Unsatisfactory Scanning Problems (Windows) Scanning Problems (macOS) Scan Results Are Unsatisfactory (Windows) Scan Results Are Unsatisfactory (macOS) Cannot Print/Scan from Smartphone/Tablet Cannot Set Correctly (Network) Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) Cannot Find Printer while Using Wi-Fi Printer Suddenly Stopped Working for Some Reason Network Key (Password) Unknown Forgot Administrator Password of Printer...
Page 413: Network Settings And Common Problems
Network Settings and Common Problems Here are frequently asked questions on network. Select a connection method you are using, or you want to use. Wireless LAN Wireless Direct Wireless LAN Cannot Find Printer Cannot Find Printer while Using Wi-Fi Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) Cannot Proceed beyond Printer Connection Screen Printer is Not Found by Printer Find Screen of Setup Searching Printer by IP Address or Host Name During Setup...
Page 414 Checking Wireless Router Network Name (SSID) for Smartphone/Tablet Setting Up Using Smartphone/Tablet Cannot Print/Scan from Smartphone/Tablet Cannot Find Printer from Smartphone/Tablet while Using Bluetooth Downloading Canon PRINT Inkjet/SELPHY Problems while Using Printer Message Appears on Computer During Setup Printer Prints Slowly...
Page 415: Network Communication Problems
Network Communication Problems Cannot Find Printer on Network Network Connection Problems Other Network Problems...
Page 416: Cannot Find Printer On Network
Cannot Find Printer on Network While performing printer setup: Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) Cannot Proceed beyond Printer Connection Screen While using printer: Cannot Find Printer while Using Wi-Fi...
Page 417: Cannot Find Printer On Check Printer Settings Screen During Setup (Windows)
Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) If the printer cannot be found and the Check Printer Settings screen appears after searching the printer by Automatic search on the Search for Printers screen, click Redetect and search for the printer again by the IP address on the Search for Printers screen.
Page 418: Power Status
Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Power Status Are printer and network device (router, etc.) turned on? Make sure the printer is turned on. Checking that Power Is On Make sure network device (router, etc.) is turned on. If printer or network device is off: Turn on printer or network device.
Page 419: Pc Network Connection
Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking PC Network Connection Can you view any web pages on your computer? Make sure the computer and network device (router, etc.) are configured and the computer is connected to the network.
Page 420 Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Printer's Wi-Fi Settings Is printer set to allow wireless communication? Make sure the icon is displayed on the touch screen. If icon is not displayed: The printer is not set to allow wireless communication. Turn on wireless communication on the printer. If icon is displayed: Checking Wi-Fi Environment...
Page 421: Wi-Fi Environment
Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Wi-Fi Environment Is the printer connected to the wireless router? Use the icon on the touch screen to make sure the printer is connected to the wireless router. is displayed: •...
Page 422 Important • Note that some wireless routers distinguish network names (SSIDs) by the last alphanumeric character according to their bandwidth (2.4 GHz or 5 GHz) or purpose (for computer or game machine). Check the network name (SSID) of the wireless router for the printer on the touch screen. Select (Setup) icon, Device settings, LAN settings, and Wi-Fi, and then check Network name (SSID).
Page 423 Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Printer's IP Address Is printer's IP address specified correctly? If printer's IP address is not specified correctly, the printer may not be found. Make sure whether printer's IP address is not used for another device. To check the printer's IP address, print out the network settings information or use the operation panel to display it.
Page 424: Security Software Settings
• If a firewall message appears: If a firewall message appears warning that Canon software is attempting to access the network, set the security software to allow access. After allowing the software to access, click Redetect on the Check Printer Settings screen to redetect the printer.
Page 425: Wireless Router Settings
Cannot Find Printer on Check Printer Settings Screen During Wi-Fi Setup (Windows)-Checking Wireless Router Settings Check wireless router settings. Check wireless router network connection settings, such as IP address filtering, MAC address filtering, encryption key, and DHCP function. Make sure the same radio channel is assigned to the printer and the wireless router. To check the settings of the wireless router, see the instruction manual supplied with the wireless router or contact the manufacturer.
Page 426: Cannot Proceed Beyond Printer Connection Screen
Cannot Proceed beyond Printer Connection Screen If you cannot proceed beyond the Printer Connection screen, check the following. Make sure USB cable is securely plugged in to printer and computer. Check1 Connect the printer and the computer using a USB cable as the illustration below. The USB port is located at the back of the printer.
Page 427 3. Restart computer. 4. Make sure you have no application software running. 5. Click here and perform setup.
Page 428: Cannot Find Printer While Using Wi-Fi
Cannot Find Printer while Using Wi-Fi Make sure printer is turned on. Check1 If not, make sure the printer is securely plugged in and press ON button to turn on. The ON lamp flashes while the printer is initializing. Wait until the ON lamp stops flashing and remains lit. Check the (Network status) icon on the touch screen.
Page 429 Note • Use 2.4 GHz or 5 GHz frequency band to connect to a wireless router. Match the network name (SSID) set for the printer with that for 2.4 GHz or 5 GHz frequency band of the wireless router. To check the network name (SSID) set for the printer, print out the network setting information. Printing Network Settings Note •...
Page 430 Make sure security software's firewall is off. Check9 If your security software's firewall is on, a message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set security software to always allow access.
Page 431: Network Connection Problems
Network Connection Problems Printer Suddenly Stopped Working for Some Reason Network Key (Password) Unknown Printer Cannot Be Used After Replacing Wireless Router or Changed Router Settings...
Page 432: Printer Suddenly Stopped Working For Some Reason
Printer Suddenly Stopped Working for Some Reason Cannot Connect to a Printer after Network Configuration Changes Cannot Connect to a Printer via Wireless LAN (Wi-Fi) Cannot Connect to a Printer through Wireless Direct Cannot Print/Scan through Network Cannot Connect to a Printer after Network Configuration Changes It may take a while for the computer to obtain an IP address, or you may need to restart your computer.
Page 433 To check the settings of the wireless router, refer to the instruction manual provided with it or contact its manufacturer. Note • Use 2.4 GHz or 5 GHz frequency band to connect to a wireless router. Match the network name (SSID) set for the printer with that for 2.4 GHz or 5 GHz frequency band of the wireless router.
Page 434 Make sure security software's firewall is off. Check9 If your security software's firewall is on, a message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set security software to always allow access.
Page 435 Is the icon displayed on the touch screen? Check2 If not, Wireless Direct is disabled. Turn on Wireless Direct. Check the settings of your device (smartphone/tablet). Check3 Make sure Wi-Fi is enabled on your device. For details, refer to your device's instruction manual. Make sure printer is selected as connection for device (e.g.
Page 436 Make sure the computer is connected to the wireless router. Check1 For more on how to check the computer settings or connection status, see your computer instruction manual or contact its manufacturer. If MP Drivers are not installed, install them. (Windows) Check2 Click here and install the MP Drivers.
Page 437: Network Key (Password) Unknown
Network Key (Password) Unknown WPA/WPA2 or WEP Key Set for Wireless Router Unknown, Cannot Connect Setting an Encryption Key WPA/WPA2 or WEP Key Set for Wireless Router Unknown, Cannot Connect For more on setting up a wireless router, see the instruction manual provided with the wireless router or contact its manufacturer.
Page 438 For macOS: Starting Up IJ Network Device Setup Utility Selecting WPA, WPA2, or WPA/WPA2 is recommended for security reason. If your wireless router is compatible with WPA/WPA2, you can also use WPA2 or WPA. • Using WPA/WPA2 (Windows) The authentication method, Wi-Fi password, and dynamic encryption type must be identical among the wireless router, the printer, and your computer.
Page 439: Printer Cannot Be Used After Replacing Wireless Router Or Changed Router Settings
Printer Cannot Be Used After Replacing Wireless Router or Changed Router Settings When you replace a wireless router, redo the network setup for the printer according to the replaced one. Click here and perform setup. Note • IJ Network Device Setup Utility allows you to diagnose and repair the network status. Select the link below to download IJ Network Device Setup Utility and install it.
Page 440 If using WPA/WPA2 key or a password, make sure encryption key for Check3 computer, network device, and printer matches key set for wireless router. The length or format of the Wi-Fi password and authentication method must be identical among the wireless router, the printer, and your computer.
Page 441: Other Network Problems
Other Network Problems Checking Network Information Restoring to Factory Defaults...
Page 442: Checking Network Information
Printing Network Settings For Windows, you can check the network setting information on the computer screen. Canon IJ Network Device Setup Utility Screen Checking Computer IP Address or MAC Address To check the IP Address or MAC address of your computer, follow the instructions below.
Page 443 2. Make sure network interface used by computer is selected, and then click Advanced. Make sure Wi-Fi is selected as network interface. 3. Click TCP/IP to check the IP address, or click Hardware to check the MAC address. Checking Communication Between the Computer, the Printer, and the Wireless Router Perform a ping test to check if communication is taking place.
Page 444 "XXX.XXX.XXX.XXX" is the IP address of the target device. A message such as the following appears. 64 bytes from XXX.XXX.XXX.XXX: icmp_seq=0 ttl=64 time=3.394 ms 64 bytes from XXX.XXX.XXX.XXX: icmp_seq=1 ttl=64 time=1.786 ms 64 bytes from XXX.XXX.XXX.XXX: icmp_seq=2 ttl=64 time=1.739 ms --- XXX.XXX.XXX.XXX ping statistics --- 3 packets transmitted, 3 packets received, 0% packet loss If "100% packet loss"...
Page 445: Restoring To Factory Defaults
Restoring to Factory Defaults Important • Initialization erases all network settings on the printer, making printing or scanning operation from a computer over a network impossible. To use the printer over a network again after restoring it to the factory defaults, click here and redo setup. Initialize the network setting using the printer's operation panel.
Page 446: Problems While Printing/Scanning From Smartphone/Tablet
Problems while Printing/Scanning from Smartphone/Tablet Cannot Print/Scan from Smartphone/Tablet...
Page 447: Cannot Print/Scan From Smartphone/Tablet
Cannot Print/Scan from Smartphone/Tablet If you cannot print/scan from your smartphone/tablet, it is possible that your smartphone/tablet cannot communicate with the printer. Check the cause of your problem according to the connection method. Cannot Communicate with Printer over Wireless LAN Cannot Communicate with Printer while It Is in Wireless Direct Note •...
Page 448 To check the settings of the wireless router, refer to the instruction manual provided with it or contact its manufacturer. To check the current network settings of the printer, print out the network setting information. Printing Network Settings Note • IJ Network Device Setup Utility allows you to diagnose and repair the network status. Select the link below to download IJ Network Device Setup Utility and install it.
Page 449 Note • IJ Network Device Setup Utility allows you to diagnose and repair the network status. Select the link below to download IJ Network Device Setup Utility and install it. Checking Printer Connection Status Using IJ Network Device Setup Utility See below for starting up IJ Network Device Setup Utility.
Page 450 • Print the network settings. Printing Network Settings Have you entered the proper password specified for the Wireless Direct? Check5 To check the password specified for the printer, display it using the operation panel of the printer or print out the network setting information of the printer.
Page 451: Printing Problems
Printing Problems Printer Does Not Print Ink Does Not Come Out Printer Does Not Pick up or Feed the Paper/"No Paper" Error Cannot Print on the Disc Label Printout Results Are Unsatisfactory...
Page 452: Printer Does Not Print
Printer Does Not Print Make sure printer is turned on. Check1 If not, make sure the printer is securely plugged in and press ON button to turn on. The ON lamp flashes while the printer is initializing. Wait until the ON lamp stops flashing and remains lit. Note •...
Page 453 • If you are using a relay device such as a USB hub, disconnect it, connect the printer directly to the computer, and retry the printing. If printing starts normally, there is a problem with the relay device. Contact the vendor of the relay device. •...
Page 454 • For Windows: Make sure "Canon XXX series" (where "XXX" is your printer's name) is selected in the Print dialog box. Note • If multiple printers are registered to your computer, set your printer as default printer to make the one selected by default.
Page 455: Ink Does Not Come Out
• If problem is not resolved after performing print head deep cleaning twice: If print head deep cleaning does not resolve the problem, the print head may be damaged. Contact your nearest Canon service center to request a repair.
Page 456: Printer Does Not Pick Up Or Feed The Paper/"No Paper" Error
Printer Does Not Pick up or Feed the Paper/"No Paper" Error Make sure paper is loaded. Check1 Loading Paper When loading paper, consider the following. Check2 • When loading two or more sheets of paper, align the edges of the sheets before loading the paper. •...
Page 457 If the paper tears in the rear tray, see List of Support Code for Error (Paper Jams) to remove it. If there are any foreign objects in the rear tray, be sure to turn off the printer, unplug it from the power supply, then remove the foreign object.
Page 458 If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 459: Cannot Print On The Disc Label
Use the multi-purpose tray supplied with this printer. For more on placing the multi-purpose tray, see Placing a Printable Disc. Unrecognizable printable disc may be placed. Check2 Canon recommends that you use printable discs specially processed to be printed on by an inkjet printer.
Page 460 Multi-Purpose Tray Jammed Pull out the multi-purpose tray gently. If the multi-purpose tray cannot be pulled out, cycle the power switch. The multi-purpose tray will automatically be ejected. When the multi-purpose tray is pulled out, place the multi-purpose tray again and retry printing. For more on placing the multi-purpose tray, see Placing a Printable Disc.
Page 461: Printout Results Are Unsatisfactory
Check the settings on your PictBridge (Wi-Fi) compliant device or using the operation panel. PictBridge (Wi-Fi) Print Settings PictBridge settings • Printing from your smartphone/tablet using Canon PRINT Inkjet/SELPHY Check the settings on Canon PRINT Inkjet/SELPHY. Print Photos from Your Smartphone Make sure appropriate print quality is selected (see list above).
Page 462 Note • When printing from a PictBridge (Wi-Fi) compliant device, set the print quality setting using the operation panel. This setting cannot be made on the PictBridge (Wi-Fi) compliant device. If problem is not resolved, check also the sections below. Check3 See also the sections below: Printouts Are Blank/Blurry or Fuzzy/Inaccurate or Bleeding Colors/Streaks or Lines...
Page 463: Printouts Are Blank/Blurry Or Fuzzy/Inaccurate Or Bleeding Colors/Streaks Or Lines
Printouts Are Blank/Blurry or Fuzzy/Inaccurate or Bleeding Colors/ Streaks or Lines Printing Is Blurry Colors Are Wrong...
Page 464 White Streaks Appear Check paper and print quality settings. Check1 Printout Results Are Unsatisfactory Check status of ink tanks. Replace ink tank if ink has run out. Check2 Replacing Ink Tanks Are the orange tape and plastic wrap still on the ink tank? Check3 Make sure all the protective plastic wrap is peeled off to expose the Y-vent area, as shown below (A).
Page 465 • If problem is not resolved after performing print head deep cleaning twice: If print head deep cleaning does not resolve the problem, the print head may be damaged. Contact your nearest Canon service center to request a repair. When using paper with one printable surface, check the correct printable side Check5 of the paper.
Page 466: Lines Are Misaligned/Distorted
Lines Are Misaligned/Distorted Check paper and print quality settings. Check1 Printout Results Are Unsatisfactory Perform print head alignment. Check2 If printed lines are misaligned/distorted or print results are otherwise unsatisfactory, adjust the print head position. Aligning the Print Head Note •...
Page 467: Paper Is Smudged / Printed Surface Is Scratched
Paper Is Smudged / Printed Surface Is Scratched Paper Is Smudged Smudged Edges Smudged Surface Printed Surface Is Scratched Check paper and print quality settings. Check1 Printout Results Are Unsatisfactory Check paper type. Check2 Make sure you are using the right paper for what you are printing. Supported Media Types Correct curl before loading paper.
Page 468 1. Roll up paper in opposite direction to paper curl as shown below. 2. Check that paper is now flat. We recommend printing curl-corrected paper one sheet at a time. Note • Depending on paper type, the paper may smudge or may not feed properly even if it is not curled inward. Follow the instructions below to curl the paper outward up to 0.1 in.
Page 469 • From computer (Windows): 1. Check that printer is turned on. 2. Open Canon IJ Printer Assistant Tool. Opening the Maintenance Tool (Canon IJ Printer Assistant Tool) 3. Select Custom Settings. 4. Select Prevents paper abrasion check box and select OK.
Page 470 1. Check that printer is turned on. 2. Open Canon IJ Printer Assistant Tool. Opening the Maintenance Tool (Canon IJ Printer Assistant Tool) 3. Select Custom Settings. 4. Drag Ink Drying Wait Time slide bar to set the wait time and select OK.
Page 471: Vertical Line Next To Image
Vertical Line Next to Image Is loaded paper size correct? Check If the loaded paper is larger than the size you specified, vertical lines (A) may appear in the left margin or the both margin. Set the paper size to match the loaded paper. Printout Results Are Unsatisfactory Note •...
Page 472: Scanning Problems (Windows)
Scanning Problems (Windows) Scanning Problems...
Page 473: Scanning Problems
Scanning Problems Scanner Does Not Work ScanGear (Scanner Driver) Does Not Start...
Page 474: Scanner Does Not Work
Scanner Does Not Work Make sure that your scanner or printer is turned on. Check 1 Connect the USB cable to a different USB port on the computer. Check 2 If the USB cable is connected to a USB hub, remove it from the USB hub and Check 3 connect it to a USB port on the computer.
Page 475: Scangear (Scanner Driver) Does Not Start
ScanGear (Scanner Driver) Does Not Start Make sure MP Drivers is installed. Check 1 If not installed, install MP Drivers from the Setup CD-ROM or our website. Select your scanner or printer on the application's menu. Check 2 Important • If your scanner or printer name is displayed multiple times, select the one that does not include WIA. Note •...
Page 476: Mechanical Problems
Mechanical Problems Printer Does Not Turn On Printer Turns Off Unexpectedly or Repeatedly USB Connection Problems Cannot Communicate with Printer via USB Wrong Language Appears in Touch Screen...
Page 477: Printer Does Not Turn On
Make sure power plug is securely connected to printer, and then turn on again. Check2 Unplug printer, leave it for at least 2 minutes, and then plug it back in and turn Check3 on again. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 478: Printer Turns Off Unexpectedly Or Repeatedly
The setting is disabled. • To disable the setting from the computer: For Windows, use Canon IJ Printer Assistant Tool or ScanGear (scanner driver) to disable the setting. Follow the procedure below to disable the setting using Canon IJ Printer Assistant Tool.
Page 479 4. Select OK. 5. Select OK on the displayed screen. The setting to shut off the power automatically is disabled. Note • Refer to below to disable the setting from ScanGear (scanner driver). Scanner Tab...
Page 480: Usb Connection Problems
USB Connection Problems Make sure of the checking item below when you find one of the followings. • Printing or scanning is slow. • Hi-Speed USB connection does not work. • A message such as "This device can perform faster" appears. (Windows) Note •...
Page 481: Cannot Communicate With Printer Via Usb
Cannot Communicate with Printer via USB Make sure printer is turned on. Check1 Connect USB cable properly. Check2 As the illustration below, the USB port is at the back of the printer. Important • Connect the "Type-B" terminal to the printer with the notched side facing UP. For details, refer to the instruction manual supplied with the USB cable.
Page 482: Wrong Language Appears In Touch Screen
Wrong Language Appears in Touch Screen Follow the instructions below to select your language. 1. Tap HOME button and wait a little. 2. Select (Setup). Using the Operation Panel 3. Select 4. Select seventh setting item from top. 5. Select a language for touch screen. 6.
Page 483: Installation And Download Problems
Installation and Download Problems Failed to MP Drivers Installation (Windows) Updating MP Drivers in Network Environment (Windows)
Page 484: Failed To Mp Drivers Installation (Windows)
Failed to MP Drivers Installation (Windows) If you cannot get past the Printer Connection screen: Other cases: If you cannot get past the Printer Connection screen: Cannot Proceed beyond Printer Connection Screen Other cases: If the MP Drivers were not installed correctly, uninstall the MP Drivers, restart your computer, and then reinstall the MP Drivers.
Page 485: Updating Mp Drivers In Network Environment (Windows)
Updating MP Drivers in Network Environment (Windows) Download the latest MP Drivers. Download the latest MP Drivers for your model on the download page of the Canon website. Uninstall the existing MP Drivers and follow the installation instructions to install the latest MP Drivers that you downloaded.
Page 486: Errors And Messages
Errors and Messages When Error Occurred Message (Support Code) Appears...
Page 487: When Error Occurred
When Error Occurred If an error occurs in printing, for example if the paper runs out or jams, a troubleshooting message appears automatically. Take the appropriate action described in the message. When an error occurs, a message is displayed on the computer or on the printer. For some errors, a support code (error number) is also displayed.
Page 488: Message (Support Code) Appears
Message (Support Code) Appears This section describes some of the messages that may appear. Note • A support code (error number) is displayed for some errors. For details on errors that have support code, see List of Support Code for Error.
Page 489 Check3 Uninstall the MP Drivers following the procedure described in Deleting the Unnecessary MP Drivers and reinstall them from the Setup CD-ROM or the Canon website. When printer is connected to your computer with a USB cable, check device Check4 status from your computer.
Page 490 • "Printer driver could not be found" Uninstall the MP Drivers following the procedure described in Deleting the Unnecessary MP Drivers and reinstall them from the Setup CD-ROM or the Canon website. • "Could not print Application name - File name"...
Page 491: List Of Support Code For Error
List of Support Code for Error Support code appears on the touch screen and your computer screen when errors occur. A "support code" is an error number, and appears along with an error message. When an error occurs, check the support code displayed on the touch screen and computer screen and take the appropriate action in response.
Page 492 • 5000 to 5ZZZ 5011 5012 5050 5100 5200 520E 5400 5700 5B00 5B01 5C02 • 6000 to 6ZZZ 6000 6001 6004 6500 6502 6800 6801 6830 6831 6832 6833 6900 6901 6902 6910 6911 6930 6931 6932 6933 6934 6935 6936 6937 6938 6940 6941 6942 6943 6944 6945 6946 6951 6A80 6A81 6D01 •...
Page 493: List Of Support Code For Error (Paper Jams)
List of Support Code for Error (Paper Jams) If paper jams, remove it following the appropriate procedure as shown below. • If you can see the jammed paper at the paper output slot or the rear tray: 1300 • If you cannot see the jammed paper at the paper output slot or the rear tray: ◦...
Page 494 1300 Cause Paper is jammed when feeding paper from rear tray. What to Do If the paper fed from the rear tray is jammed, remove the jammed paper from the paper output slot or from the rear tray following the instructions below. 1.
Page 495 • We recommend using paper sizes other than A5 to print documents with photos or graphics. A5 paper may curl and jam as it leaves the printer. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 496 The printer resumes printing. Reprint the page you were printing if it was not printed properly due to the paper jam. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 497 The printer resumes printing. Reprint the page you were printing if it was not printed properly due to the paper jam. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 498 1313 Cause Paper is jammed as printer pulled in printed paper. What to Do If the paper is jammed as the printer pulled in the printed paper, try to remove the paper from the following locations. • Paper output slot 1300 •...
Page 499: Paper Is Jammed Inside Printer
Paper Is Jammed inside Printer If the jammed paper tears and you cannot remove the paper from the paper output slot / the feed slot of the cassette / the rear tray, or if the jammed paper remains inside the printer, remove the paper following the instructions below.
Page 500 4. Hold jammed paper firmly in both hands. If the paper is rolled up, pull out it. 5. Slowly pull out paper, so as not to tear it. Pull out the paper at an angle of about 45 degrees. 6. Make sure all jammed paper is removed.
Page 501 Check the printer again for any remaining bits of paper. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 502: Removing Jammed Paper From Rear Side
Removing Jammed Paper from Rear Side Note • If paper becomes jammed during printing and you need to turn off the printer to remove it, tap Stop on the touch screen to stop the printing before you turn off the printer. 1.
Page 503 5. Slowly pull out paper. Note • Do not touch the inner parts of the printer. If you were not able to remove the paper in this step, detach the transport unit cover and remove the paper by following these steps. 1.
Page 504 2. Slowly pull out paper. Note • Do not touch the inner parts of the printer. 3. Make sure all jammed paper is removed. 4. Attach transport unit cover. Insert the transport unit cover slowly all the way into printer and take down the transport unit cover.
Page 505 6. Attach rear cover. Insert the projections of the right side of the rear cover into the printer, and then push the left side of the rear cover until it is closed completely. The print data that was sent to the printer is erased. Redo the printing. Note •...
Page 506 If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
Page 507 1000 Cause Possible causes include the following. • There is no paper in the rear tray. • Paper is not loaded in the rear tray properly. What to Do Take the corresponding actions below. • Load paper in the rear tray. Loading Paper in the Rear Tray •...
Page 508: Paper Is Not In The Cassette (1003)
Paper is Not in the Cassette (1003) Cause Possible causes include the following. • There is no paper in the cassette. • Paper is not loaded in the cassette properly. What to Do Take the corresponding actions below. • Load paper in the cassette. Loading Paper in the Cassette Note •...
Page 509 1013 Cause Multi-purpose tray compatible media is not set on multi-purpose tray, or the media position is misaligned. What to Do Remove the multi-purpose tray, place the multi-purpose tray compatible media properly, and then attach the multi-purpose tray to the printer. Placing Multi-purpose Tray Then select OK on the touch screen.
Page 510 1200 Cause Scanning unit / cover is open. What to Do Close the scanning unit / cover and wait for a while. Do not forget to close it, such as after replacing ink tanks.
Page 511 1401 Cause Print head may be damaged. What to Do Turn off the printer and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 512 1600 Cause Ink may have run out. What to Do Replacing the ink tank is recommended. If printing is in progress and you want to continue printing, tap OK on the printer with the ink tank installed. Then printing can continue. Replacing the ink tank is recommended after the printing. The printer may be damaged if printing is continued under the ink out condition.
Page 513 1660 Cause The ink tank cannot be recognized. What to Do Printing cannot be performed because the ink tank is not installed or is not compatible with this printer. Check the ink tank. If you want to cancel printing, tap Stop on the printer.
Page 514 With this operation, disabling the function for detecting the remaining ink level is memorized. Please be advised that Canon shall not be liable for any malfunction or trouble which may be caused by continuation of printing under the ink out condition.
Page 515 With this operation, disabling the function for detecting the remaining ink level is memorized. Please be advised that Canon shall not be liable for any malfunction or trouble caused by continuation of printing under the ink out condition or by using refilled ink tanks.
Page 516 Cause Ink absorber is almost full. What to Do Select OK on the touch screen to continue printing. Contact your nearest Canon service center to request a repair. Note • In the case of warnings or errors caused by remaining ink levels, the printer cannot print or scan.
Page 517: Shipping Tape Etc. Are Still Attached (1890)
Shipping Tape etc. Are Still Attached (1890) Cause Tape for securing print head holder during transportation may still be attached. What to Do Open the scanning unit / cover and make sure the tape for securing the print head holder during transportation has been removed.
Page 518 2110 Cause Paper settings for printing or copying do not match cassette paper information set on printer. Note • See below for the correct correspondence between paper settings made on the printer driver or on the printer. Paper Settings on the Printer Driver and the Printer (Media Type) (Windows) Paper Settings on the Printer Driver and the Printer (Paper Size) (Windows)
Page 519 Select the appropriate action. Note • Depending on settings, some of the options below may not appear. Print with the loaded paper. Select this option to print or copy onto the paper in the cassette without changing the paper settings. For example, if the print or copy paper setting is A5, and cassette paper information is set to A4, the A5 size setting is used to print or copy onto the paper in the cassette.
Page 520 To change the message view setting when printing or copying using the operation panel of the printer: Feed settings To change the message view setting when printing using the printer driver: Changing the Printer Operation Mode (Windows) Changing the Printer Operation Mode (macOS)
Page 521 2113 Cause Paper settings for printing or copying do not match either rear tray or cassette paper information set on printer. Note • See below for the correct correspondence between paper settings made on the printer driver or on the printer. Paper Settings on the Printer Driver and the Printer (Media Type) (Windows) Paper Settings on the Printer Driver and the Printer (Paper Size)
Page 522 Select the appropriate action. Note • Depending on settings, some of the options below may not appear. Print with the loaded paper. Select this option to print or copy onto the paper in the rear tray or the cassette without changing the paper settings.
Page 523 Note • To suppress the misprint prevention message, change the setting as described below. When you suppress the message, the printer uses the paper settings for printing or copying onto the paper in the cassette regardless of whether or not the paper matches these settings. To change the message view setting when printing or copying using the operation panel of the printer: Feed settings...
Page 524 2114 Cause Paper settings for printing or copying do not match rear tray paper information set on printer. Note • See below for the correct correspondence between paper settings made on the printer driver or on the printer. Paper Settings on the Printer Driver and the Printer (Media Type) (Windows) Paper Settings on the Printer Driver and the Printer (Paper Size) (Windows)
Page 525 Select the appropriate action. Note • Depending on settings, some of the options below may not appear. Print with the loaded paper. Select this option to print or copy onto the paper in the rear tray without changing the paper settings. For example, if the print or copy paper setting is A5, and rear tray paper information is set to A4, the A5 size setting is used to print or copy onto the paper in the rear tray.
Page 526 To change the message view setting when printing or copying using the operation panel of the printer: Feed settings To change the message view setting when printing using the printer driver: Changing the Printer Operation Mode (Windows) Changing the Printer Operation Mode (macOS)
Page 527 4103 Cause Cannot perform printing with current print settings. What to Do Tap Stop on the touch screen to cancel printing. Then change the print settings and retry printing.
Page 528 Printer error has occurred. What to Do Turn off the printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 529 Printer error has occurred. What to Do Turn off the printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 530 If you soil or scratch this part by touching it with paper or your hand, it could damage the printer. • Make sure the ink tanks are properly installed. Press ink tanks until they click into place. Turn the printer back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 531 What to Do Turn off the printer and unplug it. After a while, plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 532: 5B00
5B00 Cause Printer error has occurred. What to Do Contact your nearest Canon service center to request a repair. Note • In the case of warnings or errors caused by remaining ink levels, the printer cannot print or scan.
Page 533 List of Support Code for Error (Paper Jams) Turn off the printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
Page 534 Printer error has occurred. What to Do Turn off the printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair.
