NYC8010MS_QSG_ENG_MP_0519 5/19/04 8:57 AM Page 1
1
CONNECTING
DEW CAUTION
Condensation can form inside the DVD+VCR when it is suddenly moved
from a cold place to a warm or humid environment.In any such circum-
stance do not use this DVD+VCR 1-1/2 to 2 hours allowing complete
elimination of any condensation.
ANTENNA
AUDIO INPUT
INPUT
L
Audio input
RF Cable
Audio Cable
Audio out
2
Setting the RF Output Channel and Auto Channel Programming
DVD/VCR select button
Select the output source (DVD or VCR) to view
on the TV screen.
To use a VCR, first press VCR.
To use a DVD, first press DVD.
Setting the RF output channel
When the DVD+VCR is turned off, press and hold
CHANNEL (V/v) on the front panel for more then
five seconds to change the RF output channel
(CH03 or CH04).
"RF 03" or "RF 04" appears in the display window.
When using the Audio/Video cable, set your TV to
VIDEO
the VIDEO mode using the TV/VIDEO button on
INPUT
your TV.
R
Video input
Video Cable
Video out
Inserting The Batteries
Your REMOTE CONTROL HANDSET is
powered by two AAA type batteries.
1. To insert them, push the tab backwards
and lift off the cover of the handset.
2. Put the two batteries into the compartment
making sure the and are correctly
+ -
positioned.
3. Replace the cover.
1
Press SETUP MENU and the MAIN
menu appear.
2
Press v/V to select the TUNING menu,
then press SELECT/ENTER.
The TUNING menu will appear.
3
Press V to choose the SOURCE
SELECT option, then press b/B to
select TUNER.
Press b/B repeatedly to switch among
TUNER, LINE1 and LINE2.
4
Press v/V to choose the AUTO CHANNEL
SET option, then press b/B to set the
channel.
The tuner will automatically cycle
through all available channels
(TV/CATV) in the area and place them
in the tuner's memory.
After the AUTO CHANNEL SET PRO-
CEEDING is complete, the TUNING
menu will hide and return to the TV
screen automatically.
5
Make sure the TUNING BAND is set
appropriately (TV or CATV).
• TV : If you are using a standard antenna to
receive channels.
CATV : If you are using basic cable to receive
channels.
• Change the setting of TUNING BAND to
check the TV channels.
6
Use CH/TRK (v/V) on the remote con-
trol or CHANNEL (V/v) on the front
panel to cycle the DVD+VCR through
the channels in memory.
