Operating Instructions • Warning Information
WARNING
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
RPM OF THE ACCESSORY
RPM
RPM
RPM
MUST EXCEED TOOL RPM
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains
chemicals known to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specially designed
to filter out microscopic particles.
SPECIFICATIONS
Free Speed ................................................................ 400 RPM
Vibration .................................................................... 0.4 m/s2
Sound Pressure Level .................................................. 89 dBA
Sound Power Level .................................................... 101 dBA
Maximum Capacity .......................................................... 1/2"
Air Inlet......................................................................1/4" NPT
Air Hose Size .................................................................... 3/8"
Air Pressure ...................................................................90 psi
Average Air Consumption .............................................. 4 cfm
Overall Length ...............................................................7-7/8"
Weight ............................................................................ 4 lbs.
CAT-255
• Parts Breakdown
WARNING
1/2" Reversible Air Drill
Copyright © Professional Tool Products, 2016
1
CAT255
w/Chuck
All rights reserved
Rev. 07/12/16
Advertisement
Related Manuals for Cornwell Tools CAT255
Summary of Contents for Cornwell Tools CAT255
- Page 1 SPECIFICATIONS Free Speed ..............400 RPM Vibration ..............0.4 m/s2 CAT255 Sound Pressure Level ..........89 dBA Sound Power Level ............ 101 dBA 1/2" Reversible Air Drill Maximum Capacity ............1/2"...
- Page 2 • RPM OF THE ACCESSORY MUST EXCEED TOOL RPM • Air un der pres sure can cause se vere in ju ry. Nev er • Use accessories recommended by Cornwell Tools. di rect air at your self or oth ers. Al ways turn off the air sup ply, drain hose of air pres sure and de tach •...
- Page 3 and cause it to overheat. Reduce pres sure just before bit cuts Air Supply through the work. When bit has pen e trat ed work and is spin ning Whip Hose Do Not Install Filter Quick Coupling Nipple Nipple freely, take it from the work while the motor is run ning, then turn Here off drill.
- Page 4 PARTS BREAKDOWN - CAT-255 Ref. # Item # DESCRIPTION QTY. Ref. # Item # DESCRIPTION QTY. RS25501 Motor Housing Pin (incl'd w/#26 & #27) (4x13.8L) 6 RS76202 Spring Pin (2.5x24L) Bushing (included w/#23) RS79503 Air Inlet RS78626 Work Spindle (includes #24) RS78804 Trigger RS78627...
