- Page 1 Display Manual Sphinx II Ananda D16...
-
Page 2: Table Of Contents
Table of Contents Instructions for users 1 About Users Guide 2 Material and overall dimension 3 Function Overview 4 Normal display areas 5 Normal operation 5.1 Start/ stop 5.2 Real-time speed/ mileage data display 5.3 Automatic headlight on/ off mode 5.4 Assist walk in 6 km/h 5.5 Assist level adjustment 5.6 Battery level display... -
Page 3: Instructions For Users
Instructions for users Pay attention to safety during use. DO NOT plug in or out when the instrument is power on. This instrument shall be protected against collision as practical as possible. Send the faulty meter for repair as soon as possible. 1. -
Page 4: Function Overview
2.2 Overall dimension (in mm) The instrument key module is connected to the bottom of theinstrument display module via cable. Introduction to various keys: ◆[start/stop]key: key, substituted by word “start/stop”; ◆[plus]key: + key,substitutedbyword“plus”; ◆[minus]key: - key, substituted by word “minus”; ◆[headlight]key: key, substituted by word “headlight”;... - Page 5 ◆ USB available for charging, output voltage/ max output current: 5V/1A ◆ WiFi function ◆ Error code display ◆ Instrument is available for one-key battery wakeup. ◆ Setting function display: clearing, light sensing, speed unit, power consumption unit, language selection, factory reset, WiFi status and name, automatic shutdown time, and customized clipping function.
-
Page 6: Normal Display Areas
4. Normal display areas Area indicates the current remaining battery level. It is the mode of battery display grid in the figure. Area indicates USB charging. Area indicates the fault reminds. Area indicates WiFi. Area shows the headlight status indication, including automatic mode and manual mode Area... - Page 7 ◆ The instrument has been turned on when the battery has output. The battery will be closed and the system will be turned off if the instrument is shut off before the battery. ◆ If the instrument has been turned on when the battery has output, the instrument will be shut off by keeping the instrument on-off key pressed for 2 seconds.
-
Page 8: Real-Time Speed/ Mileage Data Display
5.2 Real-time speed/ mileage data display In the main interface, current speed will be refreshed in a real time manner and meanwhile, mileage related data can be checked. It may switch the display of ODO mileage data by pressing the key “start/ stop”, in the following sequence: Total mileage ->... -
Page 9: Automatic Headlight On/ Off Mode
5.3 Automatic headlight on/ off mode In the main interface, operations to realize the headlight function can be done. When the headlight is off, it can be turned on by keeping the key “headlight” pressed manually; if the headlight is on, it can be turned off by keeping the key “headlight”... -
Page 10: Assist Level Adjustment
5.5 Assist level adjustment In the main interface, gear position operation can be realized. It may add the gear level by pressing the key “plus” and reduce the gear level by pressing the key “minus”. Output power of motor can be changed by adding and reducing the assist level. -
Page 11: Battery Level Display
5.6 Battery level display In the main interface, battery level is displayed in the form of real-time refreshing. Battery level is displayed in two different cases. It will preferentially obtain battery level information from BMS and show the battery level in the form of pixel bar. If it fails to obtain information from BMS, battery level information will be. - Page 12 The fault code can be cleared only after eliminating the current code and meanwhile,“ ” sign shown in the above column will disappear. (Main interface for an example of error code display is added.)In case of error code 30, it must be alarmed and displayed within 5 seconds after abnormal communication and meanwhile, the instrument will be automatically turned off 60 seconds later.
-
Page 13: Usb Charging Function Display
Brake fault Check the crank before system power on Test and check whether the instrument Other faults connection is intact. Abnormal communicati Check whether the connections are intact. Start key is Test the key and replace the instrument sticky when key if this fault still exists. -
Page 14: Wifi Function Display
5.9 WiFi function display When WiFi function is activated. After start, WiFi function sign will be lighted if it has been connected to WiFi. If wireless connection is off, WiFi sign will be off. WiFi indication in case that wireless connection has been achieved. - Page 15 Setting menu interface can be divided into four levels for menu settings, as follows:...
- Page 16 Details about the setting options are described as follows: Enter setting interface by keeping keys [+] and [-] pressed. Enter pressing the key start. After entering by pressing the key start Choose via up and down keys and confirm via start/ stop Basic operating process...
-
Page 17: Trip Distance Parameter Reset
6.1 Trip distance parameter reset Display of trip distance parameter reset option Switch and choose to clear options by pressing key “minus” or “plus”. Choose the option “Yes” and press the key “OK”, to clear related data of single trip. In the option “return”, press the key “start/ stop”... -
Page 18: Setting Of Speed Unit
6.3 Setting of speed unit Options of speed unit Switch and choose the option of speed unit by pressing the key “minus” or “plus”. Confirm the current speed unit chosen by pressing the key “start/ stop”. Return to the interface of previous level by pressing the key “start/ stop”... -
Page 19: Setting Of Factory Reset
6.6 Setting of factory reset Options of factory reset Switch and choose the reset option by pressing the key “minus” or “plus”. Choose option “Yes” and then press the key “start/ stop”, to reset all data to factory default. In the option “return”, press the key “start/ stop”... -
Page 20: Setting Of Function Clipping
6.8 Setting of function clipping Options of function clipping Switch and choose the option of clipping function required by pressing the key “minus” or “plus”. After choosing the option to be clipped, press the key “start/ stop”, to choose whether the current option will be clipped. -
Page 21: Display Of Motor Read-Only Information
6.10 Display of motor read-only information Content of motor read-only information. Switch and choose the option of motor read-only information to be checked by pressing the key “minus” or “plus”. In the option “return”, press the key “start/ stop” to return the interface of previous level. - Page 22 Blue Green Black Yellow...
- Page 23 8 Instructions for Mobile APP Connection 1. According to the following website link, Android or IPhone may download and install mobile APP for product D16. Latest version of APP: IOS : https://app.bitrise.io/artifact/42180616/p/7bf11de b1cf6495ff5c57b8ede7fe329https://app.bitrise.io/artifac t/42180616/p/7bf11deb1cf6495ff5c57b8ede7fe329 Android : https://app.bitrise.io/artifact/42180612/p/32b9 c79bf38f8f6218d1dea8391515df The mobile D16 APP software icon is Open the D20 APP software shown below:...
- Page 24 Click the column “Parametres” once. The display interface is as below: Click the column “Connector un nouveau velo” in the red box once. The display interface is as below:...
- Page 25 Click “OUI” in the red block once. The display interface is as below: Click “Valider” once. The display interface is as here...
- Page 26 Click “C`est parti” once. The display interface is as below: Choose “Naka_44774” and click “Valider” once. The display interface is as here:...
- Page 27 Click “Commencer” once. The display interface is as below: Click “GO” once and enter APP control interface:...
- Page 28 Keep mobile phone 10~15 meters away from D16 instrument; turn the crank. The interface will show batter level, average speed and corresponding information, indicate the normal communication between D16 instrument and mobile Bluetooth as well as the normal functions. Turn off the vehicle system and exit mobile APP software.
-
Page 29: Q&A
9. Q&A Q: Why is the meter not turned on? A: Check whether the harness of the meter is in reliable contact with the connector of the controller. Q: What should I do if the meter shows a fault code? A: First, find the corresponding problem according to the displayed error code.
