Cooper Lighting PM613OB Specification Sheet

AR70 12V
Open Back Machined Fixture
PM613ob
A machined aluminum track fixture for low voltage
AR70 lamps for 20 or 50 watts. For use with RSA
Profile Series 60 Amp Busway.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
Open Back Machined Fixture
❑ PM613ob - AR70 for 60 Amp Busway
Ordering Example: PM613ob-50-AL
www.rsalighting.com
PM42
BUSWAY SURFACE
5.33"
6.67"
C L
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: 818-349-3031
®
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice
Catalog #
Type
Project
4.34"
370º Locking
Adjustability
Lamp Wattage
❑ 20 20 Watt 12V AR70
❑ 50 50 Watt 12V AR70
60 Amp Busway Adapter
C L
2.68"
3.84"
270º Locking
Adjustability
Finish
❑ WH White
❑ BK Black
Natural Aluminum
❑ AL
❑ PT Custom Finish
www.cooperlighting.com
PM613ob
5.96"
