Cooper Lighting PM612ob Specification Sheet

MR16 12V
Open Back Machined Fixture
PM612ob
A machined aluminum track fixture for low voltage
MR16 lamps from 20 to 71 watts. For use with RSA
Profile Series 60 Amp Busway.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Clear lens included.
Available in White, Black, Natural Aluminum or
custom finishes.
Open Back Machined Fixture
❑ PM612ob - MR16 for 60 Amp Busway
Ordering Example: PM612ob-50-AL
www.rsalighting.com
PM34
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: 818-349-3031
®
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice
Catalog #
Type
Project
Lamp Wattage
❑ 20 20 Watt 12V MR16
❑ 37 37 Watt 12V MR16
❑ 42 42 Watt 12V MR16
50 Watt 12V MR16
❑ 50
71 Watt 12V MR16
❑ 71
60 Amp Busway Adapter
Finish
❑ WH White
❑ BK Black
❑ AL Natural Aluminum
Custom Finish
❑ PT
www.cooperlighting.com
PM612ob
