Summary of Contents for Honda CB650RA 2021
- Page 1 Contents Vehicle Safety P. 2 Operation Guide P. 16 Maintenance P. 60 Troubleshooting P. 98 Information P. 109 Specifications P. 134 31MKYG00 2021 CB650RA MOM 17595 (2008)
- Page 2 Welcome Congratulations on your purchase of a new When service is required, remember that Honda vehicle. Your selection of a Honda your Honda dealer knows your vehicle best. makes you part of a worldwide family of If you have the required mechanical “know- satisfied customers who appreciate Honda's how”...
- Page 3 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...
- Page 4 Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Labels............P. 6 Safety Precautions..........P. 8 Riding Precautions ..........P. 9 Accessories & Modifications......P. 14 Loading ..............
- Page 5 Safety Guidelines Safety Guidelines Instruct your passenger on holding onto the seat strap or your waist, leaning with you in Follow these guidelines to enhance your safety: turns, and keeping their feet on the footpegs, even when the vehicle is stopped. Perform all routine and regular inspections ●...
- Page 6 Be prepared to stop quickly or perform an either. evasive maneuver. Keep Your Honda in Safe Condition Make Yourself Easy to See It's important to keep your vehicle properly Make yourself more visible, especially at night, maintained and in safe riding condition.
- Page 7 Safety Guidelines WARNING If you decide to continue riding, first turn the ignition switch to the OFF position, and evaluate Running the engine of your vehicle the condition of your vehicle. Inspect for fluid while in an enclosed or even partially leaks, check the tightness of critical nuts and enclosed area can cause a rapid build- bolts, and check the handlebar, control levers,...
- Page 8 Safety Labels Safety Labels serious injury. Read these labels carefully and don't remove them. Safety and information labels on your vehicle If a label comes off or becomes hard to read, contact your dealer for a replacement. provide important safety information and may warn you of potential hazards that could cause...
- Page 9 Safety Labels...
- Page 10 Safety Precautions Safety Precautions Helmet Should be safety-standard certified, high- Ride cautiously and keep your hands on the visibility, and correct size for your head ● handlebar and feet on the footpegs. Must fit comfortably but securely, with the ● Keep passenger's hands onto the seat strap chin strap fastened.
- Page 11 Riding Precautions Riding Precautions Gloves Full-finger leather gloves with high abrasion resistance Break-in Period Boots or Riding Shoes During the first 300 miles (500 km) of running, Sturdy boots with non-slip soles and ankle follow these guidelines to ensure your vehicle's future reliability and performance.
- Page 12 Riding Precautions Exercise caution on low traction surfaces. Anti-lock Brake System (ABS) ● The tires slip more easily on such This model is equipped with an Anti-lock Brake surfaces and braking distances are System (ABS) designed to help prevent the longer.
- Page 13 Riding Precautions Engine Braking Parking Engine braking helps slow your vehicle down Park on a firm, level surface. ● when you release the throttle. For further If you must park on a slight incline or loose ● slowing action, downshift to a lower gear. Use surface, park so that the vehicle cannot engine braking with intermittent use of the move or fall over.
- Page 14 Riding Precautions Parking with the Side Stand Refueling and Fuel Guidelines Stop the engine. Follow these guidelines to protect the engine, Push the side stand down. fuel system and catalytic converter: Slowly lean the vehicle to the left until its Use only unleaded gasoline.
- Page 15 Torque Control may not compensate for rough Honda selectable torque control road conditions or rapid throttle operation. When the Honda selectable torque control Always consider road and weather conditions, (Torque Control) detects rear wheel spin during as well as your skills and condition, when acceleration, the system will limit the amount of applying throttle.
- Page 16 We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed or approved for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.
- Page 17 Loading Loading WARNING Carrying extra weight affects your vehicle's ● Overloading or improper loading can handling, braking and stability. cause a crash and you can be seriously Always ride at a safe speed for the load you hurt or killed. are carrying.
- Page 18 Parts Location Battery (P.80) Fuse box (P.108) Front brake fluid reservoir (P.87) Front brake lever (P.96) Throttle grip (P.95) Rear brake fluid reservoir (P.87) Engine oil fill cap/dipstick (P.83) Coolant reserve tank (P.85) Rear brake pedal Brake light switch (P.89)
- Page 19 Clutch lever (P.92) Fuel fill cap (P.57) Front seat (P.81) Helmet holder (P.58) Tool kit (P.58) Rear seat (P.82) Document bag (P.59) Rear suspension spring preload adjuster (P.97) Shift lever (P.56) Drive chain (P.91) Side stand (P.90)
- Page 20 Instruments button button Display Check When the ignition switch is turned to the ON position, initial animation will show. If any part of these displays do not come on when it should, have your dealer check for problems.
- Page 21 Tachometer red zone Clock (12-hour or 24-hour display) (excessive engine rpm range) To set the clock: (P.31) Speedometer Section B display (P.25) Section A display (P.21) Gear position indicator The gear position is shown in the gear position indicator. “-” appears when the transmission is not shifted properly. Tachometer NOTICE Do not operate the engine in the tachometer red zone.
- Page 22 Instruments (Continued) Coolant temperature gauge When the coolant is over the specified temperature, the segment H flashes. If the segment H flashes while riding: (P.100) If the coolant temperature gauge indicator flashes: (P.105) Fuel gauge Remaining fuel when only 1st (E) segment starts flashing: approximately 0.85 US gal (3.2 L) If the fuel gauge indicator flashes in a repeat pattern or turns off:...
- Page 23 Section A display Changing the section A display You can select the following: With the button, you can switch the Current fuel mileage section A display between the current fuel ● Average fuel mileage [AVG] mileage, average fuel mileage, fuel ●...
- Page 24 Instruments (Continued) Current fuel mileage Average fuel mileage [AVG] Displays the average fuel mileage since the Displays the current instant fuel mileage. selected tripmeter was reset. The average fuel mileage will be calculated Display range: 0.0 to 300.0 mile/gal (L/100 based on value displayed on the tripmeter (A km or km/L) or B) selected.
- Page 25 Fuel consumption Average speed [AVG] Displays the fuel consumption since the Displays the average speed since the selected selected tripmeter was reset. tripmeter was reset. The fuel consumption will be calculated The average speed will be calculated based on based on value displayed on the tripmeter (A value displayed on the tripmeter (A or B) or B) selected.
- Page 26 Instruments (Continued) When “---” is displayed except for the above- Reserve fuel consumption [RES] mentioned cases, go to your dealer for service. Displays the fuel consumption since the 1st To reset the average speed: (E) segment of the fuel gauge starts flashing. (P.27) When the 1st (E) segment of the fuel gauge starts flashing, the current fuel mileage,...
- Page 27 Section B display Changing the section B display You can select the following: With the button, you can switch the Odometer [TOTAL] section B display between the odometer, ● Tripmeter [TRIP A/B] tripmeter A, tripmeter B, numerical ● Numerical tachometer tachometer, and reserve tripmeter.
- Page 28 Instruments (Continued) Odometer [TOTAL] Reserve tripmeter [RES] Total distance ridden. Distance ridden since the 1st (E) segment of When “------” is displayed, go to your dealer the fuel gauge starts flashing. for service. When the 1st (E) segment of the fuel gauge starts flashing, the odometer, tripmeters or numerical tachometer switches to the reserve Tripmeter [TRIP A/B]...
- Page 29 When they are reset, reset display appears at To reset the tripmeter [TRIP A/B], each indication. Then, the display returns to average fuel mileage [AVG], fuel the last selected indication. consumption, average speed [AVG] Also, the tripmeter A, average fuel mileage, and elapsed time fuel consumption, average speed and To reset the tripmeter A, average fuel mileage...
- Page 30 Instruments (Continued) To reset the tripmeter B, average fuel When they are reset, reset display appears at mileage B, fuel consumption B, average each indication. Then, the display returns to speed B and and elapsed time B (these are the last selected indication. based on tripmeter B) together, press and hold the button while tripmeter B is...
- Page 31 Display Setting Setting Mode B Setting Mode A Following items can be changed sequentially. Following items can be changed sequentially. (P.35) • Setting of REV indicator (P.30) • Time format setting RPM setting Interval RPM setting • Clock setting Brightness adjustment •...
- Page 32 Instruments (Continued) Setting Mode A Ordinary display If the buttons are not pressed for about 30 seconds, the control is automatically switched Setting Mode A from the setting mode to the ordinary Time format setting display. Clock setting If the buttons are not pressed for about 30 Backlight brightness adjustment seconds, items in the process of being set will be discarded and only items that were set...
- Page 33 1 Time format setting: 2 Clock setting: You can switch the time format between 12 Press button until the desired hour is hour format or 24 hour format. displayed. Press and hold button to advance Turn the ignition switch to the ON position. the hour quickly.
- Page 34 Instruments (Continued) 3 Backlight brightness adjustment: Press button until the desired minute is displayed. You can adjust the brightness to one of five Press and hold button to advance levels. the minute quickly. Press button. The brightness level is switched. You can adjust the brightness level from five levels.
- Page 35 4 Activating/deactivating of tripmeter 5 Changing of speed and mileage unit: A, average fuel mileage, fuel Press the button to select either “mph” consumption, average speed and and “mile” or “km/h” and “km” . elapsed time automatic reset mode: You can activate or deactivate the automatic reset mode by refueling after the 1st (E) segment of the fuel gauge starts flashing.
- Page 36 Instruments (Continued) 6 Changing the fuel mileage meter unit: Press button to select “L/100km” or “km/L”. Press button. The fuel mileage meter unit is set, and then the display moves to the ordinary display.
- Page 37 Setting Mode B Ordinary display If the buttons are not pressed for about 30 seconds, the control is automatically switched Setting Mode B from the setting mode to the ordinary Setting of REV indicator display. RPM setting If the buttons are not pressed for about 30 Interval RPM setting seconds, items in the process of being set will be discarded and only items that were set...
- Page 38 Instruments (Continued) 1 Setting of REV indicator: To change the setting mode B, turn the You can change the setting of the REV ignition switch to the ON position while pressing button until the initial indicator. animation ends. The display moves to the REV indicator blinks during setting.
- Page 39 Each time button is pressed, the "REV Tachometer Numerical indicator blinking fastest RPM" setting value tachometer will be increased by one segment (250 r/min (rpm)). When the "REV indicator blinking fastest RPM" setting value exceeds 12,500 r/min (rpm), the "REV indicator blinking fastest RPM"...
- Page 40 Instruments (Continued) Press button. The "REV indicator Each time button is pressed, the blinking fastest RPM" is set, and then the numbers of the "REV indicator blinking display moves to the setting of "REV interval RPM" advances as follows: 250 r/min indicator blinking interval RPM".
- Page 41 Press button. The "REV indicator Example: REV indicator blinking fastest blinking interval RPM" is set, and then the RPM: 12,500 r/min (rpm) display moves to the brightness adjustment REV indicator blinking interval of the REV indicator. RPM: 250 r/min (rpm) The REV indicator switches from blinking REV indicator r/min (rpm)
- Page 42 Instruments (Continued) 2 Changing of tachometer display Press button. The brightness level is switched. mode: You can adjust the brightness level from You can change the display mode of the five levels. tachometer. Press button to switch the display mode of tachometer. Press button.
- Page 43 Conventional display Conventional Peak hold display display Shows the engine RPM on the tachometer bar segment. Peak hold display Shows the engine RPM on the tachometer bar segment and peak hold segment. Tachometer Peak hold bar segment segment Continued...
- Page 44 Instruments (Continued) The peak hold segment keeps to show the maximum engine RPM temporarily. Example: Engine revolutions per minutes 10,000 r/min (rpm) Conventional Peak hold display display Peak hold Tachometer segment bar segment...
- Page 45 BLANK PAGE...
- Page 46 Indicators If one of these indicators do not come on when it should, have your dealer check for problems. Left turn signal indicator Right turn signal indicator...
- Page 47 Torque Control indicator Comes on when the ignition switch is turned to the ON position. Goes off when your ● speed reaches approximately 3 mph (5 km/h) to indicate Torque Control is ready to work. Blinks when Torque Control is operating. ●...
- Page 48 Indicators (Continued) REV indicator (P.48)
- Page 49 Low oil pressure indicator Comes on when the ignition switch is turned to the ON position. ● Goes off when the engine starts. ● If it comes on while engine is running: (P.101) PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the ON position with the engine stop switch in the (Run) position.
- Page 50 Indicators (Continued) REV Indicator • Comes on briefly when the ignition switch is turned to the ON position. Initial setting REV indicator blinking fastest RPM: 12,500 r/min (rpm) REV indicator blinking interval RPM: 250 r/min (rpm) REV indicator r/min (rpm) Blinking 12,000 r/min (rpm) Blinking fast...
- Page 51 BLANK PAGE...
- Page 52 Switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to the (Stop) position (the starter motor will not operate) to stop the engine. Start button Hazard switch Horn button Switchable when the ignition Turn signal switch switch is in the ON position.
- Page 53 Ignition switch Turns electrical system Switches the electrical system on/off, locks on for starting/riding. the steering. Key can be removed when in the OFF or Turns engine off. LOCK position. LOCK Locks steering. Continued...
- Page 54 Switches (Continued) Steering Lock Ignition key Lock the steering when parking to help prevent theft. A U-shaped wheel lock or similar device is also recommended. Locking Turn the handlebar all the way to the left. Push Turn Push the key down, and turn the ignition switch to the LOCK position.
- Page 55 Honda selectable torque control Torque Control (engine power control) can Torque Control on and off be turned on/off. Torque Control can be turned on and off by pressing and holding the Torque Control Do not operate the Torque Control switch while riding.
- Page 56 Starting the Engine Start your engine using the following Make sure the engine stop switch is in the procedure, regardless of whether the engine (Run) position. Turn the ignition switch to the ON position. is cold or warm. Shift the transmission to Neutral ( indicator comes on).
- Page 57 If the engine does not start: Open the throttle fully and press the start button for 5 seconds. Repeat the normal starting procedure. If the engine starts, open the throttle slightly if idling is unstable. If the engine does not start, wait 10 seconds before trying steps a &...
- Page 58 Shifting Gears Your vehicle transmission has 6 forward Recommended Shift Points gears in a one-down, five-up shift pattern. Shifting Up From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) From 4th to 5th 31 mph (50 km/h)
- Page 59 Refueling Opening the Fuel Fill Cap Fuel filler opening Open the lock cover, insert the ignition key, Ignition key and turn it clockwise to open the fuel fill cap. Closing the Fuel Fill Cap After refueling, push the fuel fill cap closed until it locks.
- Page 60 Storage Equipment Use the helmet holder only when parked. Helmet Holder and Tool Kit The helmet holder is located underside of the Removing the Rear Seat (P.82) front seat. The tool kit and helmet set wire (in WARNING the tool kit) are located under the rear seat. Riding with a helmet attached to the Helmet set wire holder can interfere with your ability to...
- Page 61 Document Bag and Luggage Tie-down Hooks The document bag and luggage tie-down hooks are located on the underside of the rear seat. Luggage tie-down hooks Luggage tie-down hooks Document bag Never use the tie-down hooks to tow or lift the vehicle. Removing the Rear Seat (P.82)
- Page 62 Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. An optional larger tool kit may be available. Check with your Honda dealer's parts department. Importance of Maintenance ......P. 61 Throttle ..............P. 95 Maintenance Schedule........
- Page 63 Importance of Maintenance For information about the exhaust emission and Importance of Maintenance noise emission requirements of the U.S. Keeping your vehicle well-maintained is Environmental Protection Agency (EPA), the absolutely essential to your safety and to California Air Resources Board (CARB), and the protect your investment, obtain maximum Environment and Climate Change Canada performance, avoid breakdowns, and reduce air...
- Page 64 Importance of Maintenance Follow these guidelines when performing Maintenance Safety maintenance. Always read the maintenance instructions Stop the engine and remove the key. ● before you begin each task, and make sure that Place your vehicle on a firm, level surface ●...
- Page 65 Maintenance work should be performed in owner. accordance with Honda's standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. All scheduled maintenance is considered a normal owner operating cost and will be charged to you by your dealer.
- Page 66 Inspect (clean, adjust, lubricate, or replace, if necessary) you have the necessary tools and are mechanically skilled. Lubricate Procedures are provided in an official Honda Service Manual Replace (2 P. 126). : Technical. In the interest of safety, have your vehicle serviced...
- Page 67 Maintenance Schedule Frequency Items × 1,000 mi Regular Refer to Replace page × 1,000 km 12.8 19.2 25.6 32.0 38.4 Drive Chain Every 600 mi (1,000 km): Brake Fluid 2 Years Brake Pads Wear Brake System Brake Light Switch Headlight Aim –...
- Page 68 Maintenance Record Distance Odometer Date Performed By: Notes 600 miles (1,000 km) 4,000 miles (6,400 km) 8,000 miles (12,800 km) 12,000 miles (19,200 km) 16,000 miles (25,600 km) 20,000 miles (32,000 km) 24,000 miles (38,400 km) 28,000 miles (44,800 km) 32,000 miles (51,200 km) 36,000 miles (57,600 km) 40,000 miles (64,000 km)
- Page 69 Maintenance Fundamentals Check the following items after you get on your Pre-ride Inspection vehicle: To ensure safety, it is your responsibility to Throttle action moves smoothly without ● perform a pre-ride inspection and make sure binding. P. 95 that any problem you find is corrected. A pre- Brake lever and pedal operate normally.
- Page 70 Maintenance Fundamentals Also, check the odometer reading against the Periodic Checks Maintenance Schedule and perform all You should also perform other periodic maintenance that is due. P. 63 maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently.
- Page 71 Maintenance Fundamentals Replacing Parts Color label Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering colored components, specify the model name, color, and code mentioned on the color label. The color label is attached to the left side of the frame.
- Page 72 Maintenance Fundamentals Electrolyte splashes onto your skin: Battery ● Remove affected clothing and wash your skin Your vehicle has a maintenance-free type thoroughly using water. battery. You do not have to check the battery Electrolyte splashes into your mouth: ● electrolyte level or add distilled water.
- Page 73 Wear safety glasses. recommend that you charge the battery every 30 days using a charger designed specifically for your Honda, which can be purchased from your dealer. Read the information that came with your battery charger and follow the instructions on the battery.
- Page 74 Bump starting is also not recommended. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
- Page 75 Conserving” or “Resource Conserving” on the For recommended engine oil, see circular API service symbol. “Specifications.” P. 135 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...
- Page 76 Also inspect the drive sprocket and driven surfaces. sprocket. If either has worn or damaged teeth, Wipe up spills immediately and wash thoroughly. have the sprocket replaced by your dealer. Recommended brake fluid: Honda DOT 4 Brake Fluid or equivalent WARNING Normal Worn Damaged (GOOD)
- Page 77 After cleaning, wipe dry and lubricate with the Recommended Coolant recommended lubricant. Pro Honda HP Coolant is a pre-mixed solution Recommended lubricant: of antifreeze and distilled water. Pro Honda HP Chain Lube or equivalent...
- Page 78 Maintenance Fundamentals Inspecting for Damage Tires (Inspecting/Replacing) Checking the Air Pressure Inspect the tires for Visually inspect your tires and use an air cuts, slits, or cracks that pressure gauge to measure the air pressure at exposes fabric or least once a month or any time you think the cords, or nails or other tires look low.
- Page 79 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tires that are excessively worn become visible, replace the tires immediately. or improperly inflated can cause a crash For safe riding, you should replace the tires in which you can be seriously hurt or killed.
- Page 80 Always use the size and type of tires and load range. recommended in this owner's manual. Have the wheel balanced with Honda ● Genuine balance weights or equivalent after the tire is installed.
- Page 81 Maintenance Fundamentals Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group The service life of your tires is dependent on of numbers and letters located on the sidewall many factors, including, but not limited to, of the tire.
- Page 82 Removing & Installing Body Components Battery Removal Make sure the ignition switch is in the OFF Positive position. terminal Remove the front seat. P. 81 Rubber Remove the rubber strap. strap Disconnect the negative - terminal from the battery. Disconnect the positive + terminal from the battery.
- Page 83 Removing & Installing Body Components Front Seat Front Seat Installation Install the front seat while inserting the Front seat Mounting bolts tab into the recess. Install the mounting bolts. Tighten the mounting bolts securely. Make sure that the seat is locked securely in position by pulling it up lightly.
- Page 84 Removing & Installing Body Components Rear Seat Rear Seat Installation Insert the tabs into the recesses. Tabs Push down on the rear of the rear seat. Rear seat Make sure that the seat is locked securely in position by pulling it up lightly. The seat locks automatically when closed.
- Page 85 Engine Oil Checking the Engine Oil Oil fill cap/dipstick If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the OFF Upper position and wait for 2 to 3 minutes. level Place your vehicle in an upright position on a firm, level surface.
- Page 86 Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.
- Page 87 Coolant Checking the Coolant UPPER level Check the coolant level in the reserve tank while the engine is cold. Place your vehicle on a firm, level surface. Hold your vehicle in an upright position. Check that the coolant level is between the UPPER level and LOWER level marks on the reserve tank.
- Page 88 Coolant Adding Coolant Remove the reserve tank cap and add Reserve tank cap fluid while monitoring the coolant level. Do not overfill above the UPPER level mark. Make sure no foreign objects enter the reserve tank opening. Securely reinstall the reserve tank cap. UPPER level WARNING Removing the radiator cap while the...
- Page 89 Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LOWER level mark or the brake Place your vehicle in an upright position on lever and pedal freeplay becomes excessive, a firm, level surface. inspect the brake pads for wear. Check that the brake fluid reservoir If the brake pads are not worn, you most Front...
- Page 90 Brakes Inspecting the Brake Pads Inspecting the Brake Pads Inspect the brake pads from in front Front of the brake caliper. Always inspect both left and right Check the condition of the brake pad wear brake calipers. indicators. Inspect the brake pads from the rear The pads need to be replaced if a Rear Front...
- Page 91 Brakes Adjusting the Brake Light Switch Adjusting the Brake Light Brake light switch Switch Adjusting Check the operation of the brake light switch. Pull up the lower part of rubber. Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too Rubber...
- Page 92 Side Stand Checking the Side Stand Check that the side stand operates smoothly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease. Check the spring for damage or loss of tension.
- Page 93 Drive Chain Inspecting the Drive Chain Slack Check the drive chain slack at several points along the chain. If the slack is not constant at all points, some links may be kinked and binding. Have the chain inspected by your dealer. Shift the transmission to Neutral.
- Page 94 Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary have it replaced by your Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
- Page 95 Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper clutch Freeplay cable adjuster Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. Loosen the upper lock nut. Turn the upper clutch cable adjuster until the freeplay is 3/8 - 13/16 in (10 - 20 mm). Tighten the upper lock nut and check the Upper lock nut freeplay again.
- Page 96 Clutch Adjusting the Clutch Lever Freeplay Lower Adjustment Start the engine, pull the clutch lever in, and shift into gear. Make sure the engine If the upper clutch cable adjuster is threaded does not stall and the vehicle does not out near its limit, or the correct freeplay creep.
- Page 97 Throttle Checking the Throttle Adjusting the Throttle Freeplay With the engine off, check that the throttle Slide the cable boot. rotates smoothly from fully closed to fully Loosen the lock nut. open in all steering positions and throttle Turn the adjuster until the freeplay is freeplay is correct.
- Page 98 Other Adjustments Adjusting the Brake Lever After adjustment, check that the lever operates correctly before riding. You can adjust the distance between the tip NOTICE of the brake lever and handle grip. Do not turn the adjuster beyond its natural limit. Adjustment method Adjuster Turn the adjuster until the numbers align with...
- Page 99 Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension Extension bar 2 3456 7 Adjusting the suspension requires a pin spanner. We recommend that you have your vehicle serviced by your dealer. Spring Preload You can adjust the spring preload by the Adjuster adjuster to suit the load or the road surface.
- Page 100 Troubleshooting Engine Will Not Start........P. 99 Electrical Trouble..........P. 107 Overheating (Segment H flashes in coolant Battery Goes Dead..........P. 107 temperature gauge) ........P. 100 Burned-out Light Bulb ........P. 107 Warning Indicators On or Flashing..... P. 101 Blown Fuse............
- Page 101 Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 54 sequence.
- Page 102 Overheating (Segment H flashes in coolant temperature gauge) The engine is overheating when the following Check that the radiator fan is operating, occurs: and then turn the ignition switch to the The segment H flashes in the coolant OFF position. ●...
- Page 103 Warning Indicators On or Flashing Low Oil Pressure Indicator If the engine oil level goes down rapidly, your vehicle may have a leak or another serious problem. Have your vehicle inspected by If the low oil pressure indicator comes on, your dealer.
- Page 104 Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. If the indicator operates in one of the The ABS indicator may flash if you turn the following ways, you may have a serious rear wheel while the rear wheel is lifted off...
- Page 105 Warning Indicators On or Flashing Torque Control Indicator Torque Control Indicator Even when the Torque Control indicator is on, your vehicle will have normal riding ability without Torque Control function. If the indicator operates in one of the When the indicator comes on while the following ways, you may have a serious Torque Control is in operation, you will problem with the Torque Control.
- Page 106 Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustrations. If these occur, see your dealer as soon as possible.
- Page 107 Other Warning Indications Coolant Temperature Gauge Failure Indication Coolant Temperature Gauge Failure Indication If the cooling system has an error, all segments will blink as shown in the illustration. If this occurs, see your dealer as soon as possible.
- Page 108 Tire Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tire repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.
- Page 109 Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle All light bulbs on the vehicle are LEDs. If battery charger. there is an LED which is not turned on, see Remove the battery from the vehicle before your dealer for servicing.
- Page 110 Electrical Trouble Blown Fuse Blown Fuse Fuse puller Before handling fuses, see “Inspecting and Spare Replacing Fuses.” P. 72 fuse Fuse Box Fuses Spare fuses Remove the front seat. P. 81 Remove the fuse box cover. Pull the main fuse and other fuses out one by one with the fuse puller provided in underside of the fuse box cover and Fuse box...
- Page 111 Vehicle Identification Number..... P. 119 Emission Control Systems ......P. 120 Catalytic Converter ......... P. 124 Oxygenated Fuels..........P. 125 Authorized Manuals ........P. 126 Warranty Coverage and Service ....P. 127 Honda Contacts ..........P. 130 Reporting Safety Defects ......P. 132...
- Page 112 Keys Keys Ignition key Key tag Ignition Key This vehicle has two ignition keys and a key tag with a key number and a bar code. Store the spare key and the key tag in a safe location. To make a duplicate key, take the spare key and the key tag to your dealer or a locksmith.
- Page 113 Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeters return to 0.0 when each read- out exceeds 9,999.9. Ignition Switch Document Bag Leaving the ignition switch in the ON position The owner's manual, registration, and insurance with the engine stopped will drain the battery.
- Page 114 Instruments, Controls, & Other Features Ignition Cut-off System Assist-slipper Clutch System A banking (lean angle) sensor automatically The assist-slipper clutch system helps to prevent stops the engine and fuel pump if the vehicle the rear tire from locking up when the falls over.
- Page 115 Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
- Page 116 Caring for Your Vehicle Do not direct water at the air cleaner: Washing Precautions ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...
- Page 117 Caring for Your Vehicle Aluminum Components Exhaust Pipe and Muffler Aluminum will corrode from contact with dirt, The exhaust pipe and muffler are stainless steel mud, or road salt. Clean aluminum parts but may become stained by mud or dust. regularly and follow these guidelines to avoid scratches: To remove mud or dust, use a wet sponge and...
- Page 118 Storing Your Vehicle Storing Your Vehicle When the exhaust pipe and muffler are painted, do not use a commercially available abrasive If you store your vehicle outdoors, you should kitchen cleaning compound. Use a neutral consider using a full-body cover. detergent to clean the painted surface on the If you won't be riding for an extended period, exhaust pipe and muffler.
- Page 119 For more information about storage, Canada NOTICE visit our website at www.honda.ca and look up Towing your vehicle can cause serious damage “Storage Tips” under the “Honda Warranty” in to the transmission. the Warranty tab for your Model.
- Page 120 You & the Environment You & the Environment that can hurt refuse workers and contaminate drinking water, lakes, rivers, and oceans. Owning and riding a vehicle can be enjoyable, but you must do your part to protect the environment. Choose Sensible Cleaners Use a biodegradable detergent when you wash your vehicle.
- Page 121 Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place.
- Page 122 Your vehicle engine emits combustion Compliance with the terms of the byproducts, including carbon monoxide (CO), Distributor's Warranties for Honda Motorcycle oxides of nitrogen (NOx), and hydrocarbons Emission Control Systems is necessary in order (HC). Gasoline evaporation also emits to maintain a valid emissions system warranty.
- Page 123 Emission Control Systems Noise Emission Requirements Ignition Timing Control System The ignition timing control system adjusts the The EPA requires that vehicles built after ignition timing to reduce the amount of HC, January 1, 1983 comply with applicable noise CO, and NOx produced. emission standards for one year or 3,730 miles (6,000 km) after the time of purchase when Secondary Air Injection System...
- Page 124 Emission Control Systems Evaporative Emission Control System Fuel Permeation Emission Control The fuel tank, fuel hoses, and fuel vapor charge 50 STATE (meets California) An evaporative emissions control system uses a hoses use fuel permeation control technologies canister filled with charcoal to adsorb fuel vapor to prevent fuel vapor emissions.
- Page 125 Emission Control Systems Removal of, or puncturing of any part of the Noise Emission Control System ● intake system. TAMPERING WITH THE NOISE CONTROL Lack of proper maintenance. ● SYSTEM IS PROHIBITED: Removing or disabling any emissions ● U. S. federal law prohibits, and Canadian compliance component, or replacing any provincial laws may prohibit, the following acts compliance component with a noncompliant...
- Page 126 A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine's vehicle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.
- Page 127 Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.
- Page 128 Authorized Manuals Authorized Manuals These Honda manuals are written for the professional technician. However, if you possess The Service Manual used by your the proper tools, observe the safety standards, authorized dealer is available from your Honda and are mechanically capable, you should find dealer or Helm, Inc.
- Page 129 Honda. Your warranty coverage does not apply to the normal wear Coverage and deterioration associated with use of the Your new Honda is covered by the following vehicle. warranties: Vehicle Limited Warranty ●...
- Page 130 Warranty Coverage and Service performed by a person other than an Statement on Warranty Coverage for authorized service provider caused damage to Aftermarket and Recycled Parts another part of the vehicle otherwise covered New Jersey under warranty before denying warranty The Magnuson-Moss Warranty Act, 15 U.S.C.
- Page 131 If you believe you have a problem with your dealership or their designated representative. vehicle, call the service department of your Honda dealer. Make an appointment for an inspection and diagnosis. You will be asked to authorize that inspection, and your dealer will return the results of the inspection.
- Page 132 Telephone: (888) 946-6329 Fax: (877) 939-0909 E-mail: honda_cr@ch.honda.com American Honda Motor Co., Inc. If you wish to contact Honda directly to comment Please include the following information in your on your experiences with your vehicle or with letter: your dealer, please send your comments to the Name, address, and telephone number ●...
- Page 133 Honda Contacts The sales department offers the Honda Your Honda Dealer Protection Plan to extend almost all of your The service department of your Honda dealer warranty coverage. offers trained personnel to perform regular maintenance and unexpected repairs. It has the...
- Page 134 Reporting Safety Defects Reporting Safety Defects dealer, or American Honda Motor Co., Inc. If you believe that your vehicle has a To contact NHTSA, you may call the defect which could cause a crash or Vehicle Safety Hotline toll-free at:...
- Page 135 However, Transport Canada cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.
- Page 136 Specifications Main Components ■ Displacement 39.6 cu-in (649 cm Overall length 83.5 in (2,120 mm) Bore x stroke 2.64 x 1.81 in (67.0 x 46.0 mm) Overall width 30.7 in (780 mm) Compression 11.6 : 1 ratio Overall height 42.3 in (1,075 mm) Unleaded gasoline Wheelbase 57.1 in (1,450 mm)
- Page 137 Driven sprocket resource conserving on the circular API Recommended service label, SAE 10W-30, JASO T 903 engine oil standard MA, Pro Honda GN4 4-stroke oil (USA & Canada) or Honda 4-stroke oil, or an equivalent motorcycle oil...
- Page 138 Specifications Bulbs ■ Headlight Brake light/Taillight Front turn signal/Position light LED Rear turn signal License plate light Fuses ■ Main fuse 30 A Other fuse 30 A, 20 A, 15 A, 10 A, 7.5 A...
- Page 139 Information Record Engine No. Color Label & Code Owner's Name Address City/State Phone Dealer's Name Address City/State Phone Service Manager...
- Page 140 California Proposition 65 Warning WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
