Summary of Contents for Midea MSBS584S
- Page 1 Side by Side Refrigerator USER MANUAL MSBS584S MSBS584W...
-
Page 2: Table Of Contents
CONTENTS Safety information ........2 Identifying parts of the fridge ........4 Transporting ........5 Installation ........5 Control features and functions ........7 Cleaning & Maintenance ........9 Energy saving tips ........10 Disconnection of the appliance ........10 Troubleshooting guide ........ -
Page 3: Safety Information
The appliance has not been designed or manufactured for professional use. Midea declines all responsibility for damage deriving from improper use of the appliance. The refrigerator has undergone the necessary tests on the tightness of the refrigeration circuit and complies with the safety regulations. - Page 4 SAFETY INFORMATION Safety Precautions The refrigerator is designed to operate on a single phase power supply within a voltage range of 220-240V/50Hz. Do not allow any sharp objects to come in contact with the refrigerant system to avoid damage to the refrigerant circuit. This product is for indoor use only.
-
Page 5: Identifying Parts Of The Fridge
IDENTIFYING PARTS OF THE FRIDGE Freezer door bin Freezer glass shelf Twist ice cube maker Ice cube bin Freezer drawer Refrigerator glass shelf Refrigerator door bin with egg bracket Fruit & vegetable drawer... -
Page 6: Transporting
TRANSPORTING Keep the refrigerator upright and avoid squeezing or vibration during transport. Avoid a slanting angle over 45 degrees during handling. Avoid the door or top cap from being under excessive stress when moving, otherwise it may become deformed. Do not connect your refrigerator to the power supply immediately after it is placed vertically. - Page 7 INSTALLATION Making minor adjustments between doors Figure I: Figure II: Fixed shaft Upward adjusting nut Left Right Wrench Adjustable feet Downward adjusting nut A level refrigerator is necessary for getting the doors perfectly even. Ensure it is completely leveled before adjusting the doors (see previous section on leveling the refrigerator). Before adjusting the height of the door, rotate the downward adjusting nut counterclockwise (as shown in Figure II) for 2 circles with a wrench, and loosen the downward adjusting nut.
-
Page 8: Control Features And Functions
CONTROL FEATURES AND FUNCTIONS Touch buttons Freezer temperature button Mode selection button Lock/Unlock & Confirmation button Refrigerator temperature button Display Freezer compartment temperature Vacation mode indicator Refrigerator compartment temperature Quick-Freeze mode indicator Quick-Cooling mode indicator Close icon Lock/Unlock indicator Locking and unlocking the display panel At non-lock state, hold down the button (D) for 3 seconds, Lock icon (4) will display. - Page 9 CONTROL FEATURES AND FUNCTIONS Changing the Mode Press Mode button (B) to choose running mode as the following. Vacation Quick-Freeze Quick-Freeze & Quick-Cooling Quick-Cooling None Vacation Mode When the refrigerator is in Vacation mode, it reduces energy consumption when not in use for several days.
-
Page 10: Cleaning & Maintenance
CLEANING & MAINTENANCE Cleaning the appliance Before cleaning: Turn appliance off at the power point, then remove the power cord from the outlet. This will make sure there is no chance of electric shock. WARNING Interior Clean the refrigerator interior regularly. Turn power off. Wipe the interior with a soft cloth and lukewarm soapy water. -
Page 11: Energy Saving Tips
ENERGY SAVING TIPS Reduce opening the door frequently. This will increase the appliance efficiency and reduce power consumption. To maintain good air circulation within the refrigerator cabinet, keep the shelves and drawers in the original positions as supplied. There should always be some space between food items for proper air circulation. Hot food should be cooled down before placing into the appliance, otherwise the interior temperature and power consumption will increase. -
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE If you think something may be wrong with your refrigerator, you can carry out some easy checks before calling for service. Y ou may locate the problem and spare yourself from inconvenience, saving time and money. SYMPTOM SUGGESTION efrigerator is not operating ·... -
Page 13: Repairs, Service & Warranty
Please refer to the enclosed warranty card or visit www.mideaappliances.com.au for warranty information. Ensure you have the appliance model number and proof of purchase handy before calling Midea Customer Care to enquire about a warranty claim. Complete and retain the following information for your records: Model No. -
Page 14: Specifications
SPECIFICATIONS Model MSBS584W & MSBS584S Climate Class Classification of Protection Against Electric Shock Rated Voltage 220-240V ~ Frequency 50Hz Rated Current Defrost Power 250W Lamp Rated Power Energy Consumption 1.66 kWh/24h Refrigerant R600a Amount Total Gross Volume 584L Gross Refrigerator Volume...
