Instructions for Installation and Use of

the C3100/200/400 Control Panel

Version: 1.0.1

Date: Oct. 2010

About This Manual

This manual is a guide to installation and connection of the C3100/200/400 access

control operator panel. For how to use the software of the product, see ZKAccess4.0

User Manual.

Need help?

Do you have a question about the C3-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKaccess C3-100

Page 1 Instructions for Installation and Use of the C3100/200/400 Control Panel Version: 1.0.1 Date: Oct. 2010 About This Manual This manual is a guide to installation and connection of the C3100/200/400 access control operator panel. For how to use the software of the product, see ZKAccess4.0 User Manual.
Page 2 Instructions for Installation and Use of the C3100/200/400 Control Panel Contents 1 Important Security Instructions...............1 1.1 Important Security Instructions..............1 1.2 Installation Cautions.................2 2 Introduction......................5 2.1 System Function Parameters..............5 2.2 Product Technical Parameters ..............5 2.3 Control Operator Panel Indicators.............6 3 Connection and Installation................8 3.1 Case Installation..................8 3.2 Installation of Access Control Operator Panel Wires........9 3.3 Control Operator Panel System Installation ..........10 3.4 Control Operator Panel Connection Terminals.........12 3.5 Connection with Door Sensors, Exit Switches, and Auxiliary Input Devices ........................16 3.6 Connection with Wiegand Readers............18 3.7 Relay Output Connection................20 3.8 Access Control Operator Panel System Power Supply Structure....25 4 Access Control Operator Panel System Networking ........27 4.1 Access Control Networking Wires and Wiring.........27 4.2 TCP/IP Network Communication............29 4.3 RS485 Network Communication ............29 I ...
Page 3 Instructions for Installation and Use of the C3100/200/400 Control Panel 4.4 DIP Switch Setting (485 Address Setting, Factory Setting, and Terminal Resistance Setting)..................31 II ...
Page 4 Instructions for Installation and Use of the C3100/200/400 Control Panel 1 Important Security Instructions 1.1 Important Security Instructions 1. Read, follow and keep instructions: Before operating the equipment, read and follow strictly all security and operation instructions. Please keep the instructions in good condition for future reference. 2. Accessories: Please use the accessories recommended by the manufacturer or delivered with the product. Any other related product is not recommended as the major alarming or monitoring system. The major alarming or monitoring system should comply with the local applicable fireprevention and security standards. 3. Installation cautions: Do not place this equipment on any unstable table, tripod mount, support or base, lest the equipment should fall and get damaged, and more ...
Page 5 Instructions for Installation and Use of the C3100/200/400 Control Panel If the equipment cannot work normally even though operated as  instructed, please be sure to adjust only the control components specified in the operation instructions. Incorrect adjustment of other control components may cause damage to the equipment, and add to troubleshooting workload of the qualified technicians. The equipment falls down or its performance changes obviously.  8. Replacing components: If it is necessary to replace a component, the repair personnel must use only the substitutes specified by the manufacturer. ...
Page 6 Instructions for Installation and Use of the C3100/200/400 Control Panel 2. It is recommended not to plug/unplug connection terminals frequently when the system is energized. Be sure to unplug the connection terminals before starting any relevant welding job. 3. Do not detach or replace any control panel chip without permission, because unprofessional operation may cause damage to the control panel. 4. It is recommended not to connect any other auxiliary devices without permission. ...
Page 7 Instructions for Installation and Use of the C3100/200/400 Control Panel 13. To protect the access control system against the selfinduced electromotive force generated by an electronic lock at the instant of switching off/on, it is necessary to connect a diode in parallel (please use the FR107 delivered with the system) with the electronic lock to release the selfinduced electromotive force during onsite connection for application of the access control system. 14. It is recommended that an electronic lock and a control panel should use respective power supplies. ...
Page 8 Instructions for Installation and Use of the C3100/200/400 Control Panel 2 Introduction The access control management system is a new modernized security management system, which is an effective measure for security and protection management. It is mainly used to manage entrances and exits of important places, such as banks, hotels, equipment rooms, offices, smart communities, and factories. 2.1 System Function Parameters Highspeed 32bit 400MHz CPU, 32M RAM, and 256M Flash. Embedded LINUX operating system. Onedoor/twodoor twoway access or fourdoor oneway access. A maximum of 30,000 card holders and 100,000 offline event records. Support of multiple Wiegand card formats and a password keypad, compatible with various types of cards. Use of dual communication technologies: the Ethernet plus the RS485 industrial bus, for reliable communications. With a watchdog (hardware) built in the control panel to prevent crash. Overcurrent, overvoltage, and inversevoltage protection for input of power supply to the control panel. Overcurrent protection for the power supply to card readers. ...
Page 9 Instructions for Installation and Use of the C3100/200/400 Control Panel Output load: working voltage AC ≤ 30V, rated current ≤ 8A; DC ≤ 36V, rated current ≤ 5A. Ctype electronic lock relay output terminal: 10A contact current, 12V DC, with LED status indications. Output terminal of the auxiliary relay: 2A contact current, 30V DC, with LED status indications. With detachable connection terminals made of alloysteel nonmagnetic flange materials. Outline dimensions of the control PCB: 160mm (length) × 106mm (width) for C3100/200; 218mm (length) × 106mm (width) for C3400. Mounting hole dimensions of the control PCB: 147.32mm (length) × 91.44mm (width) for C3100/200; 203.2mm (length) × 106mm (width) for C3400. External box dimensions: 345mm × 275mm × 70mm. 2.3 Control Operator Panel Indicators When the C3100/200/400 is powered on, normally the POWER indicator (red) is lit constantly, the RUN indicator (green) flashes (indicating the system is normal), and other indicators are all off. Except the cases as follows: 1. LINK indicator (green): indicates proper TCP/IP connection if it is lit constantly; ...
Page 10 Instructions for Installation and Use of the C3100/200/400 Control Panel See the C4 indicators in the following figure: Figure 21 Indicators in the C3400 7 ...
Page 11 Instructions for Installation and Use of the C3100/200/400 Control Panel 3 Connection and Installation 3.1 Case Installation 8 ...
Page 12 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.2 Installation of Access Control Operator Panel Wires Figure 31 Access Control Operator Panel Wire Installation Diagram Notes: 1. Before connection, make sure the power supply is disconnected, because connection with power connected will cause severe damage to the equipment. 2. The access control wires must be separated according to heavy and light current; the control panel wires, electronic lock wires, and exit button wires must run through their respective casing pipes.
Page 13 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.3 Control Operator Panel System Installation Printer Hub TCP/IP Ethernet Card issuer Management host C3400 control operator panel Internal Internal Internal Internal button button button button Card reader 4 Card reader 1 Card reader 2 Card reader 3 Door 1 Door 2 Door 3 Door 4 Controlling oneway entry/exit of four doors Door 1 Door 2 Controlling twoway entry/exit of two doors Figure 32 Schematic Diagram of C3400 System Installation 10 ...
Page 14 Instructions for Installation and Use of the C3100/200/400 Control Panel  Note: The diagram above takes the C3400 for example. By contrast, only onedoor twoway access is applicable to the C3100 system; only twodoor oneway or twodoor twoway access is applicable to the C3200 system. The access control management system consists of two parts: management workstation (PC) and control operator panel. They communicate via TCP/IP and RS485 ...
Page 15 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.4 Control Operator Panel Connection Terminals C3100 terminal connection diagram 12 ...
Page 16 Instructions for Installation and Use of the C3100/200/400 Control Panel C3200 terminal connection diagram 13 ...
Page 17 Instructions for Installation and Use of the C3100/200/400 Control Panel C3400 terminal connection diagram 14 ...
Page 18 Instructions for Installation and Use of the C3100/200/400 Control Panel Descriptions of the terminals: 1. The auxiliary input may be connected to infrared body detectors, fire alarms, smoke detectors, etc. 2. The auxiliary output may be connected to alarms, cameras, door bells, etc. 3. All the terminals mentioned above are set through relevant access control software. Please see the respective software instructions for details. Ports on the C3 control operator panel: C3400 C3100 C3200 (FourDoor No. Functional Port (OneDoor ...
Page 19 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.5 Connection with Door Sensors, Exit Switches, and Auxiliary Input Devices Door sensor A door sensor is used to sense the open/closed status of a door. With a door sensor switch, an access control panel can detect illegal opening of a door, and will trigger an output of alarm. Moreover, if a door is not closed within a specified period of time after it is opened, the door control panel will also prompt an alarm. It is 2 recommended to select twocore wires with a gauge over 0.22 mm .
Page 20 Instructions for Installation and Use of the C3100/200/400 Control Panel Figure 33 Connections between C3400 and Door Sensors, Exit Switches, and Auxiliary Input Devices 17 ...
Page 21 Instructions for Installation and Use of the C3100/200/400 Control Panel  Note: The diagram above takes C3400 for example. By contrast, C3100 provides no auxiliary input interface; C3200 provides two, and C3400 provides four. 3.6 Connection with Wiegand Readers C3100 can connect two Wiegand readers in the onedoor twoway mode. C3200 provides four readers, which can be connected in the twodoor twoway mode. C3400 provides four readers, which can be connected in the twodoor twoway or ...
Page 22 Instructions for Installation and Use of the C3100/200/400 Control Panel Figure 34 Connection between C3400 and Readers 19 ...
Page 23 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.7 Relay Output Connection C3100 has two relays (one used as a control lock by default, and the other used as an auxiliary output); C3200 has four relays (two used as control locks by default, and the other two used as auxiliary outputs); C3400 has eight relays (four used as control locks by default, and the other four used as auxiliary outputs). The relays for auxiliary outputs may be connected to monitors, alarms, door bells, etc. Auxiliary outputs are set through relevant access control software. For details, please see ZKAccess4.0 User Manual. A lock relay can be connected in the dry and wet modes, while an auxiliary output relay cannot. The following illustrates relay output connection with an example of door connection. ...
Page 24 Instructions for Installation and Use of the C3100/200/400 Control Panel 3. To protect the access control system against the selfinduced electromotive force generated by an electronic lock at the instant of switching off/on, it is necessary to connect a diode in parallel (please use the FR107 delivered with the system) with the electronic lock to release the selfinduced electromotive force during onsite connection for application of the access control system. 1. Wet mode：External power supply for NO Lock 2. Wet mode：External power supply for NC Lock 21 ...
Page 25 Instructions for Installation and Use of the C3100/200/400 Control Panel 3. Dry mode：External power supply for NO Lock 4. Dry mode：External power supply for NC Lock 22 ...
Page 26 Instructions for Installation and Use of the C3100/200/400 Control Panel 5. Dry mode：The system control the Normally Open lock use the switch value. 6. Dry mode：The system control the Normally Close lock use the switch value. 23 ...
Page 27 Instructions for Installation and Use of the C3100/200/400 Control Panel ...
Page 28 Instructions for Installation and Use of the C3100/200/400 Control Panel 3.8 Access Control Operator Panel System Power Supply Structure 25 ...
Page 29 Instructions for Installation and Use of the C3100/200/400 Control Panel An access control operator panel is powered by +12V DC. Generally, to reduce power interference between control panels, each control operator panel should be powered separately. When high reliability is required, control panels and electronic locks should be powered respectively. To prevent power failure of a control operator panel from making the whole system unable to work normally, the access control management system is usually required to have one UPS at least, and access control locks are powered externally to guarantee ...
Page 30 Instructions for Installation and Use of the C3100/200/400 Control Panel 4 Access Control Operator Panel System Networking 4.1 Access Control Networking Wires and Wiring 1. RS485 communication wires are made of internationally accepted shielded twisted pairs, which prove effective to prevent and shield interference. 2. The power supply is 12V DC converted from 220V. 3. The Wiegand readers use 6core communication shielded wires (RVVP 6×0.5mm) (usually there are 6core, 8core, and 10core types available for users to select according to the ports) to reduce interference during transmission. ...
Page 31 Instructions for Installation and Use of the C3100/200/400 Control Panel distribution). Metal hoses are applicable to ceiling wiring, but must be secure and goodlooking.  Shielding measures and shielding connection: If the electromagnetic interference in the wring environment is found strong in the survey before construction, it is necessary to consider shielding protection for data cables when designing a construction scheme. Overall shielding protection is required if there is a large radioactive interference source or ...
Page 32 Instructions for Installation and Use of the C3100/200/400 Control Panel 4.2 TCP/IP Network Communication The Ethernet 10/100BaseT Crossover Cable, a type of crossover network cable, is mainly used for cascade hubs and switches, or used to connect two Ethernet endpoints directly (without a hub). Both 10BaseT and 100BaseT are supported. Management host Printer Card issuer Hub TCP/IP Ethernet C3 control panel C3 control panel C3 control panel Figure 41 TCP/IP Communication System Networking 4.3 RS485 Network Communication 1. RS485 communication wires are made of internationally accepted RVSP wires (shielded twisted pairs), which prove effective to prevent and shield interference. ...
Page 33 Instructions for Installation and Use of the C3100/200/400 Control Panel 2. A single 485 bus can be connected with 63 access control operator panels at most, but preferably should be connected with less than 32. 3. To eliminate signal attenuation in communication cables and suppress interference, if the bus is longer than 300 meters, one 120ohm resistance is usually inserted between the first and last access control operator panels on the ...
Page 34 Instructions for Installation and Use of the C3100/200/400 Control Panel 4.4 DIP Switch Setting (485 Address Setting, Factory Setting, and Terminal Resistance Setting) 485 address setting Places 16 of the DIP switch are reserved to set device number for RS485 communication. The code is binary, and the lower places are in the front. When the switch is set to the ON position, it indicates 1 (on); when the switch is set downwards, it indicates 0 (off). For example, to set a device number 39=1+2+4+32, which corresponds to the binary code 111001, put places 1, 2, 3, and 6 to the ON position, as illustrated below. 485 address setting table: Switch Setting Place Address 1 ...
Page 35 Instructions for Installation and Use of the C3100/200/400 Control Panel Switch Setting Place Address 1 2 3 4 5 6 13 ON OFF ON ON OFF OFF 14 OFF ON ON ON OFF OFF 15 ON ON ON ON OFF OFF 16 OFF OFF OFF OFF ON OFF 17 ON OFF OFF OFF ...
Page 36 Instructions for Installation and Use of the C3100/200/400 Control Panel Switch Setting Place Address 1 2 3 4 5 6 40 OFF OFF OFF ON OFF ON 41 ON OFF OFF ON OFF ON 42 OFF ON OFF ON OFF ON 43 ON ON OFF ON OFF ON 44 OFF OFF ON ON ...
Page 37 Instructions for Installation and Use of the C3100/200/400 Control Panel upwards and downwards for three times within 10 seconds and finally returned to the OFF position, the factory settings will be restored after the access control operator panel is restarted. Terminal resistance setting Place 8 is for setting the RS485 termination resistance. Putting the switch to the ON position is equivalent to parallel connection of a 120ohm termination resistance between 485+ and 485. 485 terminal resistance Restore factory setting 34 ...
