- Page 1 MOTOROLA PIP12 TRAVEL DIGITAL AUDIO BABY MONITOR For: PIP12 TRAVEL User Guide...
- Page 2 Safety instructions WARNING Strangulation Hazard. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 1 metre away). Never use extension cords with AC Adaptors. Only use the AC Adaptors provided.
- Page 3 Baby monitor setup and use: • Determine a location for the baby unit that will allow you to hear your baby in his/her cot. • Place the baby unit on a flat surface, such as a dresser, bureau, or shelf or mount the unit to a wall securely using the keyhole slots under the stand.
- Page 4 1. . Welcome This booklet provides you the quick start information of your PIP12 TRAVEL. For a full explanation of all features, download the user guide from motorolanursery.com. 2. . Contents inside the box Pouch Baby unit Parent unit Quick Start Guide...
- Page 5 3. At a glance Baby unit Front view Back view A Microphone B Power button Press and hold to turn the baby unit on or off. C Power jack D Power / Linking LED indicator It lights up in green when powered on. Battery charging LED indicator It lights up in red when the batteries are charging.
- Page 6 Parent unit Front view Back view A Speaker B Microphone C Power button Press and hold to turn the parent unit on or off. D Volume down / Mute Press to decrease the speaker volume. Press and hold to mute the speaker. Volume up / Talk back Press to increase the speaker volume.
- Page 7 WARNING • Use only the approved rechargeable Ni-MH battery cells (2 x AAA Ni-MH rechargeable batteries) supplied with your PIP12 TRAVEL. • Strangulation Hazard. Children have STRANGLED in cords. Keep adaptor cords out of the reach of children (more than 1 metre away). Never use extension cords with AC adaptors.
- Page 8 Parent unit Install batteries Lift up the battery cover to remove it from the parent unit. 2. Insert the rechargeable Ni-MH battery cells supplied. Note the ’+’ and ’-’ markings inside the battery compartment and insert in the correct direction. 3.
- Page 9 5. . Before use Intended use Be aware that this Digital Audio Baby Monitor is only intended as an aid. It is not a substitute for responsible and proper adult supervision. Detach and switch on the parent and baby units The baby and parent units are attached to each other with magnets.
- Page 10 6. . Use the digital audio baby monitor Turn the baby unit on / off • Press and hold on the baby unit to turn it on. The power / linking LED indicator lights up in green. • Press and hold on the baby unit again to turn it off.
- Page 11 7. Help The power / linking LED Indicator on the parent unit does not turn on. • Check whether the parent unit is powered on. • Check whether the batteries are correctly installed and not drained. • Connect the parent unit to the power supply to recharge it. The power / linking LED indicator on the parent unit flashes.
- Page 12 Technical Specifications RF frequency bands 1881.792 MHz to 1897.344 MHz (Europe) 1921.536 MHz to 1928.448 MHz (USA & Canada) RF transmission power < 0.25 W (EU version) Line of sight operating 300 meters range between the baby and parent units Power adaptor for the baby SHENZHEN BAIJUNDA ELECTRONIC CO.
- Page 13 Meizhou, Guangdong, P.R.China . (“MZGW”) What Does this Warranty Cover? Subject to the exclusions contained below, MZGW warrants that this Motorola branded product (“Product”) or certified accessory (“Accessory”) sold for use with this product that it manufactured to be free from defects in materials and workmanship under normal consumer usage for the period outlined below.
- Page 14 PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA OR MZGW BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING...
- Page 15 (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola or MZGW are excluded from coverage.
- Page 16 FCC and IC regulations FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and 2.
- Page 17 Radiation Exposure Statement: The baby unit complies with FCC/ISED radiation exposure limits set forth for an uncontrolled environment. The baby unit should be installed and operated with minimum distance 20cm between the radiator& your body. The parent unit has been tested and comply with FCC and ISED SAR limits. For face up operation, please hold the device 10mm from your face.
- Page 18 Manufactured, distributed or sold by Meizhou Guo Wei Electronics Co. LTD., official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.
