ipf electronic touchMATRIX BA050100 Manual

Process indicator with two 16 bit analog inputs, touch screen and graphic display
Product Features:
 Operating modes for visualization of input 1, input 2 or combinations of inputs (IN1+IN2, IN2-IN2,
IN1xIN2, IN1:IN2)
 Two universal 16 bit analog inputs for -10 ... +10 V / 0 ... 10 V / 0 ... 20 mA / 4 ... 20 mA
 High accuracy reference output 10 V for potentiometers > 1 kOhm
 Bright and high-contrast display with event-dependent color variations
 Emulation of a 7-segment display inclusively icons and units
 Intuitive and easy parameterization by plain text and touchscreen
 24 V auxiliary output for encoder supply
 Totalization for each input
 Linearization with 24 control points for each input
 Numerous features, e. g. tara, averaging filter, sampling time for each input
 3.78 x 1.89 inch norm panel housing and IP65 protection
Available Options:
BA050100:
• Rosmarter Allee 14 • 58762 Altena
ipf electronic gmbh
touchMATRIX Indicator
Basic unit with 2 analog inputs (16 Bit), 3 control inputs
16 bit analog output, 4 control outputs, serial RS232 interface
Tel +49 2351 9365-0 • Fax +49 2351 9365-19
│
MANUAL • Subject to alteration! Version: December 2017
