Altronix TROVE PLUS T1RM3CK1 Installation Manual page 2

Altronix Trove Mercury wired rack kits are pre-assembled and consist of Trove rack enclosure/backplane with factory installed Altronix power
supply/charger and sub-assemblies. They also accommodate a variety of Mercury modules for up to four doors in a single enclosure.
Altronix
Model Number
T1RM3CK1
5A/
3.5
250V
T1RM3CK1D
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and authorities having jurisdiction.
These products are for indoor use only and must be installed within the protected premises.
Note: First assemble and Install Z Bracket Wire Management Accesory
(refer to Z Bracket Installation pg. 3)
1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware).
2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the
enclosure upside down. Punch out the knockout in designated location, on the back of the unit,
from outside of the drawer (Fig. 1, pg. 2). Insert the tamper switch into the knockout from outside of the
drawer with the button facing outwards and spaded connectors inside the drawer.
Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device.
To activate alarm signal open the rack drawer.
3. Slide the rack enclosure into an open 2U location in the four post rack cabinet.
4. Utilizing proper fasteners attach front ears to the rack rails.
5. Attach the rear of the adjustable slides to the rear rails of the rack cabinet with the proper fasteners.
6. Secure the rack cover (Fig. 2a, pg. 2) and rack drawer to earth ground (Fig. 2b, pg. 2).
Fig. 2
Fig. 2b
7. Make sure that all internal cofigurations (wiring, voltage selection, switch settings, etc.) are complete before mounting backplane back
into enclosure.
8. Refer to the eFlow Power Supply/Charger Installation Guide for eFlow6NB and corresponding sub-assembly Installation Guides for the
following models: ACM4(CB), PDS8(CB), VR6 for further instructions.
- 2 -
Configuration Chart:
Nominal DC
Output Voltage
Current for Main and Aux.
[DC] [Aux]
Power Supply board,
24VDC 24VDC
Output Output Distribution Module and
Range Range ACM4(CB) Access Power
(V) (V) Controller's outputs (A)
10A/ 20.28- 20.28-
32V 26.4 26.4
Installation Instructions for T1RM3CK1(D):
Overview:
Maximum Supply
Outputs on
PDS8(CB) Power
2.5
24VDC @ 5.6A
2.0
10A/ 3A/
4
250V 32V
10A/
2.5A 4
250V
Fig. 1
Back of the drawer,
viewed from outside.
Tamper Switch
mounting location
T1RM3CK1(D) Series Installation Guide
10A/ 3A/
32V 32V
9A 2.5A
Fig. 2a
