Bloomy Lotus JungleFUN - Aroma Diffuser Manual

Overview

Main body

Interchangeable Ear Features

1. Top Cover
2. Main Unit
3. Internal Cover
4. Water Marker
5. Air Outlet
6. Water Tank
7. Mist Chip
8. Mist & Time Button
9. Light Button
10. Music Button
11. Speaker
12. DC Socket
13. Power Adaptor
14. Air Inlet
15. Mist Nozzle
16. Bear ear 2pcs
17. Bunny ear 2pcs
18. Fox ear 2pcs

Instructions

1. Remove the Top Cover.

2. Remove the Internal Cover.

3. Add water to the water tank below the RED Maximum water marker.

4. Directly add 3-5 drops of natural essential oil into water tank.

5. Replace the Internal Cover.

6. Replace the top cover. Ensure mist outlet and outer cover are aligned.

7. Plug AC adapter into a power outlet.

8. Press the Power ON/OFF button on the device to start.

9. Diffuser will begin diffusing.


Interchangeable Ears

How to interchange the ear

1. Push the selected component to install.

2. Push the component lock inside of the cover to detach the ear.

3. Pull the component to remove.


1. Be sure to handle this product with care to avoid impacts or drops.
2. The unit should be placed on a level solid surface. Do not place on carpets, rugs, wooden/ polished furniture or uneven or unstable surfaces.
3. Use a suitable measuring cup to fill the water into the water tank. Never attempt to fill water under a running tap or whilst plugged in.
4. The water level should not exceed the water marker to avoid damage to this device.
5. Keep water away from Air outlet and Air inlet.
6. For best result, we recommend that you use 100% natural essential oil with this scent diffuser. Artificial fragrance, flavor, or impurities might harm to the unit.
7. Always unplug the product from electrical socket when not in use.
8. Do not remove the covers during operation.
9. Ensure to fill up the water tank before operating the diffuser in all individual setting.

Not to be operated by children, to be used under adult supervision only. Read detailed instructions and caution included before use.

Settings

After the device has plugged into the power outlet, the device will be under the STANDBY mode.

Mist & Time Button

• Press the button once and the unit is turned ON. The default time is 2 hours, indicated by the "2H" green LED light.
• Press the button a second time and the working time is set to be 4 hours, indicated by the "4H" green LED light.
• Press the button for the third time and the working time is set to be 8 hours intermittently, indicated by the "8H" green LED light. (5 mins ON and 5 mins OFF)
• Press the button a fourth time to switch the diffuser OFF.

Light Button

• The default rotating lights setting will start automatically while the device is in MIST mode.
• Press the Light button a first time to switch to "light blue".
• Press the Light button a second time to switch to "candle light".
• Press the Light button a third time to switch the "purple light".
• Press the Light button a fourth time to switch the light OFF.

*LIGHT mode can operate independently as a Night Light function by directly pressing the LIGHT button during the STANDBY mode*

Music Button

• The music will start automatically while the device is in MIST mode.
• There is three different sound volume, keep pressing to adjust the volume (LOW, MEDIUM and HIGH) or OFF the music.

*MUSIC mode can operate independently as a Music Box function by directly pressing the MUSIC button during the STANDBY mode*

Note:

1. A slight difference in mist amount produced by different units is expected.
2. Factors affecting the mist amount: water, humidity, temperature, and air flow.
3. Automatically shut-off function when the diffuser detects the water is empty or when it is tipped over.

Cleaning and Maintenance

1. Power off and disconnect the device from the power outlet.

2. Remove the Top Cover carefully.

3. Remove the Internal Cover.

4. Make sure the air duct outlet is not subject to spilling. Pour water out from the opposite side (of the air duct outlet).

5. Pour any remaining water down the drain.

6. Use cotton swab and neutral detergent, then rinse thoroughly no less than twice a week.


• Never soak or wash this product directly as it may cause mechanical malfunction or danger.
• Never use acidic cleansing agents as it may cause malfunctions to the product.
• Use cotton swab to clean the unit after each use. Rinse with tap or spring water, then wipe with a dry cloth.
• The water tank must be cleaned before the aroma oil is changed each time.
• Use tap water or spring water.
• Allow to dry thoroughly after use/ cleaning.
• Make sure no water will spit into the air duct outlet as it might break the electrical circuit.

Specification

Product Dimensions:

Troubleshooting

If you experienced unsatisfactory operations, please follow our troubleshooting guidelines listed below.

Do not attempt to dismantle or repair the product by yourself. If the unit still does not operate satisfactorily, please contact your local distributor.
