Bloomy Lotus Sky - Aroma Diffuser Manual

Please read the user manual carefully before use.

Overview

1. Glass outer cover
2. Inner lid
3. Water tank
4. Mist spout
5. Ventilation hole
6. Water marker
7. Mist chip
8. Fan
9. Air inlet
10. LED light
11. Mist button, time setting
12. Light button, color setting
13. Working hour indicator
14. DC socket
15. Power adapter

Operating Instructions

1. Hold the base and remove the glass outer cover.

2. Remove the Inner lid.

3. Add water to the water tank below the RED Maximum water marker.

4. Directly add 3-5 drops of natural essential oil into water tank.

5. Replace the inner lid.

6. Replace the glass outer cover. Ensure the glass cover and the base are aligned.

7. Plug Power adapter into a power outlet.

8. Press the Mist button to start the device and switch the timer.

9. Diffuser will begin diffusing.


1. Be sure to hold the whole product with the base carefully when moving the product. Handle this product with care to avoid impacts or drops.
2. The unit should be placed on a level solid surface. Do not place on carpets, rugs, wooden/polished furniture or unstable surfaces.
3. Use a suitable measuring cup to fill the water into the water tank. Never attempt to fill water under a running tap or whilst plugged in.
4. The water level should not exceed the water marker to avoid damage to this device.
5. Keep water away from Ventilation Hole and Air Inlet.
6. For best result, we recommend that you use natural essential oil with this scent diffuser. Artificial fragrance, flavor, or impurities might harm to the unit.
7. Always unplug the product from electrical socket when not in use.
8. Do not remove the covers during operation.

Setting Instructions

Mist Button

• Press the button once to turn ON the unit. The default time is 2 hours, indicated by the "2H" green LED light.
• Press the button a second time and the working time is set to be 4 hours, indicated by the "4H" green LED light.
• Press the button for the third time and the working time is set to be 8 hours intermittently, indicated by the "8H" green LED light. (5 mins ON and 5 mins OFF).
• Press the button a fourth time to switch the diffuser OFF.

Light Button

• The default rotating lights setting will start automatically while the device is in MIST mode.
• Press the Light button a first time to switch to "Light Blue"
• Press the Light button a second time to switch to "Candle Light".
• Press the Light button a third time to switch the "Purple Light".
• Press the Light button a fourth time to switch the light OFF.

Note:

1. A slight difference in mist amount produced by different units is expected.
2. Factors affecting the mist amount: water, humidity, temperature, and air flow.
3. Automatically shut-off function when the diffuser detects the water is empty or when it is tipped over.

Cleaning and Maintenance

• Always disconnect the AC adaptor from the device before cleaning.

1. Power off and disconnect the device from the power outlet.

2. Hold the base and remove the glass outer cover.

3. Remove the Inner lid.

4. Make sure the air duct outlet is not subject to spilling. Pour water out from the opposite side (of the air duct outlet).

5. Pour any remaining water down the drain.

6. Use cotton swab and neutral detergent, then rinse thoroughly no less than twice a week.


• Never soak or wash this product directly as it may cause mechanical malfunction or danger.
• Never use acidic cleansing agents as it may cause malfunctions to the product.
• Use cotton swab to clean the unit after each use. Rinse with tap or spring water, then wipe with a dry cloth.
• The water tank must be cleaned before the essential oil is changed each time.
• Use tap water or spring water.
• Allow to dry thoroughly after use/ cleaning.
• Make sure no water will spit into the air duct outlet as it might break the electrical circuit.

Troubleshooting

If you experienced unsatisfactory operations, please follow our troubleshooting guidelines listed below.

• Do not attempt to dismantle or repair the product by yourself. If the unit still does not operate satisfactorily, please contact your local distributor.

Product Dimensions

Product Name: SKY

Model code: BL-009

Product Size: Ø80mm(L) x 255mm(H)

Water: Room-temperature tap water/mineral water

Material: PP, Glass

Power input: DC24V / 12W

Manufacturer: Bloomy Lotus LLC

Main unit weight: 712g

Water Tank Capacity: 115ml

Coverage Area: Up to 45m2

Environment: Indoor

Run Time: 2 /4 /8 hours

Design: USA

Made in China
