330lbs Material Lift
Operator's Manual
WARNING:
Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to
follow the safety rules and other basic safety precautions may result in serious personal injury.
Keep these instructions in a safe place and accessible so that they can be reviewed as required.
Keep these instructions to assist in future servicing needs.
REV 1.1
Advertisement
Related Manuals for Super Handy GUO097
Summary of Contents for Super Handy GUO097
- Page 1 330lbs Material Lift Operator's Manual WARNING: Carefully review and understand all INSTRUCTIONS prior to operating this device. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe place and accessible so that they can be reviewed as required. Keep these instructions to assist in future servicing needs.
- Page 2 INDEX 1. WARNING -------------------------------------------------------------------------------- 1 2. MAIN USE -------------------------------------------------------------------------------- 1 3. TECHNICAL SPECIFICATIONS ---------------------------------------------------- 1 4. ASSEMBLY ------------------------------------------------------------------------- 2~5 5. COMMISSIONING&PREPARATION ---------------------------------------------- 5 6. MAIN COMPONENTS----------------------------------------------------------------- 6 7. OPERATION -------------------------------------------------------------------------- 7~9 8. MAINTENANCE ------------------------------------------------------------------ 9~12 9. TRANSPORTATION&STORAGE ------------------------------------------------ 12 10. WARRANTY ------------------------------------------------------------------------- 12 11.
- Page 3 3. TECHNICAL SPECIFICATIONS SKU# GUO097 Lifting Height 39.37" (1000mm) Max. Lifting Weight 330lbs (150kg) Towing Form Fork;...
- Page 4 4. ASSEMBLY Part No. Description Q’ty Part No. Description Q’ty Primary frame Wheel carrier Universal wheel 8" Fork Base Flat plate Flat washer 8mm Flat washer 12mm R-pin 8 pcs 8 pcs 2 pcs Hexagon flange D-pin bolt M8x60mm Nut M8 8 pcs 4 pcs 4 pcs...
- Page 5 Assembly Steps Step 1: Directional Wheel The directional wheel (B) and flat washer 12mm (C) are inserted into the axle in turn, and then R-pin (A) is inserted into the axle positioning hole. Follow this procedure for the other side of the directional wheel. (See Fig.1) Fig.
- Page 6 Step 3: Wheel carrier Insert the wheel carrier (C) into the base (A) interface, then insert the D-pin (B) into the positioning hole and secure it to prevent loosening. If the wheel carrier (C) still slides, the corresponding D-pin (B) is not properly connected and secured. (See Fig.3) Fig.
- Page 7 Step 5. Flat plate The flat plate (B) is placed flat on the fork (C), and the holes on both sides of the plate and the fork are aligned and the D-pin (A) is inserted to fix it. (See Fig.5) Fig.
- Page 8 6. MAIN COMPONENTS Part No. Description Part No. Description Universal wheel (2") Nylon rope Directional wheel (8") Winch: handle clockwise rotation to lift the fork height, counterclockwise Brake pedal: control equipment parking rotation to lower the fork height. Fork Handle Roller Nylon rope roller Positioning pin...
- Page 9 7. OPERATION 7.1 Placement of heavy objects a. Place the heavy objects on the fork flatbed with the center of the heavy objects aligned with the center of the fork (shown as below). b. If the heavy objects may slide, always center the heavy objects and secure it to the forks. Fork Center Fork Center Fork Center...
- Page 10 7.2. Operation of the brake mechanism a. When moving the lift, make sure the brake device of the lift is in the off position. the operation method is: press the pedal with your foot to release the break, as shown below (See Fig. A) b.
- Page 11 7.4. Positioning pin operation To prevent the forks from sliding when handling the lift, please screw the star bolt into the hole of the tube to fix the forks. Please loosen the star bolt when you need to lift. 7.5. Folding handle operation Folding operations.
- Page 12 8.3 Pulley replacement a. Remove the retaining ring from the pin, and then pull out the pin. b. Using the new pulley, place the nylon rope in the groove of the pulley and place the pulley at the installation position, put the pins in order and use the tool to put the retaining ring into the pins to complete the replacement of the pulley.
- Page 13 8.6 Nylon rope replacement Note: Before replacing the nylon rope, make sure the fork in the lowest position, for safety reasons, it is recommended to make the nylon rope in the loose state. a. Disassembly of nylon rope. ① Disassembly of nylon rope and support plate: first unscrew the nut, pull the wire rope with your hand, and pull out the s crew with the other hand.
- Page 14 b. Installation of nylon rope. ① Installation of nylon rope and winch. • First insert the nylon rope (unbuckled end) into the groove of the pulley first. • Thread the nylon rope through hole A (inside-out), hole B (outside-in) and hole C (inside-out) of the winch in turn and place the end of the nylon rope between the two screw holes.
- Page 15 11. TROUBLE SHOOTING 1. Normal maintenance and regular servicing will extend the life of the equipment. 2. The following troubleshooting guide lists the most common problems, causes and solutions. Problem(s) Possible Cause Corrective Action Abnormal noise 1. Foreign objects on the nylon rope. 1.
- Page 16 12. EXPLODED VIEW AND PARTS LIST Part No. Description Q’ty Part No. Description Q’ty Nylon rope pulley Wheel carrier Primary frame Universal wheel D-pin Base Fork Directional wheel Flat plate Great Circle USA Support Line: 1-866-493-0524 help@greatcircleus.com www.greatcircleus.com Size: 145x210mm 157克双铜...
