Summary of Contents for Evolution 005-0005
- Page 1 MITRE SAW STAND Original Instructions Date Published: 08/07/2022...
- Page 2 Evolution’s website by entering your which can be found on the Evolution Power Tools details and thus ensure prompt service if ever website. needed.
- Page 3 www.evolutionpowertools.com PRODUCT OVERVIEW 1. MATERIAL SUPPORT 2. EXTENSION RAIL 3. WHEEL 4. HEIGHT ADJUSTABLE LEGS 5. QUICK-RELEASE SAW BRACKET 6. HANDLE LEG LOCKING LEVERS UNIVERSAL BRACKET EXTENSION...
- Page 4 PARTS SUPPLIED Description 005-0005 Instruction Manual Universal bracket extension Mounting bracket Work supports Work support brackets Locking knobs Wheels Handle FIXINGS SUPPLIED Wheel assembly Shaft Flat washer 12mm Flat washer 10mm Nut M10 Handle assembly Socket head cap screw M8 x 20mm...
- Page 5 www.evolutionpowertools.com Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 6 Fig. 7 Fig. 5 Fig. 8 Fig. 11 Fig. 12 Fig. 9 Fig. 10 Fig. 13 Fig. 14...
- Page 6 • Be careful when raising or lowering the stand to or damaged. Contact Evolution Power Tools for prevent trapped fingers or hands. replacement labels. • Ensure that the snap buttons on each leg are in Note: All or some of the following symbols may the locked position.
- Page 7 MOUNTING EVOLUTION MITRE SAW TO THE MITRE STAND Note: The Evolution Mitre Saw Stand is suitable for most Evolution Mitre Saws. • Attach the machine to the saw mounting brackets using suitable bolts, washers and locknuts etc. The locking handles must be positioned to the front of the mitre saw.
- Page 8 Total Tools (Importing) Pty Ltd Evolution Power Tools SAS 20 Thackray Road 61 Avenue Lafontaine Port Melbourne 33560, Carbon-Blanc Vic 3207 Bordeaux T: 03 9261 1900 T: +33 (0)5 57 30 61 89 Evolution Power Tools Ltd Evolution Power Tools LLC...
