- Page 1 User Guide 7361 Airport Fwy Richland Hills, Texas 76118 800.648.4452 www.amltd.com...
- Page 2 Mounting It is highly recommended to use the ACC-0794 Universal Mount as an interface between the Firebird VMU and the mounting bracketry that will be used to attach it to the forklift. It provides clearance for power and scanner cords to connect to the rear panel and provides multiple mounting hole patterns such as VESA 75 and AMPs.
- Page 3 BRACKET INSTALLATION: VMU IN PORTRAIT MODE (USE M4 SCREWS PROVIDED WITH DEVICE) ORIENT VMU SO THAT REAR ACCESS DOOR IS AT THE TOP RECOMMENDED: USE MEDIUM STRENGTH THREAD LOCKER BRACKET INSTALLATION: VMU IN LANDSCAPE MODE...
- Page 4 Power PLUG IN POWER (5V), AND OTHER PERIPHERALS AS NEEDED. WIRE THE DC CABLE PROVIDED WITH CONVERTER KIT TO THE +VOUT (RED WIRE) AND -VOUT (BLACK WIRE) OF THE CONVERTER A DC POWER CONVERTER KIT IS REQUIRED TO CONVERT VEHICLE POWER DOWN TO THE 5V REQUIRED BY THE FIREBIRD If the vehicle’s power system is: Use this DC Power Converter Kit (converter + cable):...
- Page 5 Mounting Continued SECURE AML ACC-0794 REAR BRACKET TO A VEHICLE MOUNT INTERFACE (EXAMPLE SHOWN HERE) (MOUNT AND HARDWARE NOT INCLUDED) AML ACC-0794 REAR BRACKET EXAMPLE VEHICLE MOUNT INTERFACE ACC-0794’s REAR BRACKET FEATURES AMP, GANG, AND VESA 75 HOLE PATTERNS...
- Page 6 HOOK THE DEVICE AND FRONT BRACKET ONTO THE REAR BRAKET, AS SHOWN. RE-INSTALL THE TWO BOTTOM SCREWS AT DESIRED ANGLES (0 – 10 – 15 DEGREES POSITIONS AVAILABLE) RECOMMENDED HARDWARETO SECURE FIREBIRD VMU TO A FORKLIFT. THIS HARDWARE PROVIDES VIBRATION DAMPENING RAM® Double Socket Arm - C Size Part#:RAM-201U-B RAM®...
- Page 7 Extended Warranty Plus, 3-year, Firebird Sanitizing Your Device The best way to clean and sanitize your AML mobile computer or kiosk is to use a diluted solution of three-parts water and one-part rubbing alcohol. Rubbing alcohol is a diluted form of isopropyl alcohol.
- Page 8 Phone and email support is available Monday thru Friday, from 8:00 am to 5:00 pm CST. If your Firebird VMU is in need of repairs, you may request an RMA number (Return Material Authorization) by calling AMl Tech Support at 877-842-3990, between the hours of 8:00 am and 5:00 pm, (CST) Monday-Friday.
