Kwun-E32H First use of Quick guide
1. Open the battery cover and remove the 4G network cover using a Phillips screwdriver.
2. Take out the 4G network module, remove the cover, insert the Nano SIM card, and restore the installation.
1
* You need to buy and insert Nano SIM card by yourself
* Main traffic usage scenario: device interface interaction is about 3.2KB/s, and one OTA is about 1-50MB
* You need to configure the VPN for 4G network modules. For details, see the LTE Modem APN Configuration
Instructions.
1.Open the battery cover
2.Align the battery, and connect the battery outlet to the XT60 port on the opposite side of the connection port.
3. Close the battery cover
2
1. Hold the roller brush holder and lift the roller brush holder. Insert the flange bearing corresponding to the rotating
guide rail connecting the roller brush holder.
2. Ensure that the air socket is powered off, open the waterproof cover, connect the air socket according to the limit
prompt, and complete the installation.
3
④
深圳怪虫机器人有限公司 SHENZHEN KWUNPHI ROBOT CO., LTD.
Installing a SIM Card
Battery installation
Install the brush roller support
⑤
1 / 5
⑥
Advertisement
Table of Contents
Related Manuals for Kwunphi Kwun-E32H
Summary of Contents for Kwunphi Kwun-E32H
- Page 1 深圳怪虫机器人有限公司 SHENZHEN KWUNPHI ROBOT CO., LTD. Kwun-E32H First use of Quick guide Installing a SIM Card 1. Open the battery cover and remove the 4G network cover using a Phillips screwdriver. 2. Take out the 4G network module, remove the cover, insert the Nano SIM card, and restore the installation.
- Page 2 深圳怪虫机器人有限公司 SHENZHEN KWUNPHI ROBOT CO., LTD. Kwun-E32H First use of Quick guide ④ ⑤ ⑥ Power on Press the power button to start the device. When the first red light is off, the device is normal and enters the initialization state.。When the green light is steady on and the red light is off (the buzzer beeps once), and the initialization is successful (about 22s).
- Page 3 深圳怪虫机器人有限公司 SHENZHEN KWUNPHI ROBOT CO., LTD. Kwun-E32H First use of Quick guide Custom PV array scenarios Select the device, enter its interactive interface, click the "battery chip" icon, customize according to the operation scenario by component type, grid line, size and number of pieces, and then click Submit。...
- Page 4 深圳怪虫机器人有限公司 SHENZHEN KWUNPHI ROBOT CO., LTD. Kwun-E32H First use of Quick guide Adjust the Kwun position to start the Kwun Adjust the horizontal central axis of the device to the spacing line of the cells in row 2 and row 3 in the lower corner, and the horizontal central axis to the spacing line of the cells in row 3 and row 4 in the lower corner.
- Page 5 16. Do not use the product when it cannot work normally due to drop or damage. To avoid injury, the product should be repaired by the manufacturer or its after-sale service. 17. Please use the product according to the instructions in the manual. Kwunphi company is not responsible for any loss or injury caused by improper use.
