Summary of Contents for RoadRunner D4+ 4.0
- Page 2 RoadRunner D4+ 4.0 Electric Scooter For instructional videos on how to: get your scooter ready to ride, maintain your scooter, and repair your scooter, scan this QR code with your camera phone and browse dozens of videos.
-
Page 3: Table Of Contents
Table of Contents Scooter and Accessories D4+ 4.0 Electric Scooter Accessories Scooter Specs Charging the Scooter Battery and Charger Information Handlebar Controls and Instruments Parameter Settings (P-Settings) Operating instructions Safety Instructions Maintenance Adjusting the Stem Height Troubleshooting common errors Folding the Scooter... -
Page 4: Scooter And Accessories
Scooter and Accessories D4+ 4.0 Electric Scooter Accessories Included: 1. Owner’s Manual 2. Steering Damper 3. Charger 4. Multi-tool... -
Page 5: Scooter Specs
Scooter Specs Product name RoadRunner D4+ 4.0 Electric Scooter Product model D4+ 4.0 Folded Dimensions 49" (l) x 9" (w) x 21" (h) Unfolded Dimensions 49" (l) x 9" (w) x 50" (h) Net weight 70 lbs Max load 330 lbs... -
Page 6: Charging The Scooter
Charging the Scooter 1. Plug the charger into a power supply (wall outlet, power strip, etc.) 2. Open the waterproof cover on the charging port, then plug the charger into the charging port. 3. A red light means the scooter is charging; green means it is fully charged. 4. -
Page 7: Battery And Charger Information
Battery and Charger Information Every RoadRunner D4+ 4.0 Scooter is equipped with a dedicated lithium-ion battery and a dedicated smart charger. Please do not use any other charger or battery with your scooter, and do not use your dedicated charger with any other product. -
Page 8: Handlebar Controls And Instruments
Handlebar Controls and Instruments... - Page 9 LCD Display Power: power button (hold down for 3 seconds) Gear: current gear speed: Gear 1 (low), Gear 2 (medium), Gear 3 (fastest) To switch to different modes, hit the mode button to get to Gear 2, hit the mode button again to get to Gear 3, and once more to return to Gear 1.
-
Page 10: Parameter Settings (P-Settings)
Parameter Settings (P-Settings) To make changes to any P-settings, press the power and mode buttons simultaneously until the P-settings appear. Once the selected settings appear, quickly press the power button once to proceed to the next P-setting. Press the power button to exit the current P-settings or to advance to the next P-setting. P- settings will automatically exit if there is no activity for 8 seconds. -
Page 11: Operating Instructions
Operating instructions Power on/off: Power on/off a. Turn your key to the right to turn on, turn your key to the left to turn off. b. Long press the power button to turn the LCD display on/off. c. Press power button once quickly to switch gears (default is gear 1). Gear setting: Press the button located on the throttle to switch gears. -
Page 12: Safety Instructions
Safety Instructions Please read the following carefully before use. ● This scooter is for use by one adult rider at a time. ● When riding, please wear safety gear including a helmet. ● Always keep both hands and both feet on your scooter while riding. ●... -
Page 13: Maintenance
Adjusting the Stem Height It is extremely important to make sure the fastening clasp is extremely tight before riding the D4+ 4.0 Electric Scooter. To adjust the stem height: 1. Pull the fastening clasp outwards so the clasp is open. -
Page 14: Troubleshooting Common Errors
Parameters may be set incorrectly. b. Try resetting options. 3. Display appears opaque or shows discontinuous values. a. Maybe due to a poor contact connection or low battery. b. Restart your scooter or contact RoadRunner Support. Please contact RoadRunner Support at support@roadrunnerscooters.com if you... -
Page 15: Folding The Scooter
Folding the Scooter Pull the blue safety lever down Lower the stem towards to the deck. Press the silver the scooter deck. snap back so that the stem completely folds down as shown in picture. When you hear a click, the stem is locked, and folding is complete. -
Page 16: Unfolding The Scooter
Unfolding the Scooter Press the silver snap back towards deck of scooter to Keep pressing the silver snap completely remove the black and push the stem vertical to post from the upper slot. ground. After the stem is locked in an upright position, push the stem forward to remove pressure from the safety lever while simultaneously pushing the blue safety lever... -
Page 17: Installing Steering Damper
Installing Steering Damper Before you begin installing the Steering Damper, make sure we have all the necessary tools and hardware. The hardware includes the following (all included in box); 2x M6x1.0, 18mm long bolts 2x M8x1.25, 35mm long bolts 2x M8 spring washers 2x M6 washers 2x M8x1.25 locking nuts 1x long threaded dowel... - Page 18 1. Begin by moving the safety lever 2. If you are using thread locker, into its lowered position. apply now to the 2x M5 bolts. You will only need a little bit to get the job done. 3. Use the 5mm allen to hold the M5 bolt and put it through the lefthand hold on the neck of the scooter.
- Page 19 4. Use your fingers to thread the larger dowel onto the end of the bolt. You will want to leave it slightly loose. It may help to use the 5mm allen as a counter- torque for the bolt. 5. Now do the front dowel. The process is very similar, and should be a bit easier. Start by placing the washer onto the M5 bolt, and place it through the hole on the righthand side of the blue arm.
- Page 20 6. It is best to have both holes facing vertically as seen above. 8. Place the eyelet above the rear (larger) 7. Now slide the clamp onto the dowel hole and start threading the M8 bolt steering damper. Don’t tighten the through the eyelet in the damper and into the clamp down just yet.
- Page 21 10. Place the M8 spring washer onto the 9. Repeat step 8 using the eyelet underside of the M8 bolt, then start available on the clamp. threading the M8 locking nut onto the bolt (following the spring washer). 11. Use the 13mm socket (or adjustable spanner) to tighten the bolt onto the underside of the nut.
- Page 22 14. Finally, use the 5mm allen to tighten down the two M5 bolts. This is the last step. Please contact RoadRunner Scooters if you have any questions!
-
Page 23: How To Carry Your Scooter
When folded up, your scooter can be carried with one or two hands. Warranty Policy The RoadRunner D4+ 4.0 Scooter comes with a one-year limited warranty. For full warranty information scan this QR code with your camera phone or visit our website at: https://roadrunnerscooters.com/pages/warranty-policy-1...
