Oven
[en]
User manual and installation
instructions
C27CS22H0B
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C27CS22H0B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NEFF C27CS22H0B

  • Page 1 Oven [en] User manual and installation instructions C27CS22H0B...
  • Page 2: Table Of Contents

    en Safety ¡ Do not connect the appliance if it has been Table of contents damaged in transit. 1.2 Intended use USER MANUAL This appliance is designed only to be built into kitchen units. Read the special installation Safety ..............   2 instructions.
  • Page 3 Safety en Opening the appliance door creates a The appliance and its parts that can be draught. Greaseproof paper may come into touched may have sharp edges. contact with the heating element and catch ▶ Take care when handling and cleaning fire.
  • Page 4: Safety

    en Safety The outside of the appliance gets very hot WARNING ‒ Risk of suffocation! when the cleaning function is in progress. Children may put packaging material over ▶ Never hang combustible objects, e.g. tea their heads or wrap themselves up in it and towels, on the door handle.
  • Page 5: Preventing Material Damage

    Preventing material damage en 2  Preventing material damage Fruit juice dripping from the baking tray leaves stains 2.1 General that cannot be removed. ATTENTION! When baking very juicy fruit flans, do not pack too ▶ Objects on the cooking compartment floor at over much on the baking tray.
  • Page 6 en Environmental protection and saving energy Allow frozen food to defrost before cooking. ¡ This saves the energy that would otherwise be re- quired to defrost it. Note: The appliance requires: ¡ A maximum of 2 W in networked standby mode ¡ A maximum of 1 W when the appliance is not con- nected to the network, with the display switched on ¡...
  • Page 7: Familiarising Yourself With Your Appliance

    Familiarising yourself with your appliance en 4  Familiarising yourself with your appliance 4.1 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operat- ing status. Display Buttons Control element 4.2 Buttons The buttons are touch-sensitive areas.
  • Page 8 en Familiarising yourself with your appliance Button Name Right Navigate to the right on the display Navigate upwards on the display Down Navigate downwards on the display 4.4 Display The display shows the current settings, options or relevant information. Symbols Different symbols may appear on the display. Symbol Name Home Connect...
  • Page 9 Familiarising yourself with your appliance en Symbol Heating function Temperature Circo-roasting 50 - 250 °C Roast poultry, whole fish or larger pieces of meat. The grill element and the fan switch on and off alternately. The fan circulates the hot air around the food. CircoTherm Intensive 50 - 275 °C Cook pizza or food that requires a lot of heat from below.
  • Page 10 en Accessories When you open the appliance door, the light in the ATTENTION! cooking compartment switches on. If the appliance Do not cover the ventilation slot above the appliance door remains open for longer than 15 minutes, the light door. The appliance overheats. switches off again.
  • Page 11 You will find a comprehensive range of products for your appliance in our brochures and online: www.neff-international.com Accessories vary from one appliance to another. When Push the accessory all the way in, making sure that purchasing accessories, always quote the exact it does not touch the appliance door.
  • Page 12 en Basic operation Press ​ ⁠ to switch the appliance on. Keep the kitchen ventilated while the appliance is heating. → "Switching on the appliance", Page 12 Set the required heating function and temperature Press ​ ⁠ to switch off the appliance after 1 hour. for the heat-up process and press ​...
  • Page 13 Time-setting options en Press ​ ⁠ . a The information will be displayed for a few seconds. ▶ 8  Time-setting options Your appliance has different time-setting options, with 8.3 Cooking time which you can control its operation. Once the set cooking time has elapsed, the appliance switches off automatically.
  • Page 14 en Baking and roasting assistant Press ​ ⁠ to confirm the delayed start. Use the ​ ⁠ or ​ ⁠   button to change the end time. a The appliance will start at the appropriate time. a The setting will then be applied. a Once the cooking time has elapsed, an audible sig- Cancelling the Ready at time for delayed starts nal will sound.
  • Page 15 Childproof lock en 10  Childproof lock You can secure your appliance to prevent children Press ​ ⁠ to switch the appliance on and then start it from accidentally switching it on or changing the set- tings. 10.4 Deactivating the automatic childproof 10.1 Locks lock Your appliance has two different locks: Press and hold the...
  • Page 16: Sabbath Mode

    en Sabbath mode 11.2 Activating the "Rapid heat-up" function 11.4 Activating the "PowerBoost" function Set Top/bottom heating  ​ ⁠ and a temperature of at Place the food on a single level in the cooking com- least 100 °C. partment. Press ​ ⁠ to start. Set CircoTherm hot air ...
  • Page 17: Home Connect

    Home Connect  en Use the ​ ⁠   button to navigate to the next row. Basic setting Selection Use the ​ ⁠ or ​ ⁠   button to change the setting. Lighting ¡ On during operation Press ​ ⁠ . ¡ Off during operation To save your settings, use the ​...
  • Page 18 en Home Connect Download the Home Connect app. Open the Home Connect app and scan the follow- ing QR code. Follow the instructions in the Home Connect app. 14.2 Home Connect Settings You can adjust the settings and network settings for Home Connect by going to your appliance's basic settings. Which settings the display shows will depend on whether Home Connect has been set up and whether the appliance is connected to your home network.
  • Page 19 Cleaning and servicing en Notes 14.6 Data protection ¡ You can continue to use your appliance as normal Please see the information on data protection. while updates are downloading. Depending on your The first time your appliance is registered on a home personal settings in the app, software updates can network connected to the Internet, your appliance will also be set to download automatically.
  • Page 20 en Cleaning and servicing Appliance door Area Suitable cleaning agents Information Door panels ¡ Hot soapy water Do not use a glass scraper or a stainless steel wool. Tip: Remove the door panels in order to clean them thoroughly. → "Appliance door", Page 23 Door cover ¡...
  • Page 21: Cleaning Functions

    Cleaning functions en 16  Cleaning functions You can use the cleaning functions to clean the appli- Note: ance. The vertical bar ​ ⁠ must be to the front of the ac- cessory supports. 16.1 Self-cleaning function The "Self-cleaning" function cleans the cooking com- partment virtually automatically.
  • Page 22 en Cleaning functions Use the ​ ⁠   button to navigate to the next row. Requirements Use the ​ ⁠ or ​ ⁠   button to select the cleaning setting. ¡ You can only start the cleaning aid once the cooking compartment is cold (room temperature) and the ap- Cleaning set- Cleaning...
  • Page 23: Appliance Door

    Rails en 17  Rails To thoroughly clean the rails and the cooking compart- 17.2 Attaching the rails ment, or to replace the rails, you can remove the rails. Notes ¡ The rails only fit on the right or left. 17.1 Detaching the rails ¡...
  • Page 24 en Appliance door Note: Ensure that the appliance door slides onto the WARNING ‒ Risk of injury! hinges without any resistance. If you feel any resist- When the hinges are not secured, they can snap ance, check whether you are sliding it in at the cor- shut with great force.
  • Page 25 Appliance door en Components inside the appliance door may have sharp WARNING ‒ Risk of injury! edges. Scratched glass in the appliance door may develop Wear protective gloves. ▶ into a crack. Do not use any harsh or abrasive cleaners or Open the appliance door slightly. ▶...
  • Page 26: Troubleshooting

    en Troubleshooting Push the front pane to the appliance until the left- Screw both screws back in on the left and right of and right-hand hook ​ ⁠ is opposite the support ​ ⁠ ​ ⁠ . the appliance door. Put the door cover in position and push down on it ​...
  • Page 27 Next time, set lower or higher values. ▶ Tip: A lot of information about the food preparation and corresponding setting values can be found on our website www.neff-international.com. 19.2 Replacing the oven light bulb WARNING ‒ Risk of electric shock! When changing the bulb, the bulb socket contacts are If the light in the cooking compartment fails, change live.
  • Page 28 en Disposal Pull out the halogen bulb without turning it  ​ ⁠ . Insert the new halogen lamp and press it firmly into the socket. Make sure the pins are positioned correctly. Depending on the appliance model, the glass cover may have a sealing ring. Put the sealing ring in posi- tion.
  • Page 29: Declaration Of Conformity

    Declaration of Conformity en 22  Declaration of Conformity Constructa Neff Vertriebs-GmbH hereby declares that Hereby, Constructa Neff Vertriebs-GmbH declares that the appliance with Home Connect functionality con- the appliance with Home Connect functionality is in forms to the basic requirements and other relevant pro- compliance with relevant statutory requirements.
  • Page 30 en How it works 23.3 Roasting, braising and grilling tips Roasting in covered cookware ¡ Use a suitable lid that seals well. ¡ The recommended settings are for fridge-temperat- ¡ When roasting meat, there should be at least 3 cm ure food and unstuffed, oven-ready poultry. between the food and the lid.
  • Page 31 How it works en 23.5 List of foods Recommended settings for a variety of foods, sorted into food categories. Recommended settings for various types of food Food Accessory/cookware Shelf pos- Heating Temperature in Cooking time in ition function °C mins → Page 8 Victoria sponge cake x 2 ​...
  • Page 32 en How it works Food Accessory/cookware Shelf pos- Heating Temperature in Cooking time in ition function °C mins → Page 8 Bacon rashers Wire rack ​ ⁠ 1. First side 4-5 2. Second side Sausages, 2-4 cm thick Wire rack ​ ⁠ 10 - 15 Belly Wire rack ​...
  • Page 33 How it works en Issue Issue You want to slow ¡ Place the cold duck breast You want to serve ¡ Preheat the serving plate. cook a duck breast. into a pan. your slow-cooked ¡ Make sure that the sauces ¡ Sear the skin side first. meat as hot as pos- that accompany the duck sible.
  • Page 34: Installation Instructions

    en Installation instructions Recommended settings for baking Food Accessory/cookware Shelf pos- Heating Temperature in Cooking time in ition function °C mins → Page 8 Viennese whirls Baking tray ​ ⁠ 150 - 160 25 - 40 Viennese whirls Baking tray ​ ⁠ 140 - 150 25 - 40 Viennese whirls, on 2 levels Universal pan...
  • Page 35 Installation instructions en ATTENTION! Carrying the appliance by the door handle could break it. The door handle cannot sup- port the weight of the appliance. ▶ Do not carry or hold the appliance by the door handle. 24.2 Appliance dimensions You will find the dimensions of the appliance here ¡...
  • Page 36 en Installation instructions 24.4 Installation underneath a hob If the appliance is installed under a hob, the following The minimum worktop thickness ​ ⁠ a is based on the minimum dimensions must be adhered to (including required minimum clearance ​ ⁠ . substructure, if applicable).
  • Page 37 Installation instructions en ¡ Ensure that air exchange is guaranteed in accord- ¡ Contact protection must be guaranteed by the in- ance with the diagram. stallation. Electrically connect the appliance with the protective contact plug Note: The appliance must only be connected to a pro- tective contact socket that has been correctly installed.
  • Page 38 en Installation instructions Open the appliance door and unscrew the left and Refit the panels and screw them in place, first at the right-hand panels. top and then at the bottom. Close the appliance door. If required, the gap between the appliance door and Screw the appliance into place.
  • Page 40 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom *9001715583* 9001715583 BSH Hausgeräte GmbH Carl-Wery-Straße 34 020211 81739 München, GERMANY...
