- Page 1 ASSEMBLY INSTRUCTIONS COPENHAGEN 2 DOOR 1080MM CUPBOARD COPENCUPKT This design and instruction booklet is subject to copyright. 2 Cartons www.officeworks.com.au For spare parts or hardware call (03) 9310 3011 or email hardware@kyvas.com.au 1/15...
- Page 2 To view an assembly video, go to https://www.officeworks.com.au/ Search the product by item code or name: Click on the icon to watch the video. General Advice People Required Customer Service Contact Details More Than One Person Is Required Assemble On A Clean Flat Spare Parts &...
- Page 3 Part Overview 3/15...
- Page 4 Part List Parts located in Carton - COPENCUPC1 Parts located in Carton - COPENCUPC2 4/15...
-
Page 5: Hardware List
Hardware List Hardware Pack located in Carton - COPENCUPC2 (Ø7.8 x 30mm) (Ø6 x 35mm) (Ø7 x 38mm) (Ø15 x 12mm) X 14pcs X 8pcs X 12pcs X 8pcs Allen Key Shelf Support Sticker (Ø3.5 x 14mm) M6-size X 4 pcs X 16 pcs X 24pcs X 1pc... - Page 6 Assembly 4pcs 4pcs 8pcs 6/15...
- Page 7 Tighten cam locks once panel 2 & 3 is in place. 4pcs 7/15...
- Page 8 4pcs 8/15...
- Page 9 Tighten cam locks once panel 6 is in place. 4pcs 9/15...
- Page 10 8pcs 4pcs 10/15...
-
Page 11: Hinge Adjustment
16pcs Hinge adjustment If the doors do not appear square or aligned, loosen or tighen the appropriate screws on each case hinge as illustrated. Side to side adjustment: Loosen screw A, adjust gap with screw B and re-tighten screw A. Depth adjustment: Loosen screw A, push hinge arm forwards or backwards, re-tighten... - Page 12 CAUTION IMPORTANT: To prevent furniture from tilting forward it is recommended that you: 1. Prevent small children from climbing onto bookcase. 2. Securely attach the anti tilt straps provided to your wall. CAUTION IMPORTANT: For your safety when attaching the anti tilt straps: 1.
- Page 13 1. Fix strap L to back panel by using hardware J and K . Position furniture in front of wall stud behind plasterboard. Screw strap L into stud using hardware K and M . Important Note Do not push or pull the bookcase to re-position. This may result in broken legs.
-
Page 14: Care Advice
Care Advice Care lnstructions - PU Painting Finish Cupboard Keep away and protect from direct sunlight and heat. Do not place sharp materials(knife,fork,etc) directly onto your furniture as sharp material may scrape and damage the finish. Clean up spills quickly. Water left over a prolonged period of time may cause damage. - Page 15 Warranty 3 years Product Warranty – valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 3 years from the date of purchase by the original customer. If the product has any defects or does not work as intended during the Warranty Period, Officeworks will, at its election and at its expense, repair or replace the product.
