Island Installation; Typical Installation - IKEA HACKSTAD Manual

Overhead Cabinet Should Not Exceed a
Maximum Depth of 15" (38 cm)
30" (76.2 cm) Min.
Clearance Between the Top
of the Cooking Platform
and the Bottom of an
Unprotected Wood or Metal
Cabinet
24" (61 cm) Min. when
Bottom of Wood or Metal
Cabinet is Protected by Not
Less Than 1/8" (0.3 cm)
Flame Retardant Millboard
Covered With Not Less Than
No. 28 MGS Sheet Steel,
0.015" (0.4 mm) Stainless
Steel, 0.024" (0.6 mm)
Aluminum or 0.020" (0.5
mm) Copper.
* Letters on this figure refer to chart on page 4 except for J and K.

Island Installation

Figure 2b – Minimum
Recommended Distance
From Behind the Cabinet
Figure 2 – COUNTERTOP CUTOUT OPENING
MODEL
30"
36"
*See Figure 2c
18"
(45.7 cm)
G
24"
(61 cm)
*See Figure 2b
1⅛"
(2.9 cm)
Front
J
2" (5.1cm) 30 /
5
2" (5.1cm) 36 ¾" (93.4 cm)
K
Min.
10"
( 25.4 cm)
F
H
12"
(30.5 cm)
Approximate Location of
Junction Box

Typical Installation

Figure 2c – Minimum
Recommended Distance Between
Rear Edge of Cutout and Nearest
Combustible Surface Behind
K
" (77.8 cm)
8
J
Min. From Edge of
Cooktop to Nearest
Combustible Wall (Either
Side of Unit).
It is not recommended to use
drawer underneath cooktop.
Empty space is needed for
installation purpose.
backsplash
2"
(5 cm)
Wall
Countertop
5
