MCT242
2.4GHz MICRO TRANSCEIVER
The information, specifications, and illustrations in this manual are those in effect at the time of
printing. We reserve the right to change specifications or design at any time without notice.
Kar-Tech, Inc.
January 26, 2016
TH

Advertisement

loading

Related Manuals for KAR-TECH MCT242

Summary of Contents for KAR-TECH MCT242

  • Page 1 MCT242 2.4GHz MICRO TRANSCEIVER The information, specifications, and illustrations in this manual are those in effect at the time of printing. We reserve the right to change specifications or design at any time without notice. Kar-Tech, Inc. January 26, 2016...

  • Page 2: Operation

    OPERATION The MCT242 is a radio transceiver module for the 2.4 GHz ISM bands. The transceiver microcontroller includes a CPU, GPI/O, a fully integrated frequency synthesizer, a power amplifier, a modulator and a receiver unit.
  • Page 3 2.4GHz Macro transceiver The MCT242 is Direct Sequence Spread Spectrum that can use one of 16 channels, where Channel 1 is 2.405GHZ and Channel 16 is 2.480GHZ.

  • Page 4: Specifications

    2.4GHz Macro transceiver TRANSCEIVER PICTORIAL SPECIFICATIONS Description: Before staring the test, charge the transmitter fully using the standard Micro USB charger. Press power switch to turn transmitter on. To Power ON: Press and hold the POWER switch for about 2 seconds, until red and green light starts to blink. To Power OFF: Press and hold the POWER switch for about 2 seconds, then release.

  • Page 5: Fcc Statement

    2.4GHz Macro transceiver FCC Statement FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 2.4GHz Macro transceiver IC Statement This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada.Son fonctionnement est soumis aux deux conditions suivantes: (1) Ce dispositif ne peut causer d'interférences ;...
  • Page 7 The SAR limit of USA (FCC/IC) is 1.6 W/kg averaged over one gram of tissue. Device types: MCT242 has also been tested against this SAR limit. This device has been tested and meets the RF exposure guidelines with a conservative distance 0 mm.
