- Page 1 MOD190 MODULAR TRANSCEIVER OEM INSTALLATION AND OPERATION MANUAL NOTE: THIS MODULE IS LIMITED TO OEM INSTALLATION ONLY DECEMBER 6, 2016...
-
Page 2: Table Of Contents
MOD190 TRANSCEIVER INDEX DESCRIPTION ................2 OPERATION ................2 INSTALLATION ................. 4 BEFORE APPLYING POWER! ............6 TROUBLESHOOTING ..............6 TRANSCEIVER PICTORIAL ............8 SPECIFICATIONS ..............9 INSTRUCTION TO THE USER ........... 10 ... -
Page 3: Description
MOD190 transceiver. microcontroller responsible for the control of the The MOD190 is not designed for entire communication. multiple antenna applications MOD190 transceiver contains a should... - Page 4 MOD190 TRANSCEIVER synchronization with The MOD190 hops on 50 channel transmitter’s signals. frequencies that are selected in pseudo random order. example of the order is: {48, 25, 17, 20, 41, 37, 36, 10, 15, 44, 30, 6, 42, 33, 8, 28,...
-
Page 5: Installation
MOD190 TRANSCEIVER INSTALLATION antenna. 1) Solder MOD190 transceiver directly to the host’s compatible connector. 2) Print and attach the label as shown below: 3) Place a label on the outside of the host enclosure in a visible area. On the label,... - Page 6 MOD190 without 750mA. antenna. B) Do not remove the shield G) Documentations: on the MOD190. host’s User Manual C) If you use something other include the following: than ¼ wave a. That there are no user...
-
Page 7: Before Applying Power
BEFORE APPLYING POWER! Check power and ground for proper polarity. Read the rest of this manual. TROUBLESHOOTING There are no user serviceable parts in the MOD190 Transceiver. Contact your KAR-TECH representative further instructions or servicing. - Page 8 PARTS LIST PART NUMBER DESCRIPTION 021901A MOD190 RADIO TRANSCEIVER – WIRE ANTENNA 021902A MOD190 RADIO TRANSCEIVER – RPSMA ANTENNA There are no user-serviceable parts inside the transmitter or the receiver. Return the units for service. The information, specifications, and illustrations in this manual are those in effect at the time of printing.
-
Page 9: Transceiver Pictorial
MOD190 TRANSCEIVER TRANSCEIVER PICTORIAL... -
Page 10: Specifications
MOD190 TRANSCEIVER SPECIFICATIONS Equipment Class ......Part 15 Spread Spectrum Transmitter FCC ID:P4U-MOD190 IC:4534A-MOD190 TRANSCEIVER Power supply ................3.3VDC Operating temperature - Radio ........-40˚C to +85˚C Storage temperature ..........-40˚C to +100˚C RF Frequency ..............902.5-927 MHz RF Receive Sensitivity ............. -126 dBm... -
Page 11: Instruction To The User
MOD190 TRANSCEIVER INSTRUCTION TO THE USER This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. - Page 12 This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID:P4U-MOD190“ when the module is installed inside another device, the user manual of this device must contain below warning statements;...
-
Page 13: Industry Canada Statements
MOD190 TRANSCEIVER INDUSTRY CANADA STATEMENTS This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. - Page 14 This exterior label can use wording such as the following: “Contains IC: 4534A-MOD190” when the module is installed inside another device, the user manual of this device must contain below warning statements;...
- Page 15 MOD190 TRANSCEIVER 1. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
