INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
NOTICE: Barrier required, but may be sold separately.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
HOT GLASS
WILL
CAUSE BURNS.
DO NOT TOUCH
GLASS
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
DIRECT VENT ZERO
CLEARANCE GAS FIREPLACE
HEATER MODEL SERIES:
MILLIVOLT (MV)
DVCX(36,42)FP30(N,P)-3
INTERMITTENT PILOT (IPI)
DVCX(36,42)FP70(N,P)-3
WARNING
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
This appliance may be installed in
an aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by state or
local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
GAS-FIRED
MH30033
Page 1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for White Mountain Hearth MILLIVOLT DVCX FP30-3 Series
Summary of Contents for White Mountain Hearth MILLIVOLT DVCX FP30-3 Series
- Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL INSTALLER: DIRECT VENT ZERO Leave this manual with the appliance. CLEARANCE GAS FIREPLACE CONSUMER: HEATER MODEL SERIES: Retain this manual for future reference. MILLIVOLT (MV) DVCX(36,42)FP30(N,P)-3 WARNING INTERMITTENT PILOT (IPI) FIRE OR EXPLOSION HAZARD DVCX(36,42)FP70(N,P)-3 If the information in this manual is not followed exactly, a fire or explosion may GAS-FIRED...
- Page 2 BEFORE YOU START Read the safety information on Pages 64 - 66. If located in the Commonwealth of Massachusetts, please note the special requirements on Page 67. Where are you going to install the unit? See Pages 8-10 & 14. Frame the opening.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE All Appliances ................................ 4-43 Carton Contents ....................................4 Introduction ....................................... 5 Specifications ....................................6 Hardware Package ................................... 7 Accessories....................................... 7 Fireplace Dimensions ..................................8 Clearances ....................................9-10 Combustible Material ..................................10 Vent Termination Clearances ..............................11-12 Gas Supply ..................................... -
Page 4: All Appliances
CARTON CONTENTS DVCX(36,42)FP3 SERIES DVCX(36,42)FP7 SERIES NATURAL PROPANE NATURAL PROPANE INDEX INDEX DESCRIPTION DESCRIPTION NUMBER SUPPLIED NUMBER SUPPLIED Rock Wool Rock Wool Receptical Cover Receptical Cover Receptical Receptical Flue Restrictor Assembly - Flue Restrictor Assembly - Natural or Propane Natural or Propane Hardware Pack Hardware Pack Not Shown... -
Page 5: Introduction
INTRODUCTION Instructions to Installer The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code 1. Installer must leave instruction manual with owner after ANSI Z223.1/NFPA 54* Natural Gas and Propane Installation installation. -
Page 6: Specifications
SPECIFICATIONS DVCX36NAT DVCX36LP DVCX42NAT DVCX42LP Input BTU/Hr Maximum 37,000 34,000 40,000 36,000 29,000 Input BTU/Hr Minimum 26,000 27,000 27,000 9.96 KWH (Maximum) 10.84 11.72 10.55 7.91 7.91 KWH (Minimum) 7.62 Orifice (Front / Rear) 47 / 42 58 / 1.45 44 / 40 57 / 1.45 Air Shutter Opening 3/16... -
Page 7: Hardware Package
HARDWARE PACKAGE DVCX(36,42)FP(3,7) SERIES HEX HEAD SCREW 10 X 1/2 ACCESSORIES The following accessory parts can be obtained from your Empire Comfort Systems dealer. Contact your Empire Dealer for more acces- sory options. If you need additional information beyond what your dealer can furnish, contact Empire Comfort Systems Inc., 918 Freeburg Ave., Belleville, Illinois 62220-2623. MODEL NUMBER DESCRIPTION USED ON DF362NB Beveled Window Frame, Brushed Nickel DVCX36... -
Page 8: Fireplace Dimensions
FIREPLACE DIMENSIONS DIMENSIONS (in inches) INDEX LETTER DIMENSION DESCRIPTION DVCX36FP DVCX42FP The maximum height of firebox face (excluding standoffs) 41-7/8 41-7/8 The maximum width of the firebox face (excluding nailing flanges) 42-1/4 46-1/4 The maximum depth of the firebox 22-1/16 22-1/16 The height of the firebox opening 27-1/2 27-1/2 The width of the firebox opening 39-15/16 35-15/16 The interior depth of the firebox 15-1/4 15-1/4 The rear exterior width of the firebox 28-3/8 32-3/8 The height to the firebox standoffs 42-1/8 42-1/8 19-1/8 Width from the left side of the box to the centerline of vent 23-1/8 Depth from back of box to centerline of top vent 7-11/16... -
Page 9: Clearances
CLEARANCES Mantel Chart Clearance to Combustibles Back Stand-off 0" (0 mm) Side Stand-off 0" (0 mm) Floor 0" (0 mm) Top Stand-off 0" (0 mm) 6” (152 mm) Top Framing Edge SEE MANTEL CHART FOR MAXIMUM MANTEL DEPTH 2" x 4" HEADER SEE MANTEL CHART STAND-OFF FOR MINIMUM HEIGHT... -
Page 10: Combustible Material
CLEARANCES (CONT’D) Clearances WARNING This fireplace is not been tested nor approved to have a television or other electrical appliance installed above it. Clearance from bottom of fireplace to ceiling is 84” Clearance from side of fireplace to adjacent sidewall is 6”. Television Considerations Installing a television above a fireplace has become increasingly popular; however, the area above any fireplace gets hot and most TV manufacturers recommend against placing their products near a heat source. If you install a television above this fireplace, Empire Comfort Sys- tems accepts no responsibility for damage or injuries. -
Page 11: Vent Termination Clearances
VENT TERMINATION CLEARANCES Termination clearance for buildings with combustible and noncombustible exteriors. INSIDE CORNER OUTSIDE CORNER RECESSED LOCATION “A” = COMBUSTIBLE 9” (229mm) “F” = COMBUSTIBLE 6” (152mm) = NONCOMBUSTIBLE 2” (51mm) = NONCOMBUSTIBLE 6” (152mm) BALCONY BALCONY WITH PERPENDICULAR SIDE WALL WITH NO SIDE WALL “C”... - Page 12 VENT TERMINATION CLEARANCES Canadian Installations1 US Installations2 Canadian Installations1 US Installations2 A= Clearance above grade, 12 in (30 cm) 12 in (30cm) I= Clearance to service 3 ft (91 cm) veranda, porch, deck, or regulator vent outlet 6 ft balcony B= Clearance to window or 6 in (15 cm) for appli- 6 in (15 cm) for appli- J= Clearance to nonme-...
-
Page 13: Gas Supply
GAS SUPPLY Never use an exposed flame to check for leaks. Appliance must The gas pipeline can be brought in through the right or left side of the appliance. Consult the current National Fuel Gas Code, ANSI be disconnected from piping at inlet of control valve and pipe Z223.1 CAN/CGA-B149 (.1 or .2) installation code. -
Page 14: Locating Fireplace
LOCATING FIREPLACE NOTE: Island and Room Divider installation is possible as long as the horizontal portion of the vent system does not exceed 20 feet with a minimum vertical run of 8 feet. See details in Venting Section. NOTE: When installing this appliance against an exterior wall, insulate to applicable insulation codes. When you install your Direct Vent Fireplace in Room divider or Flat on wall corner positions, a minimum of 6 inches clearance must be maintained from the perpendicular wall and the front edge of the appliance. -
Page 15: Electrical Considerations
ELECTRICAL CONSIDERATIONS CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. Before making the electrical connection, make sure that the main power supply is disconnected. The appliance, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code ANSI/NFPA 70 (Latest Edition). -
Page 16: Installation
INSTALLATION Framing Framing and Finishing Fireplace framing can be built before or after the fireplace is set Choose unit location. 2. Frame in fireplace with a header across the top. It is important in place. Framing should be positioned to accommodate wall covering and fireplace facing material. The fireplace framing should to allow for finished face when setting the depth of the frame. 3. Attach fireplace to frame using adjustable frame. Preset depth be constructed of 2 x 4 lumber. The framing headers may rest on the fireplace standoffs. Refer to Figure 15 for minimum framing to suit facing material (adjustable to 1/2, 5/8 or 3/4-inch depths). - Page 17 INSTALLATION (CONT’D) Vent Pipe Clearance NOTICE: Maintain two inches of clearance around vertical vent pipe on first twelve inches. See Figure 18. For horizontal vent, maintain a minimum one-inch clearance to the bottom and sides of the vent, and three-inch clearance to combustibles above the vent pipe. See Figure 19. NOTICE: A two-inch clearance around pipe for the first twelve inches above the fireplace is required.
- Page 18 INSTALLATION (CONT’D) Vent Runs In planning the installation for the fireplace, it is necessary to install certain components before the appliance is completely positioned and installed. These include the direct vent system, gas piping for the appliance and the electrical wiring. (If the fan option is used.) The appliance can be mounted on any of the following surfaces: 1. A flat, hard combustible (burnable) surface.
- Page 19 INSTALLATION (CONT’D) After installing the vent system, install flue heat shield. VERTICAL, 90-DEGREE ELBOW TO HORIZONTAL OUT THE 1. Hand bend tabs on flue heat shield out 90°. WALL (12” minimum rise before elbow) Attach to insulation box as shown in Figure 26. Figure 28 (vent pipe removed for clarity) Dimensions (in inches) 14 to 15-1/2 4-3/4 to 6-1/4...
-
Page 20: Vent System Identification
VENT SYSTEM IDENTIFICATION Begin the vent system installation by selecting the type of venting Use (Figure 35) on Page 23 for venting to eliminate issues after installation. Check pipe diameter on vent system and fireplace to to be installed and the path that it will take. Verify that clearances verify the size is the same. -
Page 21: Venting Fireplace
VENTING FIREPLACE The minimum hole location dimensions for through the wall CAUTION horizontal installations with a 90-degree elbow and 12 inch rise off the top of the fireplace. Use flue restrictor for vertically terminated units only. Do not use for horizontally terminated units. Incorrect usage may cause sooting. - Page 22 VENTING FIREPLACE (CONT’D) Positioning the Fireplace Below Grade Installation Determine the exact position of the appliance so the direct-vent When it is not possible to meet the required vent termination termination will be centered (if possible) between two studs. This clearances of 12 inches (305 mm) above grade level, a snorkel kit is will avoid any extra framing.
- Page 23 VENTING FIREPLACE (CONT’D) VENTING GRAPH (Dimensions in Feet) To Use the Vent Graph Determine the height of the center of the horizontal vent pipe. Using this dimension on the Sidewall Vent Graph, locate the point it intersects with the slanted graph line. From the point of this intersection, draw a vertical line to the bottom of the graph.
-
Page 24: Top Vent - Horizontal Termination
TOP VENT - HORIZONTAL TERMINATION Two 90° Elbows One 90° Elbow INSTALLED NOTE: Subtract 3 feet from the total horizontal measurement for VERTICALLY each 90° elbow installed horizontally. Subtract 1-1/2 feet from the total horizontal measurement for each 45° elbow installed hori- zontally. INSTALLED 1’ HORIZONTALLY MINIMUM 1’ MININUM TO BOTTOM OF UNIT EXAMPLE VENT RUNS INITIAL... -
Page 25: Top Vent - Vertical Termination
TOP VENT - VERTICAL TERMINATION No Elbows Three 90° Elbows NOTE: Subtract 3ft (914 mm) from the total horizontal measure- ment for each 90° elbow installed horizontally. Subtract 1-1/2 ft (457 mm) from the total horizontal measurement for each 45° el- bow installed horizontally. Index Dimensions Letter Maximum Minimum 40 ft 10 ft Figure 40 Dimensions (in Feet) Two 90° Elbows MIN. -
Page 26: Vertical Termination
VERTICAL TERMINATION General Maintenance Locate and mark the center point of the vent pipe using a nail on Inspect venting system semi-annually as follows: the underside of the roof. Drive the nail through the center point. 1. Check for corrosion areas of the venting system exposed to Mark the outline of the roof hole around this center point. - Page 27 VERTICAL TERMINATION (CONT’D) Installing the Vent System in a Chase Vertical Through the Roof Applications A chase is a vertical box-like structure built to enclose the gas Your Gas Fireplace has been approved for: appliance and/or its vent system. Vertical vent runs on the outside of a) Vertical installations up to 40 feet in height.
-
Page 28: Framing And Finishing
FRAMING AND FINISHING Installing Support Brackets NAILS, 4 REQUIRED Install a horizontal pipe support used for each 3 feet of horizontal run to framing members. Allow 3 inch clearance to combustibles above 8 inch diameter pipe and elbows and 1 inch clearance on both sides and bottom. - Page 29 FRAMING AND FINISHING (CONT’D) Vertical Firestops Vertical runs of this system which pass through ceilings require the use of ONE ceiling firestop at the hole in each ceiling through which the vent passes. Position a plumb bob directly over the center of the vertical vent component and mark the ceiling to establish the center point of the vent.
-
Page 30: Dvvk-5F Flex Vent Instructions
DVVK-5F FLEX VENT INSTRUCTIONS The DVVK-5F FLEX VENT KIT includes the following components: • (1) Horizontal Termination Cap • (1) 4-foot section of Flex vent with spacers (5” flue/8” outer pipe) with flue adapter collar • (1) Wall Firestop/Thimble Assembly • Hardware pack that includes band clamps and screws Maintain at least ½-inch rise for every 12 inches of vent run. CAUTION • Because of sharp edges, always use gloves when han- dling the flex vent components. - Page 31 DVVK-5F FLEX VENT INSTRUCTIONS (CONT’D) 9. Prior to making the vent connections, apply high temperature sealant (1000°F min.) to the vent connections before securing with the band clamps provided. Note: the flue pipe end without the adapter is to be installed to the Termination Cap. 10. Apply sealant to the outside of the flue pipe adapter and connect to the flex flue pipe.
-
Page 32: Liner Placement
LINER PLACEMENT Note: Install Ceramic Fiber or Reflective Liner before placing logs. Refer to the instructions that came with your Liner for proper installation. GLOWING EMBERS Use only the amount of glowing embers supplied with your fireplace. Applying excess glowing embers may adversely affect fireplace performance. If you mix in platinum embers (for a distinctive glow), remove a like amount of embers from the kit supplied with the fireplace. Tear the embers into dime-size pieces and fluff each piece to maximize the glow. -
Page 33: Log Identification
LOG IDENTIFICATION Part Number Front View Top View & Description 34204 Front Right Log (A) 34203 Center Left Log (B) 34202 Front Left Log (C) 34207 Left Log (D) 34208 Center Right Log (E) 34209 Center Log (F) 34210 Rear Log (G) 34205 Right Log (H) 34206... -
Page 34: Log Placement
LOG PLACEMENT Place Front Right Log (A) onto Burner Pins 1 and 2. Note: Ember material not shown for clarity. Page 34 39634-0-0918... - Page 35 LOG PLACEMENT Place Center Left Log (B) onto Burner Pins 3 and 4. Burner Pin Layout Note: Ember material not shown for clarity. 39634-0-0918 Page 35...
- Page 36 LOG PLACEMENT Place Front Left Log (C) onto Right Pin on (B) Log. Note: Ember material not shown for clarity. Page 36 39634-0-0918...
- Page 37 LOG PLACEMENT Place Left Log (D) onto Left Pin on (B) Log. Burner Pin Layout Note: Ember material not shown for clarity. 39634-0-0918 Page 37...
- Page 38 LOG PLACEMENT Place Center Right Log (E) onto Burner Pin 5 and onto (A) Log. Note: Ember material not shown for clarity. Page 38 39634-0-0918...
- Page 39 LOG PLACEMENT Place Center Log (F) onto Burner Pin 6 and Pin on (E) Log. Burner Pin Layout Note: Ember material not shown for clarity. Page 39 39634-0-0918...
- Page 40 LOG PLACEMENT Place Rear Log (G) onto Burner Pin 7 and Pin on (F) Log. Burner Pin Layout Note: Ember material not shown for clarity. Page 40 39634-0-0918...
- Page 41 LOG PLACEMENT Place Right Log (H) onto Pins on (E) Log and (F) Log. Note: Ember material not shown for clarity. 39634-0-0918 Page 41...
- Page 42 LOG PLACEMENT Place Chunk Log (I) onto Burner Pin 8 as shown. Burner Pin Layout Note: Ember material not shown for clarity. Page 42 39634-0-0918...
- Page 43 LOG PLACEMENT Completed Logset Note: Ember material not shown for clarity. 39634-0-0918 Page 43...
-
Page 44: Millivolt System Appliances
MILLIVOLT SYSTEM OPERATING INSTRUCTIONS Millivolt System The OWNER should carefully read and follow these operating The standing pilot burns continuously even when the main burner instructions. is OFF. Initial Lighting When you ignite the pilot, the thermopile produces millivolts (electrical Lower the door assembly to view the gas controls for the fireplace. - Page 45 MILLIVOLT SYSTEM OPERATING INSTRUCTIONS STANDING PILOT OPERATING INSTRUCTIONS Installation of Remote Receiver Place remote receiver on the floor of fireplace behind the louver as REMOTE/OFF/ON Switch The fireplace is equipped with a REMOTE/OFF/ON switch. A wire far forward as possible. harness is attached to the REMOTE/OFF/ON switch. The red, Attention: The Velcro loop and hook are not necessary in this black and green (wires) female push-ons attach to the REMOTE/ installation but can be used to secure remote receiver.
-
Page 46: Wiring Diagram
MILLIVOLT SYSTEM WIRING DIAGRAM REMOTE CONTROL RECEIVER (OPTIONAL) THERMOSTAT (OPTIONAL) WALL SWITCH GAS VALVE REMOTE/OFF/ON SWITCH (OPTIONAL) REMOTE CONTROL RECEIVER REMOTE/OFF/ON SWITCH (INCLUDED) REMOTE PIEZO THERMOPILE GAS VALVE THERMOCOUPLE (REAR CONNECTION) PILOT PILOT, IGNITOR Figure 61 Page 46 39634-0-0918... -
Page 47: Lighting Instructions
MILLIVOLT SYSTEM LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. C. -
Page 48: Troubleshooting
MILLIVOLT SYSTEM TROUBLESHOOTING With proper installation and maintenance, your new Direct Vent Gas Fireplace will provide years of trouble-free service. If you do experience a problem, refer to the Trouble Shooting Guide below. This guide will assist a qualified service person in the diagnosis of problems and the corrective action to be taken. - Page 49 This page intentionally left blank. Page 49 39634-0-0918...
-
Page 50: Parts View
MILLIVOLT SYSTEM PARTS VIEW Page 50 39634-0-0918... -
Page 51: Parts List
MILLIVOLT SYSTEM PARTS LIST PART NUMBER INDEX NO. DESCRIPTION DVCX36 DVCX42 34007 34007 PILOT ASSEMBLY, NATURAL GAS 34008 34008 PILOT ASSEMBLY, PROPANE GAS 34003 34003 BURNER REAR WELDED ASSEMBLY 34004 34004 BURNER FRONT WELDED ASSEMBLY R11977 R11977 VENTURI GASKET (QTY. 2) R11978 R11978 VENTURI (QTY. -
Page 52: Intermittent Pilot Appliances
INTERMITTENT PILOT ELECTRONIC SYSTEM OPERATING INSTRUCTIONS NOTE: The gas control has a manual HI/LO flame adjustment The electronic control valve system includes the ability to switch the pilot from a standing pilot mode to an intermittent pilot mode. knob. See Figure 62. Rotate the HI/LO knob counter- •... -
Page 53: Wiring Diagram
INTERMITTENT PILOT ELECTRONIC SYSTEM WIRING DIAGRAM 39634-0-0918 Page 53... -
Page 54: Lighting Instructions
INTERMITTENT PILOT LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. This appliance has a pilot which can be lighted with the C. -
Page 55: Troubleshooting
INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING Components The gas valve is fitted with a manual HI/LO knob to allow for man- Troubleshooting ual modulation of the gas outlet pressure to the appliance burner. Before proceeding with the procedures in the following trouble- The controls are designed to be used with either Propane or Natu- shooting table, verify that the power supply (AC/DC adapter) is ral Gas and can be converted by use of an OEM supplied conver- present and that the batteries inside the receiver and/or optional... - Page 56 INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING Note: “DFC” is the acronym for Digital Fireplace Control. Page 56 39634-0-0918...
- Page 57 INTERMITTENT PILOT CONTROL SYSTEM TROUBLESHOOTING Note: “DFC” is the acronym for Digital Fireplace Control. 39634-0-0918 Page 57...
-
Page 58: Parts View
PARTS VIEW INTERMITTENT PILOT Page 58 39634-0-0918... -
Page 59: Parts List
PARTS LIST INTERMITTENT PILOT PART NUMBER INDEX DESCRIPTION DVCX36 DVCX42 R11585 R11585 PILOT ASSEMBLY, NATURAL GAS R11586 R11586 PILOT ASSEMBLY, PROPANE GAS 33633 33633 THERMOCOUPLE SHIELD 34003 34003 BURNER REAR WELDED ASSEMBLY 34004 34004 BURNER FRONT WELDED ASSEMBLY R11977 R11977 VENTURI GASKET (QTY. -
Page 60: All Appliances
FIREPLACE - ALL UNITS PARTS VIEW Page 60 39634-0-0918... -
Page 61: Fireplace - All Units Parts List
FIREPLACE - ALL UNITS PARTS LIST PART NUMBER INDEX DESCRIPTION DVCX36 DVCX42 R11935 R11935 INSULATION TOP, CENTER 39631 39632 OUTER WRAPPER TOP ASSEMBLY 34054 34054 FLUE RESTRICTOR ASSEMBLY - NATURAL GAS 34062 34062 FLUE RESTRICTOR ASSEMBLY - PROPANE GAS R7567 R7567 INLET VENT ADAPTER, 8 R7573... -
Page 62: Maintenance And Service (Screen & Glass Removal)
MAINTENANCE AND SERVICE NOTE: It is normal for steel appliances to make expansion and/or General Glass Information contraction noise during the start-up or cool-down cycle. Similar WARNING noises are found with your furnace heat exchanger or car engine. It is normal for your gas fireplace to give off some odor the first time Do not operate appliance with the glass front removed, it is burned. - Page 63 MAINTENANCE AND SERVICE MAINTENANCE AND SERVICE Glass & Barrier Removal Remove the lower panel. Lift off and remove the barrier screen. 3. Release two glass frame clamps at bottom of firebox. Remove glass frame. Glass & Barrier Replacement 1. Place the glass frame into fireplace. 2. Attach two glass frame clamps at bottom of firebox. Replace the barrier screen. Attach lower panel. GLASS FRAME CLAMPS 39634-0-0918 Page 63...
-
Page 64: Important Safety Information
IMPORTANT SAFETY INFORMATION Definitions DANGER: Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE: Addresses practices not related to personal injury. - Page 65 IMPORTANT SAFETY INFORMATION (CONT’D) Annual Inspection • Have the fireplace inspected annually before use. • More frequent inspection and cleaning may be required if the fireplace is installed in an area exposed to pet hair or dust, or to excessive lint from new carpeting or bedding materials. During The Annual Checkup, The Technician Will: • Inspect the pilot (flame safety system) and burner(s) for proper operation and replace any damaged parts. • Test and measure the flame failure response time of the flame safety system. It must de-energize the safety shut-off in no more than 30 seconds.
-
Page 66: Safety Information For Users Of Propane Gas
SAFETY INFORMATION FOR USERS OF PROPANE GAS Propane is a flammable gas which can cause fires and That will take some of the odorant out of the gas, reducing explosions. In its natural state, propane is odorless and its odor intensity. colorless. -
Page 67: Requirements For Massachusetts
REQUIREMENTS FOR MASSACHUSETTS 3. SIGNAGE. A metal or plastic identification plate shall be For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in permanently mounted to the exterior of the building at a whole or in part for residential purposes, including those minimum height of eight feet above grade directly in line owned or operated by the Commonwealth and where the with the exhaust vent termination for the horizontally... -
Page 68: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. -
Page 69: Appliance Service History
APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 69 39634-0-0918... - Page 70 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 70 39634-0-0918...
- Page 71 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 39634-0-0918 Page 71...
-
Page 72: Warranty
WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician. Limited Lifetime Parts Warranty – Combustion Chamber, Heat Exchanger, and Factory-Installed Glass If the combustion chamber, heat exchanger (see parts list) or factory-installed glass fails because of defective workmanship or material, Empire will repair or replace at Empire’s option.
