Randell 9030K-7 Specifications

Preparation Table High Volume Saladtop
model
9030K-7
Description:
Self-contained refrigerated salad top unit with raised rim cutouts
in stainless steel top. Recessed pan ledge to hold 6" deep pans,
pans not provided. R-134a expansion valve refrigeration system
is "CFC free". Randell mullion blower coil with thermostatic
control, cools base and pans. Stainless steel hinged roll cover,
lift-off louver, full length cutting board, foamed in place urethane
insulation, condensate evaporator, locking casters and cordset
for 115V operation.

Specifications:

CABINET EXTERIOR: Cabinet body is constructed of all metal. The top
and front are stainless steel. Cabinet top to be one piece die-formed 20
gauge stainless steel with 1 1/2" high square nosing. Top to have raised
rim cutouts with recessed pan ledge to hold 6" deep pans, pans not
provided. Hinged, stainless steel roll cover. All units are standard with
stainless steel ends. Door openings to be ABS and contain magnetic
strip for positive sealing of gaskets. Louver is stainless steel, removable
without tools. Full length, NSF composition 10" cutting board provided.
10" wide work surface to be at 34.875" work height with unit on
standard 6" casters (front two with locks).
CABINET INTERIOR: Unit base interior to be ABS thermoplastic at ends
only. Anodized aluminum base liner to be coved cornered to form interior
bottom, back and top meeting N.S.F. standard #7. One baked enamel
finished shelf provided behind each door. Unit insulated with a minimum
of 2.5" of CFC free, foamed in place polyurethane. Full depth interior
allows for the use of optional 18" x 26" tray racks.
DOORS: Stainless steel front with easy to grasp recessed handles,
mounted on heavy duty concealed hinges. Hinges are all stainless steel
with bronze pivot pin in nylon bushing. Doors with foamed in place
insulation, press fit magnetic gaskets - (designed for installation &
removal without tools), and deep draw ABS interior liner for maximum
insulation value.
REFRIGERATION: CFC free, R-134a Expansion Valve refrigeration system
to include condensing unit, and thermostatic control for field adjustability.
Compressor housing to allow maximum airflow and permit mounting
of standard condensate evaporator. Mullion coil, is coated to resist
corrosion, and offers maximum air flow while allowing use of the full
depth interior for maximum product storage, and the use of optional tray
racks. Units totally prewired and to be supplied with 8' cordset (NEMA
5-15P) for 115V operation.
This equipment is intended for use in rooms having an ambient
temperature of 86˚F (30˚C) or less.
9040K-7 9045K-7
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax 888-266-5244
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
models 9000K-7
9050K-7
model 9045K-7
shown with optional
refrigerated drawers
Standard Features:
• Side mounted compressor with mullion "Turbo" coil provides
proper pan cooling, and "full depth" usable interior space
• "CFC free" R-134a refrigerant
• Expansion valve
• Hot gas condensate evaporator
• Exterior stainless steel top, front & ends
• Foamed in place "CFC free" urethane insulation
• Raised rim cutouts in stainless steel top with recessed
pan ledge to hold 6" deep pans, pans not provided
• Stainless steel, hinged roll cover
• Full length NSF approved 10" wide composition
cutting board
• Durable shelf supports molded into sides
• 6" casters, front two with locks
• 8' cord and plug for 115 volt operation
• Self-closing doors with exclusive press-fit magnetic gaskets
Options & Accessories:
Stainless steel back panel
Tray racks for 24" or 27" openings only
Refrigerated drawers
Overshelves
Export voltages available
Legs in lieu of casters
Randell Preparation Table, Page 2
Revised 07/06
