Randell 9000-290 Series Operator's Manual

OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING R290 flammable refrigerant in use. Improper installation,
adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
MODEL LENGTH
9402-290 27"
9404-290 27"
9404-32-290 32"
9404-32D-290 32"
9802-290 36"
9301-290 48"
9302-290 48"
9602-290 60"
9604-290 72"
9401-290 27"
9412-32-290 32"
9412-32D-290 32"
9801-290 36"
9303-290 48"
9305-290 48"
9601-290 60"
DEPTH HEIGHT DOORS
30" 36"
30" 36"
32.75" 36"
32.75" 36" (2) 32" DRAWERS
30" 36"
30" 36"
30" 36"
30" 36"
30" 36"
30" 36"
32.75" 36"
32.75" 36" (2) 32" DRAWERS
30" 36"
30" 36"
30" 36"
30" 36"
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands recommends
referencing our product line websites, unifiedbrands.net, for the most updated product information and specifications. © 2018 Unified Brands.
All Rights Reserved.
This manual provides information for:
9000-290 SERIES
REFRIGERATOR/FREEZERS
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE: Due to a continuous program of product improvement, Unified Brands
reserves the right to make changes in design and specifications without prior notice.
NOTICE: Please read the entire manual carefully before installation. If certain
recommended procedures are not followed, warranty claims will be denied.
MODEL NUMBER _________________________
SERIAL NUMBER _________________________
INSTALLATION DATE ______________________
The serial number is located in the cabinet left side
under the drawer track.
STORAGE
CU. FT.
(1) 27" 5.7
(1) 27" 5.7
(1) 32" 8.6
8.6
(2) 18" 7.9
(2) 24" 10.8
(2) 24" 10.8
(2) 27" 13
(3) 24" 16.8
(1) 27" 5.7
(1) 32" 8.6
8.6
(2) 18" 7.9
(2) 24" 10.8
(2) 24" 10.8
(2) 27" 13.8
PART NUMBER PP MNL1710, REV. D (02/19)
HP VOLT AMPS
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 2.4
1/4 115/60/1 5.3
1/4 115/60/1 5.3
1/4 115/60/1 5.3
1/4 115/60/1 5.3
1/4 115/60/1 5.3
1/4 115/60/1 5.3
1/4 115/60/1 5.3
NEMA SHIP WT.
5-15P 185
5-15P 185
5-15P 252
5-15P 252
5-15P 220
5-15P 265
5-15P 265
5-15P 300
5-15P 330
5-15P 185
5-15P 252
5-15P 300
5-15P 245
5-15P 280
5-15P 280
5-15P 300
